KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-42HN

4x2 HDMI Matrix Switcher

P/N: 2900-300152 Rev 2

VS-42HN - Contents i

Contents

1Introduction 1

2Getting Started 2

2.1Achieving the Best Performance 2

3Overview 3

3.1Defining the EDID 4

3.2About HDMI–General Description 4

3.3About HDCP–General Description 5

3.4Defining the VS-42HN 4x2 HDMI Matrix Switcher 5

3.5Using the IR Transmitter 8

4Installing in a Rack 9

5Connecting the VS-42HN 4x2 HDMI Matrix Switcher 10

6Operating the VS-42HN 4x2 HDMI Matrix Switcher 12

6.1Acquiring the EDID 12

6.2Resetting to the Default EDID 13

6.3Storing and Recalling a Switching Setting from a Preset 13

6.4Switching Between Protocol 2000 and Protocol 3000 14

6.5Connecting to the VS-42HN 4x2 HDMI Matrix Switcher via RS-232 14

6.6Connecting to the VS-42HN 4x2 HDMI Matrix Switcher via Ethernet 14

6.7Upgrading the Firmware 16

7Technical Specifications 17

8Default Communication Parameters 18

9Default EDID 19

10Kramer Protocol 2000 21

11Protocol 3000 24

11.1Kramer Protocol 3000 Syntax 24

11.2Kramer Protocol 3000 Commands 27

Figures

Figure 1: VS-42HN 4x2 HDMI Matrix Switcher Front Panel 6

Figure 2: VS-42HN 4x2 HDMI Matrix Switcher Rear Panel 7

Figure 3: Connecting the VS-42HN 4x2 HDMI Matrix Switcher 11

Figure 4: Local Area Connection Properties Window 15

Figure 5: Internet Protocol (TCP/IP) Properties Window 16

VS-42HN - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VS-42HN 4x2 HDMI Matrix Switcher,

which is ideal for the following typical applications:

•Conference room presentations

•Advertising applications

•Rental and staging

2 VS-42HN - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Use Kramer high performance high resolution cables

Use only the power cord hat is supplied with his machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your VS-42HN away from moisture, excessive sunlight and dust

VS-42HN - Overview 3

3 Overview

The VS-42HN is a high quality 4x2 matrix switcher for HDMI signals. It reclocks

and equalizes the signals and can route any input to any or all outputs

simultaneously.

In particular, the VS-42HN features:

•Up to 6.75Gbps data rate (2.25Gbps per graphics channel)

Suitable for resolutions up to UXGA and 1080p at 60Hz

•Support for HDCP (High Definition Digital Content Protection)

•HDMI support for 3D, Deep Color, x.v.Color™, Lip Sync

•3D pass-through

•Support for up to 7.1 multi channel audio

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling & processing algorithm ensures Plug and Play operation for HDMI

systems

•Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

•A lock button to prevent unwanted tampering with the buttons on the front

panel

•Preset memory locations for quick access to common configurations

•Support for Kramer Protocol 2000 and Protocol 3000

You can control the VS-42HN using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a PC, touch screen system or other

serial controller

•The Kramer RC-IR3 infrared remote control transmitter

•A PC connected to the Ethernet port on the device via a LAN

•An external remote IR receiver (optional), see Section 3.5

4 VS-42HN - Overview

3.1 Defining the EDID

The Extended Display Identification Data (EDID) is a data-structure provided by a

display, to describe its capabilities to a graphics card (that is connected to the

display’s source). The EDID enables the VS-42HN to “know” what kind of monitor

is connected to the output. The EDID includes the manufacturer’s name, the

product type, the timing data supported by the display, the display size, luminance

data and (for digital displays only) the pixel mapping data.

EDID is defined by a standard published by the Video Electronics Standards

Association (VESA).

3.2 About HDMI–General Description

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. HDMI ensures an all-digital rendering of video without the losses associated

with analog interfaces and their unnecessary digital-to-analog conversions. It delivers

the maximum high-definition image and sound quality in use today. Note that Kramer

Electronics Limited is an HDMI Adopter and an HDCP Licensee.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered

trademarks of HDMI licensing LLC.

