KitchenAid KFP1133 Manual de usuario
KFP1133
INSTRUCTIONS
INSTRUCTIONS
INSTRUCCIONES
W10679565B.indb 1 3/22/2019 4:15:52 PM
2 | PARTS AND FEATURES
3-piece food pusher
Work bowl cover with
3-in-1 feed tube
11-cup (2.6 L)
work bowl
PARTS AND FEATURES
PARTS AND ACCESSORIES
Externally adjustable
slicing control
Heavy-duty base
W10679565B.indb 2 3/22/2019 4:15:52 PM
ENGLISH
PARTS AND FEATURES | 3
PARTS AND FEATURES
Externally
adjustable slicing
disc (thin to thick) Multipurpose
stainless steel
blade
Mini-bowl and Mini-blade
Storage case
Dough blade
Reversible (2mm-4mm)
shredding disc
Reversible shredding
disc adapter
PARTS AND ACCESSORIES
W10679565B.indb 3 3/22/2019 4:15:53 PM
4 | PARTS AND FEATURES
PARTS AND FEATURES
ACCESSORIES SELECTION GUIDE
ACTION SETTING FOOD ACCESSORY
Chop
Cheese
Chocolate
Fruit
Fresh herbs
Nuts
Tofu
Vegetables
Multipurpose stainless steel blade
OR
Mini-bowl and Mini multipurpose
stainless steel blade
+
Mince Puree
Mix
Pasta Sauce
Pesto
Salsa
Sauces
Knead
Batter
Sweet dough
Yeast dough
Plastic dough blade
Slice
thick
Slice
thin
Fruit (soft)
Potatoes
Tomatoes
Vegetables
(soft)
Externally adjustable slicing disc
A
d
j
u
s
t
a
b
l
e
S
l
i
c
i
n
g
(
t
h
i
n
t
o
t
h
i
c
k
)
Cheese
Chocolate
Fruit (hard)
Vegetables
(hard)
Shred
medium Shred
fine
Potatoes
Vegetables
(soft)
Reversible shredding disc
+
Cabbage
Cheese
Chocolate
Fruit (hard)
Vegetables
(hard)
NOTE: Accessories shown are not all available with every model.
W10679565B.indb 4 3/22/2019 4:15:55 PM
ENGLISH
FOOD PROCESSOR SAFETY | 5
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Food Processor in water
or other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they are closely supervised and instructed concerning use
of the appliance by a person responsible for their safety. Close supervision is
necessary when any appliance is used by or near children. Children should be
supervised to ensure that they do not play with appliance.
4. Turn the appliance OFF. then unplug from the outlet when not in use, before
assembling, disassembling parts and before cleaning. To unplug, grasp he plug
and pull from the outlet. Never pull from the power cord.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Contact the
manufacturer at their customer service telephone number for information on
examination, repair, or adjustment.
7. The use of attachments not recommended or sold by KitchenAid may cause
re, electric shock, or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
FOOD PROCESSOR SAFETY
W10679565B.indb 5 3/22/2019 4:15:55 PM
6 | FOOD PROCESSOR SAFETY
10. Do not ll the bowl above the marked maximum ll line (or rated capacity) to
avoid risk of injury due to damage to the cover or bowl.
11. Keep hands and utensils away from moving blades or discs while processing
food to reduce the risk of severe injury to persons or damage to the Food
Processor. A scraper may be used but must be used only when the Food
Processor is not running.
12. Blades are sharp. Handle carefully.
13. To reduce the risk of injury, never place cutting blade or discs on base without
rst putting bowl properly in place.
14. Be certain cover is securely locked in place before operating appliance.
15. Never feed food by hand. Always use the food pusher.
16. Do not attempt to defeat the cover interlock mechanism.
SAVE THESE INSTRUCTIONS
FOOD PROCESSOR SAFETY
ELECTRICAL REQUIREMENTS
Voltage: 120 Volts
Frequency: 60 Hz
NOTE: This Food Processor is equipped
with a polarized plug (one blade is wider
than the other). To reduce the risk of
electrical shock, this plug will fit in a
polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a
qualified electrician. Do not modify the
plug in any way.
