USER MANUAL

MODEL:

VS-44DT

4x4 HDMI/HDBT Matrix Switcher

Kramer Electronics Ltd.

VS-44DT –Contents
i

Contents
Introduction 1
Getting Started 1
Overview 2
Defining the VS-44DT 4x4 HDMI/HDBT Matrix Switcher 4
Mounting VS-44DT 6
Connecting the VS-44DT 7
Connecting the VS-44DT to a Serial Controller 8
Connecting the VS-44DT to a Serial Data Source/Acceptor 8
Connecting to the VS-44DT via Ethernet 8
Wiring the RJ 45 Connectors 10
Operating the VS-44DT 11
Switching Inputs to Outputs 11
Storing and Recalling Preset Configurations 12
Acquiring an EDID 12
Disconnecting One or All Outputs 13
Resetting the Device to Factory Default Configuration 13
Locking and Unlocking the Front Panel 14
Configuring the VS-44DT 15
Using the Menu 15
Selecting DHCP 17
Configuring the IP Network Address 17
Resetting the VS-44DT to Factory Default Configuration 17
Operating the VS-44DT Remotely Using the Web Pages 19
Switching Page 20
Device Settings Page 23
EDID Page 25
RS-232 Routing Page 27
Audio Settings Page 27
Advanced Page 28
Authentication Page 32
About Page 32
Updating the Firmware 33
Technical Specifications 34
Default IP Parameters 35
Protocol 3000 36
Understanding Protocol 3000 37
Kramer Protocol 3000 Syntax 37
Extended Protocol 3000 38
Protocol 3000 Commands 41
Kramer Protocol 3000 Commands 42
Packet Protocol Structure 61

Kramer Electronics Ltd.

VS-44DT –Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Congratulations on purchasing your Kramer VS-44DT 4x4 HDMI/HDBT Matrix Switcher.

This product, which incorporates HDMI™ technology, is ideal for:

•Event rooms

•Large conference rooms

•Lecture halls

•Advertising applications

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

•Review the contents of this user manual.

Go to www.kramerav.com/downloads/VS-44DT to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

•Do not secure the cables in tight bundles or roll the slack into tight coils.

•Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

•Position your VS-44DT away from moisture, excessive sunlight and dust.

Kramer Electronics Ltd.

VS-44DT –Introduction

Safety Instructions

Caution:

•This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

•For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

•There are no operator serviceable parts inside the unit.

Warning:

•Use only the power cord that is supplied with the unit.

•Disconnect the power and unplug the unit from the wall before installing.

•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified

personnel only.

•To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which located on the bottom of the unit.

Shielded Twisted Pair/Unshielded Twisted Pair

For optimum range and performance use the recommended Kramer cables available at

www.kramerav.com/product/VS-44DT.

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/support/recycling/.

Overview

VS-44DT is a 4x4 4K@60Hz (4:2:0) HDMI/HDBaseT matrix switcher that transmits video,

audio, Ethernet, RS−232 and IR signals over extended distances. The VS-44DT accepts up

to four HDMI and four IR inputs as well as Ethernet and RS−232 network and control. The

inputs can be routed to any or all of the four HDBaseT outputs, the first two of which also

have simultaneous HDMI outputs.

VS-44DT connects to compatible HDBaseT receivers such as, TP-780Rxr,

TP-580Rxr and TP-588D. It supports resolutions of up to 4K@60Hz (4:2:0). The matrix is a

PoE provider that provides power over Ethernet to compatible PoE receivers.

The VS-44DT features:

•Four HDMI and five IR inputs.

•Two HDMI, four HDBaseT and five IR outputs.

•PoE support on all four HDBaseT outputs –PoE provider to HDBaseT receivers such as

Kramer Electronics Ltd.

VS-44DT –Introduction

the TP-588D and TP-780Rxr.

•HDBaseT range up to 130m (430ft) at normal mode (2K), up to 100m at normal mode

(4K); up to 180m (590ft) ultra-mode (1080p @60Hz @24bpp) when using recommended

Kramer cables, available at www.kramerav.com/product/VS-44DT.

•An unbalanced, stereo audio output.

•Bandwidth up to 10.2Gbps (3.4Gbps per video channel).

•EDID capture—copies and stores the EDID from a display device.

•Hot-plug detection (HPD).

•HDCP 1.4 support.

•HDTV compatibility.

•Support for HDMI –4Kx2K @30Hz, 3D, Deep Color, x.v.Color™, Lip Sync , Dolby®

TrueHD, Dolby Digital Plus, DTS−HD® and linear PCM 7.1 surround sound.

