Lenovo CE0128T Switch (Gigabit Ethernet)

Product Guide

The Lenovo CE0128T Switch is a 1 Gb Ethernet (GbE) switch that delivers a compact, high-density, cost-

effective GbE solution for small network environments where space and power are at a premium. Featuring

a small, 1U footprint, this switch is designed for access-layer deployments in branches, retail and

workgroup environments, and network access in larger networks.

The CE0128T Switch offers 24x 10/100/1000BASE-T ports for server, storage, and network connectivity

and 4x 1 GbE SFP uplink ports for connections to higher-layer devices.

The CE0128T Switch supports a wide range of L2 and L3 features that provide performance, availability,

security, and manageability for campus networks.

The Lenovo CE0128T Switch is shown in the following figure.

Figure 1. Lenovo CE0128T Switch

Did you know?

The CE0128T Switch is designed to deliver non-blocking, line-rate throughput.

The CE0128T Switch supports the GARP VLAN Registration Protocol (GVRP) protocol for simplifying and

automating VLAN configuration.

The CE0128T Switch supports stacking, enabling up to eight interconnected CE0128T Switch devices to

be managed as a single logical device.

The CE1028T Switch supports Zero Touch Provisioning, which enables a switch to automatically provision

itself using the resources available on the network, without manual intervention.

Lenovo CE0128T Switch (Gigabit Ethernet) 1

Key features

The CE0128T Switch is considered particularly suited for the following customers:

Customer who need economical network connectivity solution for access layer deployments in

branch and remote offices, as well as enterprise campus networks.

Customers who want to use GbE in their infrastructure (servers and networking).

Customers who are implementing a virtualized environment and require multiple GbE ports.

Customers who want to reduce total cost of ownership (TCO) and improve performance while

maintaining high levels of availability and security.

Customers who want to implement a converged infrastructure with NAS or iSCSI.

The CE0128T Switch offers the following key features and benefits:

High performance

The CE0128T Switch provides a combination of non-blocking line-rate GbE switching with as low

as 4 microseconds latency and 256 Gbps switching capacity.

Layer 3 functionality

In addition to Layer 2 switching, the CE0128T Switch includes Layer 3 functionality, which provides

security and performance benefits of inter-VLAN routing with support for static routes.

Quality of Service

The CE0128T Switch supports traffic classification and processing to provide consistent network

performance and efficient use of network bandwidth by allocating and scheduling resources based

on service levels requirements for different data streams.

Security

Working as an enforcement point, the CE0128T Switch provides standards-based 802.1x port-

level access control for multiple devices per port, as well as Layer 2-4 policy enforcement with

Access Control Lists (ACLs).

Simplified management

To ease deployment, the CE0128T Switch supports the industry-standard Link Layer Discovery

Protocol (LLDP) and GARP VLAN Registration Protocol (GVRP) protocols, enabling the switches

to automatically discover Ethernet-enabled devices and automate VLAN configuration.

Stacking

The CE0128T Switch supports stacking, enabling up to eight interconnected CE0128T Switch

devices to be managed as a single logical device, delivering a scalable, pay-as-you-grow solution

for expanding network environments.

Zero Touch Provisioning

The CE1028T supports CPE WAN Management Protocol (CWMP) for zero-touch provisioning (ZTP).

ZTP enables a switch to automatically provision itself using the resources available on the network,

without manual intervention. ZTP automatically handles the process of upgrading the switch

software image and installing configuration files.

Components and connectors

Lenovo CE0128T Switch (Gigabit Ethernet) 2

Components and connectors

The front panel of the CE0128T Switch is shown in the following figure.

Figure 2. Front panel of the CE0128T Switch

The front panel of the CE0128T Switch contains the following components:

24x 1000BASE-T Ethernet ports for 10/100/1000 Mbps connections.

4x SFP ports for 1 GbE transceivers: 1000BASE-T, SX, or LX.

1x RJ-45 RS-232 console port for configuring the switch.

LEDs that display the status of the switch and the network.

Reset button.

