LG LS501 Manual de usuario

Color Video Camera

Instruction Manual

Models : LS501

Before installing, operating or adjusting

this product, please read this instruction

booklet carefully and completely.

CAUTION

RISK OF ELECTRIC

SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning flash with arrowhead symbol

within an equilateral triangle is intended to

alert the user to the presence of uninsulated

dangerous voltage within the product’s enclo-

sure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral tri-

angle is intended to alert the user to the pres-

ence of important operating and maintenance

(servicing) instructions in the literature accom-

panying the product.

FCC WARNING: This equipment may generate or

use radio frequency energy. Changes or modifications

to this equipment may cause harmful interference

unless the modifications are expressly approved in the

instruction manual. The user could lose the authority

to operate this equipment if an unauthorized change or

modification is made.

REGULATORY INFORMATION: FCC Part 15

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interfer-

ence when the equipment is operated in a commercial

environment.

This equipment generates, uses, and can radi-

ate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may

cause harmful interference to radio communications.

Operation of this equipment in a residential area is

likely to cause harmful interference in which case the

user will be required to correct the interference at his

own expense.

• A suitable conduit entries, knock-outs or glands

shall be provided in the cable entries of this prod-

uct in the end user.

• Caution: Danger of explosion if battery is incor-

rectly replaced. Replaced only with the same or

equivalent type recommended by the manufac-

turer. Dispose of used batteries according to the

manufacturer’s instructions.

• Holes in metal, through which insulated wires pass,

shall have smooth well rounded surfaces or shall

be provided with brushings.

Warning: Do not install this equipment in a confined

space such as a bookcase or similar unit.

Warning: Wiring methods shall be in accordance with

the National Electric Code, ANSI/NFPA 70.

Warning: This is a class A product. In a domestic envi-

ronment this product may cause radio interference in

which case the user may be required to take adequate

measures.

Warning: To reduce a risk of fire or electric shock, do

not expose this product to rain or moisture.

Caution: This installation should be made by a quali-

fied service person and should conform to all local

codes.

Caution: To avoid electrical shock, do not open the

cabinet. Refer servicing to qualified personnel only.

Caution: The apparatus shall not be exposed to water

(dripping or splashing) and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

To disconnect power from the mains, pull out the

mains cord plug. When install the product, ensure

that the plug is easily accessible.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is

attached to a product it means the product is

covered by the European Directive 2002/96/

EC.

2. All electrical and electronic products should

be disposed of separately from the municipal

waste stream via designated collection facili-

ties appointed by the government or the local

authorities.

3. The correct disposal of your old appliance will

help prevent potential negative consequences

for the environment and human health.

4. For more detailed information about disposal

of your old appliance, please contact your

city office, waste disposal service or the shop

where you purchased the product.

This product is manufactured to comply

with EMC Directive 2004/108/EC and Low

Voltage Directive 2006/95/EC.

European representative :

LG Electronics Service Europe B.V.

Veluwezoom 15, 1327 AE Almere,

The Netherlands (Tel : +31-036-547-8940)

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install

in accordance with the manufacturer's instruc-

tions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other appa-

ratus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polar-

ized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A

grounding type plug has two blades and a third

grounding prong. The wide blade or the third

prong are provided for your safety. If the pro-

vided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete

outlet.

10. Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11. Only use attachments/accessories specified by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms

or when unused for long periods of time.

14. Refer all servicing to qualified service person-

nel. Servicing is required when the apparatus

has been damaged in any way, such as power-

supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or mois-

ture, does not operate normally, or has been

dropped.

Important Safety Instructions

Contents

Features..............................6

Cautions for Safe Operation. . . . . . . . . . . . . . .7

Part Names and Functions. . . . . . . . . . . . . . . .8

Connections . . . . . . . . . . . . . . . . . . . . . . . . . .12

Mounting the Lens . . . . . . . . . . . . . . . . . . . . .14

Concerning Auto-Iris Lenses . . . . . . . . . . . . .16

Flange-back Adjustment. . . . . . . . . . . . . . . . .17

Installation of Camera . . . . . . . . . . . . . . . . . .18

MenuOperation.......................19

Camera Identification Settings . . . . . . . . . . . .22

Exposuresettings......................23

White Balance setting. . . . . . . . . . . . . . . . . . .27

Day/Night setting . . . . . . . . . . . . . . . . . . . . . .29

Motion Detection setting. . . . . . . . . . . . . . . . .30

3D-DNR setting .......................31

Privacy Mask setting . . . . . . . . . . . . . . . . . . .32

Special menu settings . . . . . . . . . . . . . . . . . .33

Resetsettings.........................38

Specification..........................39

Features

This color video camera is designed for use in monitoring system.

High resolution and high sensitivity with a 1/ 3 inch Super HAD CCD (Charge Coupled Device).

Line Lock when using AC 24V. (LS501N-B1,P-B1)

Line Lock when using AC 230V. (LS501P-C1)

C/CS Mount.

Auto White Balance

Auto exposure with (Auto) Iris control

Day & Night function

•

Power Supply

LS501N-B1/LS501P-B1:

This camera must be operated AC 24V or DC 12V

Certified/Listed, class 2 power supply only.

LS501P-C1:

This camera must be operated AC 230V Certified/

Listed, class 2 power supply only.

Note:Be careful of AC frequency when the camera is

operated with Line lock mode.

Handling of the unit

Be careful not to spill water or other liquids on the unit.

Be cautions not to get combustible or metallic material

inside the body. If used with foreign matter inside, the

camera is liable to fail or to get cause of fire or electric

shock.

• Remove dust or dirt on the surface of the lens with a

blower.

• Use a dry soft cloth to clean the body. If it is very

dirty, use a cloth dampened with a small quantity of

neutral detergent, then wipe dry.

• Avoid the use of volatile solvents such as thinners,

alcohol, benzene and insecticides.

They may damage the surface finish and/or impair

the operation of the camera.

Operating and storage location

Avoid viewing a very bright object (such as light fittings)

during an extended period. Avoid operating or storing

the unit in the following locations.

• Extremely hot or cold places (operating temperature

-10°C ~ 50°C, however, we recommend that the unit

be used within a temperature range of 0°C ~ 45°C)

• Damp or dust place

• Places exposed to rain

• Places subject to strong vibration

• Close to generators of powerful electromagnetic

radiation such as radio or TV transmitters.

Cautions for Safe Operation

Part Names and Functions

ab c

aLens mount cap

The cap is installed to protect the lens

mount section. Remove the lens mount cap

before installing a lens.

bFlange-back adjustment ring

cCamera installation bracket

The bracket can be fixed at the top or bot-

tom of the camera.

Part Names and Functions

d ef

dLens iris output connector (LENS)

This 4- pin connector is used to send the Iris con-

trol signal and power supply to an auto-iris type

lens.

eButtons for menu

To set items on the MENU, use the these buttons.

fALC Lens Setting Switch

• DC: When you attach an Auto Iris lens requir-

ing the DC control signal, please put this

switch in the DC position.

• VIDEO: When you attach an Auto Iris lens

requiring the video control signal, please put

this switch in the VIDEO position.

Part Names and Functions

LS501N-B1 / LS501P-B1

g h i j

gPower input terminal

AC 24 V or DC 12 V input terminal.

hGND

iPower indicator

Comes on when the power to the camera is on.

jVideo output connector (BNC type)

Connect this connector to a device such as a VCR

or monitor with a VIDEO IN connector.
