USER MANUAL

MODEL:

VS-88UT

8x8 HDMI/HDBT Matrix Switcher

VS-88UT - Introduction

Contents

Introduction 1

Getting Started 1

Overview 2

Typical Applications 4

Controlling your VS-88UT 4

Defining the VS-88UT 8x8 HDMI/HDBT Matrix Switcher 5

Installing in a Rack 8

Connecting the VS-88UT 9

Connect the Matrix Ports 9

Connect the Controller Ports 11

Connecting the Audio Inputs and Outputs 12

Connecting to VS-88UT via RS-232 13

Connecting VS-88UT via the Ethernet Port 13

Using the Web Pages 17

Global Mute Feature 19

Defining General Settings 20

Routing VS-88UT Ports 23

Defining Port Settings 24

Controlling Devices via the Controller 54

Room Controller Configuration via K-Config 3 55

Controlling Devices 57

Activating Macros 62

Scheduling Macros 63

Setting the Date and Time 65

Managing EDID 66

Changing the Device Settings 70

Resetting to Factory Default Parameters 70

Performing Firmware Upgrade 71

Setting Authentication 72

Setting Network Parameters 74

Changing the Ethernet Settings 74

Viewing the About Page 76

Technical Specifications 77

Default Communication Parameters 79

Protocol 3000 80

Understanding Protocol 3000 81

Kramer Protocol 3000 Syntax 81

Extended Protocol 3000 82

Other Rules 85

Protocol 3000 Commands 86

Kramer Electronics Ltd.

VS-88UT - Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of

unique, creative, and affordable solutions to the vast range of problems that confront the video,

audio, presentation, and broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by function:

GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control

Systems; GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and

Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and Scalers;

GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage;

GROUP 13: Audio; and GROUP 14: Collaboration.

Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

Review the contents of this user manual.

Go to www.kramerav.com/downloads/VS-88UT to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving the Best Performance

Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

Do not secure the cables in tight bundles or roll the slack into tight coils.

Avoid interference from neighbouring electrical appliances that may adversely influence

signal quality.

Position your Kramer VS-88UT away from moisture, excessive sunlight and dust.

This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

Kramer Electronics Ltd.

VS-88UT - Introduction

Safety Instructions

Caution:

There are no operator serviceable parts inside the unit.

Warning:

Use only the power cord that is supplied with the unit.

Warning:

Do not open the unit. High voltages can cause electrical shock! Servicing by

qualified personnel only.

Warning:

Disconnect the power and unplug the unit from the wall before installing.

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/support/recycling.

Overview

Congratulations on purchasing your Kramer VS-88UT 8x8 HDMI/HDBT Matrix Switcher.

VS-88UT is a high−performance 4K@60Hz (4:2:0) Audio-Video presentation system with

integrated range extension and an integrated control system master. The unit switches the

video, embeds the audio and outputs the signal to both HDMI and HDBaseT 2.0 with USB

extension and PoE on input and output ports. Outstanding audio support includes balanced

stereo audio, unbalanced stereo audio and embedded audio sources that output to embedded

audio, balanced stereo audio as well as a power amplified audio output.

VS-88UT includes a master room controller that can operate over Ethernet (LAN) with control

ports that include: one bidirectional RS−485, four RS−232, four IR, four GPI/O, and eight

relays to control a wide variety of AV devices. It includes a KNET™ connector interface that

enables access to the master controller from auxiliary room controllers such as control

keypads. The unit can also provide power to auxiliary room controllers via the KNET™

connectors. The VS-88UT includes an Ethernet gateway to control and manage remote I/O

ports.

The VS-88UT provides exceptional quality, advanced and user-friendly operation, and flexible

control.

Exceptional Quality

Max. Data Rate –8.91Gbps (2.97Gbps per graphics channel).

Max. Resolution –4K@60Hz (4:2:0).

Audio Level and Balance Support –DSP control.

HDMI, HDCP and DVI compliance.

Kramer Electronics Ltd.

VS-88UT - Introduction

HDBaseT certified –V2.0 support.

