Kramer 690R Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODELS:

690T

SDI Fiber Optic Transmitter

690R

SDI Fiber Optic Receiver

P/N: 2900-300083 Rev 1

690T, 690R – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

3.1 Defining the 690T and the 690R SDI Fiber Optic Transmitter and Receiver 4

4Connecting the 690T and the 690R 5

5Technical Specifications 7

Figures

Figure 1: 690T SDI Fiber Optic Transmitter Front and Rear Panels 4

Figure 2: 690R SDI Fiber Optic Receiver Front and Rear Panels 4

Figure 3: Connecting the 690T and/or 690R 6

690T, 690R - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix

Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;

GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;

GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and

GROUP 11: Sierra Products.

Congratulations on purchasing your Kramer Pico TOOLS™ 690T SDI Fiber Optic

Transmitter or 690R SDI Fiber Optic Receiver which are ideal for the following

typical applications:

•Home theater, presentation and multimedia applications

•Long range multimedia distribution for cinemas, stores, and entertainment

centers

•Video production and broadcast facilities

•Retail stores and other point-of-sale systems

•Digital signage

2 690T, 690R - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance, high resolution cables

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer 690T and the 690R SDI Fiber Optic Transmitter and

Receiver away from moisture, excessive sunlight and dust

Caution: No operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning: Disconnect the power and unplug the unit from the wall

before installing

690T, 690R - Overview 3

3 Overview

The 690T is a high-performance fiber optic transmitter for SD-SDI, HD-SDI and

3G-SDI signals. The unit converts up to two channels of serial digital signals to

light pulses that are transmitted over a dual single mode cable to a 690R receiver

that converts them back to serial digital signals. The 690T and the 690R pair have

a transmission range of 10km (more than 6.2 miles) for 3G-SDI.

The 690T and the 690R feature:

•A maximum data rate of up to 3Gbps, enabling it to be used for standard

definition, high definition and the new 3G high definition serial digital video

signals (3G-SDI)

•Two SDI gold-plated BNC connectors each for the transmitter and the receiver

•SD-SDI, HD-SDI and 3G-SDI support of video pathological patterns for

SMPTE 259M, SMPTE 344M, SMPTE 292M and SMPTE 297-2006

Standard Definition (SD-SDI)means an NTSC or PAL compatible video format,

consisting of 480 (for NTSC) or 576 (for PAL) lines of interlaced video

High Definition (HD-SDI)means a video format, consisting of 720 active lines of

progressive video or 1080 lines of progressive or interlaced video

3G-SDI means a video format, consisting of 1080 lines of progressive video

•Support of data rates of 270Mbps, 1483.5Mbps, 1485Mbps and 2970Mbps

•SMPTE 297-2006 compatible electrical-to-optical interfaces

•HDTV compatibility

•Reclocking and equalization on each channel

•Cable equalization up to 200m for 1.5GHz HD signals, and 100m for 3GHz

HD signals

•Strict regulation in accordance with Class 3R Laser Eye Safety in

compliance with ANSI Z136 and IEC 60825-1:2007

•5V DC power adapters and housing in Kramer Pico TOOLS™ enclosures.

Four units can be rack mounted side−by−side in a 1U rack space with the

optional RK-4PT rack adapter

4 690T, 690R - Overview

3.1 Defining the 690T and the 690R SDI Fiber Optic

Transmitter and Receiver

Figure 1and Figure 2define the 690T and 690R, respectively.

Figure 1: 690T SDI Fiber Optic Transmitter Front and Rear Panels

# Feature Function

1 ON LED Illuminates when receiving power

2 FIBER OUT Dual SFP

Connector

Connects to the dual optical connector on the 690R via

dual single mode cable

3 5V DC Connector Connect to the power adapter

4 SDI IN2 BNC Connector Connect to the SDI source 2

5 SDI IN1 BNC Connector Connect to the SDI source 1

Figure 2: 690R SDI Fiber Optic Receiver Front and Rear Panels

# Feature Function

1 ON LED Illuminates when receiving power

2 FIBER INDual SFP

Connector

Connects to the dual optical connector on the 690T via

dual single mode cable

3 5V DC Connector Connect to the power adapter

4 SDI OUT 1 BNC Connector Connect to the SDI acceptor 1

5 SDI OUT 2 BNC Connector Connect to the SDI acceptor 2

690T, 690R - Connecting the 690T and the 690R 5

4 Connecting the 690T and the 690R

Always switch off the power to any device before connecting it to your

690T and/or 690R. After connecting your 690T and/or 690R connect

the power and then switch on the power to the device.

To connect the 690T and the 690R as illustrated in the example in Figure 3:

1. Connect up to two SDI sources (for example, 3G-SDI video players) to the

two SDI INconnectors.

2. Connect the two SDI OUT connectors to up to two SDI acceptors (for

example, 3G-SDI displays).

The SDI 1 IN source signal on the 690T is always routed to the SDI

1 OUT acceptor on the 690R and the SDI 2 IN source signal on the

690T is always passed to the SDI 2 OUT acceptor on the 690R

3. Remove the dust caps and connect the OPTIC CABLE connector of the

690T to the OPTIC CABLE connector of the 690R, via dual single mode

cable (9/12) over LC connectors (a maximum range of 10km (more than 6.2

miles)).

4. Connect the power adapter to the 5V DC socket and to the mains electricity

for both the 690T and the 690R (not shown in Figure 3).

Avoid direct eye exposure into the optic connectors when powered,

although this product is regulated strictly enough to operate under the

Laser Class 3R for eye safety.

6 690T, 690R - Connecting the 690T and the 690R

Figure 3: Connecting the 690T and/or 690R

690T, 690R - Technical Specifications 7

5 Technical Specifications

690T 690R

INPUTS: 2 SDI/HD −SDI/3G-SDI on BNC

connectors

2 LC optical connectors

OUTPUTS: 2 LC optical connectors 2 SDI/HD −SDI/3G-SDI on BNC

connectors

BANDWIDTH: Supports up to 3Gbps bandwidth for each input

FIBER OPTIC

EXTENSION:

Up to 10km (>6.2 miles) for 3G-SDI

INPUT CABLE

EQUALIZATION

200m for SDI, 100m for 3G-SDI

FIBER-OPTIC

CONNECTION:

Dual single mode fiber (9/125) over LC connectors

POWER SOURCE: 5V DC, 480mA 5V DC, 350mA

OPERATING

TEMPERATURE:

0° to +55°C (32° to 131°F)

STORAGE

TEMPERATURE:

-45° to +72°C (-49° to 162°F)

HUMIDITY: 10% to 90%, RHL non-condensing

DIMENSIONS: 6.2cm x 5.2cm x 2.4cm (2.4" x 2.0" x 0.9") W, D, H

WEIGHT: 0.14kg (0.31lbs) approx each

ACCESSORIES: 1 Power supply

OPTIONS: RK-4PT rack adapter

Specifications are subject to change without notice at http://www.kramerelectronics.com
