KYOCERA MITA AUSTRALIA PTY LTD

ABN: 77 003 852 444

SPECIFICATION GUIDES FOR:

•PANEL 1 PHOTOCOPIER MULTIFUNCTIONAL DEVICES

AND ASSOCIATED CONSUMABLES

•PANEL 3 PRINTERS AND ASSOCIATED CONSUMABLES

•PANEL 4 FACSIMILE AND ASSOCIATED

CONSUMABLES

TABLE OF CONTENTS

PANEL 1 PHOTOCOPIER MULTIFUNCTIONAL DEVICES AND ASSOCIATED

CONSUMABLES............................................................................................................ 3

FS1028MFP......................................................................................................... 3

FS1118MFP......................................................................................................... 5

FS1128MFP......................................................................................................... 7

FSC1020MFP ...................................................................................................... 9

TASKALFA 180.................................................................................................. 11

TASKALFA 181.................................................................................................. 12

TASKALFA 221.................................................................................................. 14

KM-2560............................................................................................................. 16

KM-3060............................................................................................................. 18

CUA 25307

BUSINESS MACHINES

AND

BUSINESS MACHINES CONSUMABLES

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 2 - LAST UPDATED: 1st FEBRUARY 2010

KM-4050............................................................................................................. 20

KM-5050............................................................................................................. 22

TASKALFA 620.................................................................................................. 24

TASKALFA 820.................................................................................................. 26

TASKALFA 250ci............................................................................................... 28

TASKALFA 300ci............................................................................................... 30

TASKALFA 400ci............................................................................................... 32

TASKALFA 500ci............................................................................................... 34

TASKALFA 552ci............................................................................................... 36

PANEL 3 PRINTERS AND ASSOCIATED CONSUMABLES...................................... 38

FS1100N............................................................................................................ 38

FS1300DN ......................................................................................................... 39

FS1350DN ......................................................................................................... 40

FS2020DN ......................................................................................................... 41

FS3920DN ......................................................................................................... 42

FS4020DN ......................................................................................................... 43

FS6970DN ......................................................................................................... 44

FS9530DN ......................................................................................................... 45

FSC5100DN....................................................................................................... 46

FSC5200DN....................................................................................................... 47

FSC5300DN....................................................................................................... 48

FSC5350DN....................................................................................................... 49

FSC5400DN....................................................................................................... 50

FSC8100DN+..................................................................................................... 51

FSC8500DN....................................................................................................... 52

PANEL 4 FACSIMILE AND ASSOCIATED CONSUMABLES .................................... 53

FS1118MFP...................................................................................................... 53

FS1128MFP...................................................................................................... 54

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 3 - LAST UPDATED: 1st FEBRUARY 2010

PANEL 1 PHOTOCOPIER MULTIFUNCTIONAL DEVICES AND

ASSOCIATED CONSUMABLES

FS1028MFP

GENERAL SPECIFICATIONS

Function Description

Copy Speed 28 cpm

Duplex Standard Duplex (built in) – 60 – 105 gsm

Paper Capacity 250 Sheet Universal Cassette, (Upgradeable to 800

Sheets)

50 Sheet Multipurpose Tray

Document Processor 50 Sheet Reverse Automatic Document Processor

Warm Up Time Approx 15 seconds or less

Time to First Copy Approx 6 seconds or less

Output Capacity 150 Sheets Facedown

Dimensions (W x D x H) 494mm x 430mm x 448mm

Memory 256MB RAM, upgradeable to 768MB RAM

Maximum Original Size A4 / Letter

Continuous Copying 1 – 999 pages

Zoom Range 25 – 400% in 1% increments

Image Mode – Copy Text, photo, text/photo, Auto, Manual

PRINT SPECIFICATIONS

Print Speed 28ppm

Time to first print Approx 6 seconds or less

Standard Interface USB 2.0, USB Host Interface for USB flash memory

device

Emulations PCL6, KPDL 3

Operating Systems All current Windows operating systems, MAC OS 9.X

Print Features PDF direct print, toner save mode

SCAN SPECIFICATIONS

Functionality Scan to email, Scan to FTP, Scan to USB Host

Scan Speed 35 ipm (b/w), 14 ipm (colour) at 300 dpi, A4

Scan Resolution 600, 400, 300, 200 dpi

File Types TIFF, PD, JPEG, XPS

Original Recognition Text, photo, text/photo OCR

A4 Duplex Printer, Copier, Colour Scanner (3-in-1 model)

28ppm Monochrome Multifunction

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 4 - LAST UPDATED: 1st FEBRUARY 2010

e-FILING SPECIFICATION

OPTIONS

Paper Capacity Addition 250 Sheet Cassette (max 2)

