Kramer TP-551HDCP Manual de usuario

Kramer Electronics, Ltd.

USER MANUAL

Models:

TP-551HDCP, DVI Line Transmitter

TP-552HDCP, DVI Line Receiver

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 1

3Overview 3

3.1 Recommendations for Achieving the Best Performance 3

4Your DVI Line Transmitter / Receiver 4

4.1 Your TP-551HDCP DVI Line Transmitter 4

4.2 Your TP-552HDCP DVI Line Receiver 5

5Connecting the TP-551HDCP and TP-552HDCP 6

5.1 Adjusting the EQ. Level via the EQ. Setup DIP-switches 6

5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 8

6Technical Specifications 9

Figures

Figure 1: TP-551HDCP DVI Line Transmitter 4

Figure 2: TP-552HDCP DVI Line Receiver 5

Figure 3: Connecting the TP-551HDCP / TP-552HDCP DVI Line Transmitter/Receiver 7

Figure 4: CAT 5 PINOUT 8

Tables

Table 1: TP-551HDCP DVI Line Transmitter Features 4

Table 2: TP-552HDCP DVI Line Receiver Features 5

Table 3: Recommended Equalization Levels DIP-switch Setup 6

Table 4: CAT 5 PINOUT 8

Table 5: Technical Specifications of the TP-551HDCP and TP-552HDCP 9

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups1

Congratulations on purchasing your Kramer DigiTOOLS® TP-551HDCP

DVI Line Transmitter and Kramer DigiTOOLS®TP-552HDCP DVI Line

Receiver which are ideal for:

that are clearly defined by function.

•Home theater, presentation and multimedia applications

•Rental and staging

The package includes the following:

•TP-551HDCP and/or TP-552HDCP

•Power adapter (5V DC Input)

•This user manual2

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables3

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan

Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack

Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer TP-551HDCP and TP-552HDCP constitute a high quality DVI

line transmitter / receiver system using two STP cables.

This transmitter / receiver pair features:

•System Range1

•Cables – For optimum range and performance, use Kramer's

BC-DGKat524, BC-DGKat623 and BC-DGKat7a23

- Up to 60m (197ft) at XGA, or up to 30m (98ft) at

WUXGA on shielded BC-DGKat524 cable; 60m (197ft) at SXGA on

shielded BC-DGKat623 cable; 60m (197ft) at SXGA on shielded

BC-DGKat7a23 cable

•Support for up to 1.65Gbps bandwidth

•The passing of the EDID and HPD2

•Support for the DDWG DVI 1.0 standard

signals from the source to the display

device using the cables

Note that only the digital signal (DVI-D) is available on the DVI connector.

The TP-551HDCP DVI Line Transmitter features:

•A DVI input and a pair of RJ-45 CAT 5 output connectors

•Three status LEDs (INPUT, OUTPUT and POWER)

The TP-552HDCP DVI Line Receiver features:

•A DVI output and a pair of RJ-45 CAT 5 input connectors

•Three status LEDs (INPUT, OUTPUT and POWER)

•EQ. adjustment to enhance performance

3.1 Recommendations for Achieving the Best Performance

To achieve the best performance:

•Connect only good quality connection STP CAT 5e 24AWG or STP

CAT 6 cables, thus avoiding interference, deterioration in signal quality

due to poor matching, and elevated noise-levels (often associated with low

quality cables)

•Avoid interference from neighboring electrical appliances and position your

TP-551HDCP/TP-552HDCP away from moisture, excessive sunlight and

dust

1 Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non-

Kramer CAT 5, CAT 6 and CAT 7a cables may not reach these ranges

2 Hot Plug Detect

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your DVI Line Transmitter / Receiver

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit1

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

4 Your DVI Line Transmitter / Receiver

This section describes the:

•TP-551HDCP DVI Line Transmitter, see section 4.1

•TP-552HDCP DVI Line Receiver, see section 4.2

4.1 Your TP-551HDCP DVI Line Transmitter

Figure 1and Table 1define the TP-551HDCP:

