Kogan KAMHTDRY8PA Manual de usuario
8KG PREMIUM HEAT PUMP
DRYER
(WHITE)
KAMHTDRY8PA
2
Safety & Warnings
3
Overview
8
Installation
11
Before First Use
14
Operation
15
Cleaning & Care
22
Specifications
25
Troubleshooting
26
3
Read this manual thoroughly before first use, the safety precautions listed below reduce the
risk of fire, electric shock and injury when correctly adhered to. Retain this user guide for
future reference. If applicable, pass these instructions on to the next owner.
WARNING
• The appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children should be supervised to ensure
that they do not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• Children less than 36 months old should be kept away unless continuously supervised.
• The rear surface of the appliance shall be placed against a wall.
• Ensure the lint filter is cleaned after every cycle and whenever prompted by the dryer.
• The lint filter and filter drawer should be washed frequently.
• Ensure location of the dryer is well ventilated.
Possible Electric Shocks
• Disassembly, repair or modification must only be carried out by licenced trade
professionals.
• The household electrical supply system (the current, the voltage, the cable) such as a
fuse with suitable specifications should be provided and meet the electrical
requirements of the dryer under normal load.
• The power plug must be connected to a three-core socket with an earth wire which is
grounded properly.
• If the supply cord is damaged, it must be replaced. Cease use immediately and
contact help.Kogan.com for support.
• DO NOT disconnect the power plug by pulling the cord. Hold the power plug with your
hand.
• DO NOT touch the power plug with wet hands. Wipe dust or water drops from the
power plug using a dry cloth.
• DO NOT over-bend the power cord or place heavy objects on it.
• DO NOT use the power cord, socket or power plug if it is damaged or broken.
SAFETY & WARNINGS
4
Possible Explosions
• DO NOT put combustible liquid such as gasoline, petrol and alcohol into the appliance
or nearby. Don't put clothes with that liquid into the appliance.
• DO NOT connect or disconnect the power plug when leakage of gas or other
combustible gas occurs.
• Refrigerant R290
Preventing Fire Accidents and Electrical Hazards
• Do not install the appliance close to open flames or sources of heat.
• Do not place lit candles or cigarettes on the appliance.
• Do not install the appliance in areas prone to damp or water ingress as water on the
electrical components can damage the appliance and/or pose a hazard.
• Do not install the dryer in places exposed to direct sunshine. Prolonged exposure to
sunlight will age plastic and rubber components.
• To avoid danger of fires caused by excessive drying, do not use the appliance to dry the
following items: Cushions, quilts and the like (these items accumulate heat).
• If you have washed your laundry with stain remover, you must execute an extra rinse
cycle before loading your tumble dryer.
• Ensure that no gas lighters or matches have accidentally been left in pockets of
garments to be loaded into appliance.
• Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
tumble dryer
• Ensure carpets does not obstruct the openings in the base.
• Ensure that exhaust air must is not discharged into a flue which is used for exhausting
fumes from appliances burning gas or other fuels.
General Warning
• Keep ventilation openings clear of obstructions.
• Do not damage the refrigerant circuit.
• Never stop a tumble dry before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
• The appliance must not be supplied through an external switching device, such as a
timer or connected to a circuit that is regularly switched on and off by a utility.
5
Personal Injuries
• The appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children should be supervised to ensure
that they do not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• The package materials may be dangerous to children. Dispose of or store all packaging
materials (e.g. the plastic bag) to ensure they are out of reach of children.
• Children of less than 3 years should be kept away unless continuously supervised.
• Do not allow children or pets nearby when the dryer is being loaded as they may
become trapped inside the dryer. Always check the drum before closing the door.
Additional Safety Guidelines
• This appliance is designed for domestic use. It must not to be used for purposes other
than those for which it was designed.
• Only wash fabrics which are designed to be machine dried. Always follow the
instruction on each garment labels.
• Do not over-dry laundry. Over-drying can cause creasing and wastes energy.
• Any electrical work required to install this appliance should be carried out by qualified
electrician or authorised personnel.
• If the machine is situated on a carpeted floor, please adjust the feet in order to allow air
to circulate freely under the appliance.
• Do not climb onto the dryer or rest heavy objects / heating devices or items with water
or liquid leakage on the dryer.
• Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp
material can cause extensive damage and must not be placed into the machine.
• After having installed the appliance, check that it is not pressing or standing on its
power cable or water drain pipe.
• Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber
backed articles and clothes or pillows fitted with foam rubber pads should not be dried
in the tumble dryer.
• Always unplug the appliance after use and before cleaning and maintenance.
• Do not overload the appliance.
• Clothes which are dripping wet should not be placed in the dryer.
• Garments which have been in contact with volatile petroleum products should not be
machine dried. If volatile cleaning fluids are use, care should be taken to ensure that
the fluid is removed from the garment before placing in the machine.