Memory Additional 512MB

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 5 - LAST UPDATED: 1st FEBRUARY 2010

FS1118MFP

GENERAL SPECIFICATIONS

Function Description

LCD Display 5 line LCD Display Panel

Copy Speed 18 cpm

Paper Capacity 250 Sheet Universal Cassette, (Upgradeable to 550

Sheets)

50 Sheet Multipurpose Tray

Document Processor 50 Sheet Standard Document Feeder

Warm Up Time Approx 20 seconds or less

Time to First Copy Approx 9.5 seconds or less

Output Capacity 150 Sheets Facedown

Dimensions (W x D x H) 496mm x 421mm x 385mm

Memory 96MB RAM, upgradeable to 320MB RAM

Maximum Original Size A4 / Letter

Continuous Copying 1 – 999 pages

Zoom Range 50 - 200% in 1% increments

Image Mode – Copy Text, photo, text/photo, Auto, Manual

PRINT SPECIFICATIONS

Print Speed 18ppm

Time to first print Approx 8 seconds or less

Standard Interface USB 2.0,

Emulations PCL6, KPDL 3

Operating Systems

Print Features PDF direct print, toner save mode

SCAN SPECIFICATIONS

Functionality Scan to email, Scan to FTP, Scan to USB Host

Scan Speed 35 ipm (b/w), 14 ipm (colour) at 300 dpi, A4

Scan Resolution 600, 400, 300, 200 dpi

File Types TIFF, PD, JPEG, XPS

Original Recognition Text, photo, text/photo OCR

Copy Speed 18 cpm

Duplex Standard Duplex (built in)

Paper Capacity

50 Sheet Multipurpose Tray , 60 – 200 gsm, paper size:

70 x 148 to 216 x 356mm

Document Processor Standard Document Feeder

Warm Up Time Approx 15 seconds or less

Time to First Copy Approx 6 seconds or less

A4 Printer, Copier, Colour Scanner (3-in-1 model)

18ppm Monochrome Multifunction with optional fax

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 6 - LAST UPDATED: 1st FEBRUARY 2010

Output Capacity 150 Sheets Facedown

Dimensions (W x D x H) 494mm x 430mm x 448mm

Memory 96MB RAM, upgradeable to 320MB RAM

Maximum Original Size A4 / Letter

Continuous Copying 1 – 999 pages

Zoom Range 50 - 200% in 1% increments

Image Mode – Copy Text, photo, text/photo, Auto, Manual

FAX SPECIFICATIONS (Optional)

Modem Speed Max 33.6 kbps

Transmission Speed 3 seconds or less

Scanning Speed 2.5 seconds

Maximum Original Size A4, Folio

Memory Standard 6MB

OPTIONS

Paper Capacity Additional 250 Sheet Cassette (1 only)

Memory Additional 64MB or 256MB

Fax Card Fax System

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 7 - LAST UPDATED: 1st FEBRUARY 2010

FS1128MFP

GENERAL SPECIFICATIONS

Function Description

Copy Speed 28 cpm

Duplex Standard Duplex (built in)

Paper Capacity 250 Sheet Universal Cassette, (Upgradeable to 800

Sheets)

50 Sheet Multipurpose Tray ,

Document Processor 50 Sheet Reverse Automatic Document Processor

Warm Up Time Approx 15 seconds or less

Time to First Copy Approx 6 seconds or less

Output Capacity 150 Sheets Facedown

Dimensions (W x D x H) 494mm x 430mm x 448mm

Memory 256MB RAM, upgradeable to 768MB RAM

Maximum Original Size A4 / Letter

Continuous Copying 1 – 999 pages

Zoom Range 25 – 400% in 1% increments

Image Mode – Copy Text, photo, text/photo, Auto, Manual

PRINT SPECIFICATIONS

Print Speed 28ppm

Time to first print Approx 6 seconds or less

Standard Interface USB 2.0, USB Host Interface for USB flash memory

device

Emulations PCL6, KPDL 3

Operating Systems All current Windows operating systems, MAC OS 9.X

Print Features PDF direct print, toner save mode

SCAN SPECIFICATIONS

Functionality Scan to email, Scan to FTP, Scan to USB Host

Scan Speed 35 ipm (b/w), 14 ipm (colour) at 300 dpi, A4

Scan Resolution 600, 400, 300, 200 dpi

File Types TIFF, PD, JPEG, XPS

Original Recognition Text, photo, text/photo OCR

FAX SPECIFICATIONS

Compatibility Super G3

Modem Max 33.6 kbps

One Touch Dial 22 Numbers

Address Book 100 entries

Scanning Speed 2.5 seconds

Maximum Original Size A4, Legal

A4 Duplex Printer, Copier, Colour Scanner, Fax

(4-in-1 model)

