Kohler Mariposa K-1257-W1 Manual de usuario

Features

•Bask®heated surface creates spa-like relaxation with soothing

warmth on your back and neck.

•Three heat settings allow you to customize the surface

temperature.

•Single-speed whirlpool offers performance and value, with 5

fully adjustable jets.

•Hydromassage flow and direction can be controlled at each jet.

•Generous 6-foot length provides spacious bathing for up to two

people.

•Textured bottom surface

•Reversible drain.

Material

•Acrylic

Hydrotherapy

•Whirlpool

Codes/Standards

Installation ASME A112.19.7/CSA B45.10

•Drop-in CSA B45.5/IAPMO Z124

Additional Hydrotherapy Options ASTM E162

ASTM E662

•Soaking Bath - 1259-0 UL 1795

•Soaking Bath + Bask heated surface - 1259-W1 Greenguard UL 2818 - Gold

•BubbleMassage air bath - 1257-G

•BubbleMassage air bath + Bask heated surface - 1257-GW KOHLER®Plastic Baths and Receptors

Lifetime Limited Warranty

•VibrAcoustic - 1257-VB

•VibrAcoustic + Bask heated surface - 1257-VBW KOHLER®Hydrotherapy Components

Five-Year Limited Warranty

•Whirlpool - 1257-0

•Whirlpool + heater - 1257-H See website for detailed warranty information.

•Whirlpool + Bask heated surface - 1257-W1

Recommended Products/Accessories

K-1283 Removable Apron Available Colors/Finishes

K-1491 Bath/Whirlpool Pillow Color tiles intended for reference only.

K-7166-AF Bath Drain DescriptionCodeColor

K-9696 Whirlpool 6-Jet Trim Kit

K-24916 Wireless Music Kit White0

Biscuit96

Almond47

DuneNY

SandbarG9

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

5-25-2019 05:47 - US/CA

Mariposa®

6' Whirlpool Bath

K-1257-W1

20"

Notes

Required Electrical Service Measure your actual product for rough-in details.

One dedicated circuit required, protected with Class A

Ground-Fault Circuit-Interrupter (GFCI). Outside North America,

this device may be known as a Residual Current Device (RCD).

Install this product according to the installation

instructions.

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

120 V, 15 A, 60 HzPump, Heated

Surface:

Technical Information If installing a rim-mount faucet, make sure there

is no interference above or below the deck before

drilling any holes.

All product dimensions are nominal.

Drop-inInstallation:

EndDrain location:

50" x 24" (1270 mm x 610 mm)Basin area, bottom:

65" x 27" (1651 mm x 686 mm)Basin area, top:

116 lbs (52.6 kg)Weight:

41 lbs/ft²(200.2 kg/m²)Minimum floor load:

14" (356 mm)Water depth:

72 gal (272.5 L)Water capacity:

Drop-in, 70" x 34" (1778 mm x 864 mm)Cutout:

Pump: 120 V, 7 A, 60 Hz

Heated Surface: 120 V, 0.5 A, 60 Hz, 65

Electrical component

rating:

SinglePump speed:

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

5-25-2019 05:47 - US/CA

Mariposa®

6' Whirlpool Bath

K-1257-W1
