Landoll 5531 Manual de usuario

F-716-1213 12/2013

LANDOLL CORPORATION

1900 North Street

Marysville, Kansas 66508

(785) 562-5381

800-428-5655 ~ WWW.LANDOLL.COM

Model 5531

Grain Drill

Operator’s Manual

1-2 f-716-1213 Edition

F-716-1213 Edition i

Table of Contents

1 Introduction

Understanding Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

2 Standard Specifications

3 Assembly Instructions

Press Wheel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Small Seed Attachment Installation (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

4 Operation and Maintenance

Tractor Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Grain Drill Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Attaching Grain Drill To The Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Transport Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Folding/Unfolding the Grain Drill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Leveling the Hitch Clevis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

Leveling the Hitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Transporting the Grain Drill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

Compressor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Air System Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

Openers – Hydraulic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Hydraulic Lift System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Loup II Drill Monitor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14

Seed Meter Gate Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15

Seed Rate Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16

Meter/Seed Rate Handle Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Seed Rate Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19

Dry Fertilizer Combination Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20

Fertilizer Box – Clean Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22

Fertilizer – Rate Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23

Fertilizer – Rate Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

Small Seed Rate Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25

ii F-716-1213 Edition

Small Seed Meter Assembly/Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26

Air Spring Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

Opener Blade Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

Opener – Press Wheel Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Opener Scraper Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Opener Soil Strip Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31

Drive Shaft – Coupler Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Walkboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Ladder Use and Transport Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34

Hydraulic Row Markers (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35

Hydraulic Row Marker Disc Adjustment (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36

5531 Point Row Clutch (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37

Wheel Bearing Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38

Hydraulic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38

Hose Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39

Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40

Lubrication Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42

5 Troubleshooting Guide

1-1

Chapter 1

Introduction

The Landoll Model 5531 Grain Drill is a quality product designed to give years of trouble free performance. By

following each section of this manual, your system will perform as designed for you and your operation

CHAPTER 1 gives basic instructions on the use of this manual.

CHAPTER 2 gives product specifications. These specifications supply lengths and measures for your

equipment. A Standard Bolt Torque Table is provided to give guidelines for bolt torques to

be used when servicing this product.

CHAPTER 3 contains assembly instructions for your Model 5531 Grain Drill. When these procedures

are correctly followed, your equipment should provide you years of trouble-free operation

and service.

CHAPTER 4 instructs how to operate your equipment before using it, and describes adjustments

needed. It also gives practical advice for the care and maintenance of your Landoll

equipment. Drawings in this section locate adjustment points on the equipment.

NOTE: IF THE EQUIPMENT IS IMPROPERLY ASSEMBLED OR MAINTAINED, THE

WARRANTY IS VOID. IF YOU HAVE ANY QUESTIONS CONTACT:

LANDOLL CORPORATION

1900 NORTH STREET

MARYSVILLE, KANSAS 66508

or phone:

(785) 562-5381 or

(800) 428-5655

or FAX:

(888) 527-3909

CHAPTER 5 is a troubleshooting guide to aid in diagnosing and solving problems with the equipment.

PARTS LIST is a separate manual showing the various assemblies, subassemblies, and systems.

Refer to that manual when ordering Landoll replacement parts. Order parts from your

Landoll dealer.

WARRANTY The Warranty Registration form is included with the product documents. Fill it out and

mail it within 15 days of purchase

NOTE: IMPROPER ASSEMBLY, MODIFICATION, OR MAINTENANCE OF YOUR

LANDOLL MACHINE CAN VOID YOUR WARRANTY.

COMMENTS Address comments or questions regarding this publication to:

LANDOLL CORPORATION

1900 NORTH STREET

MARYSVILLE, KANSAS 66508

ATTENTION: PUBLICATIONS -DEPT. 55

1-2 F-716-1213 Edition

INTRODUCTION

Understanding Safety

Statements

You will find various types of safety information on the

following pages and on the machine signs (decals)

attached to the vehicle. This section explains their

meaning.

The Safety Alert Symbol means ATTENTION! YOUR

SAFETY IS INVOLVED!



