Larson Electronics LE-2317C Manual de usuario

LE-2317C

Explosion Proof Flashlight Instruction

Manual

Congratulations on the purchase of your new Handheld Waterproof

and Explosion Proof Flashlight. Please read these instructions

carefully to familiarize yourself with the safe operation and

maintenance of your new flashlight. Following these instructions will

insure many years of safe and dependable service.

Table of Contents

Operating Instructions 2

I.I

Assembly 2

I.II

Operation 2

II.

Bulb Replacement 3

III.

Warnings 4

VI.

Warranty and Disclaimer 5

VI.I

Limitation of Liability 5

VI.II

Conditions 5

VII.

Return Requests and Inquiries 6

8.1 Warranty Returns 6

8.2 Non-Warranty Returns 6

Return to Table of Contents

I. Assembly and Operation

I. Assembly

Unscrew the bottom cap and install approved

batteries like shown below. Once batteries have

been placed, screw the bottom cap back on.

II. Operation

This flashlight features a simple slide switch

for easy operation. Operators slide the switch

up to turn on, down to turn off or in the middle

for

momentary.

Slide to top for on

Slide to middle for momentary

Slide to bottom for off

Insert batteries (+ side

first) and replace cap.

Return to Table of Contents

II. Bulb Replacement

I. Replacement

Begin by unscrewing the lens cap of the flashlight. The light housing is

held together with the lens cap by clicking into place. To separate the

the housing and the lens cap simply apply force and pull them apart.

(Note: The bulb is held in place via a spring attached to the

lens, upon separation of the housing and lens cap the bulb will

be free, be careful not to drop, lose, or break the bulb.)

The bulb is now free to be replaced.

Return to Table of Contents

III. Safety Warnings and Ratings

For personal safety, always follow the safety instructions in this manual to ensure safe and long-

term use. Failing to do so can result in damage to the product or serious bodily injury.

Safety Warnings

Never place flashlight face down when light is

on or is still hot from recent use. Doing so could

burn/ignite surfaces such as seats, carpeting,

etc. and cause major property damage.Always

turn spotlight off when not

in use.

To prevent serious damage to eyesight, never

look into the flashlight when light is on. DO

NOT

shine light into the face of someone else.

DO NOT touch the lens of the flashlight when

light is on or if it was recently on. The lens will

be hot and could cause serious burns.

DO NOT allow children to handle or operate

this flashlight.

DO NOT use this product for other than its

intended use.

DO NOT operate in close proximity of

combustible or flammable materials.

DONOTattempttooperatethisspotlightifcord,

plug, battery, bulb or any part of the spotlight is

damaged or corroded.

DO NOT remove lens ring.

DO NOT allow metal parts to touch metal

contacts on battery as this can cause a short

circuit and result in a fire.

II.

Ratings

Class I, Division 1, Group C & D

Class I, Division 2, Group A, B, C, & D

Class II, Division 2, Group G - Class 3

CSA: Class I, Division 1, Group C & D

CSA: Class II, Division 1, Group G - Temp T3C

ASTM & MSHA:Approved

Return to Table of Contents

IV. Warranty and Disclaimer

Larson Electronics’, LLC. LarsonElectronics.com warrants this unit to be free of defects in materials

and workmanship for a period of three (3) years from the date of

purchase.

If the unit should malfunction, it must be returned to the factory for evaluation. Larson Electronics’

Customer Service Department will issue a Returned Merchandise Authorization (RMA) number

immediately upon phone or written request. Upon examination by Larson Electronics’, if the unit is

found to be defective it will be repaired or replaced at no charge. Larson Electronics’WARRANTY does

not apply to defects resulting from any action of the purchaser, including but not limited to mishandling,

improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.

This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence

of being damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper

specification;misapplication;misuseorotheroperatingconditionsoutsideofLarsonElectronics’control.

Larson Electronics’ is pleased to offer suggestions on the use of its various products. However, Larson

Electronics’ neither assumes responsibility for any omissions or errors nor assumes liability for any

damages that result from the use of its products in accordance with information provided by Larson

Electronics’, either verbal or written. Larson Electronics’ warrants only that the parts manufactured by

it will be as specified and free of defects.

LIMITATION OF LIABILITY

The remedies of purchaser set forth herein are exclusive and the total liability of Larson Electronics’

with respect to this order, whether based on contract, warranty, negligence, indemnification, strict

liability or otherwise, shall not exceed the purchase price of the component upon which liability

is based. In no event shall Larson Electronics’ be liable for consequential, incidental or special

CONDITIONS

Should any Product(s) be misused in any way, Larson Electronics’ assumes no responsibility as set

forth in our basic WARRANTY / DISCLAIMER language, and additionally purchaser will indemnify

Larson Electronics’ and hold Larson Electronics’ harmless from any liability or damage whatsoever

arising out of the use of the Product(s) in such a manner.

Return to Table of Contents

V. Return Requests and Inquiries

Directallwarrantyandrepairrequests/inquiriestotheLarsonElectronics’CustomerServiceDepartment.

BEFORE RETURNING ANY PRODUCT(S) TO LARSON ELECTRONICS’, PURCHASER MUST

OBTAIN A RETURNED MERCHANDISE AUTHORIZATION (RMA) NUMBER FROM LARSON

ELECTRONICS’ CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING

DELAYS). The assigned RMA number should then be marked on the outside of the return package

and on any correspondence.

The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent

breakage in transit.

For WARRANTY RETURNS please

have the following information available

BEFORE contacting Larson Electronics

III.I

Order number under which the

product was PURCHASED.

III.II

Model and serial number of the

product under warranty.

3. Repair instruction and/or specific

problems relative to the product.

For NON-WARRANTY REPAIRS consult

Larson Electronics LLC for current repair

charges. Have the following information

available BEFORE contacting Larson

Electronics LLC:

Order number to cover the COST of the

repair.

Model and serial number of product.

3. Repair instructions and/or specific

problems relative to the product.

LarsonElectronics’policyisto makerunningchanges,notmodelchanges,wheneveran improvement

is possible. This affords our customers the latest in technology and engineering.

Larson Electronics’ is a registered trademark of LARSON ELECTRONICS’, LLC.

copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-

readable form, in whole or in part, without prior written consent of LARSON ELECTRONICS’ LLC.
