Kodak Advantix C750 Manual de usuario
Consumer Imaging
EASTMAN KODAK COMPANY
Rochester, NY 14650
© Eastman Kodak Company, 2000
Pt. No. 919 5504 Printed in U.S.A.
Kodak
C750 Zoom
Camera
Unfold the front and back flaps of this manual to view the camera’s parts.
Unfold the front and back flaps of this manual to view the camera’s parts.
ENGLISH/ESPAÑOL/FRANÇAIS
1Shutter button
2Zoomdial
3Format-selectorswitch
4Lens cover/flash
5Light sensor
6Viewfinder
7Auto-focus sensors
8Lens
9Red-eye-reduction/
self-timerlamp
10 Film-doorlever
CAMERAIDENTIFICATION
1
2
3
4
5
6
7
8
9
10
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: Your model camera has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
provide reasonable protection against interference in residential use. The camera
generates, uses and can radiate radio frequency energy and, if not used in
accordance with the instructions, may cause interference to radio
communications. There is no guarantee that interference will not occur. If this
camera does cause interference to radio or television reception, which can be
determined by turning the camera off and on, you may reduce the interference by
the following:
— Reorient or relocate the receiving antenna.
— Increase the separation between the camera and the receiver.
— Consult the dealer or an experienced radio/television technician for help.
Changes or modifications not approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Camera Identification LCD Panel
11 Battery door
12 Viewfindereyepiece
13 Flash/camera-
readylamp
14 LCDpanel
15 Flash-modebutton
16 Modebutton
17 Strap post
18 Filmdoor
19 Tripodsocket
20 Mid-roll-change
(MRC)button
21 Enter/self-timer
button
22 Select button
23 Menubutton
24 Auto-flash indicator
25 Red-eye-reduction
indicator
26 Fill-flashindicator
27 Flash-off indicator
28 Mode-selectorarrow
29 PMindicator
30 ISO film-
speed display
31 Title/print-quantity
display
32 Self-timerindicator
33 Spot-focus icon
34 Nightviewicon
35 Portrait icon
36 Infinity-focus icon
37 Framecounter
38 Film-presence
indicator
39 Date/timedisplay
40 Battery symbol
12 13 14
15
16
17
18
19
11
20
21
22
23
PRINT
PM
ISO
QTY
TITLEROLL
AUTO FILL
26 27
28
30
31
32
29
333435
36
37
38
39
40
24 25
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations
1
KODAK ADVANTIX
C750 Zoom Camera
Welcome to the world of the Advanced Photo System!
And thank you for buying this KODAK ADVANTIX Camera.
NEED HELPWITH YOUR CAMERA?
Go to our Web site at http://www.kodak.com (for US) or
http://www.kodak.ca (for Canada) or call:
Kodak (USA only) from 9:00 a.m. to 7:00 p.m. (Eastern time) Monday through
Friday at 1 (800) 242-2424.
Kodak (Canada only) from 8:00 a.m. to 5:00 p.m. (Eastern time) Monday
through Friday at 1 (800) 465-6325, ext. 36100; for the Toronto area,
call (416) 766-8233, ext. 36100.
When you call, please have your camera available.
For warranty purposes, please keep your sales receipt as proof
of the date of purchase.
© Eastman Kodak Company, 2000
ENGLISH
2
CONTENTS
ADVANCED PHOTO SYSTEM
FEATURES AVAILABLE WITH
THIS CAMERA ......................................3
GETTING STARTED .................................5
Loading the battery ..............................5
Setting the language............................6
List of languages ..................................7
Date and time imprinting.......................8
Setting the date and time.....................8
ATTACHING THE STRAP .........................9
CONTROL-BUTTON ACTUATOR .......... 10
LOW-BATTERY INDICATOR .................. 10
BATTERY TIPS ...................................... 10
POWER SHUT-OFF ................................ 11
LOADING THE FILM .............................. 11
TAKING PICTURES ............................... 13
Typical print sizes (formats) ................ 14
Using the focus lock........................... 15
Tips for better pictures ....................... 15
USING THE ZOOM LENS ...................... 16
TAKING FLASH PICTURES .................. 17
Flash-to-subject distance................... 18
Flash/warning-lamp signals ............... 18
FLASH MODES ..................................... 19
Auto flash with
red-eye reduction........................... 19
Fill flash............................................... 19
Flash off ............................................. 19
Auto flash without
red-eye reduction........................... 20
Selecting the flash modes ................. 20
SPECIAL-OPTION MODES ................... 20
Infinity-focus mode............................. 21
Portrait mode...................................... 21
Nightview mode.................................. 21
Center-spot focus mode .................... 21
Selecting the special-option modes .. 21
USING THE SELF-TIMER ...................... 23
TITLE IMPRINTING ................................ 24
TITLE-SELECT LIST.............................. 24
PRINT-QUANTITY SELECTION (PQS).. 26
ISO FILM-SPEED DISPLAY .................. 26
UNLOADING THE FILM ......................... 27
Automatic rewind................................ 27
Mid-roll change (MRC)........................ 27
CARING FOR YOUR CAMERA .............. 28
TROUBLESHOOTING............................ 29
SPECIFICATIONS .................................. 31
3
Triple format selection
• You can take three different size
pictures: Classic (C), Group/HDTV (H),
and Panoramic (P) pictures from the
same film cassette.
The masking inside
the viewfinder changes to match each
format selection.
Date and time/title imprinting
• The date, time, and cassette ID
number are printed on the back of your
prints, which makes it easy to organize
pictures and order reprints. You can
choose from one of 41 pre-
programmed titles (12 languages
available) to print on the back of the
prints.
See your photofinisher for a full
description of available services.
