KitchenAid KCM1209 Manual de usuario

KCM1209

W11299037A_V2_Final.indb 1 18/10/2018 11:10:33

2| PARTS AND FEATURES

PARTS AND FEATURES

PARTS AND ACCESSORIES

Auto 12

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp PlateTimer

Clean

Bold

Brew/Cancel

Dosage ladder

Carafe lid

Carafe

handle

Glass carafe

Brew

basket

Gold tone

ﬁlter

Brew basket lid

Showerhead

Water tank lid

Cord storage in base

(not shown) Warming plate

Brew button

Water tank

handle

NOTE: Default measurement for 1 cup = approximately 5 oz (147 ml).

W11299037A_V2_Final.indb 2 18/10/2018 11:10:34

ENGLISH

PARTS AND FEATURES | 3

Auto 12 12

Auto Set 2Auto Set 1

Brew/Cancel

Hour Minute

Plate Temp Plate Timer

CleanBold

PARTS AND FEATURES

DISPLAY AND CONTROL PANEL FEATURES

Programmable display

A.M./P.M. indicator

Control panel

Brew icon

Bold icon

Auto icon 1 or 2

High Plate Temperature

Low Plate Temperature

Clock

Clean icon

Remaining Keep

Warm Time icon

W11299037A_V2_Final.indb 3 18/10/2018 11:10:34

4| COFFEE MAKER SAFETY

COFFEE MAKER SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions or is dropped or damaged in any manner. Return appliance to the

nearest Authorized Service Center for examination, repair or adjustment.

4. To protect against re, electric shock and injury to persons do not immerse

appliance in water or other liquid.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts, and before cleaning the appliance.

6. Close supervision is necessary when any appliance is used by or near children.

7. Do not let cord hang over the edge of table or counter or touch hot surfaces.

8. Do not place on or near a hot gas or electric burner, or in a heated oven.

9. The use of attachments not recommended or sold by KitchenAid may cause re,

electrical shock, or injury.

10. Do not use the appliance outdoors.

11. Do not use appliance for other than intended use.

12. Do not use appliance without lid properly placed on carafe.

13. The carafe is designed for use with this appliance. It must never be used on a

range top or in a microwave oven.

14. Do not set a hot carafe on a wet or cold surface.

15. To disconnect, turn any control to “off,” then remove plug from wall outlet.

16. Scalding may occur if the lid is removed during the brewing cycles.

17. Do not use a cracked carafe or a carafe having a loose or weakened handle.

W11299037A_V2_Final.indb 4 18/10/2018 11:10:34

ENGLISH

COFFEE MAKER SAFETY | 5

COFFEE MAKER SAFETY

18. Do not clean carafe with abrasive cleaners, steel wool pads, or other abrasive

material.

19. Do not ll the water tank above the marked maximum ll line.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

ELECTRICAL REQUIREMENTS

Voltage: 120 VAC

Frequency: 60 Hz

Wattage: 1100 Watts

NOTE: If the plug does not fit in the outlet,

contact a qualified electrician. Do not

modify the plug in any way. Do not use an

adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualified

electrician or service technician to install an

outlet near the appliance.

The cord should be arranged so that it will

not drape over the countertop or tabletop

where it can be pulled on by children or

tripped over unintentionally.

W11299037A_V2_Final.indb 5 18/10/2018 11:10:35

6| USING THE COFFEE MAKER

1 Cord is stored in base. If needed, gently pull cord

outwards until fully extended, or just long enough to

reach the outlet. Plug into a grounded 3 prong outlet.

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To set the hour: Press HOUR.

The Hour setting will begin to blink. The Hour digits

will change with each press; or press and hold

to scroll rapidly.

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To set the minutes: Press MINUTE.

The Hour setting will switch to a solid display and the

Minute setting will begin to blink. The Minute digits

will change with each press; or press and hold to scroll

rapidly.

To save the current displayed time and exit clock

setup: Press any other button (Auto Set1, Auto Set 2,

Plate Temp, Plate Timer, Bold, Clean or Brew); or do

not press any button for 10 seconds.

USING THE COFFEE MAKER

SETTING BREW STRENGTH

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To switch between Regular and Bold brew strengths:

Press the BOLD button.

Please note: While brewing small batches (2-4 cups),

using the “Bold Setting” is recommended.

NOTE: Regular is the default brew strength setting.

SETTING THE CLOCK

NOTE: When the Coffee Maker is first plugged in or when power is restored after an

interruption, the display will initially show 12:00 A.M.

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or

electrical shock.

W11299037A_V2_Final.indb 6 18/10/2018 11:10:35

ENGLISH

USING THE COFFEE MAKER | 7

USING THE COFFEE MAKER

FILLING THE COFFEE MAKER WITH WATER FOR BREWING

TIP: Brew 2 pots of fresh, cool water and discard before brewing the first pot of coffee.

Remove the water tank lid and pour with enough fresh,

cool water to make the desired amount of coffee.

Use the level markings on the water tank window.

Close the water tank lid properly.

