Kramer VP-210K Manual de usuario

Kramer Electronics, Ltd.

USER MANUAL







Model:

VP-210K

UXGA Line Amplifier

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

Your VP-210K UXGA Line Amplifier 4

Connecting the VP-210K UXGA Line Amplifier 5

Technical Specifications 6

Figures

Figure 1: VP-210K UXGA Line Amplifier 4

Figure 2: Connecting the VP-210K UXGA Line Amplifier 6

Tables

Table 1: VP-210K UXGA Line Amplifier Features 5

Table 2: Technical Specifications of the VP-210K UXGA Line Amplifier 6

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Thank you for purchasing your Kramer TOOLS VP-210K UXGA Line

Amplifier, which is ideal for:

Dual monitor systems, local or remote (loop and output)

Presentation systems for remote transmission and cable

equalization

The package includes the following items:

VP-210K UXGA Line Amplifier

Power adapter (5V DC input) and this user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high-performance high-resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The high-performance VP-210K is a line amplifier for UXGA

computer

graphics signals that provides controls to compensate for signal losses

inherent in long cable runs.

In particular, the VP-210K UXGA Line Amplifier features:

Video bandwidth of 350MHz, ensuring that it remains transparent

for all resolutions

HDTV compatibility

Separate controls for output level and cable equalization, and

independent input signal termination for red, green and blue

A looping input

KR-ISP™ advanced sync processing that ensures compatibility

with a wide range of computers (even if the sync level is too low)

by restoring the sync signal waveform

To achieve the best performance:

Use only good quality connection cables

to avoid interference,

deterioration in signal quality due to poor matching, and elevated

noise levels (often associated with low quality cables).

Avoid interference from neighboring electrical appliances that

may adversely influence signal quality and position your Kramer

VP-210K away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 XGA, as used in this manual, means any RGBHV signal on a 15-pin HD connector having a resolution from VGA up to

UXGA

2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

3 For example, part number 2535-052002

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-210K UXGA Line Amplifier

4 Your VP-210K UXGA Line Amplifier

Figure 1 and Table 1 define the VP-210K :

Figure 1: VP-210K UXGA Line Amplifier

Connecting the VP-210K UXGA Line Amplifier

Table 1: VP-210K UXGA Line Amplifier Features

# Feature Function

1 LOOP 15-pin HD (F) Connector Connects to a local display

2 OUTPUT 15-pin HD (F) Connector Connects to the computer graphics acceptor

3 HI-Z/75DIP-switches Set to 75TERM (when a local monitor is not used); set to

Hi-Z (when a local monitor is connected to the LOOP 15-pin

HD connector)

4 5V DC +5V DC connector for powering the unit

5 EQ. Control knob Adjusts the video EQ. (equalization) compensation

6 LEVEL Control knob Adjusts the video signal level

7 INPUT 15-pin HD (F) Connector Connect to the computer graphics source

8 ON LED Illuminates when receiving power

5 Connecting the VP-210K UXGA Line Amplifier

To connect your VP-210K UXGA Line Amplifier, as shown in the example in

Figure 2, do the following

1. Connect a computer graphics source (for example, a computer) to the

INPUT 15-pin HD (F) connector.

2. Connect the OUTPUT 15-pin HD (F) connector to an acceptor (for

example, a projector).

3. Connect the LOOP 15-pin HD (F) connector to an acceptor (for

example, a local display).

4. Connect the 5V DC power adapter to the 5V DC socket and connect the

transformer to the mains electricity (not illustrated in Figure 2).

5. Adjust the video output signal level and/or cable compensation equalization

level as needed.

6. Set the DIP-switches as follows:

If no terminal is attached to the LOOP connector, set the

switches down to 75TERM

If a terminal is attached to the LOOP connector, set the

switches up to HI-Z

1 Switch OFF the power on each device before connecting it to your VP-210K. After powering up your VP-210K, switch on

the power on each device

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

Figure 2: Connecting the VP-210K UXGA Line Amplifier

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications

of the VP-210K UXGA Line Amplifier

INPUT: 1 UXGA on a 15-pin HD (F) connector

OUTPUT: 1 UXGA on a 15-pin HD (F) connector

1 LOOP UXGA on an 15-pin HD (F) connector

VIDEO BANDWIDTH (-3dB): 350MHz

DIFF. GAIN: 0.41%

DIFF. PHASE: 0.53°

VIDEO S/N RATIO: 66dB

K-FACTOR: <0.05%

CONTROLS: Level: -1.2 to +6.3dB; EQ: 0 to +4dB @50MHz

POWER SOURCE: 5V DC, 108mA

DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H

WEIGHT: 0.25kg (0.55lbs) approx.

ACCESSORIES: Power supply, mounting brackets

OPTIONS: 19" rack adapters

1 Specifications are subject to change without notice

Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: [email protected]

P/N: 2900-000482 REV 1

For the latest information on our products and a list of Kramer

distributors, visit our Web site: www.kramerelectronics.com,

where updates to this user manual may be found.

We welcome your questions, comments and feedback.

Caution

Safety Warning:

Disconnect the unit from the power supply before

opening/servicing.

PN:

2900- 000482

Rev:
