PRODUCT GUIDE
PRODUCT GUIDE
INTRODUCTION
Introduction
“Good Things Come To Those Who Wait” Anonymous
What about “Great Things...”.
In 2001, Kyocera and Copystar launches the 2530 and 3530. These “clean sheet” design
MFPs quickly became the benchmark for all Copystar Products, and served notice to our com-
petition that the Copystar Brand and Kyocera Technology was a force to be reckoned with.
In 2003, our company continued the tradition with the CS-3035, CS-4035, and CS-5035,
redefining what the term “Workgroup Multifunctionals” could mean for your customers. With
strong features and options, and “Best in Class” drum yields and preventive maintenance, and
unsurpassed reliability, these impressive MFPs have been extremely successful for Copystar
and our valued Dealers.
Now, in 2006, we’ve has taken a bold step forward with three new Monochrome
Multifunctionals, the CS-5050, CS-4050 and CS-3050. Exciting new Workgroup MFPs that
expand the possibilities for your customers. Standard Network Printing. Standard Color
Scanning. An exciting new Color Touch Screen Interface. New features and options that
improve performance, exemplify ease of use in an imaging device, and provide the reliability
and durability that the market expects from the Copystar Brand.
“Great Things...” indeed. Here and now. The wait is over.
PRODUCT GUIDE
TABLE OF CONTENTS
Introduction
Product Positioning
Product Overview
Product Configuration
Product Comparison
Technology
New Features
Connectivity
Print
Scan
Copy
Fax
Document Box
Options
Solutions
Yields
Summary
Trademarks
PRODUCT GUIDE
PRODUCT POSITIONING
Copystar’s CS-5050, CS-4050 and CS-3050 Multifunctional Products combine standard net-
work printing, advanced color scanning/sending and productive copying with the integrity and
reliability that have made Copystar Products a true market leader and innovator.
Designed for the busy Workgroup and Department in any Enterprise, both large and small
businesses will discover that these innovative new MFPs provide the high performance, ease
of use, security and reliability necessary in today’s fast-paced environments.
Customers who are looking to improve overall productivity and business performance will find
the versatility and features of the CS-5050, CS-4050 and CS-3050 a strong addition to their
workflow. With fast printing and document processing, to advanced sending functions and
unique workflow solutions like iTag and KYOcapture, customers will be able to take advantage
of the best that imaging technology has to offer. While the features and performance of the CS-
5050, CS-4050 and CS-3050 is comprehensive, simplicity is also a key factor. With an easy to
navigate Color Wide Touch Screen Interface, universal design, and Kyocera’s unique KX Driver
and networking tools and utilities, every user in the office will find the CS-5050,
CS-4050, and CS-3050 beneficial for all of their imaging needs.
Document confidentiality and data security are important in today’s global business, and the
new CS-5050, CS-4050 and CS-3050 provide advanced security solutions for Print, Scan,
Copy and Fax data, controlled by your corporate infrastructure. From Encryption and Data
Overwrite technology, to secure printing and document delivery, and Network Authentication,
Kyocera provides serious security for companies that have this requirement.
Kyocera’s benchmarks with reliability have been recognized throughout the industry as leading
the market, time and time again. The new CS-5050, CS-4050 and CS-3050 uphold the tradi-
tion, with reliability as one of the foundations of these new MFPs. With high maximum monthly
page volumes, long life Amorphous Silicon Drums and the longest Preventive Maintenance
Intervals in their class, the Copystar CS-5050, CS-4050 and CS-3050 Multifunctionals provide
a strong solution for today’s business.