•A non-volatile memory for matrix configuration.

•A store and recall facility for preset configurations.

•Automatic output shutdown if no input signal is detected after a configurable idle period.

•An LCD display for easy configuration and operation.

•Support for Kramer Protocol 3000.

•A lock button to prevent unwanted tampering with the settings.

•1U height that fits a standard 19” professional rack enclosure.

You can control the VS-44DT using the front panel buttons, or remotely via:

•Built-in, embedded web pages using a standard web browser over Ethernet.

•RS-232 serial commands transmitted by a touch screen system, PC or other serial

controller.

•The Kramer infrared remote-control transmitter.

About HDBaseT™ Technology

HDBaseT™ is an advanced, all-in-one connectivity technology (supported by the HDBaseT

Alliance). It is particularly suitable in the ProAV –and also the home –environment as a

digital networking alternative, where it enables you to replace numerous cables and

connectors by a single LAN cable used to transmit, for example, uncompressed, full

high-definition video, audio, IR, as well as various control signals.

The products described in this user manual are HDBaseT certified.

Kramer Electronics Ltd.

VS-44DT –Defining the VS-44DT 4x4 HDMI/HDBT Matrix Switcher

Defining the VS-44DT 4x4

HDMI/HDBT Matrix Switcher

This section defines the VS-44DT.

Figure 1: VS-44DT 4x4 HDMI/HDBT Matrix Switcher Front Panel

Feature

Function

IR LED

Lights yellow when receiving an IR signal

IR Sensor

IR receiver for remote control

POWER LED

Lights green when the device is powered on

IN Buttons

Press to select an input after selecting an output (from 1 to 4), see Switching Inputs

to Outputs on page 11

OUT Buttons

Press to select an output followed by an input or OFF (from 1 to 4)

ALL Button

Press followed by an input to switch this input to all outputs, or press followed by the

Off button to disconnect all switches, (see Disconnecting One or All Outputs

on page 13)

STO Button

Press to store a preset configuration followed by the preset number in which to save

it, (see Storing and Recalling Preset Configurations on page 12)

EDID Button

Press to copy the EDID from an output to an input, (see Acquiring an EDID

on page 12)

LOCK Button

Press and hold to lock the front panel buttons, (see Locking and Unlocking the Front

Panel on page 14). Press and hold again to unlock

MENU Button

Press to enter the configuration menu or to move up one level when inside the menu,

(see Using the Menu on page 15)

Navigation

Pad

Use the Enter, up (▲), down (▼), left (◄), and right (►) buttons to navigate the

menu or to modify parameters or values within the menu, (see Using the Menu

on page 15)

LCD Readout

(20 char x 2

lines)

Displays either the input/output matrix currently selected or the menu during

configuration

OFF Button

Press after an output button to disconnect the currently selected outputs. Press after

the All button to disconnect all currently switched outputs (see Disconnecting One or

All Outputs on page 13)

RCL Button

Press, followed by a preset number to recall the preset configuration (see Storing and

Recalling Preset Configurations on page 12)

Kramer Electronics Ltd.

VS-44DT –Defining the VS-44DT 4x4 HDMI/HDBT Matrix Switcher

Figure 2: VS-44DT 4x4 HDMI/HDBT Matrix Switcher Rear Panel

Feature

Function

IR 1

IN 3.5mm Mini Jack

Connect to an IR sensor. Receives IR commands and sends them

over HDBT OUT 1

OUT 3.5mm Mini Jack

Connect to the first IR emitter. Transmits IR commands that are

sent over HDBT OUT 1

IR 2

IN 3.5mm Mini Jack

Connect to an IR sensor. Receives IR commands and sends them

over HDBT OUT 2

OUT 3.5mm Mini Jack

Connect to the second IR emitter. Transmits IR commands that are

sent over HDBT OUT 2

IR 3

IN 3.5mm Mini Jack

Connect to an IR sensor. Receives IR commands and sends them

over HDBT OUT 3

OUT 3.5mm Mini Jack

Connect to the third IR emitter. Transmits IR commands that are

sent over HDBT OUT 3

IR 4

IN 3.5mm Mini Jack

Connect to an IR sensor. Receives IR commands and sends them

over HDBT OUT 4

OUT 3.5mm Mini Jack

Connect to the fourth IR emitter. Transmits IR commands that are

sent over HDBT OUT 4

OUT 1

HDBT RJ-45 Connector

Connect to the first HDBT receiver, (for example, the TP-580RXR)

