KOBE Range Hoods

Brillia Series

CHX91 SQB-2 Series

Model No.: CHX9130SQB-1 (30”) / CHX9136SQB-1 (36”)

CHX9130SQB-2 (30”) / CHX9136SQB-2 (36”)

INSTALLATION INSTRUCTIONS

AND OPERATION MANUAL

IMPORTANT

READ THIS FIRST

READ BEFORE INSTALLTAION

1. Carefully check all contents of package(s).

2. Thoroughly inspect the unit for any shipping damages, cosmetic

damages or defects.

3. Have a certified contractor/electrician test the unit before installation.

IF THERE IS ANY PROBLEMS:

1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL

PACKAGING MATERIALS.

2. Have your original invoice as proof of purchase and product serial

number ready.

3. Contact your merchant for product replacement due to shipping

damages, cosmetic damages or defects.

4. For all other issues, email customer.service@koberangehoods.com.

NO RETURN, NO REFUND, NO EXCHANGE IF:

1.PRODUCT HAS BEEN INSTALLED

2.KNOCK-OUT HOLES HAVE BEEN PUNCTURED

3.MISSING ORIGINAL PACKAGING MATERIAL

AND/OR PARTS


[ENGLISH]

- READ AND SAVE THESE INSTRUCTIONS -

CONTENTS
IMPORTANGE SAFETY INSTRUCTIONS .....................................................................1
COMPONENTS OF PACKAGE ......................................................................................3
INSTALLATION...............................................................................................................4
OPERATING INSTRUCTIONS .......................................................................................9
MAINTENANCE............................................................................................................10
SPECIFICATIONS ........................................................................................................11
MEASUREMENTS & DIAGRAMS.................................................................................12
PARTS LIST..................................................................................................................14
CIRCUIT DIAGRAM......................................................................................................15
TROUBLE SHOOTING.................................................................................................16
WARRANTY..................................................................................................................17
WARRANTY INFORMATION FORM............................................................................19

 - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -

ALL WIRING MUST BE DONE BY A PROFESSIONAL AND IN
ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES

Control Number: 5011098

IMPORTANGE SAFETY INSTRUCTIONS

- PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION -

WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY,

OBSERVE THE FOLLOWING:

1. Installation and electrical wiring must be done by qualified professionals and in accordance with

all applicable codes and standards, including fire-rated construction.

2. When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other

hidden utilities.

3. Ducted fans must be vented to the outside.

a. Before servicing or cleaning unit, open the light panel and SWITCH POWER OFF AT

SERVICE PANEL.

b. Clean all grease laden surfaces frequently. To reduce the risk of fire and to disperse air

properly, make sure to vent air outside. DO NOT vent exhaust air into wall spaces, attics,

crawl spaces or garages.

NOTE

This warranty is void without an authorized agent’s receipt or if unit is

damaged due to misuse, poor installation, improper use, mistreatment,

negligence or any other circumstances beyond the control of KOBE

authorized agents. Any repair carried out without the supervision of

KOBE authorized agents automatically void the warranty.

KOBE will not be held responsible for any damages to personal property

or real estate or any bodily injuries whether caused directly or indirectly

by the range hood.

WARNING: TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE

TOP GREASE FIRE:

1. Keep all fan, baffle/spacer/filter/oil tunnel/oil container and grease-laden surfaces clean. Grease

should not be allowed to accumulate on fan, baffle/spacer/filter/oil tunnel/oil container.

2. Always turn hood ON when cooking.

3. Use high setting on cooking range ONLY when necessary.

4. Do not leave cooking range unattended when cooking.

5. Always use cookware and utensils appropriate for the type and amount of food prepared.

6. Use this unit only in the manner intended by the manufacturer.

7. Before servicing, switch power off at service panel and lock service panel (if possible) to prevent

power from switching on accidentally.

8. Clean ventilating fan frequently.

What to Do in the Event of a Range Top Grease Fire

1. SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner.

KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do

not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.

