Lenovo V320-17IKB Manual de usuario

Read the safety notices and important tips in the

included manuals before using your computer.

Lenovo V320

V320-17IKB



V320-17ISK

User Guide



Read the safety notices and important tips in the 

included manuals before using your computer.

Notes

• Before using the product, be sure to read Lenovo Safety and General Information

Guide first.

• The latest electronic compliance and environmental information are available

from the Lenovo compliance information Web sites.

- To view compliance information go to: 

http://www.lenovo.com/compliance

- To download environmental information go to: 

http://www.lenovo.com/ecodeclaration

• Some instructions in this guide may assume that you are using Windows®10.

If you are using another Windows operating system, some operations may be

slightly different. If you are using other operating systems, some operations

may not apply to you.

• The features described in this guide are common to most models. Some

features may not be available on your computer or your computer may include

features that are not described in this user guide.

• The illustrations used in this manual are for Lenovo V320-17IKB unless

otherwise stated.

• The illustrations in this manual may differ from the actual product. The

screenshots of operating system are for reference only. Please refer to the actual

product.

Regulatory Notice

• For details, refer to Guides & Manuals at http://support.lenovo.com.

First Edition (April 2017)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General

Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set

forth in Contract No. GS-35F-05925.

Contents

Chapter 1. Getting to know your computer .........................................1

Top view.......................................................................................................................1

Left-side view ..............................................................................................................6

Right-side view..........................................................................................................11

Bottom view ...............................................................................................................12

Chapter 2. Starting to use Windows 10 .............................................13

Configuring the operating system for the first time ............................................13

Operating system interfaces ....................................................................................13

Putting the computer to sleep or shutting it down..............................................16

Connecting to a wireless network ..........................................................................18

Get help from Windows...........................................................................................19

Chapter 3. Recovery system ............................................................... 20

Push-button reset ......................................................................................................20

Chapter 4. Troubleshooting ................................................................ 22

Frequently asked questions .....................................................................................22

Troubleshooting ........................................................................................................24

Appendix A. CRU instructions ............................................................ 27

Replacing the optical drive ......................................................................................28

Trademarks .......................................................................................... 31

Chapter 1. Getting to know your computer

Top view --------------------------------------------------------------------------------------

Note: The dashed areas indicate parts that are not visible externally.

Attention:

•Do not open the display panel beyond 170 degrees. When closing the display panel, be

careful not to leave pens or any other objects in between the display panel and the

keyboard. Otherwise, the display panel may be damaged.

Chapter 1. Getting to know your computer

Integrated

camera

Use the camera for video communication.

Built-in

microphone

Capture sound which can be used for video conferencing,

voice narration, or audio recording.

Wireless LAN

antennas

Connect to a wireless LAN adapter to send and receive

wireless radio signals.

Computer display

The LCD display with LED backlight provides brilliant

visual output.

Ventilation slots Dissipate internal heat.

Note: Make sure that none of the ventilation slots are blocked, or else overheating of the

computer may occur.

Touch pad The touch pad functions as a conventional mouse.

Touch pad: To move the pointer on the screen, slide your

fingertip over the pad in the direction in which you want

the pointer to move.

Touch pad buttons: The functions of the left/right side

correspond to those of the left/right mouse button on a

conventional mouse.

Note: You can enable/disable the touch pad by pressing F6 ( ).

Power Key Press this key to turn on/off the computer.

By default, when the computer is on, press and hold this

key for more than 1 second, the computer will enter sleep

mode, press and hold it for more than 5 seconds, the

computer will be turned off.

Numeric keypad For details, see “Using the keyboard” on page 3.

Fingerprint

reader (on select

models)

Registers fingerprints that can be used as passwords to

secure your computer.

Chapter 1. Getting to know your computer

Using the keyboard

Your computer has number keys and function keys and may also have a

numeric keypad incorporated into its standard keyboard.

Numeric keypad

The keyboard has a separate numeric keypad. To enable or disable the

numeric keypad, press the Num Lock key.

Chapter 1. Getting to know your computer

Using the keyboard

Hotkeys

You can access certain system settings quickly by pressing the appropriate

hotkeys.

:Mutes/unmutes the sound. :Enables/disables airplane

mode.

:Decreases the volume

level. :Enables/disables camera.

:Increases the volume level. :Locks/unlocks the LCD

screen.

:Enables/disables

microphone. :

Enables the external

projector or dangles the

external display.

:Refreshes page. :Decreases display

brightness.

:Enables/disables the touch

pad. :Increases display

brightness.

Note: If you changed the Hotkey Mode from Enabled to Disabled in the BIOS setup utility, 

you will need to press the Fn key in combination with the appropriate hotkey.

Chapter 1. Getting to know your computer

Function key combinations

Through the use of the function keys, you can change operational features

instantly. To use this function, press and hold Fn ; then press one of the

function keys .

The following describes the features of each function key.

Fn + B: Activate the break function.

Fn + P: Activate the pause function.

Fn + C: Enable/Disable the scroll lock.

Fn + Y: Activate the system request.

Fn + S + V: Set the battery Ship Mode.

Chapter 1. Getting to know your computer

Left-side view ---------------------------------------------------------------------------

AC power

adapter jack

Connects to the AC power adapter.

Battery/Charging

status indicator

AC power 

adapter status

Indicator status Meaning

Disconnected

Off The computer is in sleep mode or

turned off; The battery has more

than 20% charge.

Solid amber The battery has between 5% and

20% charge.

Fast blinking amber The battery has between 1% and 5%

charge.

Connected

Slow blinking amber The battery is being charged. When

battery charge reaches 20%, the

blinking color changes to white.

Slow blinking white The battery has between 20% and

80% charge and is still charging.

When the battery reaches 80%

charge the light will stop blinking.

Solid white The battery has more than 80%

charge, charging will continue until

the battery is fully charged.

RJ-45 port Connects the computer to an Ethernet network.

HDMI port Connects to devices with HDMI input such as a TV or a

display.
