LEGRAND Radiant Series Manual de usuario

installation guide

Smart Switch

WTRL10

table of contents

before you start..................................3

what you need ...................................4

installation and setup ................ 6–19

getting to know your switch ......20-21

specifications...................................22

faqs ..............................................23

regulatory information......... 24–27

warranty.......................................28

support ........................................29

before you start

Review this guide in its entirety before beginning device installation. Consult an

electrician with any questions or if you are unsure of your abilities.

DWarning: Incorrect installation could

result in death, serious injury, and/or

damage to your home or devices.

DCaution: To reduce the risk of injury

and/or overheating and damage to other

equipment:

• For dry, indoor use only.

• Do not use to power medical equipment.

• Not suitable as a disconnecting means.

• Do not use with loads exceeding the

device load rating (see page 22).

• Connect the smart switch to a

120 VAC, 60 Hz power source ONLY.

• Always use copper wire to install the

smart switch and follow all applicable

local and national electrical codes.

• Install in a non-metallic electrical box

to protect wireless signal strength.

Visit the Legrand website at www.legrand.us/radiant/smart-lighting.aspx to learn more

about your smart device.

what you need

REQUIRED:

Phillips-head screwdriver

Flat blade screwdriver

YOU MAY ALSO NEED:

Non-contact voltage tester, pliers, wire cutter, wire stripper, electrical tape,

ﬂashlight, radiant®screwless wallplate (included), wiring leads (included), and

wire nuts (included)

NOTE: Exercise caution when using power tools. Overtightening the screws can

damage the device.

installation & setup

step one

turn off the power for your device at the

circuit breaker

Flip the existing light switch multiple times to conﬁrm the power is off.

NOTES:

• If there are multiple devices next to your existing light switch, make sure power is

off at the circuit breaker for all of those devices.

• For three-way installations using a remote switch, follow the instructions for the

remote device (WTRL20).

OFF

installation & setup

step two

remove the existing device

Check for the following wires:

1HOT or LINE: Receives power from the circuit box. Referred to as “Hot” for the

purposes of this guide.

2LOAD: Directs power to your light(s).

3NEUTRAL: Creates a path to return current to the power source when the

device is off. Required for your switch installation.

4GROUND: Provides a safe path for electricity in the event of a short circuit.

NOTE: Refer to “faqs” on page 23 if you are unsure of your wiring.

OFF

VOLTAGE

TESTER

Load

Supply

“Hot”

installation & setup

step three

wire the smart switch

When connecting each wire, loosen the terminal screw, insert the wire into a

terminal slot, and tighten the terminal screw until the wire is secured.

1Connect the neutral wires to the WHITE terminal slots.

2Connect the load wire to any LOAD terminal slot.

3Connect the hot wire to any HOT terminal slot.

4Connect the ground wire to the green wiring lead on the device. Use a wire nut

to secure the wires together.

NOTE: If you need extra length on your wires, wire leads are included in your packaging.
