KitchenAid KFC3511MY0 Manual de usuario

English

TABLE OF CONTENTS

FOOD CHOPPER SAFETY

Important Safeguards.................................................................................................6

Electrical Requirements.............................................................................................7

Electrical Equipment Waste Disposal ........................................................................7

PARTS AND FEATURES................................................................................................8

OPERATING YOUR FOOD CHOPPER

Before First Use ........................................................................................................9

Disassembling the Food Chopper .............................................................................9

Using the Food Chopper.........................................................................................10

Removing Ingredients ..............................................................................................10

Operating Tips for Great Results ............................................................................11

CARE AND CLEANING...............................................................................................12

TROUBLESHOOTING.................................................................................................12

WARRANTY AND SERVICE.......................................................................................13

FOOD CHOPPER INSTRUCTIONS

W10505786A_01_EN_v6.indd 5 9/13/12 11:01 AM

FOOD CHOPPER SAFETY

SAVE THESE INSTRUCTIONS

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instructions.

2. To protect against risk of electrical shock do not put motor body, cord or electrical

plug of this Food Chopper in water or other liquid.

3. This appliance is not intended for use by persons (including children) with reduced

physical sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by

a person responsible for their safety.

4. Children should be supervised to ensure that they do not play with the appliance.

5. Unplug from outlet when not in use, before putting on or taking off parts, and

before cleaning.

6. Avoid contacting moving parts.

7. Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest

Authorized Service Facility for examination, repair or electrical or mechanical adjustment.

8. The use of attachments not recommended or sold by the manufacturer may cause re,

electric shock or injury.

9. Do not use outdoors.

10. Do not let cord hang over edge of table or counter.

11. Keep hands and utensils away from the cutting blade while chopping food to reduce

the risk of severe injury to person or damage to the Food Chopper. A scraper may

be used but only when the Food Chopper is not running.

12. Blade is sharp. Handle carefully.

13. To reduce the risk of injury, never place cutting blade on base without rst putting

bowl properly in place.

14. Be certain cover is securely locked in place before operating Food Chopper.

15. Do not attempt to defeat the cover interlock mechanism.

16. This product is designed for household use only.

IMPORTANT SAFEGUARDS

W10505786A_01_EN_v6.indd 6 9/13/12 11:01 AM

English

FOOD CHOPPER SAFETY

Electrical Requirements

Voltage: 220-240 Volts

Frequency: 50/60 Hertz

Wattage: 240 Watts

NOTE: If the plug does not t in the outlet,

contact a qualied electrician. Do not modify

the plug in any way.

This appliance is marked according to the

European directive 2002/96/EC on Waste

Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed

of correctly, you will help avoid potential

negative consequences for the environment

and human health, which could otherwise

be caused by inappropriate waste handling

of this product.

The symbol on the product, or on the

documents accompanying the product,

indicates that this appliance may not be

treated as household waste. Instead it shall

be handed over to the applicable collection

point for the recycling of electrical and

electronic equipment.

Disposal must be carried out in accordance

with local environmental regulations

for waste disposal.

For more detailed information about

treatment, recovery and recycling of this

product, please contact your local city ofce,

your household waste disposal service or

the shop where you purchased the product.

Electrical Equipment Waste Disposal

W10505786A_01_EN_v6.indd 7 9/13/12 11:01 AM

PARTS AND FEATURES

Domed Lid with

Wet Ingredient Adder

830 mL (3,5 Cup)

Work Bowl

Power Cord

Storage

Stainless Steel

Multipurpose Blade

Base

Speed 1/Speed 2 Buttons

The Food Chopper features easy

one-handed operation with top-mounted

buttons. 2 speeds provide optimal results,

regardless of the task: Use the Speed 1

button for everyday chopping needs. Use

the Speed 2 button to quickly purée

ingredients.

Stainless Steel Multipurpose Blade

This strong, razor-sharp blade quickly

processes small amounts of meats, fresh

or cooked fruits and vegetables, nuts and

herbs. Blade locks on the shaft to stay

in place while you pour out ingredients.

Reverse spiral design pulls foods down into

blade for uniform chopping, and minimizes

need to scrape sides of bowl. The blade is

dishwasher-safe.

Speed 1/Speed 2

Buttons

Domed Lid with Wet Ingredient Adder

The domed lid locks into place to operate

the Food Chopper, and removes easily to

add ingredients. A wet ingredient adder hole

and well in the lid allows you to add liquid

ingredients without removing the lid. The lid

is dishwasher-safe.

830 mL (3,5 Cup) Work Bowl

The BPA-free 830 mL (3,5 cup) capacity

bowl provides a generous working capacity,

and removes easily from the base. The work

bowl is dishwasher-safe.

Power Cord Storage

The power cord wraps under the base for

convenient storage.

