Lantronix SUN-PC Manual de usuario

Trading Floor Switch

SUN-PC

Product Guide

Part Number 15.00.020

Revision B

January 2002

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 2

PN 15.00.020 - 0102B

the contents of this book may be transmitted or reproduced in any form or by any means

without the written permission of Lantronix. Printed in the United States of America. Also

electronically distributed via Adobe PDF file format.

Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open

Group. Windows 95, Windows 98, Windows 2000, and Windows NT are trademarks of

Microsoft Corp. Netscape is a trademark of Netscape Communications Corporation. Adobe

Acrobat and PDF are trademarks of Adobe Corporation. Other trademarks and service marks

are held by their respective owners.

Lightwave Communications, Inc. (LCI)

100 Washington Street

Milford, CT 06460 USA

Phone (800) 871-9838 • (203) 878-9838

Fax: (203) 874-0157

Email: info@lightwavecom.com

Internet: www.lightwavecom.com

Lantronix

15353 Barranca Parkway

Irvine, CA 92618 USA

Phone: (949) 453-3990

Fax: (949) 453-3995

Internet: www.lantronix.com

Disclaimer & Revisions

Operation of this equipment in a residential area is likely to cause interference in which case

the user, at his or her own expense, will be required to take whatever measures may be

required to correct the interference.

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 3

PN 15.00.020 - 0102B

The Trading Floor Switch allows a single keyboard and mouse to control two SUN

and two PS/2-compatible CPUs. Valuable desk space is conserved by using a single

keyboard and mouse to control multiple CPUs. Video signals are not switched by the

Trading Floor Switch so that video information from each CPU may be simultaneously

displayed on separate monitors, preventing the user from missing important data.

Keyboard and mouse emulation is supplied at all times to all attached computers

regardless of switch position. There is no interruption of operation caused by a CPU

detecting the absence of a keyboard. The Trading Floor Switch stores keyboard status

(Caps Lock, Num Lock, etc.) for each CPU and restores the current status each time the

CPU is selected.

Two Models of Trading Floor Switch are described in this manual:

•SUN Trader Switch, PN 300.000.2201 uses a SUN Keyboard (Type 5 or

greater) and Mouse for the User

•PS/2 Trader Switch PN 200.000.2220 uses a PS/2 Mouse and PS/2 Keyboard

for the User.

Both models are similar except for the User’s Keyboard/Mouse connections.

The Trading Floor Switch’s small size makes it easy to locate the unit away from

valuable desktop space. A wired Remote Switch allows users to switch between CPUs

with just the push of a button; the selected CPU is indicated by an LED above the

appropriate button. When the Trading Floor Switch is used with Lightwave

Communications’ Cat 5 Extender, CPUs may be located up to 300 feet away from the

desktop.

Included with each Trading Floor Switch are several pieces of 3M Dual Lock reclosable

fastener to attach the Remote Switch to a desk, wall, or keyboard. Enough material is

included with each unit to provide multiple mounting locations.

Dimensions

Main Body (placed near CPU)

Height: 1 inch (2.54 cm)

Width: 5.25 inches (13.32 cm)

Depth: 4.69 inches (11.91 cm)

Weight: 1 lb (0.48 kg)

Remote Switch (on Desktop)

Height: 1 inch (2.54 cm)

Width: 3.50 inches (8.89 cm)

Depth: 1.13 inches (2.86 cm)

1: Product Description

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 4

PN 15.00.020 - 0102B

The Trading Floor Switch consists of two components: the Main Body, and the Remote

Switch. The main body is usually located with the CPUs, off the desktop. The remote

switch may be attached directly to the keyboard or to a location more convenient for the

user.

2.1 Power Requirements

The Trading Floor Switch is powered by the attached CPUs through the keyboard and

mouse connections. The Trading Floor Switch will not operate if the attached CPUs are

not powered. No additional power input is necessary for normal operation.

If there is a power fault that would cause damage to the Trading Floor Switch, internal

auto-reset fuses will trip to prevent overload. To reset the fuses, remove and then

reattach all cables from the main body.

