OWNER'S MANUAL

Color Video Camera

Please read this manual carefully before operating

your set and retain it for future reference.

MODEL

LCD5500-BN

LCD5500-BP

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning flash with arrowhead

symbol within an equilateral triangle

is intended to alert the user to the

presence of uninsulated dangerous

voltage within the product’s enclosure

that may be of sufficient magnitude

to constitute a risk of electric shock to

persons.

The exclamation point within an

equilateral triangle is intended to

alert the user to the presence of

important operating and maintenance

(servicing) instructions in the literature

accompanying the product.

FCC WARNING: This equipment may generate or use

radio frequency energy. Changes or modifications to this

equipment may cause harmful interference unless the

modifications are expressly approved in the instruction

manual. The user could lose the authority to operate this

equipment if an unauthorized change or modification is

made.

REGULATORY INFORMATION: FCC Part 15

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

• A suitable conduit entries, knock-outs or glands shall

be provided in the cable entries of this product in the

end user.

• Caution: Danger of explosion if battery is incorrectly

replaced. Replaced only with the same or equivalent

type recommended by the manufacturer. Dispose

of used batteries according to the manufacturer’s

instructions.

• Holes in metal, through which insulated wires pass,

shall have smooth well rounded surfaces or shall be

provided with brushings.

This Class A digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe A est conforme à la

norme NMB-003 du Canada.

Warning: Do not install this equipment in a confined space

such as a bookcase or similar unit.

Warning: Wiring methods shall be in accordance with the

National Electric Code, ANSI/NFPA 70.

Warning: This is a class A product. In a domestic

environment this product may cause radio interference

in which case the user may be required to take adequate

measures.

Warning: To reduce a risk of fire or electric shock, do not

expose this product to rain or moisture.

Warning: The product has been dropped or the case is

broken, turn off the power and unplug the power cord.

(This may cause fire, electric shock, or injury.)

Warning: If the product has no video out or sound, please

stop using. Unplug the power cable immediately and

contact the service center. (This may cause fire or electric

shock.)

Caution: This installation should be made by a qualified

service person and should conform to all local codes.

Caution: To avoid electrical shock, do not open the

cabinet. Refer servicing to qualified personnel only.

Caution: The apparatus shall not be exposed to water

(dripping or splashing) and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

Caution: Prevent the power cable from being severely bent

or having pressure exerted on it by a heavy object.

To disconnect power from mains, pull out the mains

cord plug. When installing the product, ensure that the

plug is easily accessible.

Disposal of your old appliance

1. When this crossed-out wheeled bin

symbol is attached to a product it

means the product is covered by the

European Directive 2002/96/EC.

2. All electrical and electronic products

should be disposed of separately

from the municipal waste stream

via designated collection facilities

appointed by the government or the

local authorities.

3. The correct disposal of your old

appliance will help prevent potential

negative consequences for the

environment and human health.

4. For more detailed information about

disposal of your old appliance, please

contact your city office, waste disposal

service or the shop where you

purchased the product.

EEE Compliance with Directive. (for Turkey only)

LG Electronics hereby declares that this/

these product(s) is/are in compliance

with the essential requirements and other

relevant provisions of Directive 2004/108/

EC, 2006/95/EC, and 2009/125/EC.

European Standards Centre:

Krijgsman 1, 1186 DM Amstelveen The

Netherlands

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate

normally, or has been dropped.

Important Safety Instructions

Power Supply

This camera must always be operated DC 12 V or AC 24 V.

Certified/Listed Adaptor which comply with LPS.

Handling of the unit

Be careful not to spill water or other liquids on the unit. Be

cautions not to get combustible or metallic material inside

the body. If used with foreign matter inside, the camera is

liable to fail or to get cause of fire or electric shock.

• Remove dust or dirt on the surface of the lens with a

blower.

• Use a dry soft cloth to clean the body. If it is very dirty,

use a cloth dampened with a small quantity of neutral

detergent then wipe dry.

• Avoid the use of volatile solvents such as thinners,

alcohol, benzene and insecticides. They may damage

the surface finish and/or impair the operation of the

camera.

