Kramer VS-62HA Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-62HA

6x2 HDMI/Audio Matrix

Switcher

P/N: 2900-300469 Rev 2

VS-62HA – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Using the IR Transmitter 5

3.2 About Fast Switching 5

3.3 Defining the VS-62HA 6x2 HDMI/Audio Matrix Switcher 5

4Installing in a Rack 10

5Connecting the VS-62HA 11

5.1 Connecting a Serial Controller to the VS-62HA via RS-232 12

5.2 Connecting to the VS-62HA via Ethernet 13

5.3 Connecting the Remote Contact-Closure Switches and LEDs 16

6Principles of Operation 18

6.1 Automatic Signal Detection 18

6.2 Input Switching Modes 18

6.3 EDID Operation 19

6.4 Step-in Functionality 19

7Operating the VS-62HA 6x2 HDMI/Audio Matrix Switcher 20

7.1 Switching an Input to an Output 20

7.2 Switching Analog Audio 20

7.3 Acquiring an EDID from an Output 21

7.4 Using the OFF Button 22

7.5 Locking and Unlocking the Front Panel Buttons 22

7.6 Generating a Test Pattern 23

8Configuring and Maintaining the VS-62HA 24

8.1 Setting the DIP-Switches 24

8.2 Resetting the VS-62HA to Factory Default Settings 25

8.3 Upgrading the Firmware 25

9Operating the VS-62HA Remotely via the Web Pages 26

9.1 Video Switching Page 27

9.2 Analog Audio Switching 30

9.3EDID Management 31

9.4 Authentication Page 34

9.5 Device Setting Page 35

9.6 Firmware Upgrade Page 36

9.7 About Us Page 37

10 Wiring the Twisted Pair RJ-45 Connectors 38

11 Technical Specifications 39

12 Default Communication Parameters 40

13 Default EDID 41

14 Protocol 3000 Syntax 43

14.1 Host Message Format 43

14.2 Device Message Format 43

14.3 Command Terms 44

VS-62HA - Introduction

14.4 Entering Commands 45

14.5 Bidirectional Definition 45

14.6 Command Chaining 45

14.7 Maximum String Length 46

15 Protocol 3000 Commands 47

15.1 System Commands - Mandatory 48

15.2 System Commands 53

15.3 Switching/Routing Commands 61

15.4 Video Commands 64

15.5 Audio Commands 66

15.6 Communication Commands 68

15.7 EDID Handling Commands 72

15.8 Step-in Commands 75

16 Messages and Codes 76

16.1 Device Initiated Messages 76

16.2 Result and Error Codes 76

17 Packet Protocol Structure 78

17.1 Using the Packet Protocol 78

17.2 Calculating the CRC 79

18 Parameters 76

18.1 On/Off 76

18.2 Stage 76

18.3 Signal Type 76

18.4 Genlock Types 76

18.5 Video Port Type 77

18.6 Video Resolutions 77

18.7 Color Space 79

18.8 Image Properties 79

18.9 View Modes 79

18.10 Custom Resolution Parameters 80

18.11 Detail Timing Parameters 80

18.12 Video/Audio Signal Changes 80

18.13 Font Size 81

18.14 Layer Enumeration 81

18.15 Software Programmed 81

18.16 EDID Source 81

18.17 EDID Audio Capabilities 81

18.18 Signal Validation 82

18.19 Ethernet Port Types 82

18.20 HDCP Types 82

18.21 Parity Types 82

18.22 Serial Types 82

18.23 Audio Signal Types 83

18.24 Frequency Number 83

18.25 Audio Level 83

18.26 Audio Delay 84

18.27 IR Transmit Status 84

VS-62HA – Contents

iii

Figures

Figure 1: VS-62HA 6x2 HDMI/Audio Matrix Switcher Front Panel 7

Figure 2: VS-62HA 6x2 HDMI/Audio Matrix Switcher Rear Panel 9

Figure 3: Connecting the VS-62HA 6x2 HDMI/Audio Matrix Switcher 11

Figure 4: Local Area Connection Properties Window 14

Figure 5: Internet Protocol Version 4 Properties Window 15

Figure 6: Internet Protocol Properties Window 16

Figure 7: Remote Contact-closure Switch and LED Connections 17

Figure 8: Test Patterns 23

Figure 9: Video Switching Page 27

Figure 10: The Remote Device Control Window 28

Figure 11: Test Pattern Tab 29

Figure 12: EDID Page 32

Figure 13: The Device Setting Page 35

Figure 14: The Firmware Upgrade Page 36

Figure 15: About Page 37

Figure 16: TP Pinout Wiring 38

VS-62HA - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VS-62HA 6x2 HDMI/Audio Matrix

Switcher, which is ideal for the following typical applications:

Conference rooms

Entertainment

Hospitality

VS-62HA - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/VS-62HA to check for up-to-date

user manuals, application programs, and to check if firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

For optimum range and performance, use the recommended Kramer cables

available at www.kramerav.com/product/VS-62HA

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VS-62HA away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

VS-62HA - Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at www.kramerav.com/support/recycling/.