HDBaseT Extension Reach –Up to 100m at 4K @60Hz (4:2:0), up to 130m (430ft) at full

HD (1080p @60Hz 36bpp), up to 180m (590ft) at ultra-mode and full HD

(1080p @60Hz 24bpp).

USB Support –USB 1.1 and USB 2.0 (up to 127Mbps) channelled through HDBaseT.

HDMI Support –Deep color, 3D, ARC, 7.1 PCM.

Kramer reKlocking™ and equalization technology –Rebuilds the digital signal to travel

longer distances.

Advanced and User-friendly Operation

Advanced EDID management per input.

Active source and acceptor detection.

Control options –RS-232 serial commands transmitted by a PC, touch screen system or

other serial controller, Ethernet port via LAN.

Kramer K-Config™ Compatible – Windows®-based control program for easy configuration

and upload to room controller over customer IP network.

Kramer Network Compatible –Remote control and management over customer IP

network.

Simultaneous IP control communication –With up to 15 IP control clients.

Auto-switching and auto-scanning of inputs.

Audio breakaway and AFV (audio-follow-video) operation support.

Global mute for both video and audio outputs –Allowing easy integration of the audio

system with a public announcement audio system in case of an emergency event.

Firmware Upgrade –Ethernet-based, via a user-friendly software upgrade tool.

Kramer protocol 3000 support.

Advanced EDID management per input.

Includes non-volatile memory that retains the last settings after switching the power off

and then on again.

Flexible Connectivity

4 HDMI and 4 HDMI/HDBT (selectable) inputs.

4 balanced stereo audio inputs or 8 microphone inputs (selectable) as well as 4

unbalanced stereo inputs.

6 HDMI and 2 HDBT outputs.

2 line-out balanced stereo audio outputs and one audio amplified output.

2 USB type-A hubs and 2 USB Type-B ports.

6 IR ports for HDBT tunnelling.

1 Ethernet port –Connects to control gateways for I/O port extending, and controls

IP-enabled controlled devices.

Kramer Electronics Ltd.

VS-88UT - Introduction

1G Ethernet port –For tunnelling data via HDBT ports

1 K-NET™ connector – Carrying both power and control communication; connects to room

control system, either master room controller, or auxiliary control keypads.

1 RS-485 and 2 RS-232 bidirectional control ports –Control devices via bidirectional serial

control protocols.

4 IR emitter control ports –Control devices via IR control protocols.

4 GPI/O control ports –Control devices via general purpose I/O ports, individually

configurable as digital input, digital output or analog input interface for controlling sensors,

door-locks, audio volume and light dim level, or lighting control devices.

8 Relay control ports –Control devices via relay contact closure, such as scrolling up and

down screens, drapes, shades, and blinds.

IR Sensor and IR input ports –Learn commands from IR remotes.

Typical Applications

The VS-88UT is ideal for the following typical applications:

Projection systems in conference rooms, boardrooms, hotels and churches.

Divisible conference rooms in hotels.

Classroom, lecture theatres and education applications.

Controlling your VS-88UT

Control your VS-88UT via:

By RS-232 serial commands transmitted by a touch screen system, PC, or other serial

controller (see Connecting to VS-88UT via RS-232 on page 13).

Ethernet using built-in user-friendly Web pages (see Using the Web Pages on page 17).

Kramer Electronics Ltd.

VS-88UT - Defining the VS-88UT 8x8 HDMI/HDBT Matrix Switcher

Defining the VS-88UT 8x8

HDMI/HDBT Matrix Switcher

This section defines the VS-88UT.

Figure 1: VS-88UT 8x8 HDMI/HDBT Matrix Switcher Front Panel

Feature

Function

ON LED

Lights when receiving power.

STATUS LED

Multi-color LED lights upon startup, flashes green upon boot and lights

green when ready to use. The LED lights red to indicate internal errors.

Figure 2: VS-88UT 8x8 HDMI/HDBT Matrix Switcher Rear Panel

Feature

Function

Room Controller Functionality

IR IN 1 3.5mm Mini Jack

Connect to an external IR receiver (1 and 2).

IR OUT Terminal Block

Connectors

Connect to IR emitter cables (from 1 to 4).