The rear panel of the CE0128T Switch is shown in the following figure.

Figure 3. Rear panel of the CE0128T Switch

The rear panel of the CE0128T Switch contains the following components:

AC / HVDC power connector (IEC 320-C14).

Ventilation holes.

Grounding pole.

Lenovo CE0128T Switch (Gigabit Ethernet) 3

System specifications

The following table lists system specifications for the CE0128T Switch.

Table 1. System specifications

Attribute Specification

Form factor 1U rack mount

Ports 24x Gigabit Ethernet (GbE) RJ-45 fixed ports

4x SFP ports

Media types 1 Gb Ethernet fixed ports (1000BASE-T):

RJ-45 UTP Category 5, 5e, or 6

1 Gb Ethernet SFP:

1 GbE RJ-45 SFP transceivers

1 GbE short-wavelength (SX) SFP transceivers

1 GbE long-wavelength (LX) SFP transceivers

Port speeds 1 Gb Ethernet RJ-45 fixed ports: 10/100/1000 Mbps auto-sensing

1 Gb Ethernet SFP RJ-45 transceivers: 1 Gbps

1 Gb Ethernet SFP optical transceivers: 1 Gbps

Data traffic types Unicast, multicast, broadcast.

Software

features

Layer 2 switching, Layer 3 switching, virtual local area networks (VLANs), VLAN tagging, Q-in-Q

VLAN tunneling, spanning tree protocol (STP), link aggregation groups (LAGs), L2 link failure

detection, IPv4/IPv6 management, IPv4/IPv6 static routing, stacking, zero-touch provisioning

(CWMP).

Performance Non-blocking architecture with wire-speed forwarding of traffic:

Up to 256 Gbps switching capacity.

Up to 51 Million packets per second (Mpps) forwarding rate.

As low as 4 microseconds port-to-port switching latency

Up to 9216-byte jumbo frames.

Buffer size: 1.5 MB.

Scalability MAC address forwarding database entries: 16000

VLANs: 4094

Multiple STP (MSTP) instances: 64

Link aggregation groups: 28

Ports in a link aggregation group: 8

Maximum ACL entries: 750

Maximum switches in the stack: 8

Cooling Fanless.

Power supply One fixed 100 - 240 V AC / 192 - 290 V HVDC power supply with IEC 320-C14 connector.

Hot-swap parts SFP transceivers.

Management

ports

1x RS-232 port (RJ-45).

Management

interfaces

CLI; Web-based GUI; SNMP v1, v2c, and v3.

Security features Secure Shell (SSH); HTTPS; user level security, Role-based Access Control (RBAC); RADIUS

and TACACS+ authentication; access control lists (ACLs); port-based network access control

(IEEE 802.1x).

Warranty 1-year hardware warranty with return-to-factory switch replacement.

Dimensions Height: 44 mm (1.7 in.); width: 440 mm (17.4 in.); depth: 260 mm (12.2 in.)

Weight 3.5 kg.

Lenovo CE0128T Switch (Gigabit Ethernet) 4

Models

The following table lists the Lenovo CE0128T Switch models.

Product availability: The Lenovo CE0128T Switch is available only in China.

Table 2. Lenovo CE0128T Switch models

Description Part number

Machine

Type

Feature

code

Lenovo CE0128T Switch 7Y050011CN 7Y05 B13B

The CE0128T Switch models ship with the following items:

Two mounting brackets

Documentation package

Configuration notes:

The power cable is not included and must be ordered together with the switch (see Power supplies

and cables for details).

SFP transceivers and cables are not included and should be ordered for the switch, if required (see

Transceivers and cables for details).

Lenovo CE0128T Switch (Gigabit Ethernet) 5

Transceivers and cables

With the flexibility of the CE0128T Switch, customers can choose the following connectivity technologies:

Fixed 10/100/1000 Mb Ethernet ports: Customers can use RJ-45 UTP cables for distances up to

100 meters.

SFP ports:

For distances up to 100 meters, customers can use the 1000BASE-T transceivers with RJ-45

UTP cables.

