KitchenAid 5KFPCB700A Guía rápida

FOOD

PROCESSOR

INSTRUCTIONS AND RECIPES

5KFPCB700A

Australia: 1800 990 990

New Zealand: 0800 881 200

CUPS

2.8

LITERS

KitchenAid.com.au

KitchenAid.co.nz

Proof of Purchase & Product Registration

Always keep a copy of the sales receipt

showing the date of purchase of your

Food Processor. Proof of purchase will

assure you of in-warranty service.

Before you use your Food Processor, please

fill out and mail your product registration

card packed with the unit. This card will

enable us to contact you in the unlikely

event of a product safety notification and

assist us in complying with the provisions

of the Consumer Product Safety Act. This

card does not verify your warranty.

Please complete the following for your

personal records:

Model Number ______________________________________________________________

Serial Number _______________________________________________________________

Date Purchased ______________________________________________________________

Store Name and Location______________________________________________________

Table of Contents

INTRODUCTION

Proof of Purchase & Product Registration.............................................. Inside Front Cover

Food Processor Safety .....................................................................................................2

Important Safeguards .....................................................................................................3

Electrical Requirements ...................................................................................................4

FEATURES AND OPERATION

Food Processor Features..................................................................................................5

Preparing the Food Processor for Use

Before First Use .......................................................................................................6

Work Bowl Assembly...............................................................................................6

Multipurpose Blade and Dough Blade Assembly ......................................................7

Using the Food Processor

Before Use...............................................................................................................8

Maximum Liquid Level.............................................................................................8

Turning the Food Processor On and Off ...................................................................8

Using the Pulse Control ...........................................................................................8

The 2-Piece Food Pusher..........................................................................................9

Disassembling the Food Processor................................................................................. 10

CARE AND CLEANING

Cleaning the Food Processor .........................................................................................11

Troubleshooting............................................................................................................12

FOOD PROCESSING TIPS

Using the Multipurpose Blade....................................................................................... 13

Using the Dough Blade................................................................................................. 13

Helpful Hints................................................................................................................. 14

WARRANTY AND SERVICE INFORMATION

KitchenAid®Household Food Processor Warranty..........................................................15

Service Centers..............................................................................................................16

How to Arrange for Service after the Warranty Expires..................................................16

How to Order Accessories and Replacement Parts.........................................................17

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your

appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you

and others.

All safety messages will follow the safety alert symbol and either

the word “DANGER” or “WARNING.” These words mean:

You can be killed or seriously

injured if you don’t immediately

follow instructions.

You can be killed or seriously injured

if you don’t follow instructions.

All safety messages will tell you what the potential hazard is, tell you how to

reduce the chance of injury, and tell you what can happen if the instructions are

not followed.

Food Processor Safety

DANGER

WARNING

IMPORTANT SAFEGUARDS

When using electrical appliances, basic

safety precautions should always be

followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical

shock do not put Food Processor in

water or other liquid.

3. Unplug from the outlet when not in

use, before putting on or taking off

parts, and before cleaning.

4. Avoid contacting moving parts.

5. Do not operate any appliance with a

damaged cord or plug, or after the

appliance malfunctions, or is dropped

or damaged in any manner. Return

appliance to the nearest Authorized

Service Facility for examination, repair,

or electrical or mechanical adjustment.

6. The use of attachments not

recommended or sold by the

manufacturer may cause fire, electric

shock or injury.

7. Do not use outdoors.

8. Keep hands and utensils away

from moving blades or discs while

processing food to reduce the

risk of severe injury to persons or

damage to the Food Processor. A

scraper may be used but must be

used only when the Food Processor

is not running.

9. Blades are sharp. Handle carefully.

10. To reduce the risk of injury, never

place cutting blade or discs on base

without first putting bowl properly

in place.

11. Be certain cover is securely locked in

place before operating appliance.

12. Never feed food by hand. Always

use the food pusher.

13. Do not attempt to defeat the cover

interlock mechanism.

14. This product is designed for

household use only.

15. This appliance is not intended for

use by persons (including children)

with reduced physical sensory

or mental capabilities, or lack of

experience and knowledge, unless

they have been given supervision or

instruction concerning use of the

appliance by a person responsible

for their safety.

16. Children should be supervised to

ensure that they do not play with

the appliance.