GPI/O Terminal Block

Connectors

Connect to various analog and digital sensors (from 1 to 4).

RELAYS Terminal Block

Connectors

Connect to low-voltage relay-driven devices (from 1 to 8).

RS-232 Terminal Block

Connectors

Connect to RS-232 controlled devices (from 1 to 4).

RS-485 Terminal Block

Connector

Connect to the RS-485 detachable terminal block on a switcher or PC.

Pins B (-) and A (+) are for RS-485; Pin G may be connected to the

shield (if required).

K-NET Terminal Block

Connector

Use with the K-Config control system. PIN GND is for the Ground

connection; PIN B (-) and PIN A (+) are for RS-485, and PIN +12V is for

powering other devices.

Kramer Electronics Ltd.

VS-88UT - Defining the VS-88UT 8x8 HDMI/HDBT Matrix Switcher

Feature

Function

RS-485 TERM Switch

Slide down for RS-485 termination with 120; slide up for no RS-485

line termination.

The first and the last units on the RS-485 line should be terminated

(ON). Other units should not be terminated (OFF).

K-NET TERM Switch

Use with the K-Config control system.

Slide down (in the direction of the arrow) for K-NET termination; slide up

for bus to not be terminated. The last physical device on a K-NET bus

must be terminated.

PROG Switch

For factory use only.

PROG Mini USB Connector

For factory use only.

Matrix Functionality

REMOTE MUTE 2-pin

Terminal Block Connector

Remote switch to mute all video and audio signals. Enables easy

integration of the audio system with a PA systems, usually used for

alarms or other public audio messages.

GPIO Terminal Block

Connectors

For future use.

PROGRAM DIP-switches

For future use.

Power Connector with

Switch and Fuse

AC connector, enabling power supply to the unit.

Power switch for turning the unit on or off.

AUDIO

INPUT (MIC/line)

5-pin Terminal Block

Connectors

Connect to stereo audio balanced sources (from 1 to 4) and/or

microphone inputs (from 1 to 8).

INPUT 3.5mm Mini

Jack

Connect to an unbalanced audio source (from 5 to 8).

LINE OUT 5-pin

Terminal Block

Connectors

Connect to a stereo balanced audio acceptor (1 and 2).

POWER AMP OUT

4-pin Terminal Block

Connectors

Connect to a pair of loudspeakers.

VIDEO

HDMI IN Connector

Connect to an HDMI source (from 1 to 4).

HDMI IN—HDBT IN

Connectors

Connect a source to the HDMI IN 5 and/or HDMI IN 6 inputs, or connect a

transmitter to the HDBT IN (5) and/or HDBT IN (6) inputs. The same

applies to the HDMI IN 7/8 and HDBT IN (7)/(8) pairs. For each input pair

(HDMI or HDBT), only one type of connector can be enabled (via the

Routing Settings Web page); by default, the HDBT pair is active. The

HDBT Transmitter (for example, the Kramer TP-590Txr) can pass audio

and video signals as well as USB, Ethernet, power and serial commands.

HDMI OUT

Connectors

Connect to an HDMI acceptor (1, 2, 3, 4, 7 and 8).

OUT (HDBT)

RJ-45 Connectors

Connect OUT 5 and/or OUT 6 to HDBT receivers (for example, the

Kramer TP-590Rxr) to pass audio and video signals as well as USB,

Ethernet, power and serial commands.

HDBT IR 3.5mm

Mini Jack

Connect to an external IR sensor to send IR signals (5, 6, 7 and 8) via

HDBT inputs 5, 6, 7 and 8 respectively.

OUT

Connect to an external IR emitter to receive IR signals (5 and 6) via

HDBT outputs 5 and 6, respectively.

RS-232 HDBT DATA

Terminal Block Connectors

(G, Rx, Tx)

Connect to the PC or the remote controller and pass data between this

RS-232 port and the HDBT OUT ports or one of the HDBT IN ports.

RS-232 CONTROL Port

Terminal Block Connectors

(G, Rx, Tx)

Connect to the PC or the remote controller to control the VS-88UT via

Protocol 3000 commands.

Kramer Electronics Ltd.

