Lanner NCA-1010 Manual de usuario

NCA-1010

User Manual

Version: 1.5

Date of Release: 2019/03/22

Network

Computing

NCA-1010 User Manual

The icons are used in the manual to serve as an indication of interest topics or important messages. Below

is a description of these icons:

Note: This check mark indicates that there is a note of interest and is something that you should

pay special attention to while using the product.

Warning: This exclamation point indicates that there is a caution or warning and it is something

that could damage your property or product.

The listed websites are links to the on-line product information and technical support.

Resources

URL

Lanner

http://www.lannerinc.com

Product Resource

http://www.lannerinc.com/download-center

RMA

http://eRMA.lannerinc.com

to make improvements to the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means

without the prior written permission of the original manufacturer. Information provided in this manual is

intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its

use, nor for any infringements upon the rights of third parties that may result from such use.

Intel, Pentium and Celeron are registered trademarks of Intel Corp.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

This product has passed the CE test for environmental specifications. Test conditions for passing included

the equipment being operated within an industrial enclosure. In order to protect the product from being

damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of

CE-compliant industrial enclosure products.

This equipment has been tested and found to comply with the limits for a Class B digital device.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case users will be required to correct the

interference at their own expense.

Follow these guidelines to ensure general safety:

Keep the chassis area clear and dust-free during and after installation.

Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf

and roll up your sleeves.

Wear safety glasses if you are working under any conditions that might be hazardous to your

eyes.

Do not perform any action that creates a potential hazard to people or makes the equipment

unsafe.

Disconnect all power by turning off the power and unplugging the power cord before installing

or removing a chassis or working near power supplies

Do not work alone if potentially hazardous conditions exist.

Never assume that power is disconnected from a circuit; always check the circuit.

NCA-1010 User Manual

Risk of Explosion if Battery is replaced by an incorrect type. Dispose of used batteries according to the

instructions.

Installation only by a trained electrician or only by an electrically trained person who knows all

English Installation and Device Specifications which are to be applied.

Do not carry the handle of power supplies when moving to another place.

The machine can only be used in a fixed location such as labs or computer facilities.

Electrical equipment generates heat. Ambient air temperature may not be adequate to cool

equipment to acceptable operating temperatures without adequate circulation. Be sure that the

room in which you choose to operate your system has adequate air circulation.

Ensure that the chassis cover is secure. The chassis design allows cooling air to circulate

effectively. An open chassis permits air leaks, which may interrupt and redirect the flow of cooling

air from internal components.

Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage

occurs when electronic components are improperly handled and can result in complete or

intermittent failures. Be sure to follow ESD-prevention procedures when removing and replacing

components to avoid these problems.

Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. If no wrist strap is

available, ground yourself by touching the metal part of the chassis.

Periodically check the resistance value of the antistatic strap, which should be between 1 and 10

megohms (Mohms).

Suivez ces consignes pour assurer la sécurité générale :

Laissez la zone du châssis propre et sans poussière pendant et après l’installation.

Ne portez pas de vêtements amples ou de bijoux qui pourraient être pris dans le châssis.

Attachez votre cravate ou écharpe et remontez vos manches.

Portez des lunettes de sécurité pour protéger vos yeux.

N’effectuez aucune action qui pourrait créer un danger pour d’autres ou rendre l’équipement

dangereux.

Coupez complètement l’alimentation en éteignant l’alimentation et en débranchant le cordon

d’alimentation avant d’installer ou de retirer un châssis ou de travailler à proximité de sources

d’alimentation.

Ne travaillez pas seul si des conditions dangereuses sont présentes.

Ne considérez jamais que l’alimentation est coupée d’un circuit, vérifiez toujours le circuit. Cet

appareil génère, utilise et émet une énergie radiofréquence et, s’il n’est pas installé et utilisé

conformément aux instructions des fournisseurs de composants sans fil, il risque de provoquer

des interférences dans les communications radio.

Risque d’explosion si la pile est remplacée par une autre d’un mauvais type.

Jetez les piles usagées conformément aux instructions.

L’installation doit être effectuée par un électricien formé ou une personne formée à l’électricité

connaissant toutes les spécifications d’installation et d’appareil du produit.