Operating and storage location

Avoid viewing a very bright object (such as light fittings)

during an extended period. Avoid operating or storing the

unit in the following locations.

• Extremely hot or cold places (operating temperature

-10 °C to 50 °C, however, we recommend that the unit

be used within a temperature range of 0 °C to 45 °C)

• Damp or dust place

• Places exposed to rain

• Places subject to strong vibration

• Close to generators of powerful electromagnetic radia-

tion such as radio or TV transmitters.

Cautions for Safe Operation

Features............................................................................. 8

Accessories.................................................................................. 8

Part Names and Functions ....................................................9

Connections .................................................................... 11

Basic connection.....................................................................11

Installation ...................................................................... 12

Mounting the Camera...........................................................12

Image Adjustment .................................................................14

Menu Operation.............................................................. 18

OSD Menu control buttons.................................................18

OSD Menu Overview.............................................................19

General Operation..................................................................21

Exposure Settings...................................................................22

White Balance settings .........................................................26

Day & Night Setting ...............................................................27

Motion Detection Setting....................................................28

3D-DNR Setting.......................................................................29

Privacy Mask Setting .............................................................29

Special Menu Settings ..........................................................31

SYSTEM Setting .......................................................................35

Specication ................................................................... 36

Contents

This Color Video Camera is designed for installation in a

video surveillance system.

This manual contains instructions on how to install and

manage the Color Video Camera in your video surveillance

system.

Should you require any technical assistance, please contact

authorized service center.

• High resolution and high sensitivity with a 6 mm (1/3

Type)

Exview

Super HAD CCD II.

• Automatically switch between DC 12 V and AC 24 V.

• Smart motion detector.

• Wide Dynamic Range (WDR)

Accessories

Installation sticker

FRONT

PRODUCT CENTER POSITION

MEZ62687703

n100 Cutting Line

4 Place

SELFTAPPING SCREW

CABLE HOLE (LCV5300)

CABLE HOLE (LCD5300)

Fixing screws

FRONT

PRODUCT CENTER POSITION

MEZ62687703

n100 Cutting Line

4 Place

SELFTAPPING SCREW

CABLE HOLE (LCV5300)

CABLE HOLE (LCD5300)

Features

Part Names and Functions

aDome Cover

bLens Cover

cFocus lock lever

Fixes the focus position after adjusting.

dZoom lock lever

Fixes the zoom position after adjusting.

eRotate adjuster

fLock button

You can lock the camera mounting bracket by using

the lock button.

gTilting lock screw

Fixes the tilting position after adjusting.

hSetup menu control buttons

iVideo Out connector

Use this jack for checking the picture with portable

monitor when install the camera.

Part Names and Functions

jPan adjuster

Adjusts the pan position.

kPower input connector

Supplies AC 24 V or DC 12 V from an external power

source.

lVideo output connector (BNC type)

mCamera mounting bracket

This bracket is supplied for ceiling installation.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Videocámara de otras marcas

Toshiba

Toshiba CAMILEO Z100 Manual de usuario

Panasonic

Panasonic NV-VS40B Manual de usuario

Canon

Canon RC 260 Manual de usuario

Sony

Sony Handycam DCR-DVD7E Manual de usuario

Brinno

Brinno TimeLapse TLC200 Manual de usuario

JVC

JVC GR-SXM68AC Guía de inicio rápido

Panasonic

Panasonic AG-HMC152EN Manual de usuario

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manual de usuario

MYDLINK

MYDLINK DCS-6100LH Manual de usuario

Sony

Sony video Hi8 Handycam CCD-TR555 Manual de usuario

SECURECOM

SECURECOM V-5014B Manual de usuario

Panasonic

Panasonic HDC-SD100 Manual de usuario

Sharper Image

Sharper Image U-VIDEO Manual de usuario

JVC

JVC AA-V15EG Manual de usuario

Canon

Canon LEGRIA HV40 Manual de usuario

Sony

Sony Handycam DCR-VX2000 Manual de usuario

RCA

RCA CC616 Manual de usuario

Panasonic

Panasonic NVM40 Manual de usuario