DANGER



WARNING



CAUTION

NOTE

Means that failure to follow these instructions could

cause damage to the equipment or cause it to operate

improperly.

NOTE

Make sure you read and understand the information

contained in this manual and on the machine signs

(decals) before you attempt to operate or maintain this

vehicle.

The safety statements contained in this manual relate to

the operation of the Model 5531 Grain Drill.

Danger means a life-threatening situation exists.

Death can occur if safety measures or

instructions on this label are not properly

followed.

Warning means serious injury or death can occur

if safety measures or instructions on this label

are not properly followed.

Caution means serious equipment or other

property damage can occur if instructions on this

label are not properly followed.

2-1

Chapter 2

Standard Specifications

5531 SERIES GRAIN DRILL

MODEL

NUMBER

WORKING

WIDTH

ROW

SPACING

NO. OF

OPENERS

TRANSPORT

WIDTH

TIRE AND

WHEELS

ESTIMATED

WEIGHT (LBS.)

5531-30X7.5 30’-0” 7-1/2” 48 14’-6” (4) 380/55R 16.5

(frame)

(4) 11L -15,

12 ply - 6 bolt (wing)

18,450

5531-30X10 30’-0” 10” 36 14’-6” 17,010

5531-40X7.5 40’-0” 7-1/2” 64 14’-6” 24,560

5531-40X10 40’-0” 10” 48 14’-6” 22,640

Specifications are subject to change without prior notification.

5531 SERIES GRAIN DRILL W/ FERTILIZER

MODEL

NUMBER

WORKING

WIDTH

ROW

SPACING

NO. OF

OPENERS

TRANSPORT

WIDTH

TIRE AND

WHEELS

ESTIMATED

WEIGHT (LBS.)

5531-30X7.5 30’-0” 7-1/2” 48 14’-6” (4) 380/55R 16.5

(frame)

(4) 11L -15,

12 ply - 6 bolt (wing)

18,990

5531-30X10 30’-0” 10” 36 14’-6” 17,500

5531-40X7.5 40’-0” 7-1/2” 64 14’-6” 24,560

5531-40X10 40’-0” 10” 48 14’-6” 22,560

Specifications are subject to change without prior notification.

5531 SERIES GRAIN DRILL W/ SMALL GRASS SEED

MODEL

NUMBER

WORKING

WIDTH

ROW

SPACING

NO. OF

OPENERS

TRANSPORT

WIDTH

TIRE AND

WHEELS

ESTIMATED

WEIGHT (LBS.)

5531-30X7.5 30’-0” 7-1/2” 48 15’-6” (4) 380/55R 16.5

(frame)

(4) 11L -15,

12 ply - 6 bolt (wing)

18,990

5531-40X7.5 40’-0” 7-1/2” 64 15’-6” 24,560

Specifications are subject to change without prior notification.

2-2 F-716-1213 Edition

STANDARD SPECIFICATIONS

TIRE INFLATION

TIRE

SIZE

TIRE

MANUFACTURER

PLY/LOAD

RATING

INFLATION PRESSURE

(psi) (max.)

380/55R 16.5 Goodyear 150A8/B 7400 lbs. @30

mph

74 psi

380/60R 16.5 Goodyear 150A8/B 7400 lbs. @30

mph

73 psi

11L x 15 Goodyear 12 Ply/3860 lbs 52 psi

STANDARD SPECIFICATIONS

2-3

Table 2-1: General Torque Specifications

LANDOLL CORPORATION

GENERAL TORQUE SPECIFICATIONS (REV. 4/97)

THIS CHART PROVIDES TIGHTENING TORQUES FOR GENERAL PURPOSE APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS

OR DRAWING.

ASSEMBLY TORQUES APPLY TO PLATED NUTS AND CAPSCREWS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS RECEIVED CONDITION). THEY

DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.

WHEN FASTENERS ARE DRY (SOLVENT CLEANED), ADD 33% TO AS RECEIVED CONDITION TORQUE.

BOLT HEAD IDENTIFICATION MARKS INDICATE GRADE AND MAY VARY FROM MANUFACTURER TO MANUFACTURER.

