Kohler K-1418 Instrucciones de montaje

Homeowners Guide

Bath Whirlpool

Mproduct numbers are for Mexico (i.e. K-12345M)

Los números de productos seguidos de Mcorresponden a México

(Ej. K-12345M)

Français, page ″Français-1″

Español, página ″Español-1″

K-1418

1022381-5-C

Important Information

INSTRUCTIONS PERTAINING TO A RISK OF FIRE,

ELECTRICAL SHOCK, OR INJURY TO PERSONS

READ AND FOLLOW ALL INSTRUCTIONS

SAVE THESE INSTRUCTIONS

WARNING: When using electrical products, basic precautions should always be followed,

including the following:

DANGER: Risk of personal injury. To reduce the risk of injury, do not permit children to use this

unit unless they are closely supervised at all times.

WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the

whirlpool.

WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,

telephone, radio, or television) within 5’ (1.5 m) of this whirlpool.

WARNING: Risk of hyperthermia. People using medications and/or having an adverse medical

history should consult a physician before using a whirlpool equipped with a heater.

Use this whirlpool only for its intended purpose as described in this manual. Do not use attachments not

recommended by the manufacturer.

Never drop or insert any object into any opening.

Do not operate this unit without the guard (cover) over the suction ﬁtting.

The whirlpool must be connected only to a supply circuit that is protected by a Ground-Fault

Circuit-Interrupter (GFCI) or Residual Current Device (RCD). Such a GFCI or RCD should be provided by

the installer and should be tested on a routine basis. To test the GFCI or RCD, press the test button. The

GFCI or RCD should interrupt power. Press the reset button. Power should be restored. If the GFCI or RCD

fails to operate in this manner, the GFCI or RCD is defective. If the GFCI or RCD interrupts power to the

bath without the test button being pressed, a ground current is ﬂowing, indicating the possibility of an

electric shock. Do not use this whirlpool bath. Disconnect the whirlpool and have the problem corrected by a

qualiﬁed service representative before using.

WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal

hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs

when the internal temperature of the body reaches a level several degrees above the normal body

temperature of 98.6°F (37°C). The symptoms of hyperthermia include an increase in the internal

temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia

include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c)

unawareness of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to

exit the bath, and (f) unconsciousness resulting in the danger of drowning.

IMPORTANT! Flush your whirlpool system twice a month or more depending upon usage, as described

in the ″Flushing Your Whirlpool System″section of this manual.

Do not allow the water temperature in the whirlpool to exceed 104°F (40°C).

Keep small objects such as bath toys and bathing accessories out of the whirlpool while the unit is running.

Repeated use of personal care products containing oils can damage plastic whirlpool components. Do not use

heavy, vegetable-based shampoos or bath oils.

Whirlpool hydro-massage action can cause even a small amount of bubble bath, bath soap, shampoo, or bath

oil to foam excessively. For this reason, please don’t use these products during whirlpool operation.

1022381-5-C 2 Kohler Co.

Table of Contents

Important Information .............................................................. 2

Thank You For Choosing Kohler Company .............................................. 3

Your Kohler Whirlpool ............................................................. 3

User Keypad and Whirlpool Modes/Features ............................................. 4

Optional Remote Control ........................................................... 4

Operating Your Whirlpool ........................................................... 4

Care and Cleaning ................................................................ 5

Flushing Your Whirlpool System ...................................................... 5

One-Year Limited Warranty ......................................................... 5

One-Year Warranty ............................................................... 6

Troubleshooting Procedures ......................................................... 7

Service Parts ................................................................... 10

Thank You For Choosing Kohler Company

Thank you for choosing Kohler Company. Your Kohler Company product reﬂects the true passion for design,

craftsmanship, artistry, and innovation Kohler Company stands for. We are conﬁdent its dependability and

beauty will surpass your highest expectations, satisfying you for years to come.

All information in this guide is based upon the latest product information available at the time of

publication. At Kohler Company, we strive to fulﬁll our mission of improving the level of gracious living for

each person who is touched by our products and services. We reserve the right to make changes in product

characteristics, packaging, or availability at any time without notice.

Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.

Your Kohler Whirlpool

Your new whirlpool is designed to stimulate, invigorate, and energize your body with comforting

hydro-massage therapy. The whirlpool consists of the following components:

Bath - Acts as a reservoir for water, and provides a location for the hydro-massage action.