HDMI Connector

Connect to the first HDMI receiver, (for example, an HDMI display)

OUT 2

HDBT RJ-45 Connector

Connect to the second HDBT receiver, (for example, the TP-

580RXR)

HDMI Connector

Connect to the second HDMI receiver, (for example, an HDMI

display)

HDBT OUT 3 RJ-45 Connector

Connect to the third HDBT receiver, (for example, the TP-580RXR)

HDBT OUT 4 RJ-45 Connector

Connect to the fourth HDBT receiver, (for example, the TP-

580RXR)

AUDIO OUT 3.5mm Mini Jack

Connect to an audio receiver, (for example, active speakers)

RS-232

DATA 3-pin Terminal Block

(G,Rx,Tx)

Connect to a serial source/target

CONTROL 3-pin Terminal

Block (G,Rx,Tx)

Connect to a serial controller

PROGRAM USB Connector

Connect to a PC to perform firmware upgrades

ETHERNET RJ-45 Connector

Connect to a PC via a LAN

Mains

Power Socket

Connect the mains power cord

Fuse

AC mains supply protection fuse

Power Switch

Turns the device on and off

HDMI IN 1 Connector

Connect to the first HDMI source, (for example, a Blu-ray disk

player)

HDMI IN 2 Connector

Connect to the second HDMI source, (for example, a Blu-ray disk

player)

HDMI IN 3 Connector

Connect to the third HDMI source, (for example, a Blu-ray disk

player)

HDMI IN 4 Connector

Connect to the fourth HDMI source, (for example, a Blu-ray disk

player)

IR OUT 3.5mm Mini Jack

Connect to an IR emitter or IR receiver for receiving the combined

IR signals from all HDBT port IR transmissions

IR IN 3.5mm Mini Jack

Connect to an external IR receiver for controlling VS-44DT via an

IR remote controller

Kramer Electronics Ltd.

VS-44DT –Mounting VS-44DT

Mounting VS-44DT

This section provides instructions for mounting VS-44DT. Before installing, verify that the

environment is within the recommended range:

•Operation temperature –0to 40C (32 to 104F).

•Storage temperature –-40to +70C (-40 to +158F).

•Humidity –10% to 90%, RHL non-condensing.

•VS-44DT must be placed upright in the correct horizontal position.

Caution:

•Mount VS-44DT before connecting any cables or power.

Warning:

•Ensure that the environment (e.g., maximum ambient temperature & air flow) is

compatible for the device.

•Avoid uneven mechanical loading.

•Appropriate consideration of equipment nameplate ratings should be used for avoiding

overloading of the circuits.

•Reliable earthing of rack-mounted equipment should be maintained.

To mount the VS-44DT on a rack

Attach both ear brackets by removing the screws from each side of the

machine and replacing those screws through the ear brackets or place

the machine on a table.

For more information go to www.kramerav.com/downloads/VS-44DT.

Kramer Electronics Ltd.

VS-44DT –Connecting the VS-44DT

Connecting the VS-44DT

Always switch off the power to each device before connecting it to your VS-44DT. After

connecting your VS-44DT, connect its power and then switch on the power to each device.

Figure 3: Connecting the VS-44DT 4x4 HDMI/HDBT Matrix Switcher

To connect the VS-44DT as illustrated in the example in Figure 3:

1. Connect the HDMI sources, (for example, Blu-ray players) to the HDMI IN 1 and IN 2

connectors.

2. Connect an external IR sensor to the IR 3 IN 3.5mm mini jack.

3. Connect the IR 1 OUT 3.5mm mini jack to an external IR emitter.

4. Connect the OUT 2 HDMI connector to an HDMI acceptor, (for example, a display).

5. Connect the OUT 1 HDBT RJ-45 connector to a compatible HDBT receiver, (for

example, the TP-580Rxr), and connect the HDMI output of the

TP-580Rxr to a display.

6. Connect the OUT 3 HDBT RJ-45 connector to a compatible HDBT receiver, (for

example, the TP-580Rxr), and connect the HDMI output of the

TP-580Rxr to a display.

7. Connect the AUDIO OUT 3.5mm mini jack to an audio acceptor, (for example, active

speakers).

8. Connect a controller via either RS-232 or a LAN to the Ethernet RJ-45 connector.

Kramer Electronics Ltd.

VS-44DT –Connecting the VS-44DT

Connecting the VS-44DT to a Serial Controller

You can connect the VS-44DT via an RS-232 connection to a serial controller, for example, a

PC.

