Kogan KA6VDRYERA Manual de usuario
6KG VENTED TUMBLE
DRYER
KA6VDRYERA
Read this manual thoroughly before first use, the safety precautions enclosed herein reduce
the risk of fire, electric shock and injury when correctly adhered to. Retain this user guide for
future reference. If applicable, pass these instructions on to the next owner.
• Do not attempt to repair this product yourself. If the product or its power supply
experiences any malfunction or damage, cease use immediately and contact
Kogan.com for support.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
• Ensure children are supervised so that they do not play with the appliance.
• Ensure the lint filter is cleaned after every cycle and whenever prompted by the
dryer.
• The lint filter and air intake filter should be washed frequently.
• WARNING: The appliance must not be supplied through an external switching
device, such as a timer or connected to a circuit that is regularly switched on and
off by a utility.
• Do not place naked flame sources, such as candles, on the appliance.
• Do not block any of the ventilation openings or allow them to be blocked by
newspapers, tablecloths, curtains, etc. Do not install inside a narrow cabinet.
• Ensure there is adequate ventilation to avoid the back flow of gases into the room
from appliances burning other fuels, including open fires.
• Do not dry unwashed items in the tumble dryer.
• Do not attempt to dry clothes which have been soiled with flammable liquids inside
the dryer without washing them thoroughly by hand beforehand. Do not allow
flammable or combustible materials such as gas, petrol, alcohol or lacquer in the
appliance.
• If clothes which are dirtied in this way need to be dried, the hazard can be
mitigated but not eliminated by washing first in hot water with extra detergent.
• Do not overload the dryer.
• Keep the drum clear of foreign objects and always remove items from clothing.
• The door window may become hot after a long drying cycle: keep children away.
• Install on a stable, solid surface.
• The final phase of the tumble dry cycle does not use heat (cool down cycle): this is
to ensure items are not left at a high temperature and able to be damaged due to
this.
SAFETY & WARNINGS
• Wait at least 2 minutes after turning off the power supply before turning it on again.
• Ensure all packaging is removed from the dryer before first use.
• Follow instructions for use provided with any fabric softener.
• Do not dry items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed clothes or pillows fitted with foam rubber pads.
• Do not use if industrial chemicals have been used for cleaning.
• Do not allow lint to build up around the tumble dryer.
• The power cord should only be replaced by a service agent authorised by
Kogan.com in order to avoid a hazard.
• Should the appliance need to be moved, it must be transported vertically.
Electrical safety and cord handling
Always follow basic safety precautions and accident prevention measures when using an
electrical appliance, including the following:
• Voltage: Ensure your outlet voltage and circuit frequency correspond to the voltage
indicated on the appliance’s rating label and your outlet socket is properly earthed.
If this is not the case, do not use the dryer.
• Separate circuit: We strongly recommend you connect the appliance to a
separate circuit serving only this appliance. This provides the best performance and
prevents overloading the house wiring circuits that could cause a fire hazard from
overheating.
• Electrical hazard: Do not insert any objects into the appliance.
• No extension cord: Do not use this appliance with a power adaptor or extension
cord.
• Protect the power cord. Do not kink or damage the power cord. Position the cord
out of the way so no one steps on or places anything on the cord or against it. Do
not run the cord under floor coverings. Position the cord away from high traffic
areas where it will not become a tripping hazard.
• Disconnect: Unplug the clothes dryer from the power supply after use, before
cleaning, servicing or moving the appliance. To disconnect, turn the appliance off,
switch off the power outlet and remove the plug from the power outlet. Grip the
plug when disconnecting; do not pull on the cord. After disconnection, wait at least
2 minutes before turning the appliance back on again.
• RCD: Unless your home is already fitted with a residual current device (safety
switch), we recommend installing an RCD with a rated residual operating current
not exceeding 30mA to provide additional safety protection when using electrical
appliances. Consultant an electrician for professional advice.
WARNING: If such a device must be used, the cord or outlet must be
positioned so that it is not subject to splashing or liquid ingress.
Usage conditions and restrictions
This appliance is intended for indoor household use only. It is not intended for industrial,
commercial or trade use. Do not use it outdoors. Do not use it for anything other than its
intended purpose (drying domestic quantities of washing) and only use it as described in this
manual.
Installation requirements:
• Do not install the appliance in a tight-fitting cabinet.
• Do not install it near heat sources such as radiators, heaters, air ducts or direct
sunlight. If the clothes dryer is not wall-mounted, place it on a flat, firm, dry and
stable floor in a well-ventilated area. Use the adjustable legs to assist in levelling
the dryer if required. Do not place it on any soft material such as foam or plastic.
• Ventilation: Do not block any ventilation openings. Ensure that vents are not
covered by newspapers, tablecloths, curtains, etc.
