Kogan KAGDRYCD80A Manual de usuario
8KG CONDENSER DRYER
KAGDRYCD80A
Read this manual thoroughly before first use, the safety precautions enclosed herein reduce
the risk of fire, electric shock and injury when correctly adhered to. Retain this user guide for
future reference. If applicable, pass these instructions on to the next owner.
WARNING
• The appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall
not be performed by children without supervision.
• Children of less than 3 years should be kept away unless continuously supervised.
• The rear surface of appliance must be placed against a wall.
• The appliance must not be supplied through an external switching device, such as
a timer or connected to a circuit that is regularly switched on and off by a utility.
Risk of electric shock
• Do not attempt to repair this product yourself. If the
product or its power supply experiences any malfunction or
damage, cease use immediately and contact Kogan.com
for support.
• The household electrical supply system (the current, the
voltage and the cable) such as a fuse with suitable
specifications should be provided and should meet
requirements of the dryer under normal load and safety
devices.
• The power plug must be connected to a three-core socket with an earth wire and
must be grounded properly and reliably.
• Do not disconnect the dryer by pulling the power cord. Hold the power plug with
your hand.
• Ensure the power plug is clean and dry and do not touch it with wet hands.
• Do not over-bend the supply cord or place it under heavy weight.
• Ensure the appliance is not standing on the power cord.
• Any electrical work required to install this appliance should be carried out by a
qualified electrician.
SAFETY & WARNINGS
Risk of explosion
• Do not attempt to dry clothes which have been soiled with flammable liquids inside
the dryer without washing them thoroughly by hand beforehand. Do not allow
flammable or combustible materials such as gas, petrol, alcohol or lacquer in the
appliance.
• If clothes which are dirtied in this way need to be dried, the hazard can be
mitigated but not eliminated by washing first in hot water with extra detergent.
• Do not connect or disconnect the power plug in the event of a gas leak.
Risk of fire/short circuit or electric leakage
• Do not install the appliance close to an open fire or other sources of heat.
• Do not place any burning candles or lit cigarettes on the appliance.
• Do not install the appliance in areas prone to damp or water ingress as water on
the electrical components can damage the appliance and/or pose a hazard.
• Do not install the dryer in areas exposed to direct sunshine or the plastic
components and rubber components may become aged.
• Do not use pressurised water on the appliance when cleaning it.
• Do not use the appliance to dry cushions, quilts and the like, as these items
accumulate heat and can pose a fire hazard.
• When using stain remover on your laundry, ensure you run an extra rinse cycle prior
to loading the tumble dryer.
• Ensure all pockets are empty prior to loading laundry into the tumble dryer.
• Items that have been soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
tumble dryer.
• Ensure the openings in the base are not obstructed by
carpets.
• Exhaust air must not be discharged into a flue which is used
for exhausting fumes from appliances burning gas or other
fuels.
Risk of personal injury
• This machine is not intended for use by persons,
including children with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children shall not play with the appliance. Cleaning
and user maintenance should not be performed by
children without supervision.
• To a v o i d d a n g e r t o c h i l d r e n , e n s u r e a l l p a c k a g i n g i s d i s p o s e d of safely.
• Ensure children under 3 years of age and pets are supervised at all times when they
are near the appliance. Always check the drum before closing the door.
• Wait until the drum has stopped completely prior to removing laundry from the
dryer.
• Never stop a tumble dry before the end of the drying cycle unless all items are
quickly removed and spread out so that the heat is dissipated.
Other instructions
• This appliance is designed for domestic use. It must not be used for purposes other
than those for which it was designed.
• Only wash fabrics which are designed to be machine dried. Follow the instructions
on each garment label.
• If the machine is situated on a carpeted floor, adjust the feet in order to allow air to
circulate freely under the appliance.
• Do not climb onto the dryer or rest heavy objects/heating devices or items with
water or liquid leakage on the dryer.
• Objects such as coins, safety pins, nails, screws, stones or any other hard, sharp
material can cause extensive damage and must not be placed into the machine.
• After having installed the appliance, check that it is not pressing or standing on its
electrical supply cable or vent hose.
• Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber
backed articles and clothes and pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
• Always unplug the appliance after use, and before performing cleaning and
maintenance.
• Do not overload the appliance.
• Clothes which are dripping wet should not be placed in the dryer.
• Garments which have been in contact with petroleum products should not be
machine dried. If volatile cleaning fluids are used, care should be taken to ensure
that the fluid is removed from the garment before placing in the machine.
• Never use the tumble dryer if the power supply cable, the control panel, the working
surface or the base are damaged so that the inside of the tumble dryer is
accessible.
• The dryer must not be used if industrial chemicals have been used for cleaning.
• Lint must not to be allowed to accumulate around the dryer.
• Do not dry unwashed items in the tumble dryer.
• Fabric softeners or similar products should be used as specified by the fabric
softener instructions.
• The final part of a tumble dryer cycle occurs without heat (cool down cycle) to
ensure that the items are left at a temperature that ensures that the items will not
be damaged.
• The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to hat of the tumble dryer, in such a way that a
full opening of the tumble dryer door is restricted.
• The lint trap must be cleaned frequently.
• Adequate ventilation has to be provided to avoid the back flow of gases into the
room from appliances burning other fuels, including open fires.
• Before switching on, ensure the supply voltage is the same as that indicated on the
appliance’s rating plate.
• Should the plug need to be replaced for any reason, ensure a licensed electrician
carries out any electrical work. The wires in the mains lead are coloured in
accordance with the following code:
- Green and Yellow-Earth
- Blue-Neutral
- Brown-Live
• The wire coloured green and yellow must be connected to the terminal marked
with the earth symbol or coloured green and yellow.
• Should the appliance need to be moved, it must be transported vertically.
1
Control panel
2
Water tank
3
Lint filter
4
Door
5
Condenser cover
6
Condenser
7
Adjustment leg
OVERVIEW
Control panel
1
Program selection dial
2
Time
3
Child lock
4
Dry level
5
Anti-crease
6
Buzzer
7
Delay start
8
Start/Pause
9
Indicator lights:
- Lint filer
- Drainage container
The hot air emitted by the tumble dryer can reach temperatures of up to 60°C. Therefore,
the appliance must not be installed on floors which are not resistant to high temperatures.
Level adjustment
When pushing down on the edges of the dryer’s top plate, the machine should not move at
all. If the machine rocks, adjust the feet.
• Loosen the locknuts.
• Rotate the adjustable feet clockwise to lower the dyer.
• Rotate the feet counter-clockwise to raise the dryer.
• Tighten the locknuts after ensuring the dryer is level.
The feet must never be removed. Do not place the dryer on deep pile carpets, strips of wood
or similar. This may cause heat build-up and interfere with the operation of the appliance.
Adjustable screw
INSTALLATION
Note:
The locknuts must be tightened after adjustment. Any looseness can cause
vibration and noise.
Before First Use
• Ensure that the electrical connections comply with the installation instructions.
• Open the accessory bag and ensure all accessories are present:
Drainpipe
User Guide
• Remove the polystyrene block and any material from the drum:
o Open the door.
o Pull off the adhesive strips from inside of the dryer.
o Remove the packaging foam from the dryer.
Before using your dryer for the first time, it is recommended to place a few damp cloths
inside the appliance and tumble dry for 30 minutes as there may be dust inside a brand-new
dryer.
Packaging foam
