Kogan MX10 PRO Manual de usuario

MX10 PRO CORDLESS 22.2V MOP AND

STICK VACUUM CLEANER

KAVACSTM10X

When using an electrical appliance basic safety precautions should always be followed

including the following:

Kogan.com is not liable for damage caused by failure to comply with the use requirements,

negligent use, etc.

• Children aged 8 years and above or persons with reduced physical, sensory or

mental capabilities should only use this appliance while under supervision or

instruction from an adult or carer.

• Children aged 8 and above should not clean or perform user maintenance on this

appliance unless under supervision or instruction from an adult or carer.

• Do not operate any appliance with a damaged or abnormal cord or plug. If the

main cord is damaged, it must be replaced by Kogan.com or a service agent on

Kogan.com's behalf.

• Recharge the battery using only with the charger supplied with the appliance.

• This appliance is intended for domestic use only.

• Do not use on wet or greasy surfaces.

• Before use, remove any objects that could entangle the brushes (long hair, plastic

bags, rope, wire, etc.).

• Never immerse any part of the plug or vacuum cleaner in water or other liquids.

• Never leave the vacuum unattended while the power is one.

• Please be careful when your pet is near the vacuum cleaner.

• Do not hang the power cord over the edge of the desk or counter, or touch any

sources of heat.

• It is not recommended to use any accessories other than those supplied.

• In the event of a malfunction, stop using it immediately and contact Kogan.com.

SAFETY & WARNINGS

Speed control button

Metal tube release button

Power indicator

Metal tube

Battery

Brush release button

Dust tank release button

Charging port

Display

Dust tank

OVERVIEW

Display

Battery Level

Brush Blockage Indicator

Air-duct Blockage Indicator

Failure Indicator

Eco Speed

High Speed

Speed Control

1. Insert the metal tube into the nozzle and make sure it is secure (Figure 1).

2. Press the metal tube release button and remove the metal tube (Figure 2).

Use the different accessories according to your cleaning requirements.

1. Insert the metal aluminium tube first, then install the floor brush. Ensure the brush

is secure (Figure 1).

2. The floor brush can be removed by pressing the metal tube lock (Figure 2).

OPERATION

Figure 1

Figure 2

Figure 1

Figure 2

1. Press the power button (Figure 1), the vacuum turns on in eco speed mode.

2. Press the speed control button (Figure 2) to cycle through the different speeds.

Note: When using, do not exceed the “maximum” dust collection capacity of the

dust cup.

Charging

1. Tu r n o f f t h e v a c u u m a n d i n s e r t t h e c h a r g e r i n t o t h e c h a r g i n g p o r t .

2. Plug the charger into the power outlet.

3. When charging, the blue light will flash; when the charging is finished, the light will

remain on.

4. Unplug the charger, press the power switch, and the vacuum cleaner will power on.

Figure 1

Figure 2

Note:

Please keep the air intake open during use to avoid clogging. Failure to do so, will

cause the motor to overheat causing danger.

WARNING: Only use the original charger to avoid damage to the vacuum

cleaner.

CHARGING

1. In addition to the main unit, other parts can be washed with warm soapy water.

After cleaning, it must be thoroughly dried before being returned for use. Never

immerse the main unit in water or any liquid.

2. Clean the outer casing of the vacuum cleaner only with a soft, slightly damp cloth.

Never let any liquids enter the vacuum cleaner.

3. Never use any corrosive chemicals or abrasives.

4. When the filter is damaged or worn out, it should be replaced.

5. This product contains non-removable parts and must not be disassembled or

repaired by yourself.

For the best use, empty the dust bucket and clean the filter after each use.

1. Press the dust tank release button to remove the dust tank.

2. Press and hold the dust tank bottom cover button below to empty the dust.

CLEANING & CARE

3. Separate the upper part of the dust tank from the dust tank body. Remove the

filters and wash it in warm water. Ensure the filters are completely dry before

reassembling.

4. Return the filters and reassemble the dust tank. The mark on the upper part of the

dust tank corresponds to the “unlock” position, ensure that the “3 small and 1 large”

feet are properly inserted into the dust tank and are screwed back to the "Lock"

position.

5. Put the dust tank back on the vacuum main body.

It is recommended to replace the filter every three months (depending on the use) to ensure

the best performance

Voltage supply

22.2V (Li-ion 2000mAh)

Power

250W

Battery

Charging time: Approx. 4 Hours

Operating time: Max 30-35mins (when the battery is full charged)

Power adapter

Input

100-240V~, 50/60Hz 0,5A MAX

Output

DC 26.5V, 0.5A

Protection Class

Disposal

This marking indicates that this appliance should not be disposed with other

house-hold wastes. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources.

SPECIFICATIONS
