Kramer MultiTOOLS 850 Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

850

Pattern Generator

P/N: 2900-300033 Rev 2

850 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the 850 DisplayPort Pattern Generator 4

4Connecting the 850 6

4.1 Connecting a PC 7

5Operating the 850 Pattern Generator 11

5.1 Operating the 850 Using the Front Panel Buttons 12

5.2 Operating the 850 Using the Control Application 13

6Technical Specifications 21

7Communication Parameters 22

8Serial Protocol 23

8.1 Command Format 23

8.2 Device Response 23

8.3 Commands 24

Figures

Figure 1: 850 Pattern Generator Front Panel 4

Figure 2: 850 Pattern Generator Rear Panel 5

Figure 3: Connecting the 850 Pattern Generator 6

Figure 4: Found New Hardware Wizard Window 8

Figure 5: File Location Selection Window 9

Figure 6: Insert Disk Window 10

Figure 7: Connection Method Window 13

Figure 8: Connection Error Message 14

Figure 9: Controller Software Main Window 15

Figure 10: The Menu Bar 16

Figure 11: About 16

Figure 12: User Defined Resolution Window–Standard Tab 17

Figure 13: User Defined Resolution Advanced Window–Additional Tab 18

Figure 14: User Defined Resolution Advanced Window–Timing Parameters Tab 19

Figure 15: User Defined Resolution Advanced Window–EDID Tab 20

850 - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix

Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;

GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;

GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and

GROUP 11: Sierra Products.

Congratulations on purchasing your Kramer MultiTOOLS®850 DisplayPort Pattern

Generator, which is ideal for the following typical applications:

As a diagnostic tool in AV setups

Testing and adjusting flat panel LCD displays, projectors, plasmas and

DisplayPort cables

Testing the refresh rates of LCD displays by using the motion patterns

850 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance, high resolution cables

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to

check if firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer 850 DisplayPort Pattern Generator away from

moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

850 - Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or

incineration by requiring it to be collected and recycled. To comply with the

WEEE Directive, Kramer Electronics has made arrangements with the

European Advanced Recycling Network (EARN) and will cover any costs of

treatment, recycling and recovery of waste Kramer Electronics branded

equipment on arrival at the EARN facility. For details of Kramer’s recycling

arrangements in your particular country go to our recycling pages at

http://www.kramerelectronics.com/support/recycling/.

850 - Overview

3 Overview

The 850 is a high performance, DisplayPort video test pattern generator. It can

generate 32 preset patterns at 16 popular, predefined, computer and HD video

resolutions and seven user-defined resolutions, including several unique patterns

incorporating motion.

In particular, the MultiTOOLS®850 features:

A DisplayPort output

Five dual-function and two single-function control buttons

A two-digit 7 segment display

An onboard EPROM that saves the last setting

3.1 Defining the 850 DisplayPort Pattern Generator

Figure 1 defines the front panel of the 850.

Figure 1: 850 Pattern Generator Front Panel

850 Front Panel Features

Feature

Function

FUNCTION

Buttons

ON/OFF

Press to toggle between the top row and bottom row functions.

Button LED lights when on.

When on, the top row of functions are enabled (RES, PAT, CS and

Delay). When off, the bottom row of functions (HDCP, DC, ASF

and ASD) are enabled (see Section 5.1)

RES/HDCP

Press to select either the Resolution (when the ON/OFF button is

on) or HDCP functions (when the ON/OFF button is off)

PAT/DC

Press to select either the Pattern (when the ON/OFF button is on)

or Color Depth functions (when the ON/OFF button is off)

850 - Overview

850 Front Panel Features

Feature

Function

CS/ASF

Press to select either the Color Space (when the ON/OFF button is

on) or Audio Sample Frequency functions (when the ON/OFF

button is off)

DELAY/ASD

Press to select either the Delay (when the ON/OFF button is on) or

Audio Sample Data functions (when the ON/OFF button is off)

2-digit 7-segment Display

Indicates the current setting. The display flashes if there is a

problem communicating with the display, for example, if the display

does not support HDCP or does not support the selected resolution

ON LED

Lights red when the device receives power

–Button

Press to step down through the list of available values

+Button

Press to step up through the list of available values

Figure 2 defines the rear panel of the 850.

Figure 2: 850 Pattern Generator Rear Panel

850 Rear Panel Features

Feature

Function

DP OUT Connector

Connect to the DisplayPort acceptor (see Section 4)

RS-232 9-pin D-sub

Connector

Connect to the serial port on a PC for remote control (see

Section 4.1.1)

USB Connector

Connect to a USB port on a PC for remote control

5V DC Connector

Connect to the power adapter

850 - Connecting the 850

4 Connecting the 850

Always switch off the power to any device before connecting it to your

850. After connecting your 850, connect its power and then switch on

the power to the device.

To connect the 850 as illustrated in the example in Figure 3:

1. Connect the DP OUT connector to a DisplayPort acceptor (for example, a

flat panel LCD display).

2. Optional—connect a PC to control the 850 via the RS-232 or USB port.

3. Connect the power adapter to the 5V DC socket and to the mains electricity.

Figure 3: Connecting the 850 Pattern Generator

850 - Connecting the 850

4.1 Connecting a PC

You can connect to the 850 via the RS-232 serial and via the USB port.

4.1.1 Connecting a PC via the RS-232 Serial Port

You can connect to the 850 via an RS-232 connection using, for example, a PC.

Note that a null-modem adapter/connection is not required.

To connect to the product via RS-232:

Connect the RS-232 9-pin D-sub rear panel port on the product unit via a

9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5

need to be connected) to the RS-232 9-pin D-sub port on your PC

4.1.2 Connecting a PC via the USB Port

To connect the 850 via a USB port you must download and install the USB driver

and 850 Control application.

Note: The driver only works on 32-bit systems.

To install the USB driver and Control Application:

1. Navigate to the Kramer Electronics Web site

(http://www.kramerelectronics.com) and search for the product 850.

2. Click on the Downloads tab.

3. Download the 850 Windows USB Driver.

4. Download the 850 Control Application to a designated folder on your

computer.

5. Extract the compressed USB driver file to your designated folder.

Two files are extracted, a .inf and a .sys file.

6. Connect the USB cable between your computer and the 850.

7. Connect the power supply to the 850.