W10505786A_01_EN_v6.indd 8 9/13/12 11:01 AM

English

OPERATING YOUR FOOD CHOPPER

Before First Use

1. Before using the KitchenAid Food

Chopper for the rst time, wash the

work bowl, lid, and blade in hot, soapy

water. Work bowl, lid, and blade may also

be washed in the top rack of a dishwasher.

2. Read Food Chopper Operating Tips

for recommendations on how to get

consistently great results.

Disassembling the

Food Chopper

To disassemble the Food Chopper for

cleaning and when removing ingredients

from the bowl, follow the instructions

below:

1. Be sure the Food Chopper is unplugged.

2. Holding the lid as shown, twist lid

clockwise to unlock, and lift off the bowl.

3. Pull the blade straight up to unlock and

remove it from the bowl.

4. Holding the bowl as shown, twist bowl

clockwise to unlock, and lift off the base.

W10505786A_01_EN_v6.indd 9 9/13/12 11:01 AM

OPERATING YOUR FOOD CHOPPER

Using the Food Chopper

1. Be sure the Food Chopper is unplugged.

2. Align the tabs on the work bowl with

the L-slots on the base. Twist bowl

counterclockwise to lock into place.

3. Fit the blade over the shaft in the

center of the work bowl, rotate, and

press down until it locks into operating

position.

5. Place the lid on the workbowl, aligning

the L-slots on the lid with the tabs on the

work bowl. Twist lid counterclockwise to

lock into place as shown below.

NOTE: Bowl and lid must be locked in

place for the Food Chopper to operate.

6. Plug power cord into electrical outlet.

7. Press and hold

Speed 1 button

or Speed 2 button

to start processing.

Removing Ingredients

1. Once the blade has stopped spinning,

remove lid by twisting it clockwise and

lifting it off.

2. Remove the work bowl from the base

by twisting it clockwise and lifting it off.

Blade locks on the shaft to stay in place

while you pour out ingredients

3. Use a spatula to remove ingredients

from the work bowl.

4. To remove blade for cleaning, pull the

blade straight up to unlock and remove

it from the bowl.

8. Use the wet ingredient adder to add

liquid ingredients while processing,

if desired. See “Operating Tips for

Great Results”.

9. When ingredients are chopped to the

desired consistency, release the Speed 1

button or Speed 2 button.

NOTE: Food Chopper will not

operate if both buttons are pressed

at the same time.

4. Place ingredients to be processed into

the work bowl.

W10505786A_01_EN_v6.indd 10 9/13/12 11:01 AM

English

OPERATING YOUR FOOD CHOPPER

Operating Tips for Great Results

1. To achieve optimal

results when grinding

raw meat, use the

Speed 2 button

to grind up to 225 g

(1/2 pound) of meat at one time.

2. For best processing results, press and

release the Speed 1 button or Speed 2

button. Repeat until ingredients reach

the consistency you want.

3. Use the wet ingredient adder to add

liquid ingredients such as olive oil during

processing.

4. Use your Food Chopper to make bread,

cracker, or cookie crumbs. Break bread,

crackers, or cookies into small pieces,

add to work bowl and process into

crumbs.

5. For uniform consistency of processed

foods, cut carrots, celery, mushrooms,

green peppers, onions and similar

vegetables into 2-3 cm (1 inch) pieces

before adding to work bowl.

6. Use your Food Chopper to chop nuts

and mince parsley, basil, chives, garlic

and other herbs.

7. Make baby food by using your Food

Chopper to purée cooked fruit or

vegetables. Puréed, cooked fruits and

vegetables can also be used as bases for

soups or sauces.

8. Do NOT use your Food Chopper to

process coffee beans or hard spices such

as nutmegs. Processing these foods could

damage the Food Chopper.

9. Do NOT use your Food Chopper

to chop food more than 30 seconds

continuously.

Wet ingredient

adder

W10505786A_01_EN_v6.indd 11 9/13/12 11:01 AM

TROUBLESHOOTING

If your Food Chopper should

malfunction or fail to operate,

check the following:

• Make sure that the bowl and lid are

properly aligned and locked in place.

• Press only one button at a time. The Food

Chopper will not operate if both buttons

are pressed at the same time.

• Is the Food Chopper plugged in?

• Is the fuse in the circuit to the Food

Chopper in working order? If you have

a circuit breaker box, be sure the circuit

is closed.

• Unplug the Food Chopper, then plug

it back into the outlet.

• If the Food Chopper is not at room

temperature, wait until unit reaches

room temperature and retry.

If the problem is not due to one of the

above items, see “Warranty and Service”.

1. Unplug the Food Chopper.

2. Remove the work bowl, lid and blade.

Wash in hot, soapy water. Rinse and dry.

Work bowl, lid, and blade can also be

washed in the top dishwasher rack.

3. Wipe the base clean with a damp cloth.

Do not use abrasive cleaners. Do not

immerse the base in water.

4. To protect the blade, always reassemble

your Food Chopper after cleaning.

