KitchenAid 5KFP1319 Series Manual de usuario

Food Processor

5KFP1319*

W11616360A.indb 1W11616360A.indb 1 6/21/2022 5:05:06 PM6/21/2022 5:05:06 PM

PARTS AND FEATURES

1Heavy-Duty Base

2Power Cord and Cord Storage

(not shown)

3Drive Pin

413-Cup (3.1 L) Work Bowl

5Handle Hinge

6Lid Hinge

7Slicing Knob

8Work Bowl Cover with 3-in-1 Feed

Tube

9Lid Latch

10 3-in-1 Food Pusher

11 Refrigerator Lid

12 Externally Adjustable Slicing Disc

(thin to thick)

13 Reversible Fine/Medium Shredding

Disc

14 Multipurpose Stainless Steel Blade

15 Dough Blade

16 Drive Adapter (Upper)

17 Drive Adapter (Lower)

O/Pulse

W11616360A.indb 2W11616360A.indb 2 6/21/2022 5:05:07 PM6/21/2022 5:05:07 PM

ENGLISH

PARTS AND FEATURES

18 Dicing Kit Cover

19 Dicing Blade

20 Dicing Kit Base

21 Dicing Kit Clean Out Tool

22 Storage Caddy

ACCESSORY GUIDE

Accessory Included with Model

5KFP1319*

External Adjustable Slice

•

Storage Caddy

•

Wide Mouth Opening •

3-in-1 Feed Tube •

Multipurpose Blade •

Dough Blade •

Thin and Medium Shred •

Storage Lid •

•

Dicing Kit

W11616360A.indb 3W11616360A.indb 3 6/21/2022 5:05:07 PM6/21/2022 5:05:07 PM

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. To protect against risk of electrical shock, do not put Food Processor in water

or other liquid.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they are closely supervised and instructed concerning use

of the appliance by a person responsible for their safety. Close supervision is

necessary when any appliance is used by or near children.

4. Turn the appliance “O” (off), then unplug from the outlet when not in use, before

assembling or disassembling parts and before cleaning. To unplug, grasp the

plug and pull from the outlet. Never pull from the Power Cord.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorised Service Centre for examination, repair, or

electrical or mechanical adjustment.

7. The use of attachments not recommended or sold by KitchenAid may cause

re, electric shock, or injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter.

10. Keep hands and utensils away from moving Blades or discs while processing

food to reduce the risk of severe injury to persons or damage to the Food

Processor. A scraper may be used but must be used only when the Food

Processor is not running.

11. Blades are sharp. Handle Carefully. Care should be taken when handling the

sharp cutting blades, emptying the bowl and during cleaning.

PRODUCT SAFETY

W11616360A.indb 4W11616360A.indb 4 6/21/2022 5:05:07 PM6/21/2022 5:05:07 PM

ENGLISH

12. To reduce the risk of injury, never place cutting Blade or discs on Base without

rst putting bowl properly in place.

13. Be certain Cover is securely locked in place before operating the Food

Processor.

14. Never feed food by hand. Always use the Food Pusher.

15. Do not attempt to defeat the Cover interlock mechanism.

16. Do not ll the bowl above the marked maximum ll line to avoid risk of injury

due to damage to the Cover or bowl.

17. Children should be supervised to ensure that they do not play with the

appliance

18. Never leave the appliance unattended while it is in operation.

19. If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualied persons in order to avoid a hazard.

20. Be careful if hot liquid is poured into the Food Processor as it can be ejected

out of the appliance due to a sudden steaming.

21. Allow the appliance to cool completely before putting on or taking off parts,

and before cleaning the appliance.

22. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

23. This appliance is intended to be used in household and similar applications

such as:

- staff kitchen areas in shops, ofces, or other working environments;

- farmhouses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

SAVE THESE INSTRUCTIONS

PRODUCT SAFETY

ELECTRICAL REQUIREMENTS

Voltage: 220-240 V~

Frequency: 50-60 Hz

NOTE: This Food Processor is equipped with a polarized plug (one Blade is wider than

the other). To reduce the risk of electrical shock, this plug will fit in a polarized outlet only

one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,

contact a qualified electrician. Do not modify the plug in any way.

