LEGRAND 5 720 89 Manual de usuario

LE05265AC

• ON/standby IR control

•

5 720 89

• Characteristics • •

• Mounting • •

100 VAC

240 VAC

50/60 Hz

1 x 1.5 mm2

+ 45°C

+ 5°C

Technology

Infrared

Frequency range:

20kHz to 60kHz

Wavelength: 940nm















• Dismounting • •

1.2 m

20°

1.2 m

20°

1.2 m

10m

10.5m

11.5m

9.9m

11.5m

12.5m

≥16m

5.2m

4.5m

9.5m

7.3m

10m

10.5m

≥16m

13m

12m

16m

13.8m

8.5m

3.5m

3.5m-90°

-75°

-60°

-45°

-30° 30°

45°

60°

75°

90°

-15° 15°

0°

-90°

-75°

-60°

-45°

-30°

30°

45°

60°

75°

90°

-15°

15°

0°

-90°

-75°

-60°

-45°

-30°

30°

45°

60°

75°

90°

-15° 15°

0°

15m

10.5m

11.5m

15m

≥16m

15.5m

≥16m

15.5m

Horizontal detection angles (0° incline) Horizontal detection angles (20° incline from top view) Horizontal detection angles (20° incline from Botton view)

Safety instructions

This product should be installed in line with installation rules, preferably by a quali-

ed electrician. Incorrect installation and use can lead to risk of electric shock or re.

Before carrying out the installation, read the instructions and take account of the

product’s specic mounting location.

Do not open up, dismantle, alter or modify the device except where specically

required to do so by the instructions. All Legrand products must be opened and

repaired exclusively by personnel trained and approved by Legrand. Any unautho-

rised opening or repair completely cancels all liabilities and the rights to replace-

ment and guarantees.

Use only Legrand brand accessories.

• Cabling • •

2 N

The directive 1999/5/CE of the european parliament

and of the council of March 9th, 1999

EN 301 489

EN 300 328

EN 60669-2-1

CONFORMITY DECLARATION

We declare that the products satisfy the provisions of :

On condition that they are used in the manner intented and/or in accordance with the current installation

standards and/or with the manufacturers recommandations

These provisions are ensured for directive 1999/5/CEE by conformity to the following standards :

Channel availability depends on local country regulations. Wireless LAN system administrator must choose

correct country of operation. Channels are then automatically configured to comply with specified

country's regulations.

LEARN

LEARN Led

LED ON/OFF

ON/OFF

LEARN Button

Sensor learning cell

OFF ON SLOW FLASHING (1s) QUICK FLASHING (0.25s) FLASHING MODE (60ms)

• Programming • •



2s 2s

ON/OFF







OFF





Programmation/Programming

Test de fonctionnement/Function test

Remise en conguration usine

Return to factory settings