PRODUCT GUIDE
PRODUCT OVERVIEW
Technology
• Single Board Architecture
• Multi-Task Operation
• Single Laser Writing
• Amorphous Silicon (ASi) Drums
• Monocomponent Toner
• 600 dpi, 256 Levels of gray
• Fast 1200 Mode Print Resolution
• Scan Once Print Many
• Multi Send Functions
• Network Authentication
• Single Pass Scanning
• Standard Stackless Duplex
• Section 508 Compliant
• RoHS Compliant
Speeds
Memory Management
• Standard 512MB RAM
• Standard 40GB Multipurpose HDD
Holds approximately 140,000 pages
• Maximum 1GB RAM
via 168 Pin DIMMs
• Standard Compact Flash Slot (Type1)
Document Box
• Custom Box
• Job Box
• Media Box (USB Host Print)
• Fax Box (Requires Opt. Fax System)
Publishing
• Covers
• Booklet Mode (Print)
• Page Numbering
• Opt. Booklet Fold
• Continuous Scan/Job Build
Management Reports
• 1,000 Account Codes
• User/ Department Name
• Paper Size
• Integrates with KM-NET for Accounting
Productivity and Ease of Use
• Warmup of 30 seconds or less
• Fast FCOT-
5050/4050 - 3.5 sec
3050 - 3.9 sec.
• 50 SPM/OPM Monochrome
• 25 SPM/OPM Color
• Dual Scan, Single Pass Scanning
• APS/AMS/AE/AS
• Auto Start
• Job Interrupt
• Image Rotation
• 50 Job Programs (Copy/Send)
• Copy/Send Shortcuts
• Color Wide Touch Screen Interface
• Help/Animated Guidance
• Multiple Language Selection
• Memory Gauge
• Job Status
• 1-999 Copy Selection
• Job Finish Notice (Copy/Send)
Image Quality and Versatility
• Auto, Text, Photo, Mixed, ECO and Manual
• 5R/5E Fixed Ratios
• 25%-400% Zoom
5
5050 4050 3050
Letter 50 40 30
Letter R 31 27 22
Legal 26 23 20
Ledger 26 23 20
OPM (Mono/Color) 50/25 50/25 50/25
50/40/30 Page Per Minute Workgroup Multifunctionals with Standard Network Printing and
Color Scanning. Standard Stackless Duplex, 500 x 2 Sheet Paper Drawers and 200 Sheet MPT.
Standard 512MB RAM and 40GB Multipurpose HDD. Optional 100 Sheet Dual Scan Document
Processor.Optional Paper Handling and Advanced Finishing.Optional Data Security Kit.
Optional Fax/NW Fax. Optional iTag and KYOcapture Workflow Solutions.
PRODUCT GUIDE
PRODUCT OVERVIEW
• XY Zoom
• Up to 28 lb. Bond via Paper Drawers/Decks
• 110 lb. Index via MPT
• Positive/Negative Reverse
• Mirror Image
• Transparency Mode
• Image Combination
• Memo Mode
• Erase Modes
• Auto Centering
• Proof Copy
Paper Handling
• Optional 100 Sheet DSDP (DP-700)
• Standard 3-way 1,200 sheet paper supply
• 500 x 2 Drawers
• 200 Sheet Multi-purpose Tray
• Auto Tray Switching support
• Add paper while running.
• Standard Stackless Duplex:
• 1:2, 2:2, 2:1, Book:2
• Optional Paper Handling
• 3,000 Sheet Letter Deck
• 500 x 2 Sheet Paper Drawers
Finishing
• Optional 3,000 Sheet Multi Finisher (DF-710)
• 50 Sheet Multi-position Edge Staple
• Three position stapling
• Requires AK-700 Attachment Kit
• DF-710 Enhancement Options
• Optional Booklet Folder (BF-710)
• Folds up to 16 Sheets
• Saddle Stitch Booklets
• Letter/Legal/Ledger
• Optional 2/3 Hole Punch (PH-5A)
• Optional 5 Bin Multi Tray (MT-710)