Double exposure protection (DEP)
• Don’t worry about accidentally re-
exposing your film. Your camera reads
the Film Status Indicator (FSI) on the
film cassette to prevent double
exposures.
Flip flash plus
• This system automatically adjusts
to provide just the right light in
any situation. The flash system:
–
provides extra
red-eye reduction
with the extension of the flip flash and
the red-eye-reduction mode,
–
automatically turns on for
dimly
lit scenes
,
–
delivers brighter light for clearer,
more colorful pictures for
distance shots
,
–
provides softer light for more natural
images for
close-ups
,
–
automatically
provides fill-in light for
more sparkle and clarity in harshly
lit
portraits
, and
–
recharges quickly so it is
ready to capture those
spontaneous
peak moments
.
ADVANCED PHOTO SYSTEM FEATURES
AVAILABLE WITH THIS CAMERA
4
Easy, drop-in loading
• Easy, drop-in loading is fast and
virtually error-free, eliminating blank
rolls and double exposures. The
camera uses KODAK ADVANTIX Film.
The film cassette, unlike the traditional
35 mm cartridge, communicates the
status of film and becomes the carrier
and storage container for the
processed film.
Picture quality information
exchange (PQix)
• This camera records vital scene data
on the film’s magnetic information
strip and communicates that
information to the photo lab to
optimize lighting and color for better-
looking prints.
Mid-roll change (MRC)
• You can remove your film in mid-roll
and later reload it and continue taking
pictures. MRC lets you:
–
switch film speeds in mid-roll to
match scene requirements,
–
organize by dedicating individual
film rolls to specific subjects, and
–
share a family camera in which the
members use their own roll of film.
4
3
2
1
Processed Negatives
Fully
Exposed
Partially
Exposed
Unexposed
Film status indicator (FSI)
• A highlighted indicator advances from
one symbol to another to identify the
status of the film inside the cassette.
5
GETTING STARTED
Before you take pictures, you need to
load the battery, set the language, and
set the date and time.
Loading the battery
This camera uses one 3-volt lithium
KODAK KCR2 (or equivalent) Battery
that supplies power for all camera
operations.
1. Slide the battery-door latch and lift to
open the battery door (11).
2. Insert the battery into the
battery chamber.
3. Snap the battery door closed.
• After you load a new battery into the
camera, reset the date and time.
6
2. Press and hold the menu button (23)
for approximately 4 seconds until
US appears on the LCD panel (14).
• When you release the button, the
language code “blinks.”
3. Press the right or left side of the zoom
dial (2) or the select button (22)
to cycle to your selection.
Setting the language
US English is initially set into the memory
of this camera, but you can select
another language (12 options available).
See the table on page 7 for the List of
languages
and the LCD (Liquid Crystal
Display) abbreviated codes.
1. Completely lift up the lens cover/
flash (4) to uncover the lens (8) and to
turn on the camera.
SELECT
MENU
ENTER
P
CH
7
List of languages
Languages LCD display
American English US
UK English En
German dEU
French FrA
Spanish ESP
Japanese JP
Danish dEn
Finnish FI
Italian I
Norwegian nor
Portuguese P
Swedish S
4. Press the enter/self-timer button (21)
to complete your selection.
g
SELECT
MENU
ENTER
8
Date and time imprinting
Traditional cameras print date and/or
time information directly onto the film.
Your camera uses the film’s magnetic
data-recording capability to record date
and time information, which your
photofinisher can imprint only on the
back of your photographs. This camera
has a quartz clock and automatic
calendar through the year 2099.
Setting the date and time
Choose from three formats:
(month/day/year, day/month/year, or
year/month/day) and time format
(hour/minute) with PM display.
1. Repeatedly press the menu
button (23) to scroll and select the
desired function.
2. Press the select button (22).
• The first number(s) in the date- or
time-option mode will “blink.”
3. Press the zoom dial (2) or select
button (22) to change the number(s).
• Press the right side of the zoom dial
to increase the number and the left
side to decrease the number.
SELECT
MENU
ENTER
SELECT
MENU
ENTER
Tabla de contenidos
Idiomas:
Otros manuales de Cámara digital de Kodak
Kodak
Kodak Z981 - EXTENDED GUIDE Manual de servicio
Kodak
Kodak C875 - EasyShare 8MP Digital Camera Manual de usuario
Kodak
Kodak easyshare p880 Manual de usuario
Kodak
Kodak M530 - EXTENDED GUIDE Manual de servicio
Kodak
Kodak M380 - EASYSHARE Digital Camera Manual de usuario
Kodak
Kodak EASYSHARE Z5010 Manual de servicio
Kodak
Kodak C643 - EasyShare 6.1MP Digital Camera Manual de usuario
Kodak
Kodak MD81 - Easyshare Digital Camera Manual de servicio
Kodak
Kodak DCS 600 Series Manual de usuario
Kodak
Kodak EASYSHARE CD153 Manual de usuario
Kodak
Kodak Z760 - EASYSHARE Digital Camera Manual de usuario
Kodak
Kodak EASYSHARE C1530 Manual de usuario
Kodak
Kodak M420 - EasyShare 10MP 4x Optical/5x Digital Zoom HD... Manual de servicio
Kodak
Kodak V1073 - EASYSHARE Digital Camera Manual de usuario
Kodak
Kodak SIX-20 Brownie Instrucciones de funcionamiento
Kodak
Kodak PRINTOMATIC Manual de usuario
Kodak
Kodak EasyShare Zoom Digital Camera DX7590 Manual de usuario
Kodak
Kodak C633 - Easyshare Printer Dock Series 3 Manual de usuario
Kodak
Kodak C613 - EasyShare 6.2MP Digital Camera Manual de usuario
Kodak
Kodak PIXPRO FZ41 Manual de usuario
