Kramer Galil 8-C Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

Galil 8-C (SPK-C802)

Closed-back Ceiling Speakers

P/N: 2900-300345 Rev 1

This page is intentionally left blank

Galil 8-C – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

4Your Galil 8-C Closed-back Ceiling Speakers 4

5Installing the Galil 8-C Closed-back Ceiling Speakers 6

5.1 Choosing the Best Location 6

5.2 Cutting the Ceiling Tile 6

5.3 Mounting the Speakers 7

5.4 Setting up an Array Installation 10

5.5 Painting the Speaker 13

6Technical Specifications 14

Figures

Figure 1: Galil 8-C in a Boardroom Setup 3

Figure 2: Galil 8-C Closed-back Ceiling Speaker 4

Figure 3: Galil 8-C Schematic Diagram 5

Figure 4: Mounting the Galil 8-C 8

Figure 5: Plugging and Securing the Cable 9

Figure 6: Tighten the Mounting Tabs 9

Figure 7: Adjust Tap Selector 10

Figure 8: Square Layout 11

Figure 9: Hexagonal Layout 11

Figure 10: Square Layout Parallel Wiring 12

Galil 8-C - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer Galil 8-C Closed-back Ceiling

Speakers, which are ideal for the following typical applications:

Hotel lobbies and conference rooms

Boardrooms and meeting rooms

Classrooms and lecture venues

Galil 8-C speakers are designed for indoor dry locations and are

suitable for use in air handling spaces (plenum spaces).

Galil 8-C - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer Speakers away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

Do not open the housing of the speaker; doing so may reduce the

quality of the sound.

Galil 8-C - Overview

3 Overview

The Galil 8-C consists of a pair of high performance closed back speakers.

Mount your Galil 8-C speakers to the ceiling in one of two ways: either directly

onto the ceiling or, for added protection, secure the speakers safely, using our

ceiling mounting kit that is provided free (see Section 5.3).

The Galil 8-C speakers feature a multi-tappowertransformerforselecting8Ω

(bypassing the transformer) or 70V/100V power settings that are suitable for an

array installation. Figure 1shows an example of how the Galil 8-C can be

installed in a boardroom setup:

Figure 1: Galil 8-C in a Boardroom Setup

Galil 8-C - Your Galil 8-C Closed-back Ceiling Speakers

4 Your Galil 8-C Closed-back Ceiling

Speakers

Figure 2 defines the Galil 8-C:

Figure 2: Galil 8-C Closed-back Ceiling Speaker

The following table defines the Galil 8-C hardware items (per speaker pair) for

each model in the series:

Description

A pair of

ceiling

speakers

(one shown)

Two grilles

(one shown)

Cutout

template

This table defines the ceiling mounting kit items:

Four

support

ring

screws

Two ceiling

support rings

(C-ring) –one

shown

Two pairs of

tile rails –

one of a pair

shown

Galil 8-C - Your Galil 8-C Closed-back Ceiling Speakers

Each Closed-back Ceiling speaker is supported by a C-ring and two tile rails. The tile

rails prevent the speakers from falling if the tile itself comes out or falls apart, as

their ends catch onto the T-grid. When mounting onto the ceiling tiles, use both

supports. When mounting onto a sheetrock ceiling, the C-ring alone is used to

reinforce the ceiling material.

Be sure that the tiles can support the speaker. Smaller sized tiles or

fiberglass-type tiles cannot support the weight of the speakers.

When this is the case, the speakers will need additional support.

Figure 3 shows a schematic diagram of the Galil 8-C:

Figure 3: Galil 8-C Schematic Diagram

Galil 8-C - Installing the Galil 8-C Closed-back Ceiling Speakers

5 Installing the Galil 8-C Closed-back Ceiling

Speakers

This section explains how to install the Galil 8-C, that is:

Choosing the best place to locate your speakers (see Section 5.1)

Cutting the ceiling tile (see Section 5.2)

Mounting the Speakers (see Section 5.3)

Setting up an Array Installation (see Section 5.4 )

Painting the speakers (see Section 5.5)

5.1 Choosing the Best Location

Ideally, locate the speakers above the main listening area. Before doing so, be

sure that:

The desired location is free of obstructions, such as electrical piping, AC

ducts or water lines, and so on

There is enough space behind the mounting surface for the speakers

The rear side of the speaker is not blocked by wall studs or other objects

5.2 Cutting the Ceiling Tile

To cut the ceiling tile, do the following:

1. Remove the circle in the supplied template.

Keep this template for later use as a mask, as you may want to paint the speakers (see

Section 5.5)

2. Mark the opening in the correct location by tracing the hole in the template.

3. Cut out the hole according to the template or with a circular cutter set to the

appropriate cutout size.

Initially, you can cut a smaller area inside the marked hole just to be sure that the

space above the speakers is clear