• Optional Simple Finisher (DF-730)
• 30 Sheet Single Position Staple
• Optional Internal Finisher (DF-720)
• 30 Sheet Single Position Staple
Standard Network Print
• PowerPC750/ 600MHz Processor
• Shared Memory Resources
• Fast 1200 Mode
• PDL/Emulations: PRESCRIBE, PCL 6 (XL,
5e), KPDL3 (PS3), KCGL (HP-GL/2), Diablo
630, IBM ProPrinter X24, Epson LQ850,
Line Printer
• Font Support:
• 80 Outline Fonts for PCL XL/5e
• 136 Outline Fonts for KPDL
• 1 Bitmap Font
• Driver Support
• KX Driver for Windows®
• PPD for MAC
• PPD for Linux/UNIX
• Certified Uni Driver
• Windows® 64-bit Drivers
• Operating System Support
• Windows®
95/98/Me/NT4/2000/XP/2003
• Novell 3.x/4.x/5.x/6.x
• Mac OS 8.x/9.x/10.x
• UNIX
• Protocol: TCP/IP, IPX/SPX, AppleTalk,
NetBEUI
• Standard Interfaces
• 10/100BaseTX
• High Speed USB 2.0
• Parallel IEEE1284
• USB Host Interface (3)
• Expansion Slot
• Optional Fax System
• Web Interface: Kyocera Command Center
• Utilities: KM-NET Viewer, KM-NET for
Clients, KM-NET for Accounting, PDF Direct
Print, KX SpoolCenter
Standard Network Scan
• Color and Monochrome Scanner
• Resolution: 200,300,400,600 dpi
• Scan Speed:
• 50 OPM - Monochrome
• 25 OPM - Color
• File Format:
• Monochrome - PDF, TIFF
• Color - PDF, JPG
6
PRODUCT GUIDE
PRODUCT OVERVIEW
• Scanning Features
• Scan to e-Mail
• Standard LDAP on board
• Scan to Folder (via SMB)
• Scan to FTP
• TWAIN
• Protocol: TCP/IP
• Driver: TWAIN (PC)
• Consolidated Address Book
• Web Interface: Kyocera Command Center
Optional Fax System (M)
• Fax/Network Fax
• Super G3 Fax
• Quick Scan Speed: 1.2 seconds per page
• Transmission Speed: Less than 3 seconds
per page
• Modem Speed: 33.6 kbps w/ Auto Fallback
• Data Compression: JBIG, MMR, MR, MH
• Fax Memory: Shared Resource
• Driver: KM Fax Driver
• Consolidated Address Book
• Optional Fax Backup Kit (BU-10)
• Web Interface: Kyocera Command Center
Optional Data Security Kit (C)*
• Provides Security Overwrite and Encryption
• Automatic and Manual Deletion processes
• Copy, Print and Send Data
Optional UG-30 PDF Enhancement Kit
• PDF Compression
• PDF Encryption
• Supports up to 128bit encryption
Optional Workflow Solutions
• iTag
Document Management Solution
• KYOcapture
Document Capture Workflow Solution
Maintenance and Yields
• Monocomponent Technology
• 34K Toner Yield
• Amorphous Silicon Drum
• CS-5050/CS-4050 - 500K
• CS-3050 - 400K
• Preventive Maintenance Schedules
• CS-5050/CS-4050 - 500K
• CS-3050 - 400K
• Maximum Monthly Volume
• CS-5050 - 200K
• CS-4050 - 150K
• CS-3050 - 100K
Additional Information
• 23.6” W x 25.4” D x 29.3” H
• 188 lbs.
• 120V, 60Hz, 11.5A
7
*Data Security KIt (C) is under evaluation for Common Criteria (ISO 15408) Certification
PRODUCT GUIDE
QUICK REFERENCE
8
Spec 5050 4050 3050
Letter Speed 50 40 30
Legal Speed 26 23 20
Ledger Speed 26 23 20
OPM/SPM
(Mono/Color) 50/25
DP Type Dual Scan Document Processor (DSDP)
DP Capacity 100 Sheets
Std./Max. Paper
Capacity 1,200/4,200
FCOT 3.5 sec. 3.9 sec
Warmup 25 sec.