VS-88UT - Defining the VS-88UT 8x8 HDMI/HDBT Matrix Switcher

Feature

Function

HDBT USB Device Port

Pairs

Connect up to two USB clients to each pair (1 and 2) to pass data via the

HDBT inputs or outputs.

HDBT USB HOST Ports

Connect to a USB host (1 and 2) to pass data via the HDBT inputs or

outputs.

ETH RJ-45

Ports

CONTROL

Connect to the PC or other controller through computer networking.

DATA 1G

Connect to The PC or other controller via the Ethernet to pass data

between HDBT ports and the controller.

RESET Recessed Button

Press briefly to restart the system. Press for about 5 seconds to reset

settings to factory default values and restart the system.

Kramer Electronics Ltd.

VS-88UT - Installing in a Rack

Installing in a Rack

This section provides instructions for rack mounting the VS-88UT. Before installing in a rack,

verify that the environment is within the recommended range:

Operation temperature –0to 40C (32 to 104F).

Storage temperature –-40to +70C (-40 to +158F).

Humidity –10% to 90%, RHL non-condensing.

When installing on a 19" rack, avoid hazards by taking care that:

It is located within recommended environmental conditions. Operating ambient

temperature of a closed or multi-unit rack assembly may exceed ambient room

temperature.

Once rack mounted, there is enough air still flow around the VS-88UT.

The VS-88UT is placed upright in the correct horizontal position.

You do not overload the circuit(s). When connecting the VS-88UT to the supply circuit,

overloading the circuits may have a detrimental effect on overcurrent protection and

supply wiring. Refer to the appropriate nameplate ratings for information. For example,

for fuse replacement, see the value printed on the product label.

The VS-88UT is earthed (grounded) and connected only to an electricity socket with

grounding. Pay particular attention when electricity is supplied indirectly (for example,

when the power cord is not plugged directly into the wall socket but to an extension

cable or power strip). Use only the supplied power cord.

To rack-mount the VS-88UT:

1. Attach both rack ears to the VS-88UT:

Remove the screws from each side of the VS-88UT

(5 on each side), and replace them through the rack

ears.

2. Place the rack ears of the VS-88UT against the rack

rails and insert the appropriate screws (not provided)

through each of the four holes in the rack ears.

Some models, may feature built-in rack ears:

Detachable rack ears can be removed for desktop use.

Always mount the VS-88UT in the rack before connecting any cables or power.

If you are using a Kramer rack adapter kit (for a machine that is not 19"), see the Rack

Adapters user manual for installation instructions available from our Web site

www.kramerav.com/downloads/VS-88UT.

Otros manuales para VS-88UT

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer VS-1616A Manual de usuario

Kramer

Kramer VP-8x8A Manual de usuario

Kramer

Kramer Sierra Video 3232V3S Manual de usuario

Kramer

Kramer Sierra Video 1616V3S Manual de usuario

Kramer

Kramer VS-66UHD Manual de usuario

Kramer

Kramer VS-1616SDI Manual de usuario

Kramer

Kramer VS-48HDCPxI Manual de usuario

Kramer

Kramer 1608HDS Manual de usuario

Kramer

Kramer VP-88 Manual de usuario

Kramer

Kramer TailorMade Manual de usuario

Kramer

Kramer VSM-4x4X Manual de usuario

Kramer

Kramer XL 1616S Manual de usuario

Kramer

Kramer Sierra Video 3232SXL Manual de usuario

Kramer

Kramer AFM-20DSP-LE Manual de usuario

Kramer

Kramer Sierra Pro XL 1608V3S Manual de usuario

Kramer

Kramer VS-88HCB Manual de usuario

Kramer

Kramer VS-606xl Manual de usuario

Kramer

Kramer 1616HDEE Manual de usuario

Kramer

Kramer VP-32XLN Manual de usuario

Kramer

Kramer Sierra Video 3232V5S Manual de usuario

Kramer

Kramer VS-88A Manual de usuario

Kramer

Kramer Sierra Video 1204V3S Manual de usuario

Kramer

Kramer VS-606xl Manual de usuario

Kramer

Kramer VS-622DT Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
