aFLAT-Series

CRTtoLCD-6-SM

Technical Manual (Preliminary)

Table of Contents

1.0 General Information and Important Notes

1.1 Introduction

1.2 Technical Information Summary

1.3 Configuration

1.4 Connectors

1.5 OnScreen Display

1.6 Serial OSD

1.7 Technical Specification

1.8 Supported Video Modes

1.9 Layout / Dimensions

2.0 Technical Support

2.1 Revision History

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 2 of 18

1.0 User Information

In this document Kontron Hamburg GmbH & Co.KG will also be referred to

by the short form “Kontron Hamburg”.

The information in this document has been carefully checked and is

believed to be accurate and reliable. However, no responsibility is

assumed for inaccuracies. Furthermore, Kontron Hamburg reserves the

right to make changes to any portion of this manual to improve reliability,

function or design. Kontron Hamburg does not assume any liability for any

product or circuit described herein.

1.0 Trademarks

AT and IBM are trademarks of International Business Machines.

XT, AT, PS/2 and Personal System/2 are trademarks of International

Business Machines Corporation.

Microsoft is a registered trademark of Microsoft Corporation.

Intel is a registered trademark of Intel Corporation.

All other products and trademarks mentioned in this manual are

trademarks of their respective owners.

The reproduction, transmission or use of this document or its contents is

not permitted without expressed written authority.

Offenders will be liable for damages. All rights created by patent grant or

registration of a utility model or design, are reserved.

1.0 General

For the circuits, descriptions and tables indicated no responsibility is

assumed as far as patents or other rights of third parties are concerned.

The information in the Technical Descriptions describes the type of the

boards and shall not be considered as assured characteristics.

The reproduction, transmission or use of this document or its contents is

not permitted without express written authority. Offenders will be liable for

damages. All rights, including rights created by patent grant or registration

of a utility model or design, are reserved.

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 3 of 18

1.0 Warranty

Each board is carefully and thoroughly tested before being shipped. If,

however, problems should occur during the operation, please check your

user specific settings of all boards included in your system. This is often

the source of the fault. If a board is defective, it can be sent to your supplier

for repair. Please take care of the following steps:

- The board returned should correspond to the factory default

settings since a test is only possible under this settings.

- In order to repair your board as fast as possible , we require some

additional information from you. Please fill out the attached Repair

Form and include it with the defective board.

- If possible, the board will be upgraded to the latest version without

additional cost.

- Upon receipt of the board, please be aware that your user specific

settings were changes during the test.

Within the guarantee, the repair is free as long as the guarantee conditions

were kept. If no fault has been found, you will be charged with the test cost

due to the high test expenditure. Repairs outside of the guarantee will be

charged.

This Kontron Hamburg product is warranted against defects in material and

workmanship for our guaranteed warranty period from the date of

shipment. During the warranty period, Kontron Hamburg will, at its option,

either repair or replace products which prove to be defective.

For warranty service or repair, the product must be returned to a service

facility designated by Kontron Hamburg.

The foregoing warranty shall not apply to defects resulting from improper or

inadequate maintenance or handling by buyer, unauthorized modification

or misuse, operation outside of the environmental specifications for the

product, or improper installation or maintenance.

Kontron Hamburg will not be responsible for any defects or damages due

to a faulty Kontron Hamburg product other than the products supplied by

Kontron Hamburg.

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 4 of 18

1.1 Introduction

The CRTtoLCD-6-SM is a highly integrated TFT panel interface controller,

which allows an easy adaptation of standard analog video sources to a

TFT panel with LVDS interface. The CRTtoLCD-6-SM needs only one

single 12V DC power supply and incorporates all needed functionality,

including optional 4,5 or 8 wire touch controller for USB or PS/2 interfaces,

to build up a full featured TFT monitor. The card generates the necessary

power sequencing for the flat screen. The highly flexible architecture of the

CRTtoLCD-6-SM panel interface allows adapting nearly any available TFT

panel. Therefore a variety of panel adapters and programming are

available on request.

1.2 Technical Information Summary

Analog-Input Features :

- Fully integrated 162 MHz 8-bit triple-ADC, PLL and pre-amplifier

- On-chip programmable OSD engine

- Integrated PLLs

- 10-bit programmable gamma correction

Integrated Analog Front End

- Integrated 8-bit triple ADC

- Up to 162 MHz sampling rates

- No additional components needed

- All color depths up to 24-bits/pixel are supported

High-Quality Advanced Scaling

- Fully programmable zoom

- Independent horizontal / vertical zoom

- Enhanced and adaptive scaling algorithm for optimal image quality

- Recovery Mode / Native Mode

Input Format

- Analog RGB VGA up to SXGA (75 Hz)

- Shrink from UXGA (60 Hz)

Operating Modes

- Bypass mode with no filtering

- Multiple zoom modes: - with filtering, - with adaptive (ACE) filtering

Integrated On-Screen Display

- On-chip character RAM and ROM for better customization

- Optional external OSD supported for greater flexibility

- Supports both landscape and portrait fonts

- Many other font capabilities including: blinking, overlay and transparency

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 5 of 18

1.2 Technical Information Summary

Output Format

- Support for 8 or 6-bit panels (with high quality dithering)

- One and dual port LVDS

- Output up to SXGA (75 Hz)

Built In High-Speed Clock Generator

- Fully programmable timing parameters

- On-chip PLLs generate clocks for the on-chip

- ADC and pixel clock from a single reference oscillator

Auto-Configuration / Auto-Detection

- Phase and image positioning

- Input format detection

Display Interface Features :

- Control signal generation for backlight inverter

- backlight dimming support ( Analog or optional PWM )

- voltage generation and power sequence control for panel

- Flat screens can be used with either 3.3V or 5V.