THICK NUTS MUST BE USED ON GRADE 8 CAPSCREWS.

USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.

TORQUE IS SPECIFIED IN FOOT POUNDS

UNC

Size

SAE Grade

UNF

Size

SAE Grade

1/4-20 4 [5] 6 [7] 9 [11] 1/4-28 5 [6] 7 [9] 10 [12]

5/16-18 8 [10] 13 [16] 18 [22] 5/16-24 9 [11] 14 [17] 20 [25]

3/8-16 15 [19] 23 [29] 35 [43] 3/8-24 17 [21] 25 [31] 35 [44]

7/16-14 24 [30] 35 [43] 55 [62] 7/16-20 27 [34] 40 [50] 60 [75]

1/2-13 35 [43] 55 [62] 80 [100] 1/2-20 40 [50] 65 [81] 90 [112]

9/16-12 55 [62] 80 [100] 110 [137] 9/16-18 60 [75] 90 [112] 130 [162]

5/8-11 75 [94] 110 [137] 170 [212] 5/8-18 85 [106] 130 [162] 180 [225]

3/4-10 130 [162] 200 [250] 280 [350] 3/4-16 150 [188] 220 [275] 320 [400]

7/8-9 125 [156] 320 [400] 460 [575] 7/8-14 140 [175] 360 [450] 500 [625]

1-8 190 [237] 408 [506] 680 [850] 1-14 210 [263] 540 [675] 760 [950]

1-1/8-7 270 [337] 600 [750] 960 [1200] 1-1/8-12 300 [375] 660 [825] 1080 [1350]

1-1/4-7 380 [475] 840 [1050] 1426 [1782] 1-1/4-12 420 [525] 920 [1150] 1500 [1875]

1-3/8-6 490 [612] 110 [1375] 1780 [2225] 1-3/8-12 560 [700] 1260 [1575] 2010 [2512]

1-1/2-6 650 [812] 1460 [1825] 2360 [2950] 1-1/2-12 730 [912] 1640 [2050] 2660 [3325]

1-3/4-5 736 [920] 1651 [2063] 2678 [3347] 1-3/4-12 920 [1150] 2063 [2579] 3347 [4183]

METRIC

COARSE THREAD METRIC CLASS 10.9 FASTENERS AND CLASS 10.0 NUTS AND THROUGH HARDENED FLAT WASHERS, PHOSPHATE COATED, ROCKWELL

“C” 38-45.

USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.

Nominal

Thread

Diameter

Standard Torque Nominal

Thread

Diameter

Standard Torque

Newton-

Meters

Foot-

Pounds

Newton-

Meters

Foot-

Pounds

6 10 [14] 7 [10] 20 385 [450] 290 [335]

7 16 [22] 12 [16] 24 670 [775] 500 [625]

8 23 [32] 17 [24] 27 980 [1105] 730 [825]

10 46 [60] 34 [47] 30 1330 [1470] 990 [1090]

12 80 [101] 60 [75] 33 1790 [1950] 1340 [1450]

14 125 [155] 90 [115] 36 2325 [2515] 1730 [1870]

16 200 [240] 150 [180] 39 3010 [3210] 2240 [2380]

18 275 [330] 205 [245]

2-4 F-716-1213 Edition

STANDARD SPECIFICATIONS

Table 2-2: Hydraulic Fitting Torque Specifications

LANDOLL CORPORATION

HYDRAULIC FITTING TORQUE SPECIFICATIONS

37oJIC, ORS, & ORB (REV. 10/97)

THIS CHART PROVIDES TIGHTENING TORQUES FOR HYDRAULIC FITTING APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS

OR DRAWING.

ASSEMBLY TORQUES APPLY TO PLATED CARBON STEEL AND STAINLESS STEEL FITTINGS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS

RECEIVED CONDITION).THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.

BRASS FITTINGS AND ADAPTERS - 65% OF THE TORQUE VALUE FOR STEEL. STAINLESS STEEL, ALUMINUM AND MONEL - THREADS ARE TO BE

LUBRICATED.