Ne transportez pas l’unité en la tenant par le câble d’alimentation lorsque vous déplacez

l’appareil.

La machine ne peut être utilisée qu’à un lieu fixe comme en laboratoire, salle d’ordinateurs ou

salle de classe.

L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être

adéquate pour refroidir l’équipement à une température de fonctionnement acceptable sans

circulation adaptée. Vérifiez que votre site propose une circulation d’air adéquate.

Vérifiez que le couvercle du châssis est bien fixé. La conception du châssis permet à l’air de

refroidissement de bien circuler. Un châssis ouvert laisse l’air s’échapper, ce qui peut interrompre

et rediriger le flux d’air frais destiné aux composants internes.

Les décharges électrostatiques (ESD) peuvent endommager l’équipement et gêner les circuits

électriques. Des dégâts d’ESD surviennent lorsque des composants électroniques sont mal

manipulés et peuvent causer des pannes totales ou intermittentes. Suivez les procédures de

prévention d’ESD lors du retrait et du remplacement de composants.

Portez un bracelet anti-ESD et veillez à ce qu’il soit bien au contact de la peau. Si aucun bracelet

n’est disponible, reliez votre corps à la terre en touchant la partie métallique du châssis.

Vérifiez régulièrement la valeur de résistance du bracelet antistatique, qui doit être comprise

entre 1 et 10 mégohms (Mohms).

Avant d’allumer l’appareil, reliez le câble de mise à la terre de l’équipement à la terre.

Une bonne mise à la terre (connexion à la terre) est très importante pour protéger l’équipement

contre les effets néfastes du bruit externe et réduire les risques d’électrocution en cas de foudre.

Pour désinstaller l’équipement, débranchez le câble de mise à la terre après avoir éteint l’appareil.

Un câble de mise à la terre est requis et la zone reliant les sections du conducteur doit faire plus

de 4 mm2 ou 10 AWG.

NCA-1010 User Manual

Desserrez la vis du terminal de mise à la terre.

Branchez le câble de mise à la terre à la terre.

L’appareil de protection pour la source

d’alimentation CC doit fournir 30 A de courant.

Cet appareil de protection doit être branché à la

source d’alimentation avant l’alimentation CC.

Version

Date

Descriptions

0.1

2015/03/25

Preliminary

0.2

2015/05/18

Added Appendix

0.3

2015/05/25

Modified specifications

Added safety guidelines

0.4

2015/06/19

Modified power adapter information

0.5

2015/08/11

Modified reset button to “hardware reset only”

0.6

2015/08/31

Added pin assignments

1.0

2016/04/08

Official release

1.1

2016/06/02

Added reset jumper on motherboard due to changes in motherboard

design

1.2

2016/06/13

Modified console pin assignments

1.3

2016/10/14

Added notes for “No Restore AC Power Loss”

1.4

2016/11/10

Modified FCC from Class A to Class B

1.5

2019/03/22

Updated BIOS Setup

NCA-1010 User Manual

System Specifications ................................................................................................................. 10

Front Panel ................................................................................................................................. 12

Rear Panel................................................................................................................................... 13

Motherboard Layout .................................................................................................................. 14

Block Diagram............................................................................................................................. 16

Internal Jumper & Connectors ................................................................................................... 17

Preparing the Hardware Installation .......................................................................................... 21

Installing the System Memory.................................................................................................... 21

Installing Mini PCIe Wireless Module......................................................................................... 22

Installing mSATA Mini Module ................................................................................................... 23

Main Page................................................................................................................................... 25

Advanced Page ........................................................................................................................... 26

Chipset........................................................................................................................................ 37

Security....................................................................................................................................... 41

Boot Menu.................................................................................................................................. 42

Save and Exit Menu .................................................................................................................... 43

Terms and Conditions................................................................................................................. 45

Introduction

Thank you for choosing Lanner's NCA-1010. This desktop platform is Lanner’s revolutionary ultra compact

x86 networking system built with Intel Bay Trail CPU (Atom™E3815). The central processor comes with

hardware-assisted security mechanisms including AES-NI, Secure Boot and TPM, allowing only authorized

software or data to run on NCA-1010. With built-in instruction commands, NCA-1010 helps manage and

secure devices connected to local WiFi network, like a compact entry-level firewall or multi-service gateway.