- LVDS panel interface ( one and dual port up to 24 Bit )

Operating Features :

- 5 or 6 button user interface

- On Screen Display ( OSD ) control for all features

- Full multi sync capable

- VESA DPMS and DDC2B support

- Single voltage supply ( +12V DC )

- Dynamic Power Management for minimal power consumption via DPMS

- No software drivers needed!

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 6 of 18

1.3.0 Configuration

R21 R20 R19 R18 Description Delivery

Default

Open Open Open Open Automatic Paneldetection Default

Short Open Open Open Reserved

Open Short Open Open Sharp LQ150X1LW71N

Open Open Short Open Samsung LTM150XH-L01

Open Open Open Short Chi Mei M170E6-L01

Chi Mei M190E2-L01

1.3.0 Configuring the LVDS-Interface

The LVDS-Interface must be configured for the flatpanel specific timings, updating the

board with specific panel files is done via the serial OSD feature. The panel files are

distributed via the internet database www.kontron-hh.com.

Notice : Please check carefully panel voltage supply and adjust R16/R17 (see 1.4.7) equal to

flat panel requirements.

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 7 of 18

1.4 Connectors

1.4.1 RGB analog input X1

1.4.2 OSD keypad connector X2

1.4.3 Backlight connector X5

1.4.4 LVDS-Interface X4

1.4.5 DC Power supply for XGA - Flatpanel X3

1.4.6 DC Power supply for SXGA - Flatpanel X3

1.4.7 Backlight/Flatpanel power supply configuration R15, R16, R17, R24, R26

1.4.8 Backlight control configuration R22, R23

1.4.9 4/5/8 wire touch screen connector X7

1.4.10 USB / PS2 Interface connector X8

1.4.11 Serial Port X6

1.4.1 RGB analog input X1

Connector: JST S13B-PH-SM3-TB

Matching Connector: JST PHR-13

Name Pin

Description

H_Sync 1 O

Horizontal Sync

Sync_GND 2 O

Sync Ground

V_Sync 3 O

Vertical Sync

NC 4 O

Not connected

DB_Blue 5 O

Analog Input Blue

BGND 6 O

Analog Ground Blue

DB_Green 7 O

Analog Input Green

GGND 8 O

Analog Ground Green

DB_Red 9 O

Analog Input Red

RGND 10 O

Analog Ground Red

DB_SCL 11 O

DDC serial clock

DB_SCD 12 O

DDC serial data

DB_Det 13 O

GND

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 8 of 18

1.4.2 OSD keypad connector X2

Connector: Molex 53261-1490

Matching Connector: Molex 51021-1400

Name Pin

Description

LED2 1 O

Red LED

LED1 2 O

Green LED

KGND 3 O

Key Power Ground

KEY1 4 O

Key 1 Button( Power )

KGND 5 O

Key Power Ground

KEY2 6 O

Key 2 Button( Menu )

KEY3 7 O

Key 3 Button( Right )

NC 8 O

Not Connected

NC 9 O

Not Connected

KEY6 10 O

Key 6 Button( Left )

KEY7 11 O

Key 7 Button( Exit )

KEY8 12 O

Key 8 Button( Autoadjust )

KGND 13 O

Key Power Ground

KVDD 14 O

+ 3.3 V DC Power

Key Active = Button connected to Power Ground

1.4.3 Backlight Connector X5

Apply operating voltage for backlight inverter using

connector X5

Connector Single Row, 7 Contacts, Case/Size : Right Angle, 1,25mm Pitch,

Connector: Molex 53261-1090

Matching Connector: Molex 51021-1000

Pin Name Description

X5 O

1BLON Backlight control signal (TTL), see 1.4.8

2GND Power Ground

3GND Power Ground

4Backlight power supply 5 / 12 V DC see 1.4.7

5Backlight power supply 5 / 12 V DC see 1.4.7

6Backlight power supply 5 / 12 V DC see 1.4.7

7Backlight power supply 5 / 12 V DC see 1.4.7

O 8GND Power Ground

O 9GND Power Ground

O 10 Backlight dimming control ( analog signal 0V to 4.9V)