2. NEVER PICK UP A BURNING PAN –You May Get Burned.

3. DO NOT USE WATER, including wet dishcloths or towels –a steam blast will result.

4. Use an extinguisher ONLY if:

a. You have a Class A, B, C extinguisher and know how to operate it.

b. The fire is small and contained in the area where it started.

c. The fire department has been called.

d. You can fight the fire with your back to an exit.

What to Do If You Smell Gas

1. Extinguish any open flame.

2. Do not try to turn on the lights or any type of appliance.

3. Open all doors and windows to disperse the gas. If you still smell gas, call the Gas Company and

Fire Department right away.

CAUTION

1. For general ventilation use only. Do not use to exhaust hazardous or explosive materials and

vapors.

2. To reduce the risk of fire, use only metal ductwork. Sufficient air is needed for proper combustion

and exhausting of gases through the flue (chimney) to prevent back drafting.

3. Follow the heating equipment manufacturer’s guideline and safety standards such as those

published by the National Fire Protection Association (NFPA), and the American Society for

Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and code authorities.

4. Activating any switch on may cause ignition or an explosion.

5. Due to the size and weight of this hood, installation by 2 persons is recommended.

ELECTRICAL SHOCK HAZARD –Can result in serious injury or death.

Disconnected appliance from electric power before servicing. If

equipped, the fluorescent light bulb contains small amounts of mercury,

which must be recycled or disposed of according to Local, State, and

Federal Codes.

COMPONENTS OF PACKAGE

(Must keep all materials for returns or refunds)

Range Hood Box

Duct Cover Box

(For Wall Mount Application Models Only)

{A} KOBE Range Hood

{B} Warranty Registration Card

{C} Quick Reference Guide

{D} 6” Round Vent Exhaust (Pre-Installed)

{E} 3-1/4” x 10” Exhaust

{F} Top Vent Cover with Rectangular

Opening

{G} Top Vent Cover (to block Round

Exhaust)

{H} Oil Tunnel x 1

{I} Baffle Filters x 2

{J} Stainless Steel Spacers x 2

{K} Screws

{A} {B} {C}

{D} {E} {F}

{G} {H} {I}

{J} {K}

{L} Adjust Duct Cover

{M} Duct Cover-Mounting Bracket

{N} Duct Cover Support x 2

{O} Hood-Mounting Bracket

{P} Screws

{L}

{M} {N}

{O}

{P}

•FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.koberangehoods.com OR

CONTACT KOBE RANGE HOODS AT 626-775-8880.

QTY: 6

Size: 4*8

QTY: 8

Size: 4*12

QTY: 5

Size: 4*35

INSTALLATION

PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING

Calculation before Installation

To calculate installation, please refer to TABLE 1 and TABLE 2. (All calculation in inches).

- FOR UNDER THE CABINET -

TABLE 1

A = Height of Floor to Ceiling

B = Height of Floor to Counter Top

(Standard: 36”)

C = Preferred Height of Counter Top to

Hood Bottom (Minimum 26” to 30”)

D = Height of hood

E = Height of the Cabinet

- FOR WALL MOUNT (WITH OPTIONAL DUCT COVER) -

TABLE 2

A = Height of Floor to Ceiling

B = Height of Floor to Counter Top

(Standard: 36")

C = Preferred Height of Counter Top to

Hood Bottom (Minimum 26" to 30")

D = Height of Hood

E = Height of Duct Cover [F –D]

F = Height of the Hood Installation

[A –(B+C)]

SAFETY WARNING

•HOOD MAY HAVE SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF REMOVING

ANY PARTS FOR INSTALLING, CLEANING, OR SERVICING.

•BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER DAMAGE TO THE HOOD MAY

OCCUR. USING HAND TOOLS IS RECOMMENDED. DO NOT OVER TIGHTEN SCREWS.

•MAKE SURE TO PREVENT ANY DEBRIS FROM ENTERING THE VENT OPENING TO AVOID

DAMAGE OR MALFUCTION.

