Lenovo RackSwitch G8264CS Manual de usuario

Lenovo RackSwitch G8264CS

Installation Guide

Important Product Information—

Before using this information and the product it supports, read Appendix B, “Notices” on page 81 of this manual. Also read the product

WarrantyInformation document and the Important Noticesdocument included with the product, and the Safety Information document,

the License Agreement for MachineCode (LAMC) document, and the Environmental Notices and User Guide document on the

DocumentationCD included with the product.

First Edition (August 2015)

Portions © Copyright IBM Corporation 2014.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA”

contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other countries, or both.

Safety Information

Read the Safety Information

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Prije instalacije ovog produkta obavezno pročitajte Surgonosne Upute.

Před instalací tohoto produktu si přečtěte příručku bezpečnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d'installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.’

Πριν εγκαταστήσετε το προϊόν αυτό, διαβάστε τις Πληροφορίες ασφαλείας

(safety information).

A termék telepítés előtt olvassa el a Biztonsági előírásokat!

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Πред да инсталира овој продукт, прочитајте информацијата за безбедност.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Przed zainstalowaniem tego produktu, należy zapoznaćsięz książką“Informacje

dotyczace bezpieczeństwa” (Safety Information).

4 G8264CS Installation Guide

Antes de instalar este produto, leia as Informações sobre Segurança.

Перед установкой продукта прочтитe инcтрyкции по тexникe безопасности.

Pred inštaláciou tohto zariadenia si prečítajte Bezpečnostné predpisy.

Pred namestitvijo tega proizvoda preberite Varnostne informacije.

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Bu ürünü kurmadan önce güvenlik bilgilerini okuyun.

Youq mwngz yungh canjbinj neix gaxgonq, itdingh aeu doeg aen canjbinj soengq

cungj vahgangj ancien suisik.

Safety Statements

Important—

Each caution and danger statement in this document is labeled with a number. This

number is used to cross reference the English-language caution or danger

statement with the translated versions of the caution or danger statement in the

Safety Information document.

For example, if a caution statement is labeled “Statement 1,” translations for that

caution statement are in the Safety Information document under “Statement 1.”

Be sure to read all caution and danger statements in this document before you

perform the procedures. Read any additional safety information that comes with the

system or optional device before you install the device.

Following is a compilation of the statements found throughout this manual.

Statement 3

CAUTION:

When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or

transmitters) are installed, note the following:

•

Do not remove the covers. Removing the covers of the laser product could

result in exposure to hazardous laser radiation. There are no serviceable

parts inside the device.

•

Use of controls or adjustments or performance of procedures other than

those specified herein might result in hazardous radiation exposure.

DANGER

Class 1 Laser Product

Laser Klasse 1

Laser Klass 1

Luokan 1 Laserlaite

Appareil À Laser de Classe 1

Some laser products contain an embedded Class 3A or Class 3B laser

diode. Note the following.

Laser radiation when open. Do not stare into the beam, do not view directly

with optical instruments, and avoid direct exposure to the beam.

6 G8264CS Installation Guide

Statement 5

CAUTION:

The power control button on the device and the power switch on the power

supply do not turn off the electrical current supplied to the device. The device

also might have more than one power cord. To remove all electrical current

from the device, ensure that all power cords are disconnected from the power

source.

Statement 8

CAUTION:

Never remove the cover on a power supply or any part that has the following

label attached.

Hazardous voltage, current, and energy levels are present inside any

component that has this label attached. There are no serviceable parts inside

these components. Ifyou suspect a problem with one of these parts, contact a

service technician.

Statement 13

DANGER

Overloading a branch circuit is potentially a fire hazard and a shock hazard

under certain conditions. To avoid these hazards, ensure that your system

electrical requirements do not exceed branch circuit protection

requirements. Refer to the information that is provided with your device for

electrical specifications.

Statement 25

CAUTION:

This product contains a Class 1M laser. Do not view directly with optical

instruments.

Statement 26

CAUTION:

Do not place any object on top of rack-mounted devices.

8 G8264CS Installation Guide

Statement 31

DANGER

Electrical current from power, telephone, and communication cables is

hazardous.

To avoid a shock hazard:

•

Do not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical storm.

•

Connect all power cords to a properly wired and grounded power source.

•

Connect to properly wired power sources any equipment that will be

attached to this product.

•

When possible, use one hand only to connect or disconnect signal cables.

•

Never turn on any equipment when there is evidence of fire, water, or

structural damage.

•

Disconnect the attached ac power cords, dc power sources, network

connections, telecommunications systems, and serial cables before you

open the device covers, unless instructed otherwise in the installation

and configuration procedures.

•

Connect and disconnect cables as described in the following table when

you install, move, or open covers on this product or attached devices.

To Connect:

1. Turn OFF all power sources and

equipment that is to be attached to

this product.

2. Attach signal cables to the product.

3. Attach power cords to the product.

– For ac systems, use appliance

inlets.

– For dc systems, ensure correct

polarity of -48 V dc connections:

RTN is + and -48 V dc is -. Earth

ground should use a two-hole

lug for safety.

4. Attach signal cables to other

devices.

5. Connect power cords to their

sources.

6. Turn ON all the power sources.

To Disconnect:

1. Turn OFF all power sources and

equipment that is to be attached to

this product.

– For ac systems, remove all

power cords from the chassis

power receptacles or interrupt

power at the ac power

distribution unit.

– For dc systems, disconnect dc

power sources at the breaker

panel or by turning off the power

source. Then, remove the dc

cables.

2. Remove the signal cables from the

connectors.

3. Remove all cables from the

devices.

Statement 37

DANGER

Other Important Safety Notices

Important

This product is also designed for IT power distribution systems with phase-to-phase

voltage of 230V.

This product is not intended for use in the direct field of view at visual display

workplaces.

Important

Machinenlärminformations-Verordnung—3. GPSGV, der höchste Shalldruckpegel

beträgt 70 dB (A) oder weniger.

When you populate a rack cabinet, adhere to the following guidelines:

•

Always lower the leveling pads on the rack cabinet.

•

Always install the stabilizer brackets on the rack cabinet.

•

Always install the heaviest devices in the bottom of the rack cabinet.

•

Always install devices starting from the bottom of the rack cabinet.

•

Do not extend multiple devices from the rack cabinet simultaneously,

unless the rack-mounting instructions direction you to do so. Multiple

devices extended into the service position can cause your rack cabinet

to tip.

•

If you are not using the Lenovo 9308 rack cabinet, securely anchor the

rack cabinet to ensure its stability.

10 G8264CS Installation Guide