User Keypad - Located within easy reach, the keypad allows you to turn the whirlpool and heater

on and off and regulate the water ﬂow through the jets.

Pump Motor - Provides quiet, variable speed power to circulate the water and create the soothing

hydro-massage action.

Adjustable Jets - Positioned to optimize their hydro-massage effect, the jets allow you to adjust the

air and water ﬂow and control the ﬂow direction as you desire.

Heater - Designed to automatically help maintain the temperature of the water up to 104°F (40°C) to

enhance your hydro-massage experience. The heater turns on automatically when the whirlpool is

operating, and turns off when the pump motor is turned off. The heater may be turned off, through

the keypad, at any time while the pump is operating.

Kohler Co. 3 1022381-5-C

User Keypad and Whirlpool Modes/Features

Power - Turns the whirlpool pump on and off.

Up Arrow - Increases the water ﬂow.

Down Arrow - Decreases the water ﬂow.

Heater - The heater automatically engages when the whirlpool is turned on. You may turn the

heater off by pressing the heater button. Press the button a second time to turn the heater back on.

Indicator Bar - Shows the water ﬂow volume.

Optional Remote Control

If you purchased a remote control, please refer to the Homeowners Guide packed with your remote control

for detailed information.

Operating Your Whirlpool

Turn the jet trim fully counterclockwise. Position the jet nozzles so they face down toward the basin.

NOTE: The water temperature in the whirlpool should never exceed 104°F (40°C). A built-in heater

automatically maintains the water temperature when the whirlpool is running, as long as the water

temperature does not exceed 104°F (40°C). The heater will disengage at higher temperatures.

Close the drain, and ﬁll the whirlpool to a level at least 2″(5.1 cm) above the top of the highest jet.

Use your hand to test the water temperature for comfort and safety, then carefully enter the bath.

Press Power to turn on the whirlpool. The whirlpool will start at medium volume. The heater will

also turn on and the heater icon will illuminate.

Increase or decrease the water ﬂow by pressing the up or down arrows on the keypad. An indicator

bar in the center of the keypad shows the water ﬂow volume.

Adjust the jets for optimum air/water mixture. Turn the jet trim clockwise to reduce the ﬂow, and

counterclockwise to increase the ﬂow. Position the jet nozzles to direct the water ﬂow as desired to

maximize your hydro-massage experience.

The heater turns on automatically when the whirlpool is operating, and turns off when the pump

motor is turned off. The heater may be turned off, through the keypad, at anytime while the pump

is operating.

Press Power a second time to turn off the whirlpool.

Indicator Bar -

Shows water

flow volume

Power On/Off

Heater On/Off

Heater Indicator Light

Increases Flow

Decreases Flow

Lighted User Keypad

Fill with water at least 2" (5.1 cm)

above the highest jet.

Turn the jet trim ring

clockwise to

decrease the flow. Position the jet

nozzles to direct

the water flow as

desired.

Turn the jet trim ring counterclockwise

to increase the flow.

1022381-5-C 4 Kohler Co.

Operating Your Whirlpool (cont.)

NOTE: Your whirlpool will automatically stop after approximately 20 minutes of continuous operation.

You can restart the whirlpool, if you desire, by pressing Power.

Carefully exit the bath, and open the drain to empty the whirlpool.

NOTE: Consult the ″Troubleshooting″section of this manual before calling a qualiﬁed service

representative.

Care and Cleaning

For best results, keep the following in mind when caring for your KOHLER product:

•Use a mild detergent such as liquid dishwashing soap and warm water for cleaning. Do not use

abrasive cleaners that may scratch or dull the surface.

•Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.

•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.

•Do not allow cleaners to sit or soak on the surface.

•Wipe surfaces clean and rinse completely with water immediately after cleaner application. Rinse

and dry any overspray that lands on nearby surfaces.

•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring

pad to clean surfaces.

For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &

Cleaning information, call 1-800-456-4537 and press 1 for Kohler Products and then 3 for Literature.

Flushing Your Whirlpool System

Flush your whirlpool system twice a month or more, depending upon usage. Use the following

sequence:

•Turn the jet trim rings fully clockwise to remove air induction.

•Fill the whirlpool with warm water to a level at least 2″(5.1 cm) above the highest jets, or leave

water in the whirlpool after using.

•Add 2 tablespoons (30 ml) of a low-foaming dishwasher detergent and 20 ounces (590 ml) of

household bleach (5% - 6% sodium hypochlorite) to the water.