2.2 Procedure

1. Shut down all CPUs that will be attached to the Trading Floor Switch. Remove all

mice and keyboards, but leave the monitors attached.

2. Connect the CPUs to the Trading Floor Switch using the appropriate cables, no

more than 25 feet in length. SUN CPUs are attached using a single 8-pin mini-

DIN cable for both keyboard and mouse, while PS/2 CPUs are attached using

two 6-pin mini-DIN cables (one for mouse, one for keyboard). Be sure not to

cross the PS/2 keyboard and PS/2 mouse cables between the CPU and the

Trading Floor Switch.

2: Installation

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 5

PN 15.00.020 - 0102B

(Sun Trader unit shown above)

3. Connect your keyboard to the Trading Floor Switch keyboard (K) port. If using

the PS/2 version, connect the Mouse to the Trading Floor Switch. The SUN

Mouse connects to the SUN keyboard as usual.

4. Using the provided Category 5 cable (or another fully-pinned Cat 5 cable up

to 45 feet in length), connect the Remote Switch to the main body. The 3M

Dual Lock may be placed on the remote and its mounting location if desired.

The fastener has adhesive already applied with a peel-off backing, so no

additional adhesive should be necessary. Dual Lock does not function like a

conventional hook-and-loop fastener; any Dual Lock surface will mate with

any other Dual Lock surface.

5. Turn on the power to the CPU’s. The Trading Floor Switch will power up with

the first CPU. As long as any connected CPU remains powered on, the

Switch will continue to operate.

The Trading Floor Switch may now be used normally as outlined in section 3.0.

2.3 Use with Lightwave ServerSwitch Systems

To connect a PC ServerSwitch Plus or a ServerSwitch 8200 to the Trading Floor Switch,

attach the USER port of the ServerSwitch to the appropriate port on the Trading Floor

Switch as outlined above. A PC ServerSwitch Plus should be connected to one of the

port pairs marked “PC 1” or “PC 2”, while a ServerSwitch 8200 should be connected to

one of the ports marked “SUN 1” or “SUN 2”. It is not necessary to remove power from a

ServerSwitch when attaching the keyboard and mouse cables to the Trading Floor

Switch.

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 6

PN 15.00.020 - 0102B

K M K/MMK K/M

PC 1 PC 2 SUN 1 SUN 2

Sun

CPU Sun

CPU

PC or

PS/2

CPU

PC or

PS/2

CPU

monitor monitor monitor monitor

wired remote

Trading Floor Switch

main body

Sun keyboard/mouse

8 pin mini-DIN cable straight-pinned

RJ45 cable

mouse

keyboard

keyboard/mouse

keyboard

mouse

keyboard/mouse

Trading Floor Switch Typical Installation

Trading Floor Switch SUN-PC

Lightwave Communications, a Lantronix Company 7

PN 15.00.020 - 0102B

3.0 Operation

The Trading Floor Switch is simple to operate. The User is able to fully operate one of up

to four CPUs at a time using their Mouse and Keyboard.

Remote Switch for Trading Floor Switch

The Remote Switch is placed conveniently for the User. Pushing a button on the Remote

Switch will select the desired CPU to be controlled. An LED on the Remote Switch will

light to indicate the selected server and the status of the keyboard and mouse

connection (see below).

LED Activity Keyboard/Mouse Status

always on both connected

slow blink keyboard connected, mouse missing

medium blink keyboard missing, mouse connected

fast blink both missing

In some cases, a keyboard or mouse may be intentionally disconnected from a CPU, so

the lack of one of these devices may not be a problem. If in doubt, contact your system

administrator.

3.1 Windows



Key Mapping

The Trading Floor Switch maps the Windows key and the application key commonly

found on newer PS/2 keyboards. Users can utilize these key functions with a SUN

keyboard when the PS/2 CPU is selected through the Trading Floor Switch.

The left diamond (meta) key on the SUN keyboard works as the Windows key, while the

right diamond (meta) key on the SUN keyboard works as the application key.