Despite its compact size, NCA-1010 delivers rich I/O connectivity and scalability. In terms of scalability,

NCA-1010 comes with one HDMI port for high definition display, one console port for device network

management, three LAN ports for network connections, two USB ports (one in USB 2.0 and another in USB

3.0 specifications) for external devices, and one antenna hole for signal reception. The rich I/O connectivity

makes NCA-1010 a widely deployable system in small area network environments.

For scalability, the inside of NCA-1010 provides one full-length mini-PCIe socket for Wi-Fi/3G/LTE module

to bring wireless connectivity to the system. In addition, there is also a half-length mini-PCIe socket for

mSATA storage. This will allow NCA-1010 to serve as a local media server when connected wirelessly.

With the features discussed above, NCA-1010 is ideally applicable in multi-service gateway control, entry

firewall for SMEs, retail, library and hospital environments, as well as wireless network access and

bandwidth management in small area networks.

NCA-1010 User Manual

Processor System

CPU

Intel® Bay Trail E3815 or E3825 CPU

Frequency

1.46 GHz

Core Number

E3815 CPU: single core

E3825 CPU: dual cores

BIOS

AMI SPI Flash BIOS

Chipset

N/A

Thermal

Fanless

Yes

Memory

Technology

DDR3L 1067 MHz non-ECC

Max. Capacity

8GB

Socket

1 x 204-pin DIMM

Ethernet

Controller

3 x Intel i211

Speed

10/100/1000 Mbps

Interface

RJ-45

Bypass

N/A

Storage

Type

mSATA

Installation

1 x mSATA

I/O

Reset Button

1 x reset button (Hardware reset only)

Console

1 x RJ45

USB

USB 2.0 x 1, USB 3.0 x 1

IPMI

N/A

TPM

Optional

Expansion

PCIe

1 x mini-PCIe

PCI

N/A

Cooling

Processor

Passive CPU heatsink

System

Fanless

Environment

Operating Temperature

0 ~ 40ºC

Non-operating Temperature

-20 ~ 70ºC

Relative Humidity

0% ~ 90%, non-condensing

Miscellaneous

LCD Module

N/A

Watchdog

N/A

Internal RTC with Li Battery

Yes

Mechanical

Dimension (W x H x D)

124.26 x 19.4 x 119.66 mm

Weight

0.5 kg

Mounting

N/A

Power

Type / Watts

36W power adapter

Tabla de contenidos

Otros manuales de Hardware de red de Lanner

Lanner

Lanner NCA-1513 Manual de usuario

Lanner

Lanner IIOT-I531 Manual de usuario

Lanner

Lanner FW-8756 Manual de usuario

Lanner

Lanner NCS2-VT04 Manual de usuario

Lanner

Lanner ICS-I372 Manual de usuario

Lanner

Lanner NCA-1515 Manual de usuario

Lanner

Lanner NCA-6530 Manual de usuario

Lanner

Lanner NCA-1040 Manual de usuario

Lanner

Lanner NCA-1516 Manual de usuario

Lanner

Lanner NCA-2522 Manual de usuario

Lanner

Lanner HTCA-6400 Manual de usuario

Lanner

Lanner FX-3230 Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Lanner

Lanner ICS-P570 Manual de usuario

Lanner

Lanner NCA-1011 Manual de usuario

Lanner

Lanner FX-3420 Manual de usuario

Lanner

Lanner NCA-2512 Manual de usuario

Lanner

Lanner NCA-1040SE Manual de usuario

Lanner

Lanner NCA-1611A Manual de usuario

Lanner

Lanner NCA-5230 Manual de usuario

Lanner

Lanner R6S Manual de usuario

Lanner

Lanner LWR-X8460 Manual de usuario

Lanner

Lanner HLM-1101 Manual de usuario

Lanner

Lanner NCA-4035 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Cantek

Cantek NR310-4 Manual de usuario
