Kramer SPK-WA511 Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

SPK-WA511

On-Wall Active Speakers

P/N: 2900-300112 Rev 3

This page is intentionally left blank

SPK-WA511 – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

4Defining the SPK-WA511 5

5Installing the Speakers 7

5.1 Choosing the Best Location 7

5.2 Installing the Speaker Wires 7

6Technical Specifications 9

Figures

Figure 1: Active On-Wall Speakers in a Home Theater Setup 4

Figure 2: Active On-Wall Speakers in a Conference Room Setup 4

Figure 3: SPK-WA511 Active Speaker 5

Figure 4: Connecting the Active Speaker to the Passive Speaker 7

This page is intentionally left blank

SPK-WA511 - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer SPK-WA511 On-Wall Active

Speakers, which are ideal for the following typical applications:

•Boardrooms •Presentation venues

•Conference rooms •Home theater

•Educational classrooms

The package includes one of each of the following items:

•A pair of SPK-WA511 Active Speakers

•An RCA cable (2 meters)

•A speaker cable for connecting the active speaker to the passive speaker (4

meters)

•An AC power cord (3 meters)

•A pair of U-shaped rotating mounting brackets with 4 mounting bracket

screws

•This user manual

2 SPK-WA511 - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance high-resolution cables

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (such as the Kramer BC-2S) to

avoid interference, deterioration in signal quality due to poor matching, and

elevated noise levels (often associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer SPK-WA511 away from moisture, excessive sunlight

and dust

To ensure that you obtain the best sound results, do not open the

housing of the passive speaker or the active speaker.

SPK-WA511 - Overview 3

3 Overview

The SPK-WA511 is a powered two-way speaker system designed for indoor wall

mounting. The system accepts a line level stereo input and amplifies it using a

built-in amplifier and outputs a speaker signal to the passive speaker.

The SPK-WA511 speaker system features:

•Three available inputs (that can either be connected separately or

connected simultaneously to form a mix of the inputs) that consist of:

A Line level unbalanced stereo audio input on a 3.5mm mini jack

connector

A balanced stereo audio input on a 5-pin terminal block connector

An unbalanced stereo audio input on two RCA connectors

•An output to external amplified or non-amplified speakers

•An output to an external sub-woofer

•A unique looping output, letting you chain additional pairs of active and

passive speakers

•TREBLE, BASS and VOLUME control knobs

•A control panel on the back of the active speaker that controls all the

functions of both speakers

•A magnetic shield

•Enhanced bass reflex design

•An integrated 2x30W stereo amplifier (no external amplifier required)

•A self adjusting power range of 90 to 240V AC

•Auto-power shutoff

The SPK-WA511 is enclosed in an ABS cabinet and can be mounted indoors on

the wall, vertically or horizontally. The mounting brackets are made of hardened

steel that attach to each speaker, letting you rotate each speaker to the left or

right.

4 SPK-WA511 - Overview

Figure 1and Figure 2show examples of how the speakers can be installed in

conference room and home theater setups, respectively.

Figure 1: Active On-Wall Speakers in a Home Theater Setup

Figure 2: Active On-Wall Speakers in a Conference Room Setup

SPK-WA511 - Defining the SPK-WA511 5

4 Defining the SPK-WA511

This section defines the active SPK-WA511:

Figure 3: SPK-WA511 Active Speaker

6 SPK-WA511 - Defining the SPK-WA511

Feature

Function

1 SPEAKER OUT Connectors Connect the active speaker to the (+) and (-)

stereo sockets on the passive speaker

The L speaker is active and the R speaker is

passive

2 INPUT

Connectors

5-pin Terminal Block

Connect the audio source to one or more of the

input connectors

3 3.5mm Mini Jack

4 L and R RCA

5 BASS Control Knob Rotate the button to control the bass

6 TREBLE Control Knob Rotate the button to control the treble

7 VOLUME Control knob Rotate the button to adjust the audio volume

8 AC-Input Power Supply (self

adjusting)

Connect to the AC power cord

9 POWER Switch For turning the unit ON (I), OFF (0) or AUTO

shutoff (II)

When selecting the AUTO shutoff mode, the

speaker enters the standby mode when idle

for over 10 minutes

10 POWER/STANDBY LED Illuminates in green when powered (POWER

switch set to ON or AUTO)

illuminates in red when in the standby mode

(POWER switch is set to AUTO)

In the AUTO mode, the LED illuminates green

if an input signal is detected and illuminates

red if idle for over 10 minutes

11 LOOP OUTPUT 3.5mm Mini Jack

Connector

Connect to another pair of active speakers

12 SUB OUT 3.5mm Mini Connector If required, connect an active sub-woofer to this

output for maximum bass reproduction
