Kitsound Mini Buddy Manual de usuario
1
kitsound.co.uk
JB. 3643 / Made in China. © KitSound™ 2015
Christchurch, Dorset. BH23 4FL, UK
USER MANUAL
MINI BUDDY
BLUETOOTH
SPEAKER
2 3
We are craftspeople.
We are musicians.
We are KitSound™
And we all commit ourselves to achieving
one shared goal: Bringing people closer
to their music. By truly understanding
music we stay true to its craft.
Pure, rich, incredible sound.
We’ll settle for nothing less.
4 5
Please read this manual
carefully before use.
Box contents
• KS Mini Buddy Bluetooth speaker
• Micro USB charge cable
• User manual
Functions
1. ON/OFF switch
2. LED indicator
3. Micro USB charge port
4. Aux input
2
4
1
3
USB 5 V
6 7
Charging the battery
The speaker has a built-in rechargeable
lithium battery. Make sure the speaker is
switched off. Connect one end of the micro
USB charge cable to the micro USB charge
port (3) on the speaker and connect the other
end to your PC or USB mains adaptor.
The battery will start charging.
• It takes up to 3 hours to fully charge
the battery
• Whilst charging, the LED indicator (2)
will be solid red
• When fully charged, the LED indicator (2)
will turn off
Bluetooth setup
Pairing a Bluetooth device
for the first time
With the speaker turned off:
1. Slide the ON/OFF switch (1)
to the ON position
2. Wait for 4 seconds and the LED
indicator (2) will flash blue quickly
3. Activate the Bluetooth feature on
your device and search for Bluetooth
devices (check your device’s manual
if you’re unsure how to do this)
[continued...]
8 9
Note: If your device is not connecting
automatically, it’s because it is not the
last paired device. Simply delete ‘BT MINI
BUDDY’ from the list of Bluetooth devices
on your device and re-pair.
Re-pairing or pairing new devices
1. Make sure the Bluetooth is turned
off on any previously paired devices
2. Follow ‘Pairing a Bluetooth device’
instructions from step 1
4. Select ‘BT MINI BUDDY’ from the list of
found devices
5. If asked for a passcode, enter ‘0000’ and
the speaker will then be connected to
your device
6. After pairing successfully, the LED
indicator (2) will intermittently flash blue
7. The next time the speaker is switched on,
it will automatically search for and attempt
to connect to the last paired device
[...continued] Bluetooth setup
[continued...]
10 11
Using the aux audio input
1. With the speaker turned on, insert the
3.5 mm audio cable into the aux input (4)
on the speaker
2. The LED indicator (2) will be solid blue
and any active Bluetooth connection
will disconnect
3. Plug the other end of the aux cable into
the audio/headphone output on an MP3
player or other audio source
4. Audio played through the connected device
will now be heard through the speaker
5. The volume can be adjusted on your
device only
Playing audio wirelessly
1. Follow the instructions in the ‘Pairing
a Bluetooth device’ section
2. Use the controls on your device to
select content
3. Audio played through the connected
Bluetooth device will now be heard
through the speaker
4. To play/pause and skip track you will
need use the controls on your device
5. The volume can be adjusted using only
your device
[...continued] Bluetooth setup
12 13
PLEASE NOTE:
Your device will have an internal amplifier
and if it is playing digital files like MP3s it
will also have an integrated DAC (Digital
Audio Converter). If you turn up the volume
to 100%, your device will be sending distorted
signals to the speaker. To avoid this and to
get the best sound quality from the speaker,
we recommend that you do not run your
device any higher than 95% volume.
Please DON’T:
• Get the speaker wet
• Drop the speaker as this will
invalidate your warranty
• Open up the speaker as there are
no user serviceable parts inside
• Expose the speaker to extreme
temperatures or rapid changes
of hot to cold or vice versa
Please DO:
• Clean the speaker with a soft dry
cloth and no detergents
14 15
We apologise for any inconvenience caused by minor
inconsistencies in these instructions, which may occur
as a result of product improvement and development.
Troubleshooting
We hope you’ve now got all the information
you need to get started, but if you’re having
problems with anything, please feel free to
contact us at: support@kitsound.co.uk
Specifications
Bluetooth V2.1
Bluetooth range up to 10 m
Battery Li-ion, 180 mAh
Output RMS 2 W
Frequency response 180 Hz – 20 kHz
Driver 36 mm
Aux-in 3.5 mm
Play time up to 4 hours
Charging time up to 3 hours
