Kramer KADS-100 Manual de usuario

PDF provided by Conference Room AV

Kramer KADS-1 Controllable Active Powered Wall Mounted 5.25" Speaker - Pair

P/N: 2900-300260 Rev 3 www.kramerAV.com

USER MANUAL

MODELS:

KADS-100 Master Audio Controller

KADS-1Speaker

KADS-2Speaker

KADS-100/KADS-1/KADS-2 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Using the IR Transmitter 5

4Defining the KADS-100, KADS-1 and KADS-2 6

4.1 Defining the KADS-100 Speaker 6

4.2 Defining the KADS-1 or a KADS-2 9

4.3 Defining the KADS-1 or a KADS-2 10

5Installing in a Rack 11

6Connecting the KADS-100, KADS-1 and KADS-2 12

6.1 Installing the Ferrite Rings 14

6.2 Connecting a Serial Controller 15

6.3 Wiring the RJ-45 Connectors 15

7Setting the Speaker ID 16

8Operating the KADS-100 17

8.1 Operating the KADS-100 Using the Front Panel Buttons 17

8.2 Operating the KADS-100 Using the Menu 21

8.3 Operating the KADS-100 Using the Web Pages 22

8.4 Operating the KADS-1 and KADS-2 Using the Remote Control 35

9Updating the KADS-1 or KADS-2 Firmware 36

10 Technical Specifications 37

10.1 Default IP Parameters 39

10.2 Default Logon Credentials 39

11 Protocol 3000 40

11.1 Kramer Protocol 3000 Syntax 40

11.2 Kramer Protocol 3000 Commands 43

Figures

Figure 1: KADS-100 Front Panel 7

Figure 2: KADS-100 Rear Panel 8

Figure 3: KADS-1 Rear Panel 9

Figure 4: KADS-2 Rear Panel 10

Figure 5: Connecting the KADS-100, KADS-1 and KADS-2 12

Figure 6: Looping the Cable through the Ferrite Ring 14

Figure 7: TP PINOUT 15

Figure 8: Setting the Rotary Switches 16

Figure 9: Entering Logon Credentials 23

Figure 10: The Default Page 23

Figure 11: The Switching Page 24

Figure 12: Channel Selection Example 26

Figure 13: Analog Input Selection Button 26

Figure 14: USB Input Selection Button 27

KADS-100/KADS-1/KADS-2 - Contents

Figure 15: Playlist Window 28

Figure 16: SPDIF Input Selection Button 29

Figure 17: Test Tone Selection Button 29

Figure 18: The Channel Settings Page 30

Figure 19: The Video and Audio Settings Page 31

Figure 20: The Microphone Settings Page 33

Figure 21: The Authentication Page—Security Disabled 34

Figure 22: The Authentication Page—Security Enabled 34

Figure 23: The About Us Page 35

KADS-100/KADS-1/KADS-2 – Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer KADS-100 Master Audio Controller,

KADS-1 Speaker and KADS-2 Speaker which are part of the Kramer Audio

Distribution System and are ideal for:

Small to large presentation and multimedia applications

Long-range audio distribution for schools, hospitals, stores, and security

applications

KADS-100/KADS-1/KADS-2 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerav.com/downloads/KADS-100 to check for up-to-

date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your KADS-100, KADS-1, and KADS-2 away from moisture,

excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the

wall before installing