For distances up to 550 meters, customers can use the 1000BASE-SX transceivers with 50 µ

OM2 multimode fiber optic (MMF) cables.

For distances up to 10 kilometers, customers can use the 1000BASE-LX transceivers with

9 µ single-mode fiber optic (SMF) cables.

The supported SFP transceiver and cable options are listed in the following table.

Table 3. SFP transceivers and cables

Description

Part

number

Feature

code

Maximum

quantity

supported

SFP transceivers - 1 GbE

Lenovo 1000BASE-T (RJ-45) SFP Transceiver (no 10/100 Mbps support) 00FE333 A5DL 4

Lenovo RJ45 1Gbps SFP Transceiver (no 10/100 Mbps support) 00AY240 A4M8 4

Lenovo 1000BASE-SX SFP Transceiver 81Y1622 3269 4

Lenovo 1000BASE-LX SFP Transceiver 90Y9424 A1PN 4

Optical cables for 1 GbE SFP SX transceivers

Lenovo 1m LC-LC OM3 MMF Cable 00MN502 ASR6 4

Lenovo 3m LC-LC OM3 MMF Cable 00MN505 ASR7 4

Lenovo 5m LC-LC OM3 MMF Cable 00MN508 ASR8 4

Lenovo 10m LC-LC OM3 MMF Cable 00MN511 ASR9 4

Lenovo 15m LC-LC OM3 MMF Cable 00MN514 ASRA 4

Lenovo 25m LC-LC OM3 MMF Cable 00MN517 ASRB 4

Lenovo 30m LC-LC OM3 MMF Cable 00MN520 ASRC 4

The network cables that can be used with the CE0128T Switch are listed in the following table.

Table 4. CE0128T network cabling requirements

Transceiver Type Cable Connector

1 Gb Ethernet

RJ-45 ports (fixed)

1Gb RJ-45 SFP

(00FE333, 00AY240)

1000BASE-T UTP Category 5, 5E, or 6 up to 100 meters. RJ-45

1Gb SX SFP (81Y1622) 1000BASE-SX Lenovo fiber optic cables up to 30 m (see Table 3);

50/125 µ OM2 multimode fiber optic cable up to 550 m.

1Gb LX SFP (90Y9424) 1000BASE-LX 9/125 µ single-mode fiber optic cable up to 10 km. LC

Management ports

RS-232 serial console port RS-232 DB-9-to-RJ-45 console cable (purchased separately) RJ-45

Lenovo CE0128T Switch (Gigabit Ethernet) 6

Software features

The CE0128T Switch has the following software features:

Scalability and performance:

Media access control (MAC) address learning

Static and LACP (IEEE 802.3ad) link aggregation groups (LAGs)

Broadcast storm control

IGMP snooping for limit flooding of IP multicast traffic

IGMP filtering to control multicast traffic for hosts participating in multicast groups

Configurable traffic distribution schemes over LAGs based on source/destination IP or MAC

Availability and redundancy:

IEEE 802.1D STP for providing L2 redundancy

IEEE 802.1s Multiple STP (MSTP) for topology optimization

IEEE 802.1w Rapid STP (RSTP) (rapid convergence for delay-sensitive traffic such as voice)

Rapid Link Detection Protocol (RLDP) for L2 link failure detection

VLAN support:

Port-based and protocol-based VLANs

Up to 4094 VLANs supported per switch

802.1Q VLAN tagging support on all ports

802.1Q-in-Q VLAN tunneling

802.1x with dynamic VLAN assignment

Private VLANs

Stacking:

Up to 8 switches in a stack

Single IP management

Less than 100 milliseconds failover time in case of a member switch failure

Line and ring stacking topologies

Link aggregation across member devices

Multi-Active Detection (MAD) via bi-directional forwarding detection (BFD) or link aggregation

Security:

MAC-based and IP-based access control lists (ACLs)

802.1x port-based network access control

Multiple local user IDs and passwords

User access control

Radius and TACACS+ authentication and authorization

Protection from Denial of Service (DoS) attacks

DHCP snooping (IPv4/IPv6)