To connect the VS-44DT via RS-232 to a serial controller:

•Connect the RS-232 CONTROL 3-pin terminal block on the rear of the

VS-44DT to the 9-pin D-sub connector on PC, (pin TX to pin 2, pin RX to pin 3, pin G to

pin 5).

Connecting the VS-44DT to a Serial Data

Source/Acceptor

You can connect the VS-44DT via an RS-232 connection to a serial data source or acceptor,

for example, a PC or device to be controlled.

To connect the VS-44DT via RS-232 to a serial data controller or acceptor:

•Connect the RS-232 DATA 3-pin terminal block on the rear of the

VS-44DT to the 9-pin D-sub connector on PC, (pin TX to pin 2, pin RX to pin 2, pin G to

pin 5).

Connecting to the VS-44DT via Ethernet

You can connect to the VS-44DT via Ethernet using either of the following methods:

•Directly to the PC using a crossover or straight cable (see Connecting the Ethernet Port

Directly to a PC on page 8).

•Via a network hub, switch, or router, using a straight-through cable (see Connecting the

Ethernet Port via a Network Hub or Switch on page 10).

Note: If you want to connect via a router and your IT system is based on IPv6, speak to your

IT department for specific installation instructions.

Connecting the Ethernet Port Directly to a PC

You can connect the Ethernet port of the VS-44DT directly to the Ethernet port on your PC

using a crossover or straight cable with RJ-45 connectors.

This type of connection is recommended for identifying the VS-44DT

with the factory configured default IP address.

After connecting the VS-44DT to the Ethernet port, configure your PC as follows:

1. Click Start > Control Panel > Network and Sharing Center.

2. Click Change Adapter Settings.

Otros manuales para VS-44DT

Tabla de contenidos

Otros manuales de Conmutador de matriz de Kramer

Kramer

Kramer Sierra Video 1616V3S Manual de usuario

Kramer

Kramer VS-3232A Manual de usuario

Kramer

Kramer XL 1616V4 Manual de usuario

Kramer

Kramer Sierra Video 6432V5Sxl Manual de usuario

Kramer

Kramer Cobra MX-88 Manual de usuario

Kramer

Kramer VS-44HC Manual de usuario

Kramer

Kramer Sierra Video 1204V5S Manual de usuario

Kramer

Kramer VS-62HA Manual de usuario

Kramer

Kramer VS-6YC Manual de usuario

Kramer

Kramer VS-6464DN Manual de usuario

Kramer

Kramer Sierra Pro XL 1608V3S Manual de usuario

Kramer

Kramer Sierra Video 1616V5S Manual de usuario

Kramer

Kramer 1608HD Manual de usuario

Kramer

Kramer VS-42HN Manual de usuario

Kramer

Kramer 3216S Manual de usuario

Kramer

Kramer XL 1208V2S Manual de usuario

Kramer

Kramer VP-81SID Manual de usuario

Kramer

Kramer VS-88HN Manual de usuario

Kramer

Kramer Sierra Video 4864V5Sxl Manual de usuario

Kramer

Kramer 88HD Manual de usuario

Kramer

Kramer VP-8x8A Manual de usuario

Kramer

Kramer VS-1616V Manual de usuario

Kramer

Kramer MTX3-16-M Manual de usuario

Kramer

Kramer 6464V5XL Manual de usuario

Manuales populares de Conmutador de matriz de otras marcas

Broadcast Tools

Broadcast Tools SS 8.2 Manual de usuario

Altimium

Altimium MATF32 Manual de usuario

ALFAtron

ALFAtron ALF-MUK44N Manual de usuario

Monoprice

Monoprice Blackbird 15377 Manual de usuario

PTN

PTN FMX12 Manual de usuario

CYP

CYP nT15GX01 Manual de usuario

TESmart

TESmart HMA0402A40 Manual de usuario

Octava

Octava HD4XSTPMX Manual de usuario

Intelix

Intelix FLX-88 Instrucciones de funcionamiento

Roland

Roland XS-1HD Manual de usuario

Atlona

Atlona AT-HDMI-22M Manual de usuario

Link

Link HD8X8 Manual de usuario

AMX

AMX AVS-OP-2020-117 Instrucciones y recetas

Lindy

Lindy 38042 Manual de usuario

Extron electronics

Extron electronics MTPX Plus Series Manual de usuario

Key Digital

Key Digital Champion KD-16x16CS Manual de usuario

Shinybow USA

Shinybow USA SB-8811 Manual de usuario

Optimus

Optimus Compact Manual de usuario