This product is designed for household use only
W10679565B.indb 6 3/22/2019 4:15:55 PM
ENGLISH
ASSEMBLING THE FOOD PROCESSOR | 7
ASSEMBLING THE FOOD PROCESSOR
BEFORE FIRST USE
Before using your Food Processor for the first time, wash all parts and accessories either
by hand or in the dishwasher (see “Cleaning the Food Processor” section).
NOTE: Your Food Processor is shipped with the work bowl cover installed on the work
bowl, with the mini-bowl inside the work bowl.
IMPORTANT: Place the Food Processor on a dry, level countertop with the controls
facing forward. Do not plug in the Food Processor until it is completely assembled.
HELPFUL TIP: See the “Lid Interlock Instructions” for more information on the best way
to attach the work bowl and lid for best results.
1Grasp the feed tube on the work
bowl cover and turn it clockwise to
remove it from the work bowl. 2Lift out the mini-bowl.
ATTACHING THE WORK BOWL
IMPORTANT: Your Food Processor will not operate unless the work bowl and work
bowl cover are properly locked on the base, and the large pusher is inserted to the
maximum fill line on the feed tube (approximately halfway down).
1
Place the work bowl on the base,
aligning the raised portion with the
indentation on the base. The center
hole should fit over the power shaft.
2Grasp the work bowl handle and turn
the bowl counterclockwise to lock it
on the base.
Power Shaft
W10679565B.indb 7 3/22/2019 4:15:56 PM
8 | ASSEMBLING THE FOOD PROCESSOR
ASSEMBLING THE FOOD PROCESSOR
ATTACHING THE WORK BOWL COVER
NOTE: Be sure to install the desired accessory before attaching the work bowl cover.
1
Place the work bowl cover on the
work bowl with the feed tube just
to the left of the work bowl handle.
Grasp the feed tube and turn the
cover to the right until it locks into
place.
2
Fit the food pusher into the 3-in-1
feed tube. See “Using the 3-in-1 feed
tube” for details on working with
different sized foods.
INSTALLING THE ADJUSTABLE SLICING DISC
1Hold the slicing disc by the finger
grips and lower it onto the drive
adapter. 2Install the work bowl cover, being sure
it locks into place.
TIP: You may need to turn the disc/drive adapter until it drops down into place.
W10679565B.indb 8 3/22/2019 4:15:56 PM
ENGLISH
ASSEMBLING THE FOOD PROCESSOR | 9
ASSEMBLING THE FOOD PROCESSOR
ADJUSTING THE SLICING THICKNESS
NOTE: The lever only works with the
adjustable slicing disc. Changing thickness
settings with other discs or blades
installed will have no effect on operation.
INSTALLING THE REVERSIBLE SHREDDING DISC
Thicker
Thinner
1
Hold the or reversible shredding
disc by the 2 finger grips with the
desired shredding side facing UP.
Insert the disc adapter into the hole
in the bottom of the disc.
2With the work bowl installed, slide
the drive adapter onto the power
shaft.
TIP: You may need to turn the disc/adapter until it drops down into place.
Drive adapter
Finger grip
3Install the work bowl cover, being sure
it locks into place.
Set the desired slicing thickness by
moving the lever to the left for thinner
slices or to the right for thicker slices.
W10679565B.indb 9 3/22/2019 4:15:57 PM
10 | ASSEMBLING THE FOOD PROCESSOR
ASSEMBLING THE FOOD PROCESSOR
INSTALLING THE MULTIPURPOSE BLADE OR DOUGH BLADE
IMPORTANT: The multipurpose blade and dough blade can only be used with the work
bowl.
1Place the blade on the power shaft.
Rotate the blade so it falls into place
on the power shaft. 2Push to lock: Press down firmly on
the blade until it is down as far as it
will go.
TIP: The multipurpose blade features an internal seal that fits tightly over the center of
the work bowl.
3Install the work bowl cover, being sure
it locks into place.
W10679565B.indb 10 3/22/2019 4:15:57 PM