Quality of Service (QoS):

IEEE 802.1p, IP ToS/DSCP, MAC/IP, and port traffic classification and processing

Traffic shaping and re-marking based on defined policies

Eight priority queues per port for processing qualified traffic

Strict-Priority (SP) scheduling

Weighted Round Robin (WRR) scheduling

Weighted Fair Queueing (WFQ) scheduling

IPv4/IPv6 ACL metering

IP v4 Layer 3 functions:

Host management

IP filtering with ACLs

Static routes

DHCP server, client and relay operations

IGMP v1/v2 snooping

Lenovo CE0128T Switch (Gigabit Ethernet) 7

IP v6 Layer 3 functions:

IPv6 host management

IPv6 filtering with ACLs

Static routes

DHCPv6 server, client and relay operations

Manageability:

Command Line Interface (CLI)

Serial console

Telnet

SSH v1 and v2

Web-based management graphical user interface (GUI): HTTP/HTTPS

Simple Network Management Protocol (SNMP v1, v2c, and v3)

Firmware image and configuration file management: TFTP

Link Layer Discovery Protocol (LLDP) for discovering network devices

GARP VLAN Registration Protocol (GVRP) for automated VLAN configuration

CPE WAN Management Protocol (CWMP) for auto-configuration and dynamic service

provisioning

Network Time Protocol (NTP) / Simple NTP (SNTP) for switch clock synchronization

Monitoring:

Status LEDs for port status and switch status indication

Remote Monitoring (RMON) agent to collect statistics and proactively monitor switch

performance

Switched Port Analyzer (SPAN) / Remote SPAN (RSPAN) for monitoring network traffic

Syslog feature for change tracking and remote logging

Ethernet standards

The CE0128T Switch supports the following Ethernet standards:

IEEE 802.1AB: Link Layer Discovery Protocol (LLDP)

IEEE 802.1D Spanning Tree Protocol (STP)

IEEE 802.1s Multiple STP (MSTP)

IEEE 802.1w Rapid STP (RSTP)

IEEE 802.1p Class of Service (CoS) prioritization

IEEE 802.1Q VLAN tagging

IEEE 802.1Q-in-Q VLAN tunneling

IEEE 802.1x port-based authentication

IEEE 802.3 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX copper Fast Ethernet

IEEE 802.3ab 1000BASE-T copper twisted-pair Gigabit Ethernet

IEEE 802.3z 1000BASE-SX short range fiber optics Gigabit Ethernet

IEEE 802.3z 1000BASE-LX long range fiber optics Gigabit Ethernet

IEEE 802.3x Full-duplex Flow Control

IEEE 802.3az Energy Efficient Ethernet (EEE)

IEEE 802.3ad Link Aggregation Control Protocol (LACP)

Power supplies and cables

Lenovo CE0128T Switch (Gigabit Ethernet) 8

Power supplies and cables

The CE0128T Switch has one fixed AC / HVDC power supply with an IEC 320-C14 connector.

The CE0128T Switch ships without any power cables. The part numbers and feature codes to order the AC

power cables are listed in the following table (one cable is required per switch).

Table 5. AC power cable options

Description

Part

number

Feature

code

4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable 39Y7932 6263

Installation

The CE0128T Switch can be mounted on a wall or in 2-post or 4-post rack cabinets by using the two

mounting brackets that come with the switch.

Physical specifications

The CE0128T Switch has the following approximate dimensions and weight:

Height: 44 mm

Width: 440 mm

Depth: 260 mm

Weight: 3.5 kg

Operating environment

The CE0128T Switch is supported in the following environment:

Operating temperature: 0° to 50° C

Storage temperature: -40° to 70° C

Operating altitude: up to 3000 m

Relative humidity operating: 10% to 90%

Relative humidity non-operating: 5% to 90%

Electrical:

AC input:

100 - 240 V AC (nominal); 50 Hz or 60 Hz

AC rated current: 0.6 A

HVDC input:

192 - 290 V HVDC

HVDC rated current: 0.12 A - 0.2 A

Power consumption:

Maximum: 20.7 W

Idle: 17.1 W

Heat dissipation:

Maximum: 71 BTU/hour

Idle: 59 BTU/hour

Warranty

The CE0128T Switch has a 1-year hardware warranty that provides return-to-factory switch replacement.