17. Switch off the appliance

and disconnect from supply

before changing accessories or

approaching parts that move in use.

SAVE THESE INSTRUCTIONS

Model 5KFPCB700A:

Volts: 230-240 V.A.C.

Hertz: 50 Hz

NOTE: Model 5KFPCB700A has a 3 prong

grounded plug. To reduce the risk of

electrical shock, this plug will fit in an outlet

only one way. If the plug does not fit in the

outlet, contact a qualified electrician. Do not

modify the plug in any way.

Do not use an extension cord. If the

power supply cord is too short, have a

qualified electrician or serviceman install

an outlet near the appliance.

Electrical Shock Hazard

Plug into a grounded 3 prong

outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in death,

fire, or electrical shock.

WARNING

Electrical Requirements

Food Processor Features

Pulse

Stainless Steel

Multipurpose

Blade

Dough

Blade

Heavy-Duty Base

2-Piece

Food Pusher

Work Bowl

Cover with Tall

Feed Tube

12-Cup (2.8 L)

Work Bowl

Work Bowl Cover with Tall Feed Tube

Feed tube accommodates long food items

with a minimum of sectioning, so the

entire length of the tube can be filled

with food.

2-Piece Food Pusher

Pusher moves food through the tall feed

tube smoothly and easily. A small hole in

the bottom of the pusher insert makes it

easy to drizzle oil into ingredients – just

fill the insert with the desired amount of

oil. For smaller items, simply remove the

pusher insert and use the built-in small

feed tube. With the insert removed, the

pusher can also be used as a convenient

4 oz. (120 ml) measuring cup.

12-Cup (2.8 L) Work Bowl

The durable bowl provides capacity for

large jobs.

Stainless Steel Multipurpose Blade

Versatile blade chops, minces, blends,

mixes, and emulsifies in a matter

of seconds.

Dough Blade

The dough blade is specially designed for

mixing and kneading yeast dough.

Heavy-Duty Base

The base features the ”O”, “I”, and PULSE

buttons along with the power shaft,

which rotates the blades.

Preparing the Food Processor for Use

Before First Use

Before using your Food Processor for the

first time, wash the work bowl, work bowl

cover, feed tube pusher, and blades either

by hand or in the dishwasher (see “Cleaning

the Food Processor” on page 11).

Work Bowl Assembly

1. Place the Food Processor base on a

dry, level countertop with the controls

facing forward. Do not plug in the

Food Processor until it is completely

assembled.

2. With the handle just to the left of

center, place the work bowl on the

base, fitting the center opening over

the power shaft.

3. Grasp the work bowl handle and turn

the bowl to the right until it locks

into position.

4. Insert the mulitpurpose blade or

dough blade into the work bowl.

Place the blade on the power shaft.

Rotate the blade so it falls into place

on the shaft.

5. Place the work bowl cover on the work

bowl with the feed tube just to the left

of the work bowl handle. Grasp the

feed tube and turn the cover to the

right until it locks into place.

NOTE: To avoid damage to the work

bowl, do not attach the cover to the work

bowl before the work bowl is locked on

the base.

6. Fit the 2-piece food pusher into the

feed tube.

WARNING

Cut Hazard

Handle blades carefully.

Failure to do so can result in cuts.

OPulse

7. Plug into a proper electrical outlet (see

“

Electrical Requirements” on page 4).

NOTE: Your Food Processor will not

operate unless the work bowl and work

bowl cover are properly locked on the

base, and the pusher is inserted to the

maximum fill line on the feed tube.

Do not remove the work bowl from the

base without first removing the work

bowl cover. Damage to the work bowl

may result.

Multipurpose Blade and

Dough Blade Assembly

Place the blade on the power shaft.

Rotate the blade so it falls into place on

the shaft.

Off Pulse

WARNING

Cut Hazard

Handle blades carefully.

Failure to do so can result in cuts.

Electrical Shock Hazard

Plug into a grounded 3 prong

outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in death,

fire, or electrical shock.

WARNING

Preparing the Food Processor for Use

Before Use

Before operating the Food Processor, be

sure the work bowl, blades, and work

bowl cover are properly assembled on the

Food Processor base (see “Preparing the

Food Processor for Use” starting on page 6).

Maximum Liquid Level

This line on the work bowl indicates the

maximum level of liquid (32 oz. [1.0 L])

that can be processed by the Food

Processor.

