Lexmark 2000-Sheet Drawer Optra T Manual de usuario

Optra T

2000-Sheet Drawer

User’s Guide

Optra T

Gaveta de 2000 folhas

Guia do usuário

Optra T

Tiroir 2000 feuilles

Manuel d’utilisation

Optra T

2000-Blatt-Zuführung

Benutzerhandbuch

Optra T

Cassetto da 2000 fogli

Guida per l’utente

Optra T

Alimentador de 2000 hojas

Guía del usuario

English

Optra T 2000-Sheet Drawer User's Guide

First Edition (June 1999)

The following paragraph does not apply to any country where such provisions are inconsistent with

local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,

THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions;

therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made

to the information herein; these changes will be incorporated in later editions. Improvements or changes in the

products or the programs described may be made at any time.

References in this publication to products, programs, or services do not imply that the manufacturer intends to

make these available in all countries in which it operates. Any reference to a product, program, or service is not

intended to state or imply that only that product, program, or service may be used. Any functionally equivalent

product, program, or service that does not infringe any existing intellectual property right may be used instead.

Evaluation and verification of operation in conjunction with other products, programs, or services, except

those expressly designated by the manufacturer, are the user’s responsibility.

Lexmark and Optra are trademarks of Lexmark International, Inc., registered in the United States and/or other

countries.

Other trademarks are the property of their respective owners.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS. This software and documentation are

provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to

restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software

clause at DFARS 252.227-7013 and in applicable FAR provisions: Lex-mark International, Inc., Lexington,

KY 40550.

2000-Sheet Drawer User’s Guide

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Unpacking the 2000-Sheet Drawer . . . . . . . . . . . . . . . 2

Attaching Stabilizer Feet . . . . . . . . . . . . . . . . . . . . . . . 3

Installing the 2000-Sheet Drawer. . . . . . . . . . . . . . . . . 6

Verifying Installation. . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the Paper Type . . . . . . . . . . . . . . . . . . . . . . . 11

Changing the Paper Size. . . . . . . . . . . . . . . . . . . . . . 12

Selecting Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Clearing a Paper Jam . . . . . . . . . . . . . . . . . . . . . . . . 20

2000-Sheet Drawer User’s Guide

2000-Sheet Drawer User’s Guide 1

Introduction

The 2000-sheet drawer gives your printer added capacity by

allowing you to load up to four reams (approximately 2,000 sheets)

of 20 lb paper.

Your drawer is pre-configured to either letter or A4 paper size. To

use a different paper size, see page 12.

Your printer has an autoconnect feature that recognizes when the

2000-sheet drawer has been installed. After starting your printer,

this option is shown as Tray 2,Tray 3,Tray 4 or Tray 5,depending

upon the number of installed paper sources.

To ensure reliable paper feeding, it is important that you select

paper recommended for use with the 2000-sheet drawer and that

you load it properly. See page 15 for information on paper

specifications and page 16 for loading instructions.

To ensure compatibility with your printer, verify your drawer is

labeled with a colored triangle located on the top left front corner.

Refer to your printer documentation for information pertaining to

electronic emissions, safety, and warranty.

2000-Sheet Drawer User’s Guide

Unpacking the 2000-Sheet Drawer

1Remove all items shown in the illustration from the carton. If

any items are missing, contact the place where you bought

the 2000-sheet drawer.

Note: The 16 AWG power cord is included only with units

intended to operate at 100 - 127V power.

2Remove all packing material and tape from each item.

Note: Save the carton and packing material in case you

need to repack the 2000-sheet drawer for service or

storage.

3Peel the appropriately numbered decals from the sheet and

attach them to the recessed areas on the drawer. Choose

the number that corresponds to the number of paper

options you are attaching, including the standard output

tray.

Stabilizer feet

16 AWG power cord

Decals

2000-sheet drawer

Jumper cord

Printer compatibility label

(colored triangle)

2000-Sheet Drawer User’s Guide 3

Attaching Stabilizer Feet

CAUTION: If you are not using an optional printer stand,

the four stabilizer feet

must

be attached to the

drawer.

1Carefully invert the 2000-sheet drawer so the bottom faces

up.

2Remove the screws securing the rubber feet to the drawer.

Save the screws and rubber feet for use in step 5 on page

Note: If you later choose to use the drawer with the printer

stand, you must remove the stabilizer feet and re-

attach the rubber feet.

2000-Sheet Drawer User’s Guide

3Insert the tab on the end of the stabilizer foot into the slot on

the bottom of the drawer. Rotate the stabilizer foot down

until it is aligned with the bottom of the drawer.

4Slide the foot away from the center of the tray until it locks

into place.