In particular, HDMI:

•Provides a simple interface between any audio/video source, such as a set-

top box, DVD player, or A/V receiver and video monitor, such as a digital flat

LCD / plasma television (DTV), over a single lengthy cable

SIMPLICITY - With video and multi-channel audio combined into a single cable, the cost,

complexity, and confusion of multiple cables currently used in A/V systems is reduced

LENGTHY CABLE - HDMI technology has been designed to use standard copper cable

construction at up to 15m

•Supports standard, enhanced, high-definition video, and multi-channel digital

audio on a single cable

MULTI-CHANNEL DIGITAL AUDIO - HDMI supports multiple audio formats, from

standard stereo to multi-channel surround-sound. HDMI has the capacity to support

Dolby 5.1 audio and high-resolution audio formats

•Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

VS-42HN - Overview 5

•Benefits consumers by providing superior, uncompressed digital video quality

via a single cable, and user-friendly connector

HDMI provides the quality and functionality of a digital interface while also supporting

uncompressed video formats in a simple, cost-effective manner

•Is backward-compatible with DVI (Digital Visual Interface)

•Supports two-way communication between the video source (such as a DVD

player) and the digital television, enabling new functionality such as automatic

configuration and one-button play

•Has the capacity to support existing high-definition video formats (720p, 1080i

and 1080p), standard definition formats such as NTSC or PAL, as well as

480p and 576p

3.3 About HDCP–General Description

The High-Bandwidth Digital Content Protection (HDCP) standard developed by

Intel, protects digital video and audio signals transmitted over DVI or HDMI

connections between two HDCP-enabled devices to eliminate the reproduction of

copyrighted material. To protect copyright holders (such as movie studios) from

having their programs copied and shared, the HDCP standard provides for the

secure and encrypted transmission of digital signals.

3.4 Defining the VS-42HN 4x2 HDMI Matrix Switcher

Figure 1 and Figure 2 define the VS-42HN.

Figure 1: VS-42HN 4x2 HDMI Matrix Switcher Front Panel

# Feature Function

1 IR Receiver Signal receiver for the infrared remote control transmitter

2 INPUT SELECTOR

Buttons TO OUTPUT 2 Press one of the 4 inputs to switch it to Output 2

3 TO OUTPUT 1 Press one of the 4 inputs to switch it to Output 1

4 OFF Button Output 1 Press to disconnect output 1 from the inputs

5 OFF Button Output 2 Press to disconnect output 2 from the inputs

6 EDID Button Press to capture the EDID (see Section 6.1)

7 STO Button Press to store the current switching setting to a preset (see Section 6.3)

8 RCL Button Press to recall the switch setting from a preset (see Section 6 3)

9 LOCK Button Press and hold to toggle the locking/release of the front panel buttons.

When storing or recalling presets, press to store or recall the preset (see Section 6.3)

6VS-42HN – Overview

VS-42HN – Overview 7

Figure 2: VS-42HN 4x2 HDMI Matrix Switcher Rear Panel

# Feature Function

10 IN HDMI Connectors (1 to 4) Connect to up to 4 HDMI sources

11 OUT HDMI Connector (1 to 2) Connect to the first and second HDMI acceptors

12 RS-232 9-pin D-sub Serial Port Connector Connect to a PC/serial controller

13 ETHERNET RJ-45 Connector Connect to a PC via a LAN

14 RESET Button Press to reset to factory default definitions:

IP number −192.168.1.39, Mask – 255.255.0.0, Gateway – 0.0.0.0

First, disconnect the power cord and then connect it again while pressing the ETH Factory Reset

button. The unit powers up and loads its memory with the factory default definitions and erases all

stored preset

15 REMOTE IR Opening

Connect to an external IR receiver for controlling the device via an IR remote controller (see

Section 3.5)

Covered by a cap. The 3.5mm jack at the end of the internal IR connection cable fits into this

opening

16 Mains Power Connector, Fuse and

Illuminated Power Switch Plug in the power cord and switch the device on and off