W11616360A.indb 5W11616360A.indb 5 6/21/2022 5:05:07 PM6/21/2022 5:05:07 PM

Action Setting Food Accessory

Chop 1 or Pulse

Cheese*

Chocolate*

Fruits

Fresh herbs

Nuts*

Tofu

Vegetables

Beef***

Multipurpose Stainless

Steel Blade

Mince or Purée 2 or Pulse

Mix 1

Pasta Sauce

Pesto

Salsa

Sauces

Batters

Slice

(thin to thick)

Fruit (soft)

Potatoes

Tomatoes

Vegetables (soft) Externally Adjustable

Slicing Disc

Cheese

Fruit (hard)

Vegetables (hard)

Shred

(ﬁne to medium)

1Potatoes

Vegetables (soft)

Reversible Fine/Medium

Shredding Disc

Cabbage

Cheese

Chocolate

Fruits (hard)

Vegetables (hard)

Dice 1

Potatoes

Vegetables

Fruit

Cheese

Dicing Kit

Knead 1Yeast**

Dough** Dough Blade

ACCESSORIES SELECTION GUIDE

GETTING STARTED

*For these ingredients it is not recommended to process quantities larger than 500g

(1∕4of work bowl) with the Multipurpose Stainless Steel Blade.

**For these ingredients it is not recommended to process quantities larger than 384g.

***Do not process more than 225g, chop beef into 1cm cubes prior to adding to bowl.

NOTE: Do not operate the appliance exceeding a maximum of 3 minutes. After 3

minutes the appliance needs to cool down to avoid overheating.

W11616360A.indb 6W11616360A.indb 6 6/21/2022 5:05:07 PM6/21/2022 5:05:07 PM

ENGLISH

Before ﬁrst use

Before using your Food Processor for the first time, wash all parts and accessories either

by hand or in the dishwasher (see “Care and Cleaning” section).

NOTE: Your Food Processor is designed so that all accessories may be stored inside the

Work Bowl.

Lift up the Lid Latch to unlock the Cover.

Tilt the Work Bowl Cover back and lift it

straight up so that the Lid Hinge pulls out

of the Handle Hinge.

Remove all parts and accessories from

the Work Bowl, and lift the Food Pusher

out of the Feed Tube.

Place the Work Bowl on the Base, aligning

the Handle with the raised button on the

right side of the Base. The bowl will click

into place and should be flush against the

Base when properly aligned.

Place the Drive Adapter in the Work

Bowl, lowering it onto the Drive Pin.

PRODUCT ASSEMBLY

IMPORTANT: Place the Food Processor on a dry, level countertop with the controls

facing forward. Do not plug in the Food Processor until it is completely assembled.

W11616360A.indb 7W11616360A.indb 7 6/21/2022 5:05:08 PM6/21/2022 5:05:08 PM

PRODUCT ASSEMBLY

NOTE: For ease of assembly, install the desired Blade or Disc before attaching the Work

Bowl Cover.

NOTE: Your Food Processor will not operate unless the Work Bowl Cover is fully closed,

the large Food Pusher is in place, and the Work Bowl is properly seated on the Base.

To attach the Work Bowl Cover, hook the

Lid Hinge into the Handle Hinge on the

Work Bowl and close the Cover.

Once the Work Bowl Cover is closed, the

Lid Latch will lock in position.

5 6

INSTALLING THE MULTIPURPOSE BLADE OR DOUGH BLADE

Install the Lower Drive Adapter onto the

Upper Drive Adapter. Place the Blade on

the Drive Adapter. Rotate the Blade so it

falls down to the Base of the Adapter.

Install the Work Bowl Cover, and be sure

the Lid Latch is pushed down to the

locked position.

W11616360A.indb 8W11616360A.indb 8 6/21/2022 5:05:08 PM6/21/2022 5:05:08 PM

ENGLISH

PRODUCT ASSEMBLY

TIP: You may need to adjust the Drive Adapter with a slight turn on the power shaft until

it drops into place. For easiest installation, make sure the Adjustment Knob is in the “0”

position.

INSTALLING THE EXTERNALLY ADJUSTABLE SLICING DISC

ADJUSTING THE SLICING THICKNESS

Hold the Slicing Disc by the finger grips

and lower it onto the Drive Adapter.

To attach the Work Bowl Cover, hook the

Lid Hinge into the Handle Hinge on the

Work Bowl and close the Cover.

Once the Work Bowl Cover is closed, the

Lid Latch will lock in position.

NOTE: The Knob only works with

the Externally Adjustable Slicing Disc.

Changing thickness settings with other

discs or Blades installed will have no effect

on operation.

