Kramer VS-48HDCPxl Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-48HDCPxl

4x8 DVI Matrix Switcher

P/N: 2900-300015 Rev 3

VS-48HDCPxl – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

3Overview 3

3.1 About HDCP 4

3.2 Defining EDID 4

3.3 Defining the VS-48HDCPxl 4x8 DVI Matrix Switcher 4

3.4 Using the IR Transmitter 7

4Installing in a Rack 8

5Connecting the VS-48HDCPxl 9

5.1 Connecting to the VS-48HDCPxl via RS-232 10

5.2 Connecting to the VS-48HDCPxl via Ethernet 10

6Operating the VS-48HDCPxl 4x8 DVI Matrix Switcher 13

6.1 Routing Inputs to Outputs 13

6.2 Disconnecting the Outputs 13

6.3Storing and Recalling a Setup 13

6.4 Acquiring the EDID 15

6.5 Locking and Unlocking the Front Panel 17

6.6 Resetting the Ethernet Configuration to Default Values 17

6.7 Controlling Configuration via the Ethernet Port 17

7Firmware Upgrade 18

8Technical Specifications 19

9Default Communication Parameters 20

10 Kramer Protocol 2000 21

Figures

Figure 1: VS-48HDCPxl 4x8 DVI Matrix Switcher 5

Figure 2: Connecting to the VS-48HDCPxl Rear Panel 9

Figure 3: Local Area Connection Properties Window 11

Figure 4: Internet Protocol (TCP/IP) Properties Window 12

Figure 5: SELECTOR Buttons 14

VS-48HDCPxl - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix

Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;

GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;

GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and

GROUP 11: Sierra Products.

Congratulations on purchasing your Kramer VS-48HDCPxl 4x8 DVI Matrix

Switcher, which is ideal for conference room presentations and advertising

applications as well as for rental and staging.

2 VS-48HDCPxl - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables

•Use only the power cord that is supplied with this machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer VS-48HDCPxl away from moisture, excessive sunlight

and dust

VS-48HDCPxl - Overview 3

3 Overview

The high quality Kramer VS-48HDCPxl is an HDCP compatible 4 x 8 DVI Matrix

Switcher that accepts up to four DVI inputs and routes the selected DVI input

signal to any or all of eight DVI outputs.

DVI-D (Digital). Note that only the digital signal (DVI D) is available on the DVI connector.

The VS-48HDCPxl features:

•Support for up to 2.25Gbps bandwidth per graphic channel

Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

•Support for HDCP (High Definition Digital Content Protection)

•HDMI Support – HDMI (V1.4a with Deep Color, x.v.Color™, 3D Pass-

Through, HDMI Compressed Audio Channels)

•Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

•EDID PassThru that passes EDID/HDCP signals from source to display

•A PANEL LOCK button to prevent unwanted tampering with the buttons on

the front panel

•16 preset memory locations for quick access to common configurations

•2U height that fits into a standard 19” professional rack enclosure

You can control the VS-48HDCPxl using the front panel buttons or remotely via:

•RS-232 serial commands transmitted by a touch screen system, PC or other

serial controller

•The Kramer infrared remote control transmitter

•The Ethernet port

4 VS-48HDCPxl - Overview

3.1 About HDCP

The HDCP (High-Bandwidth Digital Content Protection) standard (developed by

Intel), protects digital video and audio signals transmitted over DVI or DVI

connections between two HDCP-enabled devices to eliminate the reproduction of

copyrighted material. To protect copyright holders (such as movie studios) from

having their programs copied and shared, the HDCP standard provides for the

secure and encrypted transmission of digital signals.

3.2 Defining EDID

The Extended Display Identification Data (EDID) is a data-structure, provided by a

display, to describe its capabilities to a DVI source.

Defined by a standard published by VESA (Video Electronics Standards Association).

The EDID enables the VS-48HDCPxl to “know” what kind of monitor is connected

to the output. The EDID includes the manufacturer’s name, the product type, the

timing data supported by the display, the display size, luminance data and (for

digital displays only) the pixel mapping data. See Section 6.4 for details of how to

acquire the EDID.

3.3 Defining the VS-48HDCPxl 4x8 DVI Matrix Switcher

This section defines the VS-48HDCPxl.

VS-48HDCPxl - Overview 5

Figure 1: VS-48HDCPxl 4x8 DVI Matrix Switcher

6 VS-48HDCPxl - Overview

VS-48HDCPxl Front Panel Features

Feature

Function

1 IR Receiver and LED IR remote control sensor. LED lights yellow when receiving an IR

signal

2 POWER LED Lights green when the unit is turned on

3 ALL Button Press to select all inputs or all outputs (see Section 6.1)

4 OFF Button Press to disconnect one or all outputs (see Section 6.2)

5 SELECT OUT Buttons Press to select an output (from 1 to 8)

6 SELECT IN Buttons Press to select an input (from 1 to 4)

7 STO Button Press to store a switching configuration

8 RCL Button Press to recall a switching configuration

9 LOCK Button Press and hold to lock the front panel buttons and to acquire the

EDID (see Section 6.5). Press and hold a second time to unlock the

front panel buttons

10 EDID Button Press to acquire the EDID

11 OUTPUT 1 to 6 Indicates the output channels and their respective input selections

on the 7-segment display

12 INPUT 7-segment

Display

Number shown on the display indicates the relevant input channel

VS-48HDCPxl Rear Panel Features

Feature

Function

13 INPUT DVI Connectors Connect to the DVI sources (from 1 to 4)

14 RS-232 9-pin D-sub (F)

Connector

Connect to a PC or the serial remote controller (see Section 9)

15 ETHERNET RJ-45

Connector

Connect to a PC or other Ethernet controller via a LAN (see

Section 9)

16 RESET Button

Press and hold to reset the Ethernet configuration to its factory

default values (see Section 9)

17 OUTPUT DVI

Connectors

Connect to the DVI acceptors (from 1 to 8)

18 REMOTE IR

3.5mm Mini Jack

Connect to an external IR receiver unit for controlling the machine

via an IR remote controller (instead of using the front panel IR

receiver), see Section 3.4

19 Mains Power Connector

with Switch and Fuse

Connect to the AC mains supply and use the switch to turn the unit

on or off

VS-48HDCPxl - Overview 7

3.4 Using the IR Transmitter

You can use the RC IR3 IR transmitter to control the machine via the built-in IR

receiver on the front panel or, instead, via an optional external IR receiver (Model:

C-A35M/IRR-50). The external IR receiver can be located up to 15 meters away

from the machine. This distance can be extended to up to 60 meters when used

with three extension cables (Model: C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm

connector that fits into the REMOTE IR opening on the rear panel. Connect the

external IR receiver to the REMOTE IR 3.5mm connector.
