Kramer TOOLS VP-210XL Manual de usuario

Kramer Electronics, Ltd.

USER MANUAL







Model:

VP-210xl

XGA Line Amplifier

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

Your VP-210XL XGA Line Amplifier 4

Connecting the VP-210XL XGA Line Amplifier 6

Technical Specifications 8

Figures

Figure 1: VP-210XL XGA Line Amplifier 4

Figure 2: VP-210XL XGA Line Amplifier (Underside) 5

Figure 3: Connecting the VP-210XL XGA Line Amplifier 7

Tables

Table 1: VP-210XL XGA Line Amplifier Features 4

Table 2: VP-210XL XGA Line Amplifier (Underside) Features 5

Table 3: Technical Specifications of the VP-210XL XGA Line Amplifier 8

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function. Congratulations on purchasing your Kramer TOOLS VP-210

XGA Line Amplifier, which is ideal for:

Dual monitor systems, local or remote

Presentation systems for remote transmission and cable equalization

The package includes the following items:

VP-210

XGA Line Amplifier

Power adapter (12V DC input) and this user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The high performance VP-210

is a line amplifier for XGA

computer

graphics signals that provides controls to compensate for signal losses

inherent in long cable runs.

In particular, the VP-210

XGA Line Amplifier:

Features a video bandwidth of 380MHz, ensuring that it remains

transparent for all resolutions

Is HDTV compatible

Includes separate controls for output level and cable equalization, ID Bit

control, and independent input signal termination for red, green and blue

Has a looping input

Achieving the best performance means:

Connecting only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching, and

elevated noise levels (often associated with low quality cables)

Avoiding interference from neighboring electrical appliances and

positioning your VP-210

away from moisture, excessive sunlight and

dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an HD15 connector

having a resolution from VGA up to UXGA

2 For example: model number AD2512C, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-210xl XGA Line Amplifier

4 Your VP-210

XGA Line Amplifier

Figure 1 and Table 1 define the VP-210

Figure 1: VP-210XL XGA Line Amplifier

Table 1: VP-210XL XGA Line Amplifier Features

# Feature Function

1 LOOP HD15F Connector Connect to a local display

2 INPUT HD15F Connector Connect to the computer graphics source

3 OUTPUT HD15F Connector Connect to the computer graphics acceptor

4 LEVEL Control knob Adjusts the video signal level

5 EQ. Control knob Adjusts the video EQ. (equalization) compensation

6 ON LED Illuminates when receiving power

7 12V DC +12V DC connector for powering the unit

Your VP-210xl XGA Line Amplifier

Figure 2 and Table 2 define the underside of the VP-210

Figure 2: VP-210XL XGA Line Amplifier (Underside)

Table 2: VP-210XL XGA Line Amplifier (Underside) Features

# Feature Function

1 ID Bit Switch Slide up to set to ON

; down to set to OFF

2 BLUE

GREEN



TERM /

Hi-Z

Switches RED

Slide up to set to 75TERM (when a local monitor

is not used); down to set to Hi-Z (when a local

monitor is connected

)

1 The default. Enabling the notebook or laptop to output a VGA signal to an external VGA monitor

2 To the LOOP HD15F connector

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VP-210xl XGA Line Amplifier

5 Connecting the VP-210

XGA Line Amplifier

To connect your VP-210

XGA Line Amplifier, as the example in Figure 3

illustrates, do the following

1. Connect a computer graphics source (for example, a computer) to the

INPUT HD15F connector.

2. Connect the OUTPUT HD15F connector to an acceptor (for example, a

projector).

3. Connect the LOOP HD15F connector to an acceptor (for example, a local

display).

4. Connect the 12V DC power adapter to the 12V DC socket and connect

the transformer to the mains electricity (not illustrated in Figure 3).

5. If required, adjust the video output signal level and/or cable compensation

equalization level, and/or set the:

Red, green and blue signal termination switches on the underside

ID Bit switch to ON

1 Switch OFF the power on each device before connecting it to your VP-210

. After powering up your VP-210

, switch on

the power on each device

Connecting the VP-210xl XGA Line Amplifier

Figure 3: Connecting the VP-210XL XGA Line Amplifier

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

Table 3 includes the technical specifications:

Table 3: Technical Specifications

of the VP-210XL XGA Line Amplifier

INPUT: 1 XGA on an HD15F connector

OUTPUT: 1 XGA on an HD15F connector

1 LOOP XGA on an HD15F connector

VIDEO BANDWIDTH (-3dB): 380MHz

DIFF. GAIN: 0.05%

DIFF. PHASE: 0.03°

VIDEO S/N RATIO: 74.8dB

K-FACTOR: 0.05%

CONTROLS: Level: 0 to +6dB, EQ.: 0 to +8dB @ 50MHz

POWER SOURCE: 12VDC, 60mA

DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H

WEIGHT: 0.25kg. (0.55lbs) approx.

ACCESSORIES: Power supply, mounting brackets

OPTIONS: 19" rack adapters

1 Specifications are subject to change without notice
