Kramer VP-311DVI Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VP-311DVI

Automatic DVI/Audio Switcher

P/N: 2900-000120 Rev 3

VP-311DVI – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Terminology Used in this User Manual 5

3.2 Defining the VP-311DVI Automatic DVI/Audio Switcher 6

4Connecting the VP-311DVI 7

4.1 Setting the DIP-switches 8

4.2 Connecting the Contact Closure Remote Control Pins 9

4.3 Connecting to the VP-311DVI via RS-232 10

4.4 Controlling via the ETHERNET 11

5Technical Specifications 15

Figures

Figure 1: VP-311DVI Automatic DVI/Audio Switcher 6

Figure 2: Connecting the VP-311DVI Automatic DVI/Audio Switcher 8

Figure 3: VP-311DVI DIP-switches 8

Figure 4: Connecting the Contact Closure Remote Control PINS 10

Figure 5: Crossed Cable RS-232 Connection 10

Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter 11

Figure 7: Local Area Connection Properties Window 12

Figure 8: Internet Protocol Version 4 Properties Window 13

Figure 9: Internet Protocol Version 6 Properties Window 13

Figure 10: Internet Protocol Properties Window 14

VP-311DVI - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VP-311DVI Automatic DVI/Audio

Switcher, which is ideal for the following typical applications:

Systems requiring automatic DVI routing

Presentation and multimedia applications

VP-311DVI - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VP-311DVI away from moisture, excessive sunlight

and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VP-311DVI - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VP-311DVI - Overview

3 Overview

The VP−311DVI is a high−performance switcher for DVI−D video, stereo and

S/PDIF audio signals. When configured as a standby switcher, the selected input

switches to the next highest priority input if the signal is interrupted.

The VP-311DVI features:

A maximum data rate of 4.95Gbps (1.65 Gbps per graphic channel)

HDTV compatibility

HDCP compliance

HDMI support for HDMI Compressed Audio Channels

Input/output - DVI−D signals (on DVI−I connectors)

Standby switching priority set with user−definable DIP−switches

The VP-311DVI switches any one of three DVI-D HDCP compliant sources to a

single display device, on DVI-I connectors with the corresponding:

Digital audio (S/PDIF) input signals switched to an S/PDIF output, on RCA

connectors or

Unbalanced stereo audio input signals on 3.5mm mini jack connectors

switched to an unbalanced stereo audio output on a 3.5mm mini jack

connector, as well as to a balanced stereo audio output on a 5-pin terminal

block connector

The VP-311DVI can operate either in the manual mode or in the auto mode:

In the manual mode, the VP-311DVI acts as a regular switcher, switching the

input video and audio signals to the output via the three front panel INPUT

SELECT buttons.

In the auto mode, you can switch any input to the output via the three front

panel INPUT SELECT buttons, but once the selected video signal is lost, the

machine automatically switches to the highest priorityinput, according to the

input priority setup. The VP-311DVI switches back to the primary input when

a DVI signal is detected on that input.

VP-311DVI - Overview

The VP-311DVI is housed in a desktop-sized enclosure and is 12V DC fed.

Control the VP-311DVI using the front panel buttons, or remotely via:

RS-232 serial commands transmitted by a touch screen system, PC, or other

serial controller

The Kramer infrared remote control transmitter

The ETHERNET

Remote control contact closure

3.1 Terminology Used in this User Manual

This table defines some terms that are used in this user manual.

Term

Definition

802.3

The standard specification for ETHERNET that is maintained by the

Institute of Electrical and Electronics Engineers (IEEE).

Dynamic Host

Configuration

Protocol (DHCP)

Allows the network administrator to distribute IP addresses from a

central point and automatically send a new IP address when an

Ethernet point is plugged into a different network location.

Gateway

A network position serving as an entry to another network. On the

Internet, a node or stopping point can be either a gateway node or a

host (end-point) node.

IP Address

A 32-binary digit number that identifies each sender or receiver

(within a network via a particular server or workstation) of data

(HTML pages or emails) that is sent in packets across the Internet.

Every device connected to an IP network must have a unique IP

address. This address is used to reference the specific unit.

Local Area Network

(LAN)

Computers sharing a common communications line or wireless link,

which often share a server within a defined geographic area.

Media Access

Control (MAC)

Address

A computer's unique hardware number (or address) in a LAN or

other network. On an Ethernet LAN, the (MAC) address is identical to

the Ethernet address.

Transmission

Control

Protocol/Internet

Protocol (TCP/IP)

The basic communication language or protocol of the Internet that

breaks the message into appropriately sized packets for the network,

and can be used as a communications protocol in an intranet or an

extranet.

VP-311DVI - Overview

3.2 Defining the VP-311DVI Automatic DVI/Audio Switcher

This section defines the VP-311DVI.

Figure 1: VP-311DVI Automatic DVI/Audio Switcher

Feature

Function

IR Receiver

The red LED lights when receiving signals from the

Infrared remote control transmitter

POWER Switch

Illuminated switch for turning the unit ON or OFF

INPUT SELECT Buttons

Press the INPUT button (from 1 to 3) to select the input to

switch to the output

AUDIO

LINE

BALANCED OUT

TerminalBlock

Connector

Connects the balanced stereo audio output to a balanced

stereo audio acceptor

OUT 3.5mm Mini

Jack

Connect to an unbalanced stereo audio output

IN 3.5mm Mini Jack

Connect to unbalanced stereo audio inputs (from 1 to 3)

S/PDIF

OUT RCA Connector

Connect to a digital audio (S/PDIF) output

IN RCA Connectors

Connect to digital audio (S/PDIF) inputs (from 1 to 3)

RS-232 9-pin D-sub Connector

Connect to the PC or the Remote Controller

PRIORITY SETUP DIP-switches

DIP-switches for setup of the machine: DIPs 1, 2, 3 are

for setting the signal priorities, DIP 4 is for setting to the

manual or the AUTO mode (see Section 4.1)

REMOTE Terminal Block

Connects to a dry contact switch (see Section 4.2)

OUT DVI-IConnector

Connect to the DVI acceptor

IN DVI-I Connectors

Connect to the DVI sources (from 1 to 3)

ETHERNET Connector

Connect to the PC or other Serial Controller through

computer networking

12V DC

+12V DC connector for powering the unit

VP-311DVI - Connecting the VP-311DVI

4 Connecting the VP-311DVI

Always switch off the power to each device before connecting it to your

VP-311DVI. After connecting your VP-311DVI, connect its power and

then switch on the power to each device.

To connect the VP-311DVI as illustrated in the example in Figure 2:

1. Connect a DVI source (for example, an HDCP-compliant DVD) to the IN 1

DVI connector and connect the digital audio input to the IN 1 S/PDIF RCA

connector.

You can also connect a DVD player with an HDMI (High Definition Multimedia Interface)

connector, using an HDMI-DVI adapter to transfer video signals.

2. Connect a DVI source (for example, a DVI computer graphics source) to the

IN 3 DVI connector and connect the digital audio input to the IN 3 3.5 mini-

jack connector.

Alternatively you can connect it to the 3.5mm mini jack connector.

3. Connect the OUT DVI connector to the DVI acceptor (for example, a

DVI/HDMI plasma display).

4. Connect the AUDIO OUT S/PDIF RCA connector and the AUDIO OUT 3.5

mini-jack connector to a digital audio acceptor (for example, an AV receiver).

If the inputs are connected only to the 3.5mm mini jack connectors, connect the AUDIO

OUT 3.5mm mini jack connector and/or the BALANCED OUT terminal block connector

only.

5. Set the PRIORITY SETUP DIP-switches (see Section 4.1)

6. If required, connect a PC and/or controller to the RS-232 port (see

Section 4.3) and/or the ETHERNET port (see Section 4.4).

7. If required, connect the contact closure remote control PINS (see

Section 4.2).

The connection is not illustrated in Figure 2.

8. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity.

Otros manuales para VP-311DVI

Tabla de contenidos

Otros manuales de Cambiar de Kramer

Kramer

Kramer VP-770 Manual de usuario

Kramer

Kramer VS-41DVI-R Manual de usuario

Kramer

Kramer VS-21HDCP Manual de usuario

Kramer

Kramer KDS-USB2 Kit Manual de usuario

Kramer

Kramer VP-440H2 Manual de usuario

Kramer

Kramer VM-114H4C Manual de usuario

Kramer

Kramer VP-740 ProScale Manual de usuario

Kramer

Kramer FC-46xl Manual de usuario

Kramer

Kramer VP-727A-BA Manual de usuario

Kramer

Kramer VP-727A Manual de usuario

Kramer

Kramer VP-81SIDN Manual de usuario

Kramer

Kramer VS-21B Manual de usuario

Kramer

Kramer DIP-31M Manual de usuario

Kramer

Kramer VP-23C Manual de usuario

Kramer

Kramer VP-725xl Manual de usuario

Kramer

Kramer VM-4HDxl Manual de usuario

Kramer

Kramer VS-311HDMI Manual de usuario

Kramer

Kramer VS-81HDxl Manual de usuario

Kramer

Kramer VS-81DVI-R Manual de usuario

Kramer

Kramer 6241HDx1 Manual de usuario

Kramer

Kramer TOOLS VP-211K Manual de usuario

Kramer

Kramer VP-41 Manual de usuario

Kramer

Kramer VS-211UHD Manual de usuario

Kramer

Kramer VS-21A Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