• Before use: Make sure to remove transport packaging from the rear of the dryer.
• Suitability for tumble drying: Only load suitable items into the clothes dryer.
Always follow the instructions on garment labels.
• Preparation: Make sure all pockets having been emptied. Hard, sharp objects such
as coins, safety pins, bra wires, nails, screws, lighters or matches must be removed
as they can cause extensive damage to the dryer.
• No dripping water: All clothes must be thoroughly spin-dried before placing them
in the dryer. Dripping water may cause an electrical hazard.
• No open flames: Do not place open flame sources such as candles on the dryer.
• Hot surface: The door window may be hot after a long drying cycle. Always ensure
children are kept away from the machine.
• Repair: Except for the filters that require regular cleaning, this appliance contains
no user-serviceable parts inside. Do not attempt to open, disassemble or repair it
yourself; only have it serviced by qualified personnel.
• Liability: Improper use or installation may result in the risk of fire, electric shock
and/or injury. We assume no liability for any damages caused by improper use or
handling or by any other noncompliance with the instructions in this user guide.
WARNING: Before loading the dryer, always ensure children or pets have not climbed into it.
Do not overload the clothes dryer.
WARNING: Any damage or malfunction resulting from foreign objects is not covered by your
warranty and may lead to expensive repairs.
WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are
safely removed and spread out to allow the heat to dissipated.
Unsuitable Items:
The items listed below are unsuitable for tumble drying. They can cause fire in the clothes
dryer or extensive damage. Do not place the following items into the clothes dryer.
• Items containing foam rubber (also known as latex foam) or similarly textured
rubber-like materials - when heated, these materials can spontaneously combust
and cause a fire.
• Items that have been spotted or soaked with cooking oil or with highly flammable
substances - these substances constitute a fire hazard. Highly flammable
substances used in domestic environments include acetone, alcohol, petrol,
kerosene, some stain removers, dry-cleaning solvents, turpentine, waxes, wax
removers and some hair care products. (This also includes items that have
previously been cleaned or spotted with dry-cleaning solvents or other flammable
or explosive substances.)
• Washing these items thoroughly beforehand in hot water with an extra amount of
detergent will reduce, but not necessarily eliminate the hazard. The ‘cool down’
cycle of a clothes dryer should be used to reduce the temperature of the items.
They should not be removed from the clothes dryer or piled or stacked while hot.
• Undergarments that contain metal reinforcements (such as underwire bras) - these
parts can come loose during drying and damage the clothes dryer.
• Plastic articles such as shower caps or waterproof baby bibs.
• Rubber-backed articles, clothes fitted with foam rubber pads, pillows, galoshes and
rubber coated tennis shoes.
• Fabric softeners or similar products, unless they are specifically recommended by
the product manufacturer for use in a clothes dryer to eliminate the effects of static
electricity.
Caution:
Hot surface! Do not touch the air intake during a drying cycle: it will
be hot.
Adequate ventilation has to be provided to avoid the backflow of
gases into the room from appliances burning other fuels, including
open fires.
This appliance contains no user-serviceable parts. If it suffers any failure or damage, cease
immediately and contact Kogan.com for support after consulting the Troubleshooting
section of this user guide.
OVERVIEW
Rear cover
Casing
Exhaust vent
Window
Door gasket
Drum
Air intake
shroud
Control panel
Door
Remove all packaging from the rear of the tumble dryer prior to first use.
• Place the dryer in a well-ventilated area away from heat and direct sunlight.
• If not wall-mounting, install on firm and stable ground. Leave at least 15cm
between dryer and walls.
• Assemble fixed legs (included) to ensure stability.
ASSEMBLY
Legs
Wall Mounting Kit
Wall Brackets (x2)
Spacers (x2)
Exhaust Connector
12mm Screws (x4)
25mm Screws (x4)
To o l s R e q u i r e d
Drill & ⌀3mm drill bit
Phillips head
screwdriver
12x50 Timber screws
(x4)
Note: It is highly recommended to seek the assistance of a second person to help lift the
dryer on onto the wall bracket.
WALL MOUNTING
Mounting the Dryer
1. Determine the location for installation and mark the wall. If installing above a top
loader washing machine, leave sufficient space to open the lid.
2. Securely attach the wall brackets (included) to the wall 563mm apart, ensuring you
are mounting into the wall studs (Figure 1).
If the position of the wall studs is too far apart, a timber slat (not included) can be
attached to the studs to provide a suitable mounting surface for the wall brackets.
Figure 1
Celling
WARNING: The dryer must be mounted to the wall studs and not the
plaster. If you are unsure, consult a trade professional.
Ensure brackets are securely fastened.
Use a timber slats if necessary.