VS-62HA - Overview

3 Overview

The VS-62HAis a 4K UHD 6x2 matrix switcher for HDMI and analog audio signals.

It reclocks and equalizes the signals and can route any input to either or both

outputs simultaneously. It supports resolutions of up to 4K UHD including

4K@60Hz (4:2:0).

In particular, the VS-62HA features:

Up to 8.91Gbps data rate (2.97Gbps per graphics channel)

Maximum resolution of up to 4K@60Hz UHD (4:2:0).

Support for HDCP 1.4 (High Definition Digital Content Protection)

HDMI 2.0 Support –3D, Deep Color, x.v.Color™, Lip Sync , Dolby®

TrueHD, Dolby Digital Plus, DTS−HD®, and 7.1 multi-channel audio

Four unbalanced and two balanced audio inputs and two balanced audio

outputs on a matrix switcher

Contact closures to mirror front panel switching selection buttons and LEDs

Per input EDID capture that copies and stores the EDID from a display

device

Independent (breakaway) audio routing of HDMI and analog audio content to

two balanced audio ports

Programmable step-in functionality when used in conjunction with

compatible step-in devices, such as the SID-X3N and DIP-31 (using an

HDMI cable that supports HEC, the HDMI Ethernet Channel)

True video clock detection

Advanced auto AV switching modes (last connected and priority switching)

Non-volatile EDID storage

Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

A lock button to prevent unwanted tampering with the buttons on the front

panel

Internal pattern generator

VS-62HA - Overview

Support for Kramer Protocol 3000

Static or dynamic DHCP IP addressing

Flexible control options including front panel buttons, IR remote (included),

optional external remote IR receiver, RS−232, Ethernet, buttons and LED

over contact closure, embedded Web server and step-in.

Mini-USB port for upgrading firmware

19” 1U enclosure for rack mounting

3.1 Using the IR Transmitter

You can use the RC-IR3 IR transmitter to control the machine via an optional

external IR receiver (for example, P/N C-A35M/IRR-50). The external IR receiver

can be located up to 15m away from the machine. This distance can be extended

to up to 60m when used with three extension cables (for example, P/N

C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (for example, P/N: 505-70434010-S) with

the 3.5mm connector that fits into the REMOTE IR opening on the rear panel.

Connect the external IR receiver to the REMOTE IR 3.5mm connector.

3.2 About Fast Switching

To switch to a new digital video signal upon the loss of a digital video signal, older

display devices require the following:

A long period of time between the signal loss and the signal acquisition

Physical interconnecting cable disconnection

These enable older display devices to detect and adjust to the new video attributes

and parameters. Therefore, regular switching methods include a 5V signal

disconnection and a delay in switching.

However, many new display devices are now capable of “on-the-fly” switching.

Depending on the display device in use, the VS-62HA enables:

Fast switching –minor reset, connection kept alive

Otros manuales para VS-62HA

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer Sierra Video 3264V5Sxl Manual de usuario

Kramer

Kramer VS-88UHDA Manual de usuario

Kramer

Kramer Sierra Video 1204V3S Manual de usuario

Kramer

Kramer VP-4x4K Manual de usuario

Kramer

Kramer VS-88HN Manual de usuario

Kramer

Kramer VS-84HDCPxl Manual de usuario

Kramer

Kramer VSM-4x4A Manual de usuario

Kramer

Kramer Sierra Video 4848V5xl Manual de usuario

Kramer

Kramer XL 1208V4S Manual de usuario

Kramer

Kramer VS-44HDCP Manual de usuario

Kramer

Kramer VS-1616D-MD Manual de usuario

Kramer

Kramer VS-2616 Manual de usuario

Kramer

Kramer VS-84UT Manual de usuario

Kramer

Kramer VS-5x5 Manual de usuario

Kramer

Kramer Cobra MX-1616 Manual de usuario

Kramer

Kramer LASSEN XL 3232S Manual de usuario

Kramer

Kramer VP-88ETH Manual de usuario

Kramer

Kramer Sierra Video 1204V3 Manual de usuario

Kramer

Kramer VS-66HDCPxl Manual de usuario

Kramer

Kramer VS-44UHDA Manual de usuario

Kramer

Kramer VS-6464DN Manual de usuario

Kramer

Kramer Sierra Video 3216V3 Manual de usuario

Kramer

Kramer VS-88HDCPxl Manual de usuario

Kramer

Kramer Sierra Video 1616V5S Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
