Larson Electronics EPL-48-2L-T12VHO Manual de usuario

EPL-48-2L-T12VHO

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 1of 3

Surface Mount Explosion Proof, Waterproof Fluorescent Lights

T12 Very High Output - Oil Rigs - 2 L

Instruction Manual

•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY

RELEVANT LOCAL BUILDING CODES.

•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL

SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.

•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP

OBJECTS. SUITABLE FOR DAMP LOCATIONS.

IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE EPL-48-2L-T12VHO MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE

AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.

RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.

RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

Thank you for your purchase of the Larson Electronics EPL-48-2L-T12VHO.

)

WARNING:

READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

WARNING

TO AVOIDTHE RISKOF FIRE,EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,

INSPECTEDAND MAINTAINEDBY A QUALIFIED ELECTRICIANONLY, IN ACCORDANCEWITHALL

APPLICABLEELECTRICAL CODES.

TO AVOIDELECTRIC SHOCK:

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING

CONDUCTOR.

TO AVOID EXPLOSION:

•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.

•ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS

ATMOSPHERE.

•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT

NAMEPLATE.

•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR

DAMAGED. IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.

•ALL FASTENERS SHOULD BE PROPERLY SEATED.

The Larson Electronics EPL-48-2L-T12VHO Explosion Proof Fluorescent Light Fixture is NRTL Listed for United States

and Canada Class 1 Division 1 and Class 1 Division 2 for hazardous locations where flammable chemical/petrochemical

vapors exist or have the potential to exist. The unit carries a T6 temperature rating, it is also approved for Paint Spray

Booths.

EPL-48-2L-T12VHO

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 2of 3

WIRING

Standard pigtail(flying leads) wiring

We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas

where weatherproofing may be required. Universal voltage driver permits operation at 120V OR 277V AC.

Warning: Check product label for correct input voltage!

Attach supply line wires to the appropriate light fixture wires as shown

in thediagram 

Secure each pair of wires according to the diagram. Utilize a junction box or

similar device and take precautionary steps for weatherproofing all

connections if installed in a location where water may come in contact with the

unit. Ensure the unit is properly grounded and that wiring is done according to

all local and national electrical/building codes.

ADJUSTABLE SURFACE MOUNTING BRACKETS

Each bracket is cinched to the bracket mounting peg on each side of the light. The angle of the bracket is set by tightening

two cap screws on either side of the bracket. The cap screws act as a set screw. The bracket itself is mounted via a single

bolt hole at the top the bracket. There are two brackets, one on each end of the light. Once the brackets are mounted to a

surface (ceiling, floor or wall), the light fixture can be removed from the brackets by loosening the cap screws that hold the

bracket to the mounting peg.

SUSPENSION MOUNTING

Pendant mount fixtures hang from the ceiling and are suspended by rigid pipe. Each fixture features a 1/2” NPT junction box

on one end, and a 1/2” NPT adjustable L-bracket on the other end of the fixture. Operators bring rigid pipe down to the

threaded mounting hubs. Wiring is fed down through the rigid pipe to the junction box and tied in to the fixture’s lead wires,

completing the electrical connection. The adjustable L-shape mounting bracket provides support for the opposite end of the

fixture.

INSTALLATION

We strongly recommend that only a licensed electrician install this product.

Warning: Make sure that the power is disconnected before installing. This fixture is extremely heavy and must be

mounted to a surface that can structurally support the load. Note: this fixture requires a minimum of 50 inches of

clearance from re-lamp end for lamp replacement. An optional drop mounting kit that will allow for end to end row

mounting is available, please consult factory.

Warning: Do not let fixture hang on one bracket at any time. Failing to comply can result in breakage of and end

casting or mounting bracket allowing the fixture to fall which can cause serious injury or death.

•The mounting brackets are shipped installed on the fixture.

•Install the brackets to wall or ceiling with two 3/8’’ bolts (not supplied) at center measurements.

•Fixture is now ready for mounting.

It is strongly suggested to use two licensed electricians to proceed with the final mounting of the fixture to

avoid any possible personnel injury or damage to the fixture as the unit weights up to 66lbs (30.0 kg) and will

be slightly awkward to hold in position and attach to brackets mounted on wall or ceiling. Depending on

mounting height and scaffolding, a hydraulic man–lift or two good quality ladders should be used.

•Remove the upper center screw cap on the re-lamp end (field wiring compartment).

•Install approved cable connector or conduit fitting into ½’’ npt hub on field wiring compartment.

•Install a three conductor cable into the connector, allowing 3 inches of wire inside compartment for connection.

•Using approved wire connectors, splice wires as per color codes: black to black (line) white to white (common) and green to green

(ground).

•Replace end-cap, making sure there are no wires protruding that maybe pinched causing a possible short circuit.

Warning: Fixture must be grounded as required per paragraph 410-21 and article 250 of

the National Electric Code and/or rule 30-500. Failure to properly ground this fixture will

create and electrical shock, which can cause serious injury or death.

WIRING INSTRUCTIONS

EPL-48-2L-T12VHO

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com 3of 3

MAINTENANCE

Caution:To avoid personal injury,disconnect powerto the light and allow theunit to cool down before performing maintenance.

Warning: No user serviceable parts inside of fixture.Risk of electricshock.Removalof the lenswill void the warranty.

1. Perform visual,mechanical and electrical inspections on a regular basis.We recommend routine checks to be made on a

yearly basis. Frequency of use and environment shoulddetermine this. It is recommendedto follow an Electrical Preventive

Maintenance Program as described in NFPA 70B: Recommendedpractice for Electrical Equipment.

2. The lens should be cleaned periodically as neededto ensure continued photometric performance. Clean the lens with a

damp, non-abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid cleaner.

3. Inspect the cooling fins on the luminaire to ensure that they are free of any obstructions or contamination (i.e.excessive

dust build-up). Clean with a non-abrasive clothif needed.

4. Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The EPL-48-2L-T12VHO is designed to provide years of reliable performance. Should the need for replacement parts

arise, please contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
