LaCie 301336U Manual de usuario

d2 Quadra

DESIGN BY NEIL POULTON

ENTERPRISE CLASS

eSATA 3Gb/s | FireWire 800 & 400 | USB 2.0

Professional Hard Disk

Enterprise Class Data Protection

The LaCie d2 Quadra Enterprise Class has been developed

and enhanced to keep your data and information safe and

secure. Featuring the option to implement government-

grade 128-bit AES hardware encryption, it’s perfect for

professionals that have sensitive or conﬁdential information

on their drive that needs to be kept safe. Set up a password

and make the LaCie d2 Quadra Enterprise Class a near-

vault, safeguarding against any unauthorized access!

The Enterprise Class Difference

The LaCie d2 Quadra Enterprise Class is the most complete

hard disk solution for professionals that need a powerful solution

to handle multiple tasks. Featuring a SATA Enterprise disk that

guarantees robust performance, the LaCie d2 Quadra Enterprise

Class offers optional 128-bit AES hardware encryption and comes

with 24K gold-plated cable contacts. It’s the perfect solution for

professionals that need ﬂexible and high speed storage.

Enterprise Class Performance

The 24K gold-plated contacts on the d2 Quadra Enterprise Class’s cables offer

accurate and fast signal transfer, giving you sophisticated performance and

capabilities. With fast burst transfer rates of up to 105-115MB/s* via eSATA, this

industry-leading hard disk delivers high speeds and provides up to 2TB capacity in

a relatively compact device. It comes with four interfaces—eSATA 3Gb/s, FireWire

800, FireWire 400, and USB 2.0—offering complete universal connectivity for PC

and Mac®users.

MEGABYTES PER SECOND

BURST READ TRANSFER RATE BENCHMARK*

PERFORMANCE COMPARISON

0306090120

FIREWIRE 400

FIREWIRE 800

eSATA 3Gb/s

USB 2.0

• Enterprise Class internal SATA disk

• Five years of Enterprise Class Service included

• 128-bit AES hardware encryption for optional data protection

• Aluminum fanless cooling design for quiet operation

• High-end cables with 24K gold-plated contacts

Advanced Power-Saving Design

The LaCie d2 Quadra Enterprise Class’s design is sturdy, compact and

versatile, making it ideal for intensive professional use. The unique, fanless

aluminum heat sink design with 60% more surface area for heat dissipation

keeps it quiet and as safe as possible at all times. Thanks to its Triple Power

Management System, it is able to switch into standby mode automatically—

reducing power consumption signiﬁcantly. In addition, the LaCie d2

Quadra Enterprise Class is RoHS-certiﬁed, meaning that LaCie has made a

commitment to producing technology that’s better for our planet.

Enterprise Disk

The internal Enterprise Class disk included with the d2 Quadra

Enterprise Class comes with our ﬁve-year Enterprise Class Service

guarantee. This high-quality internal disk features 32MB cache

memory and 7200RPM, and targets an ambitious 1.2 million hours

MTBF (Mean Time Before Failure). Enterprise Class disks have been

developed with rotational vibration resistance technology, helping

them to be even more reliable and robust in a RAID tower or

rackmounted conﬁguration.

Backup, Restore, and Recover

The LaCie d2 Quadra Enterprise Class comes with Genie Backup Manager

ProTM for Windows®and Intego Backup Manager ProTM for Mac. This

software lets you to reliably and efﬁciently back up your documents, emails,

settings, or other digital assets. With its ease of use, you can either program

the LaCie Shortcut Button using the LaCie Desktop Manager to launch a

backup with one push, or schedule and customize the type of backup you

create. Ideal for creative professionals, the Genie and Intego programs

can easily ﬁnd previous versions of your documents and restore them.

With a computer recovery option, professionals will be able to restore their

conﬁguration and to go right back to work in the event of a disaster with

their workstation. It’s easy to back up directly from your Mac with the native

solution, since the LaCie d2 Quadra Enterprise Class is compatible with

Time Machine®.

1TB**

=2 hours of uncompressed HD video or 70 hours of DVD or 77,500 RAW photos***

Heat Sink

Design

Standard

Design

Apple® Time Machine and Leopard Compatible

The LaCie d2 Quadra Enterprise Class is compatible with Mac OS X v10.5 Leopard, including Time Machine, making it an ideal

partner for your Mac. Time Machine automatically backs up your Mac’s system ﬁles, applications, accounts, preferences, music,

photos, movies, and documents to an external hard drive and you can easily go back in time to recover anything.