•Run the whirlpool for 5 to 10 minutes. Turn off the whirlpool and drain.

•If desired, rinse the bath surfaces with water.

•Rinse the surfaces of the jets, faucet, handrails, drain, etc. and wipe them dry with a soft cloth.

One-Year Limited Warranty

KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year

from date of installation.

Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection

discloses any such defects occurring in normal usage within one (1) year after installation. Kohler Co. is not

responsible for removal or installation costs. Use of in-tank toilet cleaners will void the warranty.

To obtain warranty service contact Kohler Co. either through your Dealer, Plumbing Contractor, Home

Center or E-tailer, or by writing Kohler Co., Attn.: Customer Service Department, 444 Highland Drive,

Kohler, WI 53044, USA, or by calling 1-800-4-KOHLER from within the USA, 1-800-964-5590 from within

Canada and 001-877-680-1310 from within Mexico.

Implied warranties including that of merchantability and ﬁtness for a particular purpose are expressly

limited in duration to the duration of this warranty. Kohler Co. and/or seller disclaims any liability for

special, incidental or consequential damages.

Some states/provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or

limitation of special, incidental or consequential damages so these limitations and exclusions may not apply

Kohler Co. 5 1022381-5-C

One-Year Limited Warranty (cont.)

to you. This warranty gives you speciﬁc legal rights. You may also have other rights which vary from

state/province to state/province.

This is Kohler Co.’s exclusive written warranty.

One-Year Warranty

KOHLER CO.

It is recommended that at the time of purchase, you verify that all accessories and components are complete

in this package.

This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the

date of purchase as shown on the invoice or receipt.

1. Kohler Co. will only service its commercialized products through its authorized distributors.

2. To obtain warranty service, please present the invoice and corresponding warranty.

3. Through its authorized distributors, Kohler Co. promises to repair the defective product or provide a new

replacement or an equivalent model (in those cases that the model has been discontinued) when the product

is beyond repair, without any charge to the consumer.

4. The time of repair will not exceed six (6) weeks commencing on the date the product is received.

5. It is recommended that the consumer save the invoice or receipt as additional protection, as it may

substitute the warranty in the case that there is a discrepancy in the validity of the warranty.

EXCEPTIONS AND RESTRICTIONS

The Warranty will not be valid in the following cases:

1. When the product is not operated in accordance with the instructions concerning use and operation set

forth in the owner’s manual or installation instructions, and when the recommendations and warnings

included are not observed.

2. When the product has been modiﬁed or dismantled partially or totally; or has been used in a negligent

fashion and as a consequence has suffered damages attributable to the consumer, individual, or hardware not

authorized by Kohler Co.

3. This warranty does not cover the damages as a result of disaster such as ﬁre or acts of God, including

ﬂooding, earthquake, or electric storms, etc. To obtain a list of distributors in your area where you can

exercise your rights under this warranty, please call 001-877-680-1310.

KOHLER CO., KOHLER, WI 53044 U.S.A.

IMPORTER:

INTERNACIONAL DE CERÁMICA, S.A.B. DE C.V.

AV. CARLOS PACHECO NO. 7200

CHIHUAHUA, CHIH., MEXICO C.P. 31060

TEL: 52 (14) 29-11-11

1022381-5-C 6 Kohler Co.

Troubleshooting Procedures

Remove the Jets

NOTE: A special tool is provided with the jets that will allow you to remove them from the whirlpool.

This tool is also supplied with each trim kit.

Position the jet ball nozzle so it is pointing upward.

NOTE: The nozzle must remain pointed up or the tool will slip off.

Insert the removal tool, hooked end up, into the opening of the jet and hook the inside top of the

nozzle.

Grasp the tool ﬁrmly and place your thumb against the whirlpool wall. Pull steadily on the tool

until the jet assembly pulls free of the hole. Be careful not to lose the O-ring.

Reinstall the Jets

NOTE: The jet O-ring must be correctly positioned, must be lubricated, and must be in good condition to

permit easy rotation and proper operation of the jet.

Install the O-ring onto the ﬁrst shoulder of the jet. Lubricate the O-ring with silicone lubricant to

prevent noisy operation of the jet.

Carefully insert the jet into the housing, and lightly push and rotate the jet until it snaps into

position. Do not force the jet.

NOTE: When installed correctly, the jet should turn smoothly both clockwise and counterclockwise.