Remove the water tank lid and then lift the water tank

up gently using handle. Pour enough fresh, cool water

to make the desired amount of coffee. Place the water

tank back in position. Use the alignment feature on the

water tank to make sure the water tank is properly in

place.

IMPORTANT: Make sure to fill the water tank with only the amount of water needed to

brew your desired number of cups. If you put in 12 cups of water, the Coffee Maker will

brew all 12 cups.

AutoSet 1

Brew/Cancel

AutoSet 2

Hour Minute

PlateTemp PlateTimer

Clean

Bold

Brew/Cancel

Place the Carafe in the Coffee Maker. Make sure the

lid is securely in position and bottom of the carafe is

fully seated; otherwise, the Pause and pour feature

may not engage, causing water and coffee to overﬂow

the brew basket.

ASSEMBLY AND USAGE OF BREW BASKET

Auto12

Raise the brew basket lid and remove the brew basket.

Insert the Gold Tone permanent ﬁlter or cone paper

ﬁlter into the brew basket.

TIP: The coffee ﬁlter can also be inserted and coffee

grounds added with or without removing the brew

basket from the Coffee Maker.

IMPORTANT: Do not use both types of ﬁlters at the same time.

Using both ﬁlters might cause water and coffee to overﬂow the brew basket.

W11299037A_V2_Final.indb 7 18/10/2018 11:10:36

8| USING THE COFFEE MAKER

USING THE COFFEE MAKER

AUTO SET 1 AND AUTO SET 2 FEATURE

Your Coffee Maker comes with two preset time options. Auto Set 1 and Auto Set 2 provide you

the ability to preset the coffee brewing time twice in week or day.

As desired, you can use Auto Set 1 to preset coffee brewing time for weekdays and Auto Set 2

can be preset for weekends. Or as per your preference, you can use Auto Set 1 to preset coffee

brewing time for morning coffee and Auto Set 2 can be preset for evening coffee.

NOTE: When the Coffee Maker is first plugged in or when power is restored after an

interruption, the display will initially show 12:00 A.M.

IMPORTANT: Be sure to set the correct time as per the instructions in “Setting the clock”

before using Auto Set 1 or Auto Set 2 feature.

PROGRAMMING THE AUTO SET 1 OR AUTO SET 2

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To Program the Coffee Maker to brew coffee at a

preset time: Press the AUTO SET 1 or AUTO SET 2

button one time. The “Auto 1 or 2” icon will ﬂash

respectively and the time display will change to the

currently set Auto Set 1or 2 time.

(12:00 A.M. is the default time.)

If using the Gold Tone permanent ﬁlter, add enough

amount of coffee ground by using Dosage Ladder

provided inside the Gold Tone permanent ﬁlter.

For example: If you need 12 cups of Brew Coffee, then

add coffee grounds till 12 cups scale level.

If using a cone paper coffee ﬁlter, place the ﬁlter inside

the brew basket, by gently pressing the ﬁlter into the

sides of the brew basket. Pre-wetting the paper ﬁlter is

not required.

Use the “Coffee Dosage Chart” provided on water

tank to add the enough amount of ground coffee.

NOTE: Use a medium grind appropriate for automatic drip Coffee Makers. Too fine a grind

will produce bitterness and may clog the coffee filter.

Auto12

Brew/Cancel

Auto12

Clean

Minute

Shake the brew basket slightly to even out the bed of

coffee ground. Place the basket into the Coffee Maker

and rotate the handle toward the front of the Coffee

Maker to lock the brew basket in place. Be sure the

brew basket lid is fully closed before brewing.

NOTE: Do not operate the Coffee Maker without the brew basket in place.

W11299037A_V2_Final.indb 8 18/10/2018 11:10:36

ENGLISH

USING THE COFFEE MAKER | 9

USING THE COFFEE MAKER

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To set the time the Coffee Maker should begin

brewing: Press the HOUR button. The hour digits will

change with each press; or press and hold to scroll

rapidly.

Next, press the MINUTE button. The Hour setting will

stay solid and the Minute setting will begin to blink.

The minute digits will change with each press; or press

and hold to scroll rapidly.

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To save the current displayed time and exit Auto Set

1 or Auto Set 2: Wait for 10 seconds, or press any

button (Clean, Bold or Brew). The Auto 1 or 2 indicator

will remain lit and the time display will go back to the

current time.

To cancel the Auto Set 1 or 2 time after programming

is complete: Press AUTO SET 1 or AUTO SET 2 again;

or press the BREW/CANCEL button.

NOTE: Please consider the default Brewing cycle time for a full pot (12 cups) is

approximately 10-minutes.

USING THE PREVIOUSLY PROGRAMMED AUTO SET 1 OR 2 TIME

These steps can be followed to save the Auto Set 1 or Auto Set 2 time after following the

steps in the “Programming the Auto Set 1 or 2 feature” section.

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Press the AUTO SET 1 or AUTO SET 2 button.

The Auto indicator will ﬂash and the time display will

show the previously set Auto time.