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 9 of 18

1.4.4 LVDS-Interface X4

Connector: JAE FI-X30S-HF

Matching Connector: JAE FI-X30H

Name Pin

Description

FTX0- 1 O

Even Receiver Signal

FTX0+ 2 O

Even Receiver Signal

FTX1- 3 O

Even Receiver Signal

FTX1+ 4 O

Even Receiver Signal

FTX2- 5 O

Even Receiver Signal

FTX2+ 6 O

Even Receiver Signal

GND 7 O

Power Ground

FTXC- 8 O

Even Clock Signal

FTXC+ 9 O

Even Clock Signal

FTX3- 10 O

Even Receiver Signal

FTX3+ 11 O

Even Receiver Signal

STX0- 12 O

Odd Receiver Signal

STX0+ 13 O

Odd Receiver Signal

GND 14 O

Power Ground

STX1- 15 O

Odd Receiver Signal

STX1+ 16 O

Odd Receiver Signal

GND 17 O

Power Ground

STX2- 18 O

Odd Receiver Signal

STX2+ 19 O

Odd Receiver Signal

STXC- 20 O

Odd Clock Signal

STXC+ 21 O Odd Clock Signal

STX3- 22 O Odd Receiver Signal

STX3+ 23 O Odd Receiver Signal

GND 24 O Power Ground

PID_0 25 O Panel ID 0

PPWR 26 O Controls Panel Digital Power

PID_1 27 O Panel ID 1

PANEL_VCC 28 O Panel Power (see 1.4.7)

PANEL_VCC 29 O Panel Power (see 1.4.7)

PANEL_VCC 30 O Panel Power (see 1.4.7)

Kontron Hamburg GmbH & Co.KG

Marschnerstieg 7

22081 Hamburg / Germany

Fon: +49 (0)40 20 00 90-0

Fax: +49 (0)40 20 00 90-10

http://www.kontron-hh.com

CRTtoLCD-6-SM

15.04.2004 Page 10 of 18

1.4.5 DC power supply X3 for XGA - Flatpanel

Apply operating voltage using connector X3.

Connector: YeonHo 40006WR-02A00

Matching Connector: YeonHo 40006HS-02

Pin Name Description

X3 O 1 GND Power Ground

O 2 +12V In +12 V DC Power In

1.4.6 DC power supply X3 for SXGA-Flatpanel

Apply operating voltage using connector X3.

Connector: Hirose DF3D-2P-2H

Matching Connector: Hirose DF3-2S-2C

Pin Name Description

X3 O 1 GND Power Ground

O 2 +12V In +12 V DC Power In

1.4.7 Backlight and flatpanel power configuration

This configuration is only valid for X4 and X5.

Short pins R15 or R16 or R17 or R24 or R26 to choose required

voltage supply.

Caution ! Only one configuration for backlight and flatpanel is

allowed, otherwise the board is permanently damaged.

Resistor Name Description Delivery Default

R15 +12V +12V DC Power for flatpanel power Open

R16 VCC + 5V DC Power for flatpanel power Short for 5V DC

Flatpanel

R17 +3,3V + 3.3V DC Power for flatpanel power Short for 3.3V

Flatpanel

R24 VCC + 5V DC Power for backlight power Open

R26 +12V +12V DC Power for backlight power Short

1.4.8 Backlight control configuration

Use to control polarity of backlight control signal of X5

R23 Short R22 Short Delivery Default

/BLON BLON

R23 open

R22 Short

Never short R23 and R22 at the

same time! This will cause damage

to the system!

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Kontron

Kontron

Kontron BL Pi-Tron CM3+ Manual de usuario

Kontron

Kontron nanoETXexpress-SP Manual de usuario

Kontron

Kontron ADA-SDVO-PEG16 Manual de usuario

Kontron

Kontron KBox E-200 Series Manual de usuario

Kontron

Kontron COMe-bP5020 Manual de usuario

Kontron

Kontron 082-0220-00 Backplane Manual de usuario

Kontron

Kontron microETXexpress-SP Manual de usuario

Kontron

Kontron SMARC-sAMX8 Manual de usuario

Kontron

Kontron COMe-cEL6 Manual de usuario

Kontron

Kontron COMe-cDC2 Manual de usuario

Kontron

Kontron COMh-caRP Manual de usuario

Kontron

Kontron COMh-caRP Manual de usuario

Kontron

Kontron cPCI-DMXS64GX Manual del producto

Kontron

Kontron PC/104-PCMCIA-1 Manual de usuario

Kontron

Kontron COMh-caRP Manual de usuario

Kontron

Kontron COMe-mSP1 Manual de usuario

Kontron

Kontron AT8060 Manual de usuario

Kontron

Kontron KTQ77/Flex Manual de usuario

Kontron

Kontron CP6500-V Manual de usuario

Kontron

Kontron CP3002-RC Manual de usuario

Kontron

Kontron cPCI-MXS64GX Manual del producto

Kontron

Kontron PCI-946-1 Manual del producto

Kontron

Kontron CP6016 Manual de usuario

Kontron

Kontron CP3003-SA Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario

Advantech

Advantech ASMB-935 Series Manual de usuario

Jupiter

Jupiter RAM PACK Manual de usuario

Kontron aFLAT Series Manual de usuario

Manuales populares de Hardware de computadora de otras marcas