28ppm Monochrome Multifunction

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 8 - LAST UPDATED: 1st FEBRUARY 2010

Fax Memory Capacity 256 Sheets

Features Network faxing, duplex reception

e-FILING SPECIFICATION

OPTIONS

Paper Capacity Addition 250 Sheet Cassette (max 2)

Memory Additional 512MB

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 9 - LAST UPDATED: 1st FEBRUARY 2010

FSC1020MFP

GENERAL SPECIFICATIONS

Function Description

Memory 128MB, upgradeable to 384MB

Copy Speed 20ppm

Warm Up Time Approx 10 seconds from ECO mode, 48 seconds from

power on

First Copy Out Approx 30 seconds or less

Continuous Copy 1 – 99 pages

Image Adjustments Text, Photo, Text/Photo

Zoom Range 25 – 400% in 1% increments

Features Electronic sort,

Paper Handling 250 Sheet Universal Cassette, A4, Legal and Letter,

Single Sheet Multipurpose tray

Document Processor 35 Sheet Automatic Document Feeder

Duplex Standard Duplex

Dimensions (W x D x H) 420mm x 493mm x 476mm

PRINT SPECIFICATIONS

Standard Interfaces USB 2.0, Ethernet 10/100 Base

Operating Systems Windows 2000/XP/Server 2003/Vista/Server 2008, Mac

OS X V10.2.8 or later

Emulations PostScript 3, PCL 6/5c

Time to First Print 14 seconds

Features Toner save mode, password print, greyscale print,

duplex print sort

SCAN SPECIFICATIONS

Functionality Scan-to-email, scan-to-FTP, scan-to-SMB, TWAIN

Scan Speed Mono – 5 seconds or less, Colour – 10 seconds or less

Scan Resolution 1200 x 1200 dpi

Max Scan Size A4

File Types PDF, JPEF (Colour Only), TIFF (B/W Only)

FAX SPECIFICATIONS

Compatibility ITU-T Super G3

Modem Speed Max 33.6 kbps

Transmission Speed Less than 4 seconds

Max Original Size A4, Folio

Memory Reception Up to 100 pages

A4 Duplex Printer, Copier, Colour Scanner, Fax

(4-in-model)

20ppm Colour Multifunction

CUA 25307 BUSINESS MACHINES AND BUSINESS MACHINES CONSUMABLES KYOCERA

- 10 - LAST UPDATED: 1st FEBRUARY 2010

Address Book 50 Entries

Quick Dial 20 Entries

Features Manual reception, pc fax (send only on Windows), one

touch dial, out of paper reception

e-FILING SPECIFICATION

OPTIONS

Paper Capacity Additional 500 Sheet Paper Cassette (1 only)

Memory Additional 256MB

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Kyocera

Kyocera

Kyocera TASKalfa 4501i Manual de usuario

Kyocera

Kyocera Jogger 4200 Manual de usuario

Kyocera

Kyocera TASKalfa 8000i Manual de usuario

Kyocera

Kyocera FS-3040MFP Manual de usuario

Kyocera

Kyocera TASKalfa 650c Instrucciones originales

Kyocera

Kyocera KM-C2520 Guía de configuración

Kyocera

Kyocera TASKalfa 220 Manual de usuario

Kyocera

Kyocera FS-1116MFP Manual de usuario

Kyocera

Kyocera TASKalfa 250ci Manual de usuario

Kyocera

Kyocera TASKalfa 3500i Manual de usuario

Kyocera

Kyocera Ecosys M2735dn Manual de usuario

Kyocera

Kyocera TASKalfa 255 Manual de instalación y funcionamiento

Kyocera

Kyocera FS-2100DN Manual de usuario

Kyocera

Kyocera ECOSYS FS-6525MFP Manual

Kyocera

Kyocera ECOSYS M2040dn/KL3 Manual de usuario

Kyocera

Kyocera KM-1500 Manual de instalación

Kyocera

Kyocera FS-1028MFP DP Manual de usuario

Kyocera

Kyocera FS-2100DN Manual de usuario

Kyocera

Kyocera ECOSYS M5526cdn Manual de usuario

Kyocera

Kyocera FS-2100DN Manual de usuario

Kyocera

Kyocera FS-9100DN - B/W Laser Printer Manual de usuario

Kyocera

Kyocera ECOSYS M5526cdn Manual de usuario

Kyocera

Kyocera TASKalfa 2551ci Manual de usuario

Kyocera

Kyocera FS-1018MFP Manual de usuario

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Sharp

Sharp MX-2310U Guía

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario