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To save the current displayed time and exit Auto Set:

Wait for 10 seconds, or press any button (Clean, Bold

or Brew). The Auto indicator will remain lit and the

time display will go back to the current time.

SETTING THE PLATE TEMPERATURE AND TIMER FEATURE

NOTE: Default Plate temperature for Coffee Maker is set at High Temperature.(icon)

Auto 1

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To set Plate Temperature: Press PLATE TEMP button.

By each press, you can select between Low Plate

temperature or High Plate temperature.

W11299037A_V2_Final.indb 9 18/10/2018 11:10:37

10 | USING THE COFFEE MAKER

USING THE COFFEE MAKER

BREWING COFFEE

TIP: Brew 2 pots of fresh, cool water and discard before brewing the first pot of coffee.

Auto12

AutoSet

Hour

BoldClean

Minute

Brew/Cancel

Brew

Auto 12

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Press the BREW button to begin brewing coffee. You

can use any of the BREW buttons provided on side or

on front. The Coffee Maker will beep 1 time, and the

“Brew” icon will light up in the display when the Brew

cycle is started. Also, front Brew button will light up.

NOTE: Default Standard Brewing cycle time for a full pot (12 cups) is approximately

10-minutes.

2 Auto 12

The Coffee Maker will beep 3 times when the Brew

cycle is complete, then will automatically initiate the

Keep Warm mode. The Brewing icon will turn off and

the Warming icon will light up. The screen will display

remaining time of Warm mode. After the Warm mode

completes, one long beep will sound.

NOTE: Allow the Coffee Maker to cool for 5 minutes before starting the next brew cycle.

Auto12

AutoSet

Hour

Bold Clean

Minute

Brew/Cancel

Brew

Auto 12

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

After Warm mode countdown is ﬁnished, the front

brew button light will go off and the coffee maker will

automatically turn off.

To Cancel the Brew cycle or Warm mode : Press the

BREW button once. The Brew cycle or Warm mode will

be cancelled.

NOTE: Opening the brew basket while coffee is brewing will interrupt the brew process

and impair flavor.

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

To set time for Plate temperature: Press PLATE TIMER

button. The display will show Keep Warm Time and

Keep Warm Time icon.

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Auto Set 1

Brew/Cancel

Auto Set 2

Hour Minute

Plate Temp Plate Timer

Clean

Bold

Press the HOUR button. The hour digits will change

with each press between 0 to 4.

Next, press the MINUTE button. The Hour setting will

stay solid and the Minute setting will begin to blink.

The minute digits will change with each press by 0 or

30 minutes.

To save the current displayed time and exit Keep

Warm setup: Press any other button (Auto Set1, Auto

Set 2, Plate Temp, Plate Timer, Bold, Clean or Brew);

or do not press any button for 10 seconds.

IMPORTANT: You can select time for Plate temperature from 0:00 to maximum 4:00 hours.

NOTE: Heating the brewed coffee for more time adds bitterness to the coffee taste.

It is advised to consume brewed coffee as early after brewing cycle completes.

W11299037A_V2_Final.indb 10 18/10/2018 11:10:37

Otros manuales para KCM1209

Tabla de contenidos

Idiomas:

Otros manuales de Cafetera de KitchenAid

KitchenAid

KitchenAid KES6403 Manual de usuario

KitchenAid

KitchenAid JavaStudio KCM525 Manual de usuario

KitchenAid

KitchenAid KCM1209 Manual de usuario

KitchenAid

KitchenAid KCM223 Manual de usuario

KitchenAid

KitchenAid 5KCM0812A Manual de usuario

KitchenAid

KitchenAid 5KES2102 Manual de usuario

KitchenAid

KitchenAid KCM514ER - JavaStudio Stainless-Steel Programmable... Manual de usuario

KitchenAid

KitchenAid KCM0512 Manual de usuario

KitchenAid

KitchenAid KPCM050PM - Pro Line Single-Carafe Coffee... Manual de usuario

KitchenAid

KitchenAid KCM1208 Hoja de especificaciones

KitchenAid

KitchenAid Pro 10 Manual de usuario

KitchenAid

KitchenAid KCM1209 Manual de usuario

KitchenAid

KitchenAid KES6404 Manual de usuario

KitchenAid

KitchenAid KES6403 Manual de usuario

KitchenAid

KitchenAid 5KES2102A Manual de usuario

KitchenAid

KitchenAid JAVASTUDIO 4KCM511 Manual de usuario

KitchenAid

KitchenAid KCM1202 Manual de usuario

KitchenAid

KitchenAid KCM111OB Manual de usuario

KitchenAid

KitchenAid JavaStudio II KCM534ER0 Manual de usuario

KitchenAid

KitchenAid KCM1204 Manual de usuario

KitchenAid

KitchenAid KCM1209 Hoja de especificaciones

KitchenAid

KitchenAid PRO LINE 4KPES100ER1 Manual de usuario

KitchenAid

KitchenAid 5KCM4212SX Manual de usuario

KitchenAid

KitchenAid 5KES2102A Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