Memory 512MB RAM, 40GB HDD
CPU Speed 600MHz
Finisher Stack
Capacity
Main Tray (A) - 3,000 Sheets;
Sub Tray (B) - 200 Sheets; Sub Tray (C) - 50 Sheets
Staple Position and
Capacity
Three Positions - Top Left, Bottom Left, Left Side
50 Sheets - Letter, 30 Sheets - Legal, Ledger
Saddle Stitch and
Fold Up to 16 Sheets (40 Originals); Requires BF-710 Option
Hole Punch Optional 2 and 3 Holes
Toner Yield 34K
Drum Yield 500K 400K
PM Schedule 500K 400K
Max. Monthly
Volume 200K 150K 100K
PRODUCT GUIDE
PRODUCT CONFIGURATION
Option Description Item Code Related Option/Notes
DP-700 100 Sheet Dual Scan Document Processor 1203JX6KL0
PF-700 500 x 2 Universal Paper Drawers 1203J42US0
PF-750 3,000 Sheet Letter Deck 1205H02US0
DF-710 3,000 Sheet Multi Finisher 1203JY0UN0
DF-720 Internal Finisher 1203J30UN0
DF-730 1,000 Sheet Simple Finisher 1205H10UN0
AK-700 Attachment Kit 1703JY0U10 DF-710; DF-730
JS-700 Job Separator 1203KB0UN0 Cannot be installed w/ DF-720
BF-710 Booklet Folder 1203J10UN0 DF-710
PH-5A 2/3 Hole Punch Kit 1203KA2US0 DF-710
MT-710 7 Bin Mailbox 1203J20UN0 DF-710
Fax System (M) Fax/Network Fax System 1503KH2US0 Fax System (M)
BU-10 Fax Backup System 1703KJ0UN0
Data Security Kit (C) HDD Overwrite and Encryption Kit 1503KP0UN0
UG-30 PDF Enhancement Kit 1503KR0UN0
PRODUCT GUIDE
PRODUCT CONFIGURATION
Base Unit with Optional DP-700
Document Processor and PF-750
Large Capacity Tray
Base Unit with Optional DP-700
Document Processor, PF-700
Dual Paper Drawers and DF-730
Simple Finisher
Base Unit with Optional DP-700
Document Processor, PF-750
Large Capacity Tray and
DF-710 Multi Finisher
Base Unit with Optional DP-700
Document Processor, PF-750
Large Capacity Tray and DF-710
Multi Finisher equipped with
optional BF-710 Booklet Folder
and MT-710 Multi Tray Unit
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Impresora todo en uno de Kyocera
Kyocera
Kyocera TASKalfa 6550ci Manual de usuario
Kyocera
Kyocera ECOSYS M6026cdn Type B Manual de usuario
Kyocera
Kyocera FS-1028MFP DP Manual de usuario
Kyocera
Kyocera Ecosys M812cidn Manual de usuario
Kyocera
Kyocera TASKalfa 5500i Manual de usuario
Kyocera
Kyocera FS-3040MFP Manual de usuario
Kyocera
Kyocera FS-1116MFP Manual de usuario
Kyocera
Kyocera TASKalfa 250ci Manual de usuario
Kyocera
Kyocera KM-2560 Manual de usuario
Kyocera
Kyocera FS-1028MFP DP Manual de usuario
Kyocera
Kyocera ECOSYS FS-C8520MFP Manual de usuario
Kyocera
Kyocera TASKalfa 181 Manual de usuario
Kyocera
Kyocera KM-4050 Manual de usuario
Kyocera
Kyocera TASKalfa 250ci Manual de usuario
Kyocera
Kyocera 1102H03NL0 Manual de usuario
Kyocera
Kyocera ECOSYS FS-3640MFP Manual de usuario
Kyocera
Kyocera TASKalfa 650c Manual de usuario
Kyocera
Kyocera TASKalfa 2550ci Manual de usuario
Kyocera
Kyocera ECOSYS M2835dw Manual de usuario
Kyocera
Kyocera TASKalfa 255 Manual de instalación y funcionamiento
Manuales populares de Impresora todo en uno de otras marcas
Triumph Adler
Triumph Adler DC 2016 Manual
Epson
Epson WorkForce WF-2510 Guía del usuario
Epson
Epson Stylus Scan 2000 Manual de instalación y operación
Epson
Epson PictureMate Snap PM 240 Manual de instrucciones
Konica Minolta
Konica Minolta bizhub C35 Manual de usuario
Brother
Brother MFC-J430w Manual de usuario