Troubleshooting Guide

This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualiﬁed

electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale

distributor.

Troubleshooting the Whirlpool System

Symptoms Probable Causes Recommended Action

1. User keypad does not

illuminate when power

button is pressed or outer

ring is rotated.

A. No power to control. A. Check wiring and connect power. If

problem persists, refer to

installer/dealer.

Remove the Jets

Insert the tool hook as shown and pull the jet out of the

housing. The jet should be facing up when this is done.

Housing

Reinstall the Jets

Insert the jet into the housing, and lightly

push and rotate until it snaps in position.

Slide the O-ring

onto the first

shoulder of the jet.

Inspect and

lubricate the O-ring.

Kohler Co. 7 1022381-5-C

Troubleshooting Procedures (cont.)

Troubleshooting the Whirlpool System

Symptoms Probable Causes Recommended Action

B. GFCI or RCD circuit

breaker is tripped. B. Reset GFCI or RCD.

C. Wiring harness from user

keypad to control is loose,

disconnected, or damaged.

C. Check wiring for proper connections.

Replace wiring harness if necessary.

Refer to installer/dealer.

D. Keypad is not working. D. Replace user keypad. Refer to

installer/dealer.

E. Control is not working. E. Replace control. Refer to

installer/dealer.

2. Motor starts, but all jets are

not functioning. A. Jet is closed. A. Rotate jet trim ring counterclockwise

to open.

B. Jet not installed correctly. B. Reinstall jet; check for O-ring damage.

C. Jets are blocked. C. Remove obstruction.

3. User keypad is illuminated

but does not respond to

buttons or ring.

A. Control program is locked. A. Reset GFCI or RCD.

B. Wiring harness from user

keypad to control is loose,

disconnected, or damaged.

B. Check wiring for proper connections.

Replace wiring harness if necessary.

Refer to installer/dealer.

C. Keypad is not working. C. Replace user keypad. Refer to

installer/dealer.

D. Control is not working. D. Replace control. Refer to

installer/dealer.

4. User keypad indicator bar

keeps scanning at

power-up.

A. Control program is locked. A. Reset GFCI or RCD.

B. Wiring harness from user

keypad to control is loose,

disconnected, or damaged.

B. Check wiring for proper connections.

Replace wiring harness if necessary.

Refer to installer/dealer.

C. Keypad is not working. C. Replace user keypad. Refer to

installer/dealer.

D. Control is not working. D. Replace control. Refer to

installer/dealer.

5. User keypad is illuminated,

but pump will not start. A. Power cord from pump to

control is loose,

disconnected, or damaged.

A. Check wiring for proper connections.

If problem persists, refer to

installer/dealer.

B. Pump is not working. B. Replace pump. Refer to

installer/dealer.

C. Control is not working. C. Replace control. Refer to

installer/dealer.

6. Motor runs but pump will

not prime (cavitates). A. Pump is shimmed too

high. A. Lower pump/control to subﬂoor level.

B. Small air leak at pump

inlet. B. Securely tighten nut(s) on intake side

of pump.

C. Motor/pump is not

working. C. Replace motor/pump. Refer to

installer/dealer.

D. Controller is not working. D. Replace control. Refer to

installer/dealer.

7. Pump stops before 18

minutes. A. GFCI or RCD tripped. A. Identify source of fault, and correct.

Reset GFCI or RCD.

B. Suction is blocked. B. Remove obstruction.

C. Jets are blocked. C. Remove obstruction.

D. Motor overheated and

protection device activated. D. Check for blockage at suction and/or

jets. Remove obstruction and allow

motor to cool.

8. Pump does not

automatically stop after 22

minutes.

A. 20-minute timer

inadvertently disabled. A. See Service Manual.

1022381-5-C 8 Kohler Co.

Troubleshooting Procedures (cont.)

Troubleshooting the Whirlpool System

Symptoms Probable Causes Recommended Action

9. Pump will not turn off

when the power button on

user keypad is pressed.

A. Keypad is not working. A. Replace user keypad. Refer to

installer/dealer.

B. Control is not working. B. Replace control. Refer to

installer/dealer.

10. Pump operates but variable

speed feature does not

work.

A. Motor/pump is not

working. A. Replace motor/pump. Refer to

installer/dealer.

B. Control is not working. B. Replace control. Refer to

installer/dealer.

11. Bath water cools while

pump is operating. A. Water temperature is above

104°F (40°C). A. Allow bath water to cool.