TORQUE IS SPECIFIED IN FOOT POUNDS

PARKER BRAND FITTINGS

Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)

-4 11-13 15-17 13-15

-5 14-16 — 21-23

-6 20-22 34-36 25-29

-8 43-47 58-62 40-44

-10 55-65 100-110 57.5-62.5

-12 80-90 134-146 75-85

-16 115-125 202-218 109-121

-20 160-180 248-272 213-237

-24 185-215 303-327 238-262

-32 250-290 — 310-340

GATES BRAND FITTINGS

Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)

-4 10-11 10-12 14-16

-5 13-15 — —

-6 17-19 18-20 24-26

-8 34-38 32-40 37-44

-10 50-56 46-56 50-60

-12 70-78 65-80 75-83

-14 — 65-80 —

-16 94-104 92-105 111-125

-20 124-138 125-140 133-152

-24 156-173 150-180 156-184

-32 219-243 — —

AEROQUIP BRAND FITTINGS

Dash Size 37 Degree JIC O-Ring (ORS) O-Ring Boss (ORB)

-4 11-12 10-12 14-16

-5 15-16 — 18-20

-6 18-20 18-20 24-26

-8 38-42 32-35 50-60

-10 57-62 46-50 72-80

-12 79-87 65-70 125-135

-14 — — 160-180

-16 108-113 92-100 200-220

-20 127-133 125-140 210-280

-24 158-167 150-165 270-360

-32 245-258 — —

Tabla de contenidos

Otros manuales de Maquinaria agrícola de Landoll

Landoll

Landoll 2110 Manual de usuario

Landoll

Landoll Brillion SCP-51 Manual de usuario

Landoll

Landoll ICON 6510 Instrucciones de construcción

Landoll

Landoll 850 Series Manual del propietario

Landoll

Landoll Brillion PPD Series Manual del producto

Landoll

Landoll Brillion Alfalfa SS108 Manual de usuario

Landoll

Landoll 2211 Manual de usuario

Landoll

Landoll 1550 Series Manual de usuario

Landoll

Landoll 9650 Manual de usuario

Landoll

Landoll 2130 Manual de usuario

Landoll

Landoll 2110 Manual de usuario

Landoll

Landoll 9650FH Manual de usuario

Landoll

Landoll 876 Series Manual de usuario

Landoll

Landoll 8530 Manual de usuario

Landoll

Landoll 7430 Series Manual de usuario

Landoll

Landoll 1230 Series Manual de usuario

Landoll

Landoll Brillion X108 Manual de usuario

Landoll

Landoll Brillion BH1020 Manual de usuario

Landoll

Landoll 2132 Manual de usuario

Landoll

Landoll Brillion FPS-6 Manual de usuario

Landoll

Landoll Wing Tilloll 876 Series Manual de usuario

Landoll

Landoll 7812 Manual del producto

Landoll

Landoll 2210 Manual de usuario

Landoll

Landoll 3631-30 Manual de usuario

Manuales populares de Maquinaria agrícola de otras marcas

GSi

GSi PNEG-2314 Manual de usuario

Checchi & Magli

Checchi & Magli TEXDRIVE Manual de usuario

Amazone

Amazone Cenius 4003-2TX Manual de usuario

MASSEY FERGUSON

MASSEY FERGUSON MF 9313S Manual de usuario

Cima

Cima BLITZ Instrucciones de funcionamiento y mantenimiento

Amazone

Amazone CombiDisc 3000 Instrucciones de instalación

HE-VA

HE-VA Disc-Roller XL Contour Manual de usuario

AGT

AGT AGT-SSFM Manual de usuario

Milestone

Milestone 72-84 Manual de usuario

KUHN

KUHN Hector 3000 Manual de usuario

Krone

Krone X-Disc 6200 Manual de usuario

Eliet

Eliet DZC450 Manual de usuario

Taarup

Taarup BIO+ B4000 Manual de usuario

Garland

Garland SHAKER 310 DPG Manual de usuario

stable comfort

stable comfort StableWall System Manual de usuario

Raven

Raven AccuBoom Manual de usuario

International

International 710 Manual de usuario

Ashland

Ashland HDW-3217-14 Manual de usuario