Features

• eSATA 3Gb/s, FireWire 800, FireWire 400, and USB 2.0

• Superior heat dissipation

• Triple (Auto/On/Off) power management

• AES 128-bit hardware encryption

• Daisy-chainable (FireWire)

• Plug & play

• LaCie Desktop Manager

• Advanced backup software

Box Content

• LaCie d2 Quadra Enterprise Class

• eSATA-to-eSATA (3Gb/s) cable with 24k gold-plated contacts

• USB 2.0 cable with 24k gold-plated contacts

(compatible with USB 1.1)

• FireWire 400 to FireWire 400 (6-to-6 pin) cable with

24k gold-plated contacts

• FireWire 800 to FireWire 800 (9-to-9 pin) cable with

24k gold-plated contacts

• Quick Install Guide

• LaCie Utilities and User Manual

• LaCie Desktop Manager

• Genie Backup Manager Pro software with computer

recovery option for Windows XP, Windows Vista, Windows 7

• Intego Backup Manager Pro software with computer

recovery option for Mac OS X 10.5, 10.6

Minimum System Requirements

• Computer with an eSATA, FireWire 800, FireWire 400 or USB 2.0 port

• Latest version of Windows XP, Windows Vista®, Windows 7 /

Mac OS X 10.5, 10.6

• Minimum free disk space: 600MB recommended

Enterprise Class Service

Fully developed to be a reliable storage solution for professionals, the LaCie d2 Quadra Enterprise

Class features ﬁve years of Enterprise Class Service, which includes a ﬁve-year warranty , a ﬁve-year

Advance Care Option, and a ﬁve-year data recovery service option (data recovery available in Europe

only)▼. LaCie can only provide Enterprise Class Services in the country where the product has been

purchased and where there is a local LaCie subsidiary or ofﬁce. For more information on Enterprise

Service Class and term and conditions please visit www.lacie.com

LaCie d2 Quadra Enterprise Class

301336 301436

1TB 2TB

eSATA 3Gb/s, FireWire 800, FireWire 400, USB 2.0

eSATA 3Gb/s: up to 3Gb/s (300MB/s)

FireWire 800: up to 800Mbits/s (100MB/s)

FireWire 400: up to 400Mbits/s (50MB/s)

USB 2.0: up to 480Mbits/s (60MB/s)

With and Without Encryption:

eSATA 3Gb/s: up to 105-115MB/s

FireWire 800: up to 75-85MB/s

FireWire 400: up to 35-40MB/s

USB 2.0: up to 30-35MB/s

Without Encryption

eSATA 3Gb/s : 80-90MB/s

FireWire 800: 75-80MB/s

FireWire 400: 35-40 MB/s

USB 2.0: 30-35 MB/s

7200rpm / 32MB or greater

<10ms (eSATA)

Launch any application (backup, music, slideshows) with one push

Manages encryption to prevent unauthorized data access

“Auto” for energy efﬁciency; “On” for instant access; “Off” for data protection

60 x 168 x 183 mm / 2.3 x 6.6 x 7.2 in

1.7 kg / 3.7 lbs.

5-year

Item Number

Capacity**

Interface

Interface Transfer Rates

(maximum theoretical bus speed)

Read Burst Transfer Rates*

(maximum drive speed)

Read Average Transfer Rates*

(average drive speed)

Rotational Speed

Seek Time (Read)

LaCie Shortcut Button

LaCie Desktop Manager

Triple Power Management

Dimensions (WxDxH)

Weight

Warranty

LaCie d2 Quadra

Enterprise Class

LaCie 2big Quadra

Enterprise Class

LaCie 4big Quadra

Enterprise Class

With Encryption

eSATA 3Gb/s : 75-80MB/s

FireWire 800: 60-65MB/s

FireWire 400: 30-35 MB/s

USB 2.0: 30-35 MB/s

*Maximum interface transfer rate = theoretical bus bandwidth, whereas burst transfer rate = maximum drive speed. Burst and average transfer rates vary from one computer to another

and may vary slightly from one drive to another.

**1TB (Terabyte) = 1000GB. 1GB = 1000MB. 1MB = 1,000,000 Bytes. Total accessible capacity varies depending upon operating environment (typically 10% less).

***Calculations are based on 1080i 60 (8-bit) for uncompressed HD video, NTSC DV 25 standard-denition 720x486, 29.97 fps for digital video; and an estimation of Digital SLR

resolution of 10 megapixels for RAW photos of 12MB. These calculations are only estimations and may vary with the codec used.

▼ For conﬁdential and technical reasons LaCie will not recover data from an encrypted drive.

Speciﬁcations and appearance are given as guidelines and may change without notice. www.lacie.com

100128v1