UNDER CABINET INSTALLATION

Before Installation

1. Read any provided document(s).

2. Test the range hood by temporarily connecting it to an outlet and turning ON the fan and lights.

3. If you run into any problems, contact KOBE Range Hoods.

Venting Options and Requirements

4. The range hood has 3 exhaust options: Top 6” Round, Top

3-1/4” x 10” Rectangular, and Rear 3-1/4” x 10”

Rectangular. The range hood is factory set for vertical or

horizontal venting using round or rectangular vent adapter.

5. Decide the location of the venting pipe from the hood to

the outside. A straight, short vent run will allow the hood to

perform more efficiently. Try to avoid elbows, transitions,

and long run as much as possible as this may reduce the

performance of the hood. Make sure that the duct work

leads to the outside.

6. It is recommended to use metal/aluminum duct/pipe with a

uniform size (ex. 6” round pipe from range hood to the

outside).

7. If an elbow is necessary, a minimum of 12” straight run is

necessary before the elbow.

8. For Top 6” Round vent installation: The 6” Round vent is

already attached. (Refer to Figure 1)

9. For Top 3-1/4” x 10” Rectangular vent installation only:

Remove attached 6” Round vent and discard. Keep seven

screws to install the rectangular vent. Align and secure

Top Vent Cover with RectangularOpeningwith one screw.

Then align and secure 3-1/4” x 10” Rectangular with two

screws. (Refer to Figure 2)

10. For Rear 3-1/4” x 10” Rectangular vent installation only:

Remove attached 6” Round vent and discard. Keep seven

screws to install the rectangular vent. Align and secure

Top Vent Cover with seven screws to block the top

exhaust (Figure 3). Remove the duct knockout from back

of the hood. Keep the screws and discard the duct

knockout. Then align and secure 3-1/4” x 10” Rectangular

with two screws (Figure 4).

Clearance

11. Clearance is the distance between the cooktop and the

bottom of the range hood. The recommended minimum

clearance for this model is 26” and the maximum clearance

is 30”.

12. It is important to install the hood at the recommended

clearance. Installing too low could result in damage and/or

fire hazard while installing too high may result in reduce

performance and efficiently.

*Note: 6” Round Vent Exhaust is pre-installed

on the range hood.

Figure 1

Figure 2

Figure 3

Hood Installation

13. Remove any protective film off the hood, if any.

14. For installing under the cabinet with recessed bottom,

attach 4-inch wide wood filler strips (not included) on each

side (Figure 5).

15. Create access opening for electrical plug or wires and

hood exhaust under the cabinet.

16. Align the hood in the center of the cabinet. As an optional

step, you may position a flat-surfaced object below the

hood as a support. Alternatively, another person can

temporarily hold the hood.

17. There are 4 installing holes on top of the hood. Attached

four 4*35 screws through the installing holes from the

bottom to the top. The best way is to do this in a diagonal

pattern: front left screw first then back right screw or vice

versa. Make sure all the screws are tightened and the

hood is secured before releasing hold/support.

18. Optional step: There areadditional 4 installing holes at the

back of the hood. Attached four 4*35 screws through the

installing holes from the front to the back. The best way is

to do this in a diagonal pattern. Make sure all the screws

are tightened and the hood is secured before releasing

hold/support.

Ductwork

19. Once the hood is attached to the cabinet, connect the pipe

onto the hood exhaust and secure the joint with duct tape.

Make sure that it is completely air tight.

Electrical Wire

20. Connect the range hood to an outlet.

21. If hardwired is desired, cut off the plug and connect three wires (black, white, green) to the outlet

wires and cap with wire connections (not provided). Connect the wires according to color (ex.

black to black).

Finish

22. Before using, make sure that any accessories such as filters are properly installed where

applicable.

23. Test the range hood to see if it is working properly.

THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY

QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND LOCAL

ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL

AND LOCK SERVICE PANEL TO PREVENT POWER FROM BEING SWITCHED ON ACCIDENTALLY.

Figure 4

Figure 5

WALL MOUNT INSTALLATION

Before Installation

1. Read any provided document(s).

2. Test the range hood by temporarily connecting it to an outlet and

turning ON the fan and lights.

