Kramer VS-801USB Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-801USB

8x1 USB Switcher

P/N: 2900-300030 Rev 2

VS-801USB – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

3.1 Defining the VS-801USB 8x1 USB Switcher 4

4Connecting the VS-801USB 6

4.1 Connecting to the VS-801USB via RS-232 7

4.2 Connecting to the VS-801USB via the ETHERNET 7

5Operating the VS-801USB 10

5.1 The Front Panel Buttons 10

5.2 The REMOTE Terminal Block Connector 10

5.3 The Application Software 10

6Firmware Upgrade 11

7Technical Specifications 12

8Default Communication Parameters 13

9Kramer Protocol 2000 14

10 Protocol 3000 16

10.1 Kramer Protocol 3000 Syntax 16

10.2 Kramer Protocol 3000 Commands 19

Figures

Figure 1: VS-801USB 8x1 USB Switcher 4

Figure 2: Connecting to the VS-801USB 7

Figure 3: Local Area Connection Properties Window 8

Figure 4: Internet Protocol (TCP/IP) Properties Window 9

Figure 5: Connecting the Contact Closure Remote Control PINs 10

VS-801USB - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP

5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP

7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer VS-801USB 8x1 USB Switcher,

which is ideal for educational institutions, presentation and display systems and

home theater applications.

2 VS-801USB - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Use Kramer high performance high resolution cables

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Position your Kramer VS-801USB away from moisture, excessive sunlight

and dust

Caution: No operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning: Disconnect the power and unplug the unit from the

wall before installing

VS-801USB - Overview 3

3 Overview

The Kramer VS-801USB is a high quality 8x1 USB switcher. It accepts up to eight USB

devices and switches the selected device to the host.

In particular, the VS-801USB features:

•Hi speed USB revision 2.0

•Eight DEVICE SELECT buttons

•Firmware upgrade via RS-232

•Remote control via the RS-232 port, the RC-IR3 IR remote control

transmitter, the Ethernet and/or remote contact closure

•An external 5V DC source, making it suitable for field operation

The VS-801USB is housed in a compact MegaTOOLS™ enclosure, enabling two

units to be rack mounted side-by-side in a 1U rack space using the optional

RK-T2B universal rack adapter.

4 VS-801USB - Overview

3.1 Defining the VS-801USB 8x1 USB Switcher

Figure 1: VS-801USB 8x1 USB Switcher

Feature

Function

1 HOST USB (type B) Port Connects to the host

2 DEVICE USB (type A) port Connects to a USB device (from 1 to 8)

3 REMOTE Switch Terminal

Block

Connect to contact closure switches for duplicating the

function of the front panel DEVICE SELECT buttons (see

Section 5.2)

4 ETHERNET RJ-45

Connector

Connect to a remote controller via a LAN (see Section

4.2)

5 RESET Button Reset to the Ethernet factory default values

6 5V DC +5V DC connector for powering the unit

7 IR Receiver Receives signals from the infrared remote control

transmitter

VS-801USB - Overview 5

Feature

Function

8 IR LED The yellow LED lights when receiving IR signals

9 RS-232 9-pin D-sub

Connector

Connects to a PC for firmware upgrade and control

10 PROG Push in for “Program” using a small screwdriver to

upgrade to the latest Kramer firmware via RS-232, or

release for “Normal” (the factory default)

11 DEVICE SELECT Buttons Select a device to switch to the host (from 1 to 8)

12 ON LED Illuminates green when receiving power

6 VS-801USB - Connecting the VS-801USB

4 Connecting the VS-801USB

Always switch off the power to each device before connecting it to your

VS-801USB. After connecting your VS-801USB, connect its power

and then switch on the power to each device.

To connect the VS-801USB as illustrated in the example in Figure 2:

1. Connect the USB devices (for example, hard drives and/or memory sticks)

to the DEVICE ports. For example, a:

Hard drive to port 1

Memory stick to port 4

Hard drive to port 6

Memory stick to port 8

2. Connect the HOST USB port to an acceptor (for example, a laptop).

3. If required, you can connect a PC and/or controller to the:

RS-232 terminal block (see Section 4.1)

Ethernet connector (see Section 4.2)

For best results it is advised to use high quality USB cables

4. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity (not shown in Figure 2).

VS-801USB - Connecting the VS-801USB 7

Figure 2: Connecting to the VS-801USB

4.1 Connecting to the VS-801USB via RS-232

You can connect to the VS-801USB via an RS-232 connection using, for example,

a PC. Note that a null-modem adapter/connection is not required.

To connect to the VS-801USB via RS-232, connect the RS-232 9-pin D-sub front

panel port on the VS-801USB unit via a 9-wire straight cable (only pin 2 to pin 2,

pin 3 to pin 3, and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub

port on your PC.

4.2 Connecting to the VS-801USB via the ETHERNET

You can connect to the VS-801USB via Ethernet using either of the following

methods:

•Direct connection to the PC using a crossover cable (see Section 4.2.1)

•Connection via a network hub, switch, or router, using a straight-through

cable (see Section 4.2.2)
