KitchenAid®New Generation

Stand Mixer Service Manual

Intended for Professional Service Technician Only

Domestic Models - Including Commercial - KF26M22,KF26M2C,KF26M2X,KG25H0W,KG25H0X,

KG25H3X,KL26M8X,KM25G0X,KP26KPRA,KP26M1FQ,KP26M1P,KP26M1XA,KP26M1X, KP26M1XEP,

KP26M1XFQ,KP26M1XQ,KP26M8X,KP26N9X,KT2651X,KV25G0X,KV25H0X, KV25MCX,KV25MEX,

InternationalModel–4KB25G1,4KG25H3X,4KP26M1X,4KV25H0X,8KP2670T,





KitchenAid®

New Gen Stand Mixer Service/Repair Manual

Intended for Professional Service Technician Only

CoversDomesticModel–KB26G1X,KF26M22,KF26M2C,KF26M2X,KG25H0W,KG25H0X,

KG25H3X,KL26M8X,KM25G0X,KP26KPRA,KP26M1FQ,KP26M1P,KP26M1XA,

KP26M1X,KP26M1XEP,KP26M1XFQ,KP26M1XQ,KP26M8X,KP26N9X,KT2651X,KV25G0X,

KV25H0X,KV25MCX,KV25MEX,

InternationalModel–4KB25G1,4KG25H3X,4KP26M1X,4KV25H0X,8KP2670T,

Table of Contents

Subject Page(s)

Color Variation Parts Diagram 4

Base and Pedestal Diagram 6

Commercial Bowl Lift Diagram 7

Case, Gearing and Planetary Diagram 10

Important Service Workplace Safety Recommendations 24

Service Environment 24

Personal Protection 25

Electrical Considerations 25

Important Safeguards 25

Electrical Requirements 26

List of Tools Required 26

Testing the Stand Mixer 26

Service Procedures: 27

Removal of the Trim Band 27

Removal of the Upper Housing 27

Remove Control Board 28

Remove Transmission Housing 28

Remove 1st Stage Gear 28

Remove Motor 29

Remove Planetary 30

Removal of the Lower Housing 30

Remove Base 30

Remove Bowl lift Mechanism 31

Rebuilding the New Generation Stand Mixer 32

Replacing the Bowl Lift Mechanism 32

Replace Lower Housing 32

Replace Planetary 33

Replace Gears 33

Replace Transmission Cover 34

Replace Motor 34

Replace Control Board 35

Replace Upper Housing 35

Appendix Subject Page(s)

A. Tools Required for Stand Mixer Service

Introduction

All KitchenAid Stand Mixers are well designed and carefully built. Normally they will give continual use year after

year without service attention.

Records have been maintained to determine and correct, through improved design, any troubles that might possibly

develop. An effort has been made in preparation of this manual to cover them all.

These units have had many improvements over time, please pay close attention to the following

illustrations. There are multiple gear and motor combinations as well as housings.

Models – KT, KD, all used the 53 tooth 1st stage gear and a 8 tooth motor. If you change the 1st stage gear to the

new 60 tooth 1st stage gear then you must change to the 10 tooth motor. Same as if you change the motor you will

have to change the 1st stage gear because they will not work unless they are paired up right. You may also need to

change the lower housing because the new motor (9706548) will not fit into the original housing (Pictures on

pages 17 and 18).

KitchenAid recommends that the plastic Transmission Housings be replaced with the new Magnesium Housing

and Gasket. (8212396)

The new control board(9706509) can be used on older units as long as you change the cord to the new

cord(W10325656).

5 QT. STAND MIXER

MODELS:

KG25H0XWH5 (White)

KG25H0XBK5 (Imperial Black)

KG25H0XOB5 (Onyx Black)

KG25H0XER5 (Empire Red)

KG25H0XMC5 (Metallic Chrome)

KG25H0XCL5 (Crystal Blue)

KG25H0XCE5 (Copper Pearl)

KG25H0XBU5 (Cobalt Blue)

KG25H0XQG5 (Liquid Graphite)

KG25H0XGA5 (Green Apple)

KG25H0XIC5 (Ice)

KG25H0XAQ5(AquaSky)

KG25H0XBY5 (Boysenberry)

KG25H0XES5 (Espresso)

KG25H0XGC5 (Gloss Cinnamon)

KG25H0XMY5 (Majestic Yellow)

KG25H7XWH5 (White)

KG25H7XOB5 (Onyx Black)

KG25H7XER5 (Empire Red)

KG25H7XSL5 (Silver)

KG25H3XWH5 (White)

KG25H3XOB5 (Onyx Black)

KG25H3XER5 (Empire Red)

KG25H3XSL5 (Silver)

4KG25H3XER5 (Empire Red)

4KG25H3XOB5 (Onyx Black)

4KG25H3XSL5 (Silver)

4KG25H3XWH5 (White)





1

2

5

3

ColorVariationParts



Illus.No. PartNo.Descr Illus.No.  PartNo.Descr.