3. If you run into any problems, contact KOBE Range Hoods.

Venting Options and Requirements

4. The range hood has 3 exhaust options: Top 6” Round, Top 3-1/4”

x 10” Rectangular, and Rear 3-1/4” x 10” Rectangular. The range

hood is factory set for vertical or horizontal venting using round or

rectangular vent adapter.

5. Decide the location of the venting pipe from the hood to the

outside. A straight, short vent run will allow the hood to perform

more efficiently. Try to avoid elbows, transitions, and long run as

much as possible as this may reduce the performance of the

hood. Make sure that the duct work leads to the outside.

6. It is recommended to use metal/aluminum duct/pipe with a

uniform size (ex. 6” round pipe from range hood to the outside.).

7. If an elbow is necessary, a minimum of 12” straight run is

necessary before the elbow.

8. For Top 6” Round vent installation: The 6” Round vent is already

installed. (Refer to Figure 1)

9. For Top 3-1/4” x 10” Rectangular vent installation only: Remove

attached 6” Round vent and discard. Keep seven screws to install

the rectangular vent. Align and secure Top Vent Cover with

Rectangular Opening with one screw. Then align and secure 3-

1/4” x 10” Rectangular with two screws. (Refer to Figure 2)

10. For Rear 3-1/4” x 10” Rectangular vent installation only: Remove

attached 6” Round vent and discard. Keep seven screws to install

the rectangular vent. Align and secure TopVent Cover with seven

screws to block the top exhaust (Figure 3). Remove the duct

knockout from back of the hood. Keep the screws and discard the

duct knockout. Then align and secure 3-1/4” x 10” Rectangular

with two screws (Figure 4).

Clearance

11. Clearance is the distance between the cooktop and the bottom of

the range hood. The recommended minimum clearance for this

model is 26” and the maximum clearance is 30”.

12. It is important to install the hood at the recommended clearance.

Installing too low could result in damage and/or fire hazard while

installing too high may result in reduced performance and efficiently.

Hood Installation

13. Secure hood-mounting bracket and two duct cover-mounting bracket support on top of the hood

with eight 4*12 screws. Refer to Figure 5.

*Note: 6” Round Vent Exhaust is pre-

installed on the range hood.

Figure 1

Figure 2

Figure 3

Figure 4

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Campana de ventilación de KOBE

KOBE

KOBE CH22 SQB-5 Series Guía de solución de problemas

KOBE

KOBE CX-183 Guía de solución de problemas

KOBE

KOBE RA9436SQF Guía de solución de problemas

KOBE

KOBE BRILLIA INX26 Series Guía de solución de problemas

KOBE

KOBE IN-027 Series Guía de solución de problemas

KOBE

KOBE CHX2030SQB-1 Guía de solución de problemas

KOBE

KOBE IS2336SQB-DC16-1 Guía de solución de problemas

KOBE

KOBE CHX8136SF Guía de solución de problemas

KOBE

KOBE IN28 SQP Series Guía de solución de problemas

KOBE

KOBE RA2230SQB-1 Guía de solución de problemas

KOBE

KOBE RA9230SQB-DC30-1 Guía de solución de problemas

KOBE

KOBE Brillia CHX7930SQB-WM-1 Manual de operación y mantenimiento

KOBE

KOBE INX28 SQ-700-2 Series Guía de solución de problemas

KOBE

KOBE RA3830S Guía de solución de problemas

KOBE

KOBE RA-094 Guía de solución de problemas

KOBE

KOBE IS2336SQ Guía de solución de problemas

KOBE

KOBE RA9230SQB Guía de solución de problemas

KOBE

KOBE CX1836GS Guía de solución de problemas

KOBE

KOBE SQB-650-5A Series Guía de solución de problemas

KOBE

KOBE CHX81 SQB-1 Manual de usuario

KOBE

KOBE CH2230SQB-1 Guía de solución de problemas

KOBE

KOBE CH9130SQB Guía de solución de problemas

KOBE

KOBE CH7936SQB Manual de usuario

KOBE

KOBE Brillia RAX21 SQB-2 Series Guía de solución de problemas

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