6
• Never use the tumble dryer if the power cable, the control panel, the working surface or
the base is damaged. Cease use immediately and contact help.Kogan.com for
support.
• The tumble dryer is not to be used if industrial chemicals have been used for cleaning.
• Lint must not to be allowed to accumulate around the tumble dryer.
• Do not dry unwashed items in the tumble dryer.
• Fabric softeners or similar products should be used as specified by the fabric softener
instructions. The final part of a tumble dryer cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that ensures that the items will
not be damaged.
• The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
• Machine must be placed in a clean place, away from water, ice and combustible
materials. To keep vibration and noise to a minimum when the dryer is in use, it should
be placed on a firm, level surface.
• If the tumble dryer is not completely levelled, adjust the front feet up: to lower the dryer
by turning anti-clockwise and to ascend it by turning clockwise till the appliance will not
shake.
• Adequate ventilation must be provided to avoid the back flow of gases into the room
from appliances burning other fuels, including open fires.
• Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
tumble dryer.
• Remove all objects from pockets such as lighters and matches.
• Oil-affected items can ignite spontaneously, especially when exposed to heat sources
such as in a tumble dryer. The items become warm, causing an oxidation reaction in
the oil.
• Oxidation creates heat. If the heat cannot escape, the items can become hot enough
to catch fire. Piling, stacking or storing oil soaked items can prevent heat from escaping
and so create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable or cooking oil or have been
contaminated by hair care products be placed in a tumble dryer they should first be
washed in hot water with extra detergent - this will reduce, but not eliminate, the
hazard.
• Contains fluorinated greenhouse gases covered by the Kyoto Protocol.
• Hermetically sealed system.
• Do not vent gases into the atmosphere.
• If the power cord is damaged, it must be replaced by Kogan.com or an authorised
representative in order to avoid a hazard.
7
Electrical Connection
• This appliance must be earthed. In case of failure or damage, earth can provide a
minimum resistance to reduce the possibility of electric shock. The power cord has a
grounding and must be inserted into a properly installed and grounded socket (in
accordance with all local rules and standards).
• Any electrical work required to install this appliance should be carried out by qualified
electrician or authorised personnel.
• Before switching on, make sure the electricity supply voltage is the same as that
indicated on the appliance's rating plate.
• A cut off plug inserted into a socket is a serious safety (shock) hazard.
• Ensure that the cut off plug is disposed of safety.
• In the case of permanent connection, it is necessary that you install a double pole
switch. The switch must not break the yellow and green earth cable at any point.
Disposal:
This marking indicates that this appliance should not be disposed with other
household wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources.
WARNING: The appliance must be earthed.
8
Accessories
The following parts are optional depending on your dryer model. If your dryer includes the
following parts, it is recommended to wear gloves during the installation of accessories.
OVERVIEW
Power cord
Top
Water tank
Drum
Filter
Control panel
Door
Air inlet
Maintenance cover
Note:
The above image is for illustrative purposes only. Actual product may differ slightly.
Hose holder
Drain hose
Connector
9
Control Panel
Power button
Turns the dryer ON/OFF
Start/Pause
Press the button to start or pause the drying cycle.
Options
Select additional functions.
Display
The display shows the settings, estimated programme
time remaining and status messages of your dryer.
Programmes
Different drying cycles can be selected according to
the users need and the type of laundry to be dried.
My Cycle
Jeans
Extra
Extra
Standard
Iron
Delicate
Mix
Refresh
Standard
Bed Linen
Sports
Shirts
Warm
Cool
Wool
Delay
Time
Anti-Crease
Intensity
On/Off
Start/Pause
Signal
Lamp
10
Display
Delay
Child lock
Remaining Time indicator/Error message
Cycle phase status
Filter
Clean filters (warning)
Full
Empty water container (warning)
Intensity (4 levels)
Lamp
Buzzer
Anti-Crease
My Cycle
Tabla de contenidos
Otros manuales de Secadora de Kogan
Kogan
Kogan KAMHTDRY10A Manual de usuario
Kogan
Kogan KAGVNTDRY7A Manual de usuario
Kogan
Kogan KAGDRYCD80A Manual de usuario
Kogan
Kogan KROMO KRRACKHEATA Manual de usuario
Kogan
Kogan KA6VDRYERA Manual de usuario
Kogan
Kogan 8 Series Manual de usuario
Kogan
Kogan KA7VENTDRYA Manual
Kogan
Kogan KAG8HTPPDYA Manual de usuario
Kogan
Kogan KA7HPUMDRYA Manual de usuario
Kogan
Kogan 8KG Series Manual de usuario
Manuales populares de Secadora de otras marcas
Indesit
Indesit IDV 75 Manual de usuario
Infiniton
Infiniton SD-DG85C Manual de usuario
BOMANN
BOMANN WT 5019 Manual de usuario
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manual de usuario
Asko
Asko T793C Manual de usuario
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