1  MotorHousing  4  BowlSupportandPins

9703311White     9707633White

9703532ImperialBlack     9708853ImperialBlack

9705296OnyxBlack9707876OnyxBlack

9705300EmpireRed9707883EmpireRed

9709571Silver9709582Silver

9703433MetallicChrome   9709123MetallicChrome

W10562403CrystalBlue   W10532418CrystalBlue

9709152CopperPearl    W10625482CopperPearl

9705380CobaltBlue    W10672071CobaltBlue

W10513715LiquidGraphite   W10707409LiquidGraphite

W10342782GreenApple   W10726831GreenApple

W10726426IceW10726436Ice

W10577728AquaSkyW10808334AquaSky

W10342784Boysenberry   W10819157Boysenberry

W10453625EspressoW10808331Espresso

W10114555GlossCinnamon   W10808330GlossCinnamon

9705301MajesticYellow   W10819160MajesticYellow

2 W10749681TrimBand   5  LowerGearcase

3  Planetary9706047White

9708172White9706301ImperialBlack

9708174ImperialBlack9706311OnyxBlack

9708176OnyxBlack    W10343980Boysenberry

9708180EmpireRed9706331EmpireRed

9709575Silver9709578Silver

9708175MetallicChrome   9706306MetallicChrome

W10562408CrystalBlue   W10562412CrystalBlue

9709156CopperPearl9709159CopperPearl

9708182CobaltBlue9706341CobaltBlue

W10513719LiquidGraphite   W10513724LiquidGraphite

W10343681GreenApple   W10343978GreenApple

W10726430IceW10726433Ice

W10577733AquaSkyW10577750AquaSky

W10343683BoysenberryW10453632Espresso

W10114559GlossCinnamon   W10114562GlossCinnamon

9708181MajesticYellow   9706336MajesticYellow





ColorVariationParts

Illus.No. PartNo.Descr Illus.No.  PartNo.Descr.

6  ColumnandPin 7 BaseandFootAssembly

9703673White9703690White

9703526ImperialBlack9703511ImperialBlack

9705320OnyxBlack9705344OnyxBlack

9705324EmpireRed9705348EmpireRed

9709585Silver9709588Silver

9703349MetallicChrome   9703346MetallicChrome

W10562421ChrystalBlue   W10562424CrystalBlue

9709166CopperPearl9709169CopperPearl

9706341CobaltBlue9705388CobaltBlue

W10513737LiquidGraphite   W10513740LiquidGraphite

W10344072GreenApple   W10344173GreenApple

W10726438IceW10726441Ice

W10577769AquaSkyW10577773AquaSky

W10344074Boysenberry   W10344175Boysenberry

W10453639EspressoW10453644Espresso

W10114569GlossCinnamon   W10114572GlossCinnamon

9705325MajesticYellow   9705349MajesticYellow





BaseandPedestalUnitParts



BaseandPedestalUnitParts



Illus.No.  PartNo.Description



1  W10581080  UseandCareGuide

2  W10439369  Foot

3   W10354780  Bowl

4  240185  Pin,RetainingBowl

5  W10504114  BowlRetainer

6  3400018  Screw

7  BowlSupportandPins(RefertoColorVariationPartsPageforModelNumber) 

8  BaseandFootAssembly(RefertoColorVariationPartsPageforModelNumber)

9  9708649  Foot

10  9703307  RetainingRing

11  9706787  BowlLiftRod

12  9237LiftRodSpring

13  9703439  Washer

14  8533907  Nut

15  ColumnandPins(RefertoColorVariationPartsPageforModelNumber)

16  W10376294  FlatBeater(Stainless)

17  W10462785  DoughHook(Stainless)

18  9706885  BowlLiftArm

19  W10600940  WireWhip

20  9703426  AdjustingCam

21  3400863  Screw

22  9706788  BowlLiftHandle

23  9706814  VentScreen

24  3400200  Screw