CARE AND CLEANING

W10505786A_01_EN_v6.indd 12 9/13/12 11:01 AM

English

WARRANTY AND SERVICE

Household KitchenAid Food Chopper Warranty

Length of

Warranty: KitchenAid Will Pay For: KitchenAid Will Not

Pay For:

Europe,

Australia and

New Zealand:

For Model

5KFC3515:

Two years Full

Warranty from

date of purchase.

The replacement parts and

repair labor costs to correct

defects in materials or

workmanship. Service must

be provided by an Authorized

KitchenAid Service Center.

A. Repairs when Food Chopper

is used for operations other

than normal household

food preparation.

B. Damage resulting from accident,

alterations, misuse, abuse, or

installation/operation not in

accordance with local

electrical codes.

KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR

INDIRECT DAMAGES.

Service Centers

All service should be handled locally by

an Authorized KitchenAid Service Center.

Contact the dealer from whom the unit was

purchased to obtain the name of the nearest

Authorized KitchenAid Service Center.

In the U.K.:

Call: 0845 6011 287

In Ireland:

M.X. ELECTRIC

Service Department

25 Alymer Crescent

Kilcock, Co. KILDARE

Call: 87 2581574

Fax: 1 628 4368

In Australia:

Call: 1800 990 990

In New Zealand:

Call: 0800 881 200

Customer Service

In U.K. & Ireland:

Tollfree number 0800 988 1266

(Calls from mobile phones are charged

standard network rate)

For Southern Ireland:

Tollfree number +44 (0) 20 8616 5148

www.KitchenAid.co.uk

www.KitchenAid.eu

Address:

KitchenAid Europa, Inc.

PO BOX 19

B-2018 ANTWERP 11

BELGIUM

W10505786A_01_EN_v6.indd 13 9/13/12 11:01 AM

W10505786A

Specications subject to change without notice. 09/12

W10505786A_01_EN_v6.indd 14 9/13/12 11:01 AM

Tabla de contenidos

Otros manuales de Procesador de alimentos de KitchenAid

KitchenAid

KitchenAid KFP1355 Manual de usuario

KitchenAid

KitchenAid 5KFP0719 Manual de usuario

KitchenAid

KitchenAid 4KFP750ER1 Manual de usuario

KitchenAid

KitchenAid KFP1317 Manual de usuario

KitchenAid

KitchenAid KFPM770NK1 Manual de usuario

KitchenAid

KitchenAid 5KFP1319 Series Manual de usuario

KitchenAid

KitchenAid KFC3516 Instrucciones de instalación

KitchenAid

KitchenAid KFP0918L Manual de usuario

KitchenAid

KitchenAid KFP1333 Manual de usuario

KitchenAid

KitchenAid KFP300 Manual de usuario

KitchenAid

KitchenAid KFC3511 Manual de usuario

KitchenAid

KitchenAid KJA09 Manual de usuario

KitchenAid

KitchenAid KFP1133WH Manual de usuario

KitchenAid

KitchenAid KFC0516 Manual de usuario

KitchenAid

KitchenAid KFP1642 Manual de usuario

KitchenAid

KitchenAid KFP0719L Manual de usuario

KitchenAid

KitchenAid 5KFP1318 Series Manual de usuario

KitchenAid

KitchenAid KFP0919Q Manual de usuario

KitchenAid

KitchenAid 4KFPW760OB1 Manual de usuario

KitchenAid

KitchenAid 5KFC3511DWH0 Manual de usuario

KitchenAid

KitchenAid KFP600 - Ultra Power Food Processor Manual de usuario

KitchenAid

KitchenAid KSMMGA Manual de usuario

KitchenAid

KitchenAid KJA03 Manual de usuario

KitchenAid

KitchenAid 4KFP740WH1 Manual de usuario

Manuales populares de Procesador de alimentos de otras marcas

INNOLIVING

INNOLIVING INN-727 Manual de usuario

Berkel

Berkel C32 Manual de usuario

Beko

Beko CHP5554W Manual de usuario

QUIGG

QUIGG KM 2017Wi.20 Manual de usuario

Lakeland

Lakeland PRESS AND CHOP 31557 Manual de usuario

Bosch

Bosch MMR08 GB Series Manual de usuario

HOFFEN

HOFFEN Chef Express T9532 Manual de usuario

Garland

Garland 852 ZG Manual de usuario

Robot Coupe

Robot Coupe CL50 Gourmet Manual de usuario

SAPIRHOME

SAPIRHOME SP-1111-K Manual de usuario

Moulinex

Moulinex DJ3051 Manual de usuario

Bosch

Bosch MUM5 Manual de usuario

cecotec

cecotec Mambo Touch Manual de usuario

Black & Decker

Black & Decker hc 300 Instrucciones de instalación

Gorenje

Gorenje SBR 1000 DV Manual de usuario

Arzum

Arzum AR 1128 Manual de usuario

Saturn

Saturn ST-FP0069 Manual de usuario

Vitek

Vitek VT-1641 W Manual de usuario