B. Heater is turned off on

user keypad. B. Turn heater on.

C. Wiring from heater to

control is loose,

disconnected, or damaged.

C. Check wiring for proper connections.

Refer to installer/dealer.

D. Heater is not working. D. Replace heater. Refer to

installer/dealer.

E. Control is not working. E. Replace control. Refer to

installer/dealer.

12. Noisy operation. A. Pump banding straps have

not been cut. A. Cut pump banding straps with tin

snips.

B. Dry or dislodged jet O-ring

(squeal). B. Remove jet, replace and lubricate

O-ring, and reinstall jet.

13. Remote control (if

equipped) does not work. A. Batteries improperly

installed or dead. A. Replace batteries.

B. Antenna on wiring harness

is damaged. B. Replace wiring harness. Refer to

installer/dealer.

C. Remote control not

programmed correctly. C. See remote control Homeowners

Guide or Service Manual.

D. Remote control is not

working. D. Replace remote control.

E. Control is not working. E. Replace control. Refer to

installer/dealer.

Kohler Co. 9 1022381-5-C

Service Parts

**Finish/color code must be specified when ordering.

1-1/2" Tubing

*Note: All tubing 1" unless otherwise noted.

1015008

Wire Harness

Tee Heater

1022381-5-C 10 Kohler Co.

Otros manuales para K-1418

Tabla de contenidos

Idiomas:

Otros manuales de Bañera de Kohler

Kohler

Kohler K-1109 Instrucciones de montaje

Kohler

Kohler K-1122-XHGLA-7 Instrucciones de montaje

Kohler

Kohler K-1224P Guía de inicio rápido

Kohler

Kohler K-1159-L Guía de inicio rápido

Kohler

Kohler K-1630 Manual de usuario

Kohler

Kohler K-12105 Manual de usuario

Kohler

Kohler K-856-M Instrucciones de montaje

Kohler

Kohler K-1375-CT Instrucciones de montaje

Kohler

Kohler EVOK 2.0 25163A-0 Manual de usuario

Kohler

Kohler K-1227 Instrucciones de montaje

Kohler

Kohler Windward BubbleMassage K-1112-GLF Guía de inicio rápido

Kohler

Kohler Underscore K-1969-H2-0 Instrucciones de montaje

Kohler

Kohler LITHOCAST Manual de usuario

Kohler

Kohler K-1257-H Guía de inicio rápido

Kohler

Kohler Jacob Delafon ELITE E6D030RU-00 Manual de usuario

Kohler

Kohler K-1248 Guía de inicio rápido

Kohler

Kohler K-1123-RA Guía de inicio rápido

Kohler

Kohler K-1162-S1CB Guía de inicio rápido

Kohler

Kohler K-1162-H Guía de inicio rápido

Kohler

Kohler K-1122-GLA Guía de inicio rápido

Kohler

Kohler REVIVAL K-873 Manual de usuario

Kohler

Kohler K-1257P-LA Guía de inicio rápido

Kohler

Kohler VOLUTE K-20610T Manual de usuario

Kohler

Kohler Underscore Oval K-5714-XH2G Manual de usuario

Manuales populares de Bañera de otras marcas

Agua

Agua BARTOLI-66 Manual de usuario

PAA

PAA PRELUDE Manual de usuario

BETTE

BETTE SILHOUETTE Manual de usuario

American Standard

American Standard Whirlpool/Bathing Pool 2748.XXXW Manual de usuario

Oliveri

Oliveri Naples Manual de usuario

Lyons

Lyons Elite ETLxx663219 Series Manual de usuario

Woodbridge

Woodbridge BJ500 Instrucciones de montaje

Whirlpool

Whirlpool Ariel ARL-702 Manual de usuario

TEIKO

TEIKO EXCELLENT DUO Manual de usuario

American Standard

American Standard Colony 5-1/2' x 32" Manual de usuario

American Standard

American Standard 3052OD.X0X Guía de inicio rápido

agape

agape MARSIGLIA AVAS1075 Manual de usuario

Kallista

Kallista P50045-G5 Instrucciones de montaje

Ariel

Ariel AM Series Manual de usuario

Agua

Agua BAHLI-60 Manual de usuario

DURAVIT

DURAVIT XViu 700443 Manual de usuario

American Standard

American Standard Colony 2740 Series Manual de usuario

Rapsel

Rapsel OFURO Manual
