LG 32SE3D Guía de inicio rápido

P/No: MFL70040102 (1704-REV01)

LG Digital Signage

(MONITOR SIGNAGE)

ENGLISH Easy Setup Guide

Please read this manual carefully before operating your set and retain it for future reference.

32SE3D 43SE3D 49SE3D 55SE3D 65SE3D

32SE3KD 43SE3KD 49SE3KD 55SE3KD 65SE3KD

AAA

12

0

English

Dimensions

(Width x

Height x Depth)

/ Weight

32SE3D Head 729.4 mm x 428.9 mm x 55.5 mm / 5.2 kg

(28.7 inches x 16.8 inches x 2.1 inches / 11.4 lbs)

Head + Stand 729.4 mm x 481 mm x 154.2 mm / 6 kg

(28.7 inches x 18.9 inches x 6.0 inches / 13.2 lbs)

Head + Speaker 729.4 mm x 428.9 mm x 95.7 mm / 5.7 kg

(28.7 inches x 16.8 inches x 3.7 inches / 12.5 lbs)

Head + Speaker + Stand 729.4 mm x 481 mm x 154.2 mm / 6.5 kg

(28.7 inches x 18.9 inches x 6.0 inches / 14.3 lbs)

43SE3D Head 969.6 mm x 563.9 mm x 38.6 mm / 9.6 kg

(38.1 inches x 22.2 inches x 1.5 inches / 21.1 lbs)

Head + Stand 969.6 mm x 622.2 mm x 193 mm / 12.1 kg

(38.1 inches x 24.4 inches x 7.5 inches / 26.6 lbs)

Head + Speaker 969.6 mm x 563.9 mm x 67.9 mm / 10.1 kg

(38.1 inches x 22.2 inches x 2.6 inches / 22.2 lbs)

Head + Speaker + Stand 969.6 mm x 622.2 mm x 193 mm / 12.6 kg

(38.1 inches x 24.4 inches x 7.5 inches / 27.7 lbs)

49SE3D Head 1102.2 mm x 638.5 mm x 38.6 mm / 13.9 kg

(43.3 inches x 25.1 inches x 1.5 inches / 30.6 lbs)

Head + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.2 kg

(43.3 inches x 27.4 inches x 8.6 inches / 37.9 lbs)

Head + Speaker 1102.2 mm x 638.5 mm x 67.9 mm / 14.4 kg

(43.3 inches x 25.1 inches x 2.6 inches / 31.7 lbs)

Head + Speaker + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.7 kg

(43.3 inches x 27.4 inches x 8.6 inches / 39.0 lbs)

55SE3D Head 1238 mm x 714.9 mm x 38.6 mm / 17.1 kg

(48.7 inches x 28.1 inches x 1.5 inches / 37.6 lbs)

Head + Stand 1238 mm x 773.4 mm x 219.6 mm / 20.4 kg

(48.7 inches x 30.4 inches x 8.6 inches / 44.9 lbs)

Head + Speaker 1238 mm x 714.9 mm x 67.9 mm / 17.6 kg

(48.7 inches x 28.1 inches x 2.6 inches / 38.8 lbs)

Head + Speaker + Stand 1238 mm x 773.4 mm x 219.6 mm / 19.9 kg

(48.7 inches x 30.4 inches x 8.6 inches / 43.8 lbs)

65SE3D Head 1456.9 mm x 838 mm x 41.1 mm / 27.7 kg

(57.3 inches x 32.9 inches x 1.6 inches / 61.0 lbs)

Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 32.9 kg

(57.3 inches x 35.3 inches x 11.5 inches / 72.5 lbs)

Head + Speaker 1456.9 mm x 838 mm x 70.4 mm / 28.2 kg

(57.3 inches x 32.9 inches x 2.7 inches / 62.1 lbs)

Head + Speaker + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.4 kg

(57.3 inches x 35.3 inches x 11.5 inches / 73.6 lbs)

WARNING: This product contains chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm.

Wash hands after handling.

Dimensions

(Width x

Height x Depth)

/ Weight

32SE3KD Head 729.4 mm x 428.9 mm x 55.5 mm / 5.4 kg

(28.7 inches x 16.8 inches x 2.1 inches / 11.9 lbs)

Head + Stand 729.4 mm x 481 mm x 154.2 mm / 6.2 kg

(28.7 inches x 18.9 inches x 6.0 inches / 13.6 lbs)

43SE3KD Head 969.6 mm x 563.9 mm x 54 mm / 10.0 kg

(38.1 inches x 22.2 inches x 2.1 inches / 22.0 lbs)

Head + Stand 969.6 mm x 622.2 mm x 193 mm / 12.5 kg

(38.1 inches x 24.4 inches x 7.5 inches / 27.5 lbs)

49SE3KD Head 1102.2 mm x 638.5 mm x 54 mm / 14.3 kg

(43.3 inches x 25.1 inches x 2.1 inches / 31.5 lbs)

Head + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.6 kg

(43.3 inches x 27.4 inches x 8.6 inches / 38.8 lbs)

55SE3KD Head 1238 mm x 714.9 mm x 54 mm / 17.5 kg

(48.7 inches x 28.1 inches x 2.1 inches / 38.5 lbs)

Head + Stand 1238 mm x 773.4 mm x 219.6 mm / 20.8 kg

(48.7 inches x 30.4 inches x 8.6 inches / 45.8 lbs)

65SE3KD Head 1456.9 mm x 838 mm x 56.5 mm / 27.9 kg

(57.3 inches x 32.9 inches x 2.2 inches / 61.5 lbs)

Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.1 kg

(57.3 inches x 35.3 inches x 11.5 inches / 72.9 lbs)

32SE3D 43SE3D 49SE3D 55SE3D

32SE3KD 43SE3KD 49SE3KD 55SE3KD

32/43/49/55SE3D

RS-232C

IN

RS-232C

IN

65SE3D 65SE3KD

65SE3D

RS-232C

IN

RS-232C

IN

1

3

2

4

2

P/NO : MFL69040901 (1603-REV04)

(INFORMACION REGULATIVA)

REGULATORY

INFORMATION