Turning the Food Processor

On and Off

1. To turn on the Food Processor, press

the “I” Button. The Food Processor

will run continuously and the indicator

light will glow.

2. To stop the Food Processor, press

the ”O” Button. The indicator light

will go out and an automatic brake

will stop the action of the blade

within seconds.

3. Wait until the blade comes to a

complete stop before removing the

work bowl cover. Be sure to turn off

the Food Processor before removing

the work bowl cover, or before

unplugging the Food Processor.

NOTE: If the Food Processor fails to

operate, make sure the work bowl and

cover are properly locked on the base (see

“Preparing the Food Processor for Use“

starting on page 6).

Using the Pulse Control

The pulse control allows precise control of

the duration and frequency of processing.

It’s great for jobs which require a light

touch. Just press and hold the PULSE

Button to start processing, and release it

to stop. The indicator light will glow each

time the PULSE Button is pressed.

Pulse

Rotating Blade Hazard

Always use food pusher.

Keep fingers out of openings.

Keep away from children.

Failure to do so can result in

amputation or cuts.

WARNING

Using the Food Processor

Tabla de contenidos

Otros manuales de Procesador de alimentos de KitchenAid

KitchenAid

KitchenAid KFP1333 Manual de usuario

KitchenAid

KitchenAid KFP740 Guía rápida

KitchenAid

KitchenAid KFP0922 Manual de usuario

KitchenAid

KitchenAid 5KFC3515 Manual de usuario

KitchenAid

KitchenAid 5KCF0104 Manual de usuario

KitchenAid

KitchenAid KFP1333 Instrucciones de funcionamiento

KitchenAid

KitchenAid KFP1642 Manual de usuario

KitchenAid

KitchenAid 5KFC3516EER Manual de usuario

KitchenAid

KitchenAid KSMMGA Manual de usuario

KitchenAid

KitchenAid 5KFCB519A Manual de usuario

KitchenAid

KitchenAid KJA16 Manual de usuario

KitchenAid

KitchenAid KJA09 Manual de usuario

KitchenAid

KitchenAid 5KFP13FF Manual de usuario

KitchenAid

KitchenAid KFPW760QER - 700 Watt Ultra Wide Mouth Food... Manual de usuario

KitchenAid

KitchenAid KSM12FPA Manual de usuario

KitchenAid

KitchenAid 5KFP1318 Series Manual de usuario

KitchenAid

KitchenAid KFPW760 Manual de usuario

KitchenAid

KitchenAid 5KFC3511 Manual de usuario

KitchenAid

KitchenAid 5KFP0719 Manual de usuario

KitchenAid

KitchenAid KFC3516IC Manual de usuario

KitchenAid

KitchenAid KFP750AQ - Food Processor, Martha Stewart Guía rápida

KitchenAid

KitchenAid 5KFP1319 Series Manual de usuario

KitchenAid

KitchenAid 5KFP0719 Manual de usuario

KitchenAid

KitchenAid PRO LINE KPFP850 series Manual de usuario

Manuales populares de Procesador de alimentos de otras marcas

INNOLIVING

INNOLIVING INN-727 Manual de usuario

Berkel

Berkel C32 Manual de usuario

Beko

Beko CHP5554W Manual de usuario

QUIGG

QUIGG KM 2017Wi.20 Manual de usuario

Lakeland

Lakeland PRESS AND CHOP 31557 Manual de usuario

Bosch

Bosch MMR08 GB Series Manual de usuario

HOFFEN

HOFFEN Chef Express T9532 Manual de usuario

Garland

Garland 852 ZG Manual de usuario

Robot Coupe

Robot Coupe CL50 Gourmet Manual de usuario

SAPIRHOME

SAPIRHOME SP-1111-K Manual de usuario

Moulinex

Moulinex DJ3051 Manual de usuario

Bosch

Bosch MUM5 Manual de usuario

cecotec

cecotec Mambo Touch Manual de usuario

Black & Decker

Black & Decker hc 300 Instrucciones de instalación

Gorenje

Gorenje SBR 1000 DV Manual de usuario

Arzum

Arzum AR 1128 Manual de usuario

Saturn

Saturn ST-FP0069 Manual de usuario

Vitek

Vitek VT-1641 W Manual de usuario