NOTE: Your Food Processor will not

operate unless the Work Bowl Cover is

fully closed and the Work Bowl is properly

seated on the Base.

Set the desired thickness by moving the

Knob to the left for thinner slices and to

the right for thicker slices.

Thinner

Thicker

1 2

W11616360A.indb 9W11616360A.indb 9 6/21/2022 5:05:09 PM6/21/2022 5:05:09 PM

INSTALLING THE DICING KIT

With the Work Bowl removed from the

Base, place Dicing Kit Base, Blade (text

side up) , and Cover in the Work Bowl.

Align Dicing Kit Cover with wide mouth

feed shoot.

Place the Work Bowl Cover on the Work

Bowl. Take out small and/or medium

Feed Tube. Insert food to dice.

After dicing, remove the Work Bowl

Cover, Dicing Kit Cover and Dicing Blade,

then insert the Dicing Kit Clean Out Tool

into the Dicing Kit Base and push any

extra food through the grid.

1 2

3 4

PRODUCT ASSEMBLY

PRODUCT USAGE

Before operating the Food Processor, be

sure the Work Bowl, Blades/Disc, and Work

Bowl Cover are properly assembled on the

Base (see the “Product Assembly” section).

W11616360A.indb 10W11616360A.indb 10 6/21/2022 5:05:09 PM6/21/2022 5:05:09 PM

Tabla de contenidos

Idiomas:

Otros manuales de Procesador de alimentos de KitchenAid

KitchenAid

KitchenAid 5KFP13FF Manual de usuario

KitchenAid

KitchenAid 5KFPCB700A Guía rápida

KitchenAid

KitchenAid 12 CUP KFP750 Manual de usuario

KitchenAid

KitchenAid 5KFC3516P Manual de usuario

KitchenAid

KitchenAid KFP0722 Manual de usuario

KitchenAid

KitchenAid KFP750WH - Food Processor With 2 Bowls Manual de usuario

KitchenAid

KitchenAid KFC0516 Manual

KitchenAid

KitchenAid KFC0516CU Manual de usuario

KitchenAid

KitchenAid KFP0919Q Manual de usuario

KitchenAid

KitchenAid 4KFP740CR0 Manual de usuario

KitchenAid

KitchenAid KFP710 Guía rápida

KitchenAid

KitchenAid KFP750 Guía rápida

KitchenAid

KitchenAid KFP1317 Manual de usuario

KitchenAid

KitchenAid KFP0718 Manual de usuario

KitchenAid

KitchenAid Food Processor Guía rápida

KitchenAid

KitchenAid KFP0719L Manual de usuario

KitchenAid

KitchenAid KFC3511 Manual de usuario

KitchenAid

KitchenAid KFPW760 Manual de usuario

KitchenAid

KitchenAid KFC3511 Manual de usuario

KitchenAid

KitchenAid KFP0718 Manual de usuario

KitchenAid

KitchenAid KFP0718L Manual de usuario

KitchenAid

KitchenAid KFCR500 Manual de usuario

KitchenAid

KitchenAid PRO LINE KPFP850 series Manual de usuario

KitchenAid

KitchenAid PROFESSIONAL 670 Guía rápida

Manuales populares de Procesador de alimentos de otras marcas

INNOLIVING

INNOLIVING INN-727 Manual de usuario

Berkel

Berkel C32 Manual de usuario

Beko

Beko CHP5554W Manual de usuario

QUIGG

QUIGG KM 2017Wi.20 Manual de usuario

Lakeland

Lakeland PRESS AND CHOP 31557 Manual de usuario

Bosch

Bosch MMR08 GB Series Manual de usuario

HOFFEN

HOFFEN Chef Express T9532 Manual de usuario

Garland

Garland 852 ZG Manual de usuario

Robot Coupe

Robot Coupe CL50 Gourmet Manual de usuario

SAPIRHOME

SAPIRHOME SP-1111-K Manual de usuario

Moulinex

Moulinex DJ3051 Manual de usuario

Bosch

Bosch MUM5 Manual de usuario

cecotec

cecotec Mambo Touch Manual de usuario

Black & Decker

Black & Decker hc 300 Instrucciones de instalación

Gorenje

Gorenje SBR 1000 DV Manual de usuario

Arzum

Arzum AR 1128 Manual de usuario

Saturn

Saturn ST-FP0069 Manual de usuario

Vitek

Vitek VT-1641 W Manual de usuario
