KT&C KNC-p3TR3XIR Guía del usuario

KNC-p3TR3XIR

KNC-p3TR4XIR

KNC-p3TR6XIR

3 Megapixel Plug & Play Capable

IP66 EXIR IP Turret Cameras

Quick Operation Guide

KNC-p3TR_XIR IP Turret Camera·Quick Operation Guide

Thank you for selecting this KT&C Omni IP Series product. For

additional information please refer to the complete User Guide for

this cameras series. End users should contact their KT&C Certified

Dealer for service. Certified Dealers can obtain support directly from

KT&C.

About This Guide

While KT&C makes every effort to insure the completeness and

accuracy of the information contained in this Guide, we are not

responsible for typographical errors or misprints. At the same time,

KT&C reserves the right to make changes to improve the performance

of our products at any time without notice, and so the specifications

and content of this document are subject to change without notice.

Every effort will be made to include updates in new versions of this

manual and/or online.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of this

product. UL has only tested for fire, shock or casualty hazards as

outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification

does not cover the performance or reliability of the security or

signaling aspects of this product. UL MAKES NO REPRESENTATIONS,

WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING

RELATED FUNCTIONS OF THIS PRODUCT.

KNC-p3TR_XIR IP Turret Camera·Quick Operation Guide

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in

a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own

expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized European

standards listed under the Low Voltage Directive 2006/95/EC, the

EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

KNC-p3TR_XIR IP Turret Camera·Quick Operation Guide

2012/19/EU (WEEE directive): Products marked with

this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information

see: www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this symbol,

which may include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery to your supplier

or to a designated collection point. For more information see:

www.recyclethis.info

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

Safety Instructions

These instructions are intended to ensure that the camera is installed

in a manner that avoids danger to persons or property loss.

These precautionary measures are divided into “Warnings” and

“Cautions”

Warnings: Serious injury or death may occur if any of the warnings

are neglected.

Cautions: Injury or equipment/property damage may occur if any of

the cautions are neglected.

Warnings

●In the use of the product, you must be in strict compliance with

the electrical safety regulations of the nation and region. Please

refer to technical specifications for detailed information.

●Input voltage should meet the requirements for both the SELV

(Safety Extra Low Voltage) and Limited Power Source for 12 VDC

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

according to the IEC60950-1 standard; or 802.3af PoE. Please

refer to technical specifications for detailed information.

●If connecting several devices to one power supply, to avoid any

overload that may cause over-heating or a fire hazard insure that

the power supply is adequate for the power load.

●Please make sure that all plugs are firmly connected to the

power sockets. When the product is mounted on wall or ceiling,

the device shall be firmly attached, taking into consideration any

wind, snow loading, or other factors. The mounting surface shall

be capable of supporting several times the base weight of the

camera.

●If smoke, unusual odors or noise come from the device, turn off

the power at once and unplug the power cable, and then

contact authorized service personnel.

Cautions

●Make sure the power supply voltage is correct before using the

camera.

●Do not drop the camera or subject it to physical shock.

●Do not touch lenses or sensor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and wipe gently.

If the camera will not be used for an extended period, please

protect the lens openings from damage and/or debris.

●Avoid aiming the camera at the sun or extremely bright light

sources. Blooming or smearing may occur in excessive light

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

(which is not a malfunction), and could compromise the

performance of the sensor.

●The sensor may be damaged if exposed to laser energy, so when

any laser equipment is in use, make sure that the sensor will not

be exposed to the laser beam.

●Do not place the camera in extremely hot or cold (see camera

specifications) locations. Do not exceed the rated environmental

(IP66) conditions. Do not expose the camera to high levels of

electromagnetic (RF) radiation.

●To avoid heat accumulation, good ventilation is required in the

operating environment.

●Keep the camera away from solvents while in use; exposure to

liquids should not exceed IP66 environmental conditions.

●During shipping, the camera shall be packed in its original

packing, or packing providing the equivalent protection.

●Improper use or replacement of any batteries (if so equipped)

may result in the hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the

instructions provided by the battery manufacturer.

●If the product does not function properly, Dealers please contact

KT&C; End Users please contact your KT&C Certified Dealer or an

authorized service center. Do not disassemble the camera for

repair or maintenance by yourself. (KT&C shall not assume any

responsibility for problems caused by unauthorized repair or

maintenance.)

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

Table of Contents

1 Appearance and Description .......................................................... 8

2 Installation.................................................................................... 10

3 Setting the Network Camera over the LAN ......Error! Bookmark not

defined.

4 Accessing via Web Browser ................ Error! Bookmark not defined.

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

1Appearance and Description

Figure 1-1 Overview

Table 1-1 Description

NO.

Description

10M/100M self-adaptive Ethernet interface

Power Cable

Trim Ring

KNC-p3TR_XIR IP Turret Camera ·Quick Operation Guide

NO.

Description

Lens

IR LED

Enclosure

Dome Drive

Please make sure that the power adapter is compatible with the

camera. This series of camera supports Power over Ethernet (PoE),

and the standard power supply is 12 VDC.