Regulatory compliance

Lenovo CE0128T Switch (Gigabit Ethernet) 9

Regulatory compliance

The CE0128T Switch conforms to the following regulations:

China CCC GB4943, GB9254 Class A, GB17625.1

China CECP

China MII

China RoHS

China REACH

China WEEE

Network connectivity

The following table lists the network switches that are offered by Lenovo that can be used with the

CE0128T Switch in IT solutions.

Table 6. Ethernet LAN switches

Description Part number

1 Gb Ethernet switches

Lenovo CE0128P Switch 7Y050012CN

Lenovo CE0152T Switch 7Y060021CN

Lenovo RackSwitch G7028 (Rear to Front) 7159BAX

Lenovo RackSwitch G7052 (Rear to Front) 7159CAX

Lenovo RackSwitch G8052 (Rear to Front) 7159G52

Juniper EX2300-C PoE Switch 7165H1X

Juniper EX2300-24p PoE Switch 7165H2X

10 Gb Ethernet switches

Lenovo ThinkSystem NE1032 RackSwitch (Rear to Front) 7159A1X

Lenovo ThinkSystem NE1032T RackSwitch (Rear to Front) 7159B1X

Lenovo ThinkSystem NE1072T RackSwitch (Rear to Front) 7159C1X

Lenovo RackSwitch G8124E (Rear to Front) 7159BR6

Lenovo RackSwitch G8264 (Rear to Front) 7159G64

Lenovo RackSwitch G8264CS (Rear to Front) 7159DRX

Lenovo RackSwitch G8272 (Rear to Front) 7159CRW

Lenovo RackSwitch G8296 (Rear to Front) 7159GR6

For more information, see the list of Product Guides in the Top-of-rack Switches category:

http://lenovopress.com/servers/options/switches#rt=product-guide

Lenovo CE0128T Switch (Gigabit Ethernet) 10

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Lenovo

Lenovo

Lenovo BladeCenter Virtual Fabric 10Gb Switch... Manual de usuario

Lenovo

Lenovo Flex System Fabric CN4093 Manual de usuario

Lenovo

Lenovo ThinkSystem DB620S Manual de usuario

Lenovo

Lenovo ThinkSystem NE1032 Manual de usuario

Lenovo

Lenovo RackSwitch G8296 Manual de usuario

Lenovo

Lenovo RackSwitch G8264CS Manual de usuario

Lenovo

Lenovo ThinkSystem SM27A17643 Manual de usuario

Lenovo

Lenovo SI4093 Manual de usuario

Lenovo

Lenovo RackSwitch G8052 Manual de usuario

Lenovo

Lenovo RackSwitch G7028 Manual de usuario

Lenovo

Lenovo ThinkSystem NE0152T Manual de usuario

Lenovo

Lenovo Flex System Fabric CN4093 Guía del usuario

Lenovo

Lenovo RackSwitch G8264CS Manual de usuario

Lenovo

Lenovo ThinkSystem SM27A17643 Manual de usuario

Lenovo

Lenovo Flex System EN4023 Manual de usuario

Lenovo

Lenovo Flex System Fabric CN4093 Guía del usuario

Lenovo

Lenovo ThinkSystem NE10032O RackSwitch Manual de usuario

Lenovo

Lenovo RackSwitch G8296 Manual de usuario

Lenovo

Lenovo RackSwitch G8124E Manual de usuario

Lenovo

Lenovo ThinkSystem DB610S Manual de usuario

Lenovo

Lenovo RackSwitch G8264CS Manual de usuario

Lenovo

Lenovo RackSwitch G7052 Manual de usuario

Lenovo

Lenovo ThinkSystem NE25720 Manual de usuario

Lenovo

Lenovo ThinkSystem NE10032 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
