LanPro LP-570G Fast Installation Guide,
setup as an Access Point (AP)
LP570G_M123_ENB01W
LanPro LP-570G
Fast Installation Guide,
setup as an Access Point (AP)
www.lanpro.com
Wireless - Equipment - LP-570G - Fast Installation Guide, setup as an Access Point (AP)
2
Figure 1
Insert the CD in the package in your CD or DVD
reader and wait for the automatic execution of the
installation application. In case the software doesn´t
start automatically, please select: “My PC” the CD
or DVD unit and execute the setup.exe program as
shown in figure 1:
1
3.2
Once the application has been executed, a list will
be shown so you can select the language for your
installation. This is shown in figure 2. Once done,
select: “Next”.
2
Figure 2
The installation assistant proceeds to install the
driver and the utilities as shown in figure 3.
3
Figure 3
Once finished, please select: “Next” in the window
shown in figure 4.
4
Figure 4
www.lanpro.com
Wireless - Equipment - LP-570G - Fast Installation Guide, setup as an Access Point (AP)
3
The assistant will proceed to configure the Driver
and the Utilities as shown in figure 5.
5
Figure 5
Please select: “Finish” in the window shown in
figure 6.
6
Figure 6
The desktop bar will show the icon of the utility at
the side of the hour indication, please see figure 7.
7
Figure 7
Please screw the antenna on the SMA connector as
shown in figure 8.
8
Figure 9
Proceed to insert the LP-570G in one of the USB
ports of your PC as shown in figure 9:
9
Figure 8
www.lanpro.com
Wireless - Equipment - LP-570G - Fast Installation Guide, setup as an Access Point (AP)
4
The driver will install automatically.
For the connection of the LP-570G to a WLAN,
please select the icon showing amplitude of signal
vertical bars located in the lower right of the window
as shown in figure 10, click the right button of the
mouse on it and select the “Set wizard” option:
10
Figure 10
A window will pop-up showing the application,
please see figure 11. Please select: “AP” and then:
“Next”.
11
Figure 11
In the window shown in figure 12, please select
your preferred configuration as: “Normal User” or
“Advanced User”, then select “Next”.
12
Figure 12
In the window shown in figure 13, input the name
of the WLAN and the encryption mode, then select
“Next”.
13
Figure 13
www.lanpro.com
Wireless - Equipment - LP-570G - Fast Installation Guide, setup as an Access Point (AP)
5
Input a Network Key of your preference, as shown
in figure 14. The key should be between 8 and 63
characters long. Then select: “Next”. This Key will
be the one used by the clients that connect to the
WLAN.
14
Figure 14
In the next window shown in figure 15, you will be
prompted to confirm the parameter. Select: “Next”
to accept.
15
Figure 15
In the window shown in figure 16, please select the
physical card that provides the Internet Service and
then select: “Next”.
16
Figure 16
Proceed to confirm the WLAN AP creation by
selecting: “Finish” in the figure 17.
17
Figure 17
The configuration message will pop-up, meaning
your card is ready to receive connections from other
equipment.
18
Figure 18
It is important to mention this is not a full-blown AP, it is only a simple solution for sharing Internet
service through your operating system.