Figure 1: TP-551HDCP DVI Line Transmitter

Table 1: TP-551HDCP DVI Line Transmitter Features

Feature

Function

1 5V DC +5V DC connector for powering the unit

2 CAT 5 OUT RJ-45

Connector B Connect to the CAT 5 IN B RJ-45 connector on the TP-552HDCP

3 A Connect to the CAT 5 IN A RJ-45 connector on the TP-552HDCP

4 DVI IN Connector Connect to the DVI source

5 INPUT LED Lights when an input is connected

6 OUTPUT LED Lights when an output is detected

7 POWER LED Lights when receiving power

1 For example, part number 2535-052002

Your DVI Line Transmitter / Receiver

4.2 Your TP-552HDCP DVI Line Receiver

Figure 2and Table 2define the TP-552HDCP:

Figure 2: TP-552HDCP DVI Line Receiver

Table 2: TP-552HDCP DVI Line Receiver Features

Feature

Function

1 5V DC +5V DC connector for powering the unit

2 DVI OUT Connector Connect to the HDMI acceptor

3 CAT 5 IN RJ-45

Connector B Connect to the CAT 5 OUT B RJ-45 connector on the TP-551HDCP

4 A Connect to the CAT 5 OUT A RJ-45 connector on the TP-551HDCP

5 INPUT LED Lights when an input is detected

6 OUTPUT LED Lights when an output is connected

7 EQ. SETUP DIP-switches Adjust the cable compensation equalization level (see section 5.1)

8 POWER LED Lights when receiving power

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-551HDCP and TP-552HDCP

5 Connecting the TP-551HDCP and TP-552HDCP

You can use the TP-551HDCP DVI Line Transmitter with the TP-552HDCP

DVI Line Receiver to configure a DVI transmitter/receiver system.

To connect the TP-551HDCP to the TP-552HDCP, as illustrated in the

example in Figure 3, do the following:

1. Connect the CAT 5 OUT A and B RJ-45 connectors on the TP-551HDCP to

the CAT 5 IN A and B RJ-45 connectors on the TP-552HDCP, respectively,

via two STP CAT 5e 24AWG cables (see section 5.2).

2. On the TP-552HDCP, connect the DVI OUT connector to an acceptor (for

example, a display).

3. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity on both1

Figure 3the TP-551HDCP and the

TP-552HDCP (not shown in ).

4. On the TP-551HDCP, connect the source (for example, a computer graphics

source) to the DVI IN connector.

5. On the TP-552HDCP, adjust the equalization level (see section 5.1).

5.1 Adjusting the EQ. Level via the EQ. Setup DIP-switches

To adjust the EQ. level, set the DIP-switches according to the cable length2

Table 3, as

defined in :

Table 3: Recommended Equalization Levels DIP-switch Setup3

Distance [m]

DIP 1 DIP 2 DIP 3 DIP 4

Up to 50 OFF OFF ON ON

Up to 40 ON ON ON ON

Up to 30 OFF ON ON ON

1 The TP-551HDCP/TP-552HDCP does not include the Kramer power connect feature

2 The complete list of recommended Kramer cables is on our Web site at http://www.kramerelectronics.com

3 The optimum DIP-switch settings are dependent on the cable type and length, as well as the video resolution and

environment. The table shows the settings for typical installations using Kramer cabling at 1080p. Experimentation may be

necessary in a specific application, and any of 16 possible switch combinations may be applied

Connecting the TP-551HDCP and TP-552HDCP

Figure 3: Connecting the TP-551HDCP / TP-552HDCP DVI Line Transmitter/Receiver

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-551HDCP and TP-552HDCP

5.2 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors

Table 4and Figure 4define the STP CAT 5 PINOUT1

, using a straight pin-to-

pin cable with RJ-45 connectors (note, that the cable Ground shielding must

be connected / soldered to the connector shield):

Figure 4: CAT 5 PINOUT

7812 5

145 78

Shield

632

Table 4: CAT 5 PINOUT

EIA /TIA 568A EIA /TIA 568B

Wire Color

1 Green / White 1 Orange / White

2 Green 2 Orange

3 Orange / White 3 Green / White

4 Blue 4 Blue

5 Blue / White 5 Blue / White

6 Orange 6 Green

7 Brown / White 7 Brown / White

8 Brown 8 Brown

Pair 1 4 and 5 Pair 1 4 and 5

Pair 2 3 and 6 Pair 2 1 and 2

Pair 3 1 and 2 Pair 3 3 and 6

Pair 4 7 and 8 Pair 4 7 and 8

1 CAT 6 or similar (heavier gauge) cabling can also be used
